EMJM2CB06Wireless Mouse

Mini Wireless Optical Mouse Instruction Manual HO98792 For technical support contact Jasco Products at 1-800-654-8483 or www.jascoproducts.com. Page 2 TABLE OF CONTENTS 1. PACKAGE CONTENTS--------------------- 3 2. SYSTEM REQUIREMENTS--------------- 3 3. SPECIAL MOUSE FUNCTIONS---------- 3 4. BATTERY INSTALLATION---------------- 4 5. HARDWARE INSTALLATION------------ 5 6. TROUBLE SHOOTING--------------------- 6 7. FIVE YEAR LIMITED WARRANTY---- 7 8. FCC STATEMENT---------------------------- 8 Page 3 1. Package Contents • Mini Wireless Optical Mouse • 2 AAA Batteries • Mini Instruction Manual • Mini USB Receiver 2. System Requirements • Windows® 98 SE or higher • Mac OSX 10.1 or higher • Available USB Port 3. Special Mouse Functions • The mouse will go to sleep when idle for a long period of time to save batteries. The mouse wakes up by pressing any buttons. • When the Low Battery LED (located on the receiver) is illuminated, change the batteries. 4. Battery Installation Battery Compartment Cover PUSH HERE PUSH HERE Replacing batteries in your GE mini mouse is easy! 1) Simply grip the sides of the mouse and slide the battery cover back. 2) Replace the old batteries with two AAA batteries 3) Replace the battery cover. Page 4 Page 5 5. Hardware Installation Please keep these directions in a safe place. 1) Insert the enclosed batteries into the battery compartment of your mouse following the directions in Section 4. 2) Plug the Optical Mini Mouse receiver into an available USB port on your computer or USB hub. It is not necessary to reboot your computer. 3) If prompted, insert your Windows disk and follow the on screen instructions. (This step is not necessary for all operating systems. Your system will prompt you if it is necessary.) 4) The mouse should auto link requiring no further installation procedure. 5) In case the auto link feature does not occur, you must manually link your mouse to your receiver. 6) Press the link button on your receiver. 7) Press the link button on the bottom of your mouse. 8) Your mouse should now function normally. Move your mouse to test functionality. Page 6 6. Trouble Shooting • The Mini Optical Mouse does not work properly ¾ Optical mice do not work well on glass or highly reflective surfaces. If this applies to you, try using your mouse on a different surface. ¾ Re-link your mouse. Press the link button on the receiver. Press the link button on the bottom of your mouse. ¾ Change the batteries on your mouse. See section 4. • Mouse will not move ¾ Re-link your mouse. See section 5. ¾ Sometimes screen savers interfere with the wake feature. Turn off your screen saver. If the mouse works, try using a different screen saver. ¾ Change the batteries on your mouse. See section 4. Page 7 7. Five Year Limited Warranty Jasco Products Company warrants this product to be free from manufacturing defects for a period of five years from the original date of consumer purchase. This warranty is limited to the repair or replacement of this product only and does not extend to consequential or incidental damage to other products that may be used with this unit. This warranty is in lieu of all other warranties express or implied. Some states do not allow limitations on how long an implied warranty lasts or permit the exclusion or limitation of incidental or consequential damages, so the above limitations may not apply to you. This warranty gives you specific rights, and you may also have other rights which vary from state to state. If unit should prove defective within the warranty period, return prepaid with dated proof of purchase to: Jasco Products Company 10 East Memorial Dr Oklahoma City, OK 73114 Page 8 8. FCC Statement Notice: Federal Communications Commission (FCC) requirements, Part 15 This equipment has been tested and found to comply with the limits for a class B digital device, pursuant to part 15 of the FCC Rules. These limits are designed to provide reasonable protection against harmful interference in a residential installation. This equipment generates, uses and can radiate radio frequency energy and, if not installed and used in accordance with the instructions, may cause harmful interference to radio communications. However, there is no guarantee that interference will not occur in a particular installation. If this equipment does cause harmful interference to radio or television reception, which can be determined by turning the equipment off and on, the user is encouraged to try to correct the interference by one or more of the following measures: • Reorient or relocate the receiving antenna. • Increase the separation between the equipment and receiver. • Connect the equipment into an outlet on a circuit different from that to which the receiver is connected. • Consult the dealer or an experienced radio/TV technician for help. CAUTION: Any changes of modifications not expressly approved by the grantee of this device could void the users authority to operate the equipment. This device complies with Part 15 of the FCC Rules. Operation is subject to the following two conditions: (1) this device may not cause harmful interference, and (2) this device must accept any interference received, including interference that may cause undesired operation. is a trademark of the General Electric Company and is used under license to Jasco Products Company LLC, 311 N.W. 122nd Street, Oklahoma City, OK 73114. www.jascoproducts.com Page 9

PRIMAX Electronics Ltd _ No. 669, RueyKyang Road, Neihu 114, Taipei, Taiwan, R.O.C Federal Communications Commission 7435 Oakland Mills Road Columbia MD 21046 Subject: Request for Confidentiality FCC ID: EMJM2CB06 To Whom It May Concern: Pursuant to the provisions of Sections 0.457 and 0.459 of the Commission’s rules (47 CFR §§0.457, 0.459), we are requesting the Commission to withhold the following attachments as confidential document from public disclosure indefinitely. Schematic Diagram Block Diagram Theory of Operation Above mentioned document contains detailed system and equipment description are considered as proprietary information in operation of the equipment. The public disclosure of above documents might be harmful to our company and would give competitor an unfair advantage in the market. C. Huang Manager PRIMAX Electronics Ltd

PRIMAX Electronics Ltd _ No. 669, RueyKyang Road, Neihu 114, Taipei, Taiwan, R.O.C Date: 26 JAN 2006 American Telecommunications Certification Body 6731 Whittier Avenue Suite C110 McLean, VA 22101 To whom it may concern: We, the undersigned, hereby authorize the Shenzhen office of Compliance Engineering Services, Inc., d.b.a. Compliance Certification Services and hereafter referred to as CCS SZ, to act on our behalf in all manners relating to application for equipment authorization, including signing of all documents relating to these matters. Any and all acts carried out by CCS SZ on our behalf shall have the same effect as acts of our own. We, the undersigned, hereby certify that we are not subject to a denial of federal benefits, that includes FCC benefits, pursuant to Section 5301 of the Anti-Drug Abuse Act of 1988, 21 U.S.C. 853(a). In authorizing CCS SZ as our agent, we still recognize that we are responsible to: a) comply with the relevant provisions of the certification program; b) make all necessary arrangements for the conduct of the evaluation, including provision for examining documentation and access to all areas, records (including internal audit reports) and personnel for the purposes of evaluation (e.g. testing, inspection, assessment, surveillance, reassessment) and resolution of complaints; c) make claims regarding certification only in respect of the scope for which certification has been granted; d) do not use our product certification in such a manner as to bring the Certification Division into disrepute and not make any statement regarding our product certification which the Certification Division may consider misleading or unauthorized; e) upon suspension or cancellation of certification, discontinue use of all advertising matter that contains any reference thereto and return any certification documents as required by the Certification Division; f) use certification only to indicate the products are certified as being in conformity with specified standards; g) endeavor to ensure that no certificate or report nor any part thereof is used in a misleading manner; h) ensure that any reference to our product certification in communication media such as documents, brochures or advertising, complies with the requirements of the Certification Division; i) keep a record of all complaints made known to the us relating to the product’s compliance with requirements of the relevant standard and to make these records available to the Certification Division when requested; j) take appropriate action with respect to such complaints and any deficiencies found in products or services that affect compliance with the requirements for certification; k) document the actions taken. This authorization is valid until further written notice from the applicant. Sincerely Yours, REMARK: 1. This authorization letter will be sent along with your application when filing with the Certification Division. 2. Please follow the format and type it on company letterhead and send original to us.

American Telecommunications Certification Body Inc. 6731 Whittier Ave, McLean, VA 22101 January 31, 2007 RE: Primax Electronics, Ltd. FCC ID: EMJM2CB06 I have a few comments on this Application. Depending on your responses, kindly understand there may be additional comments. 1.) The FCC database lists C. Huang as the Grantee code contact window. But the signer of the Confidentiality Request and the POA appears to be Keene. Under what authority does Keene act on behalf of Primax? We must have an unbroken chain from the contact person listed at the FCC database and the signer of any documents. Please review. 2.) Was the device tested across three orthogonal planes as required by ANSI C63.4, or was it tested simply in a “normal” position on the site table at 3M? William H. Graff President and Director of Engineering mailto: [email protected] The items indicated above must be submitted before processing can continue on the above referenced application. Failure to provide the requested information may result in application termination. Correspondence should be considered part of the permanent submission and may be viewed from the Internet after a Grant of Equipment Authorization is issued. Please do not respond to this correspondence using the email reply button. In order for your response to be processed expeditiously, you must submit your documents through the AmericanTCB.com website. Also, please note that partial responses increase processing time and should not be submitted. Any questions about the content of this correspondence should be directed to the sender.

LABEL LOCATION

Compliance Certification Services (Shenzhen) Inc. Report No.: SZ070119B05-RP FCC ID: EMJM2CB06 Date of Issue: January 22, 2007 Note: This report shall not be reproduced except in full, without the written approval of Compliance Certification Services Inc. This document may be altered or revised by Compliance Certification Services Inc. personnel only, and shall be noted in the revision section of the document. Page 1 Total Page: 17 Rev. 00 FCC 47 CFR PART 15 SUBPART C TEST REPORT For Crossbow 5030 Mouse Model: MORFCBUOA / 98792 Trade Name: PRIMAX / Jasco Issued to PRIMAX ELECTRONICS LTD. NO.669, RUEYKUANG ROAD, NEIHU 114, TAIPEI, TAIWAN, R.O.C Issued by COMPLIANCE CERTIFICATION SERVICES (SHENZHEN) INC. NO. 5, JINAO INDUSTRIAL PARK, NO. 35 JUKENG ROAD, DASHUIKENG VILLAGE, GUANLAN TOWN, BAOAN DISTRICT, SHENZHEN, CHINA TEL: 86-755-28055000 FAX: 86-755-28055221 LAB CODE:200577-0 Compliance Certification Services (Shenzhen) Inc. Report No.: SZ070119B05-RP FCC ID: EMJM2CB06 Date of Issue: January 22, 2007 Page 2 Rev. 00 TABLE OF CONTENTS 1. TEST RESULT CERTIFICATION............................................................................................. 3 2. EUT DESCRIPTION .................................................................................................................... 4 3. TEST METHODOLOGY ............................................................................................................. 5 3.1 EUT CONFIGURATION.............................................................................................................. 5 3.2 EUT EXERCISE......................................................................................................................... 5 3.3 GENERAL TEST PROCEDURES.................................................................................................. 5 3.4 FCC PART 15.205 RESTRICTED BANDS OF OPERATIONS .............................................. 6 3.5 DESCRIPTION OF TEST MODES................................................................................................. 6 4. INSTRUMENT CALIBRATION................................................................................................. 7 5. FACILITIES AND ACCREDITATIONS ................................................................................... 8 5.1 FACILITIES.............................................................................................................................. 8 5.2 EQUIPMENT............................................................................................................................. 8 5.3 LABORATORY ACCREDITATIONS AND LISTING....................................................................... 8 6. SETUP OF EQUIPMENT UNDER TEST .................................................................................. 9 6.1 SETUP CONFIGURATION OF EUT.............................................................................................. 9 6.2 SUPPORT EQUIPMENT....................................................................................................... 9 7. FCC PART 15.227 REQUIREMENTS...................................................................................... 10 7.1 26 DB BANDWIDTH .......................................................................................................... 10 7.2 RADIATED EMISSIONS........................................................................................................... 12 7.3 POWERLINE CONDUCTED EMISSIONS.................................................................................... 16 APPENDIX 1 PHOTOGRAPHS OF TEST SETUP....................................................................... 17 Compliance Certification Services (Shenzhen) Inc. Report No.: SZ070119B05-RP FCC ID: EMJM2CB06 Date of Issue: January 22, 2007 Page 3 Rev. 00 1. TEST RESULT CERTIFICATION Applicant: PRIMAX ELECTRONICS LTD. NO.669, RUEYKUANG ROAD, NEIHU 114, TAIPEI, TAIWAN, R.O.C Equipment Under Test: Crossbow 5030 Mouse Tr a d e N a m e : PRIMAX / Jasco Model: MORFCBUOA / 98792 Date of Test: January 19-22, 2007 APPLICABLE STANDARDS STANDARD TEST RESULT FCC 47 CFR Part 15 Subpart C No non-compliance noted We hereby certify that: The above equipment was tested by Compliance Certification Services (Shenzhen) Inc.. The test data, data evaluation, test procedures, and equipment configurations shown in this report were made in accordance with the procedures given in ANSI C63.4 and the energy emitted by the sample tested as described in this report is in compliance with the requirements of FCC Rules Part 15.227. The test results of this report relate only to the tested sample identified in this report. Approved by: Tested By: Henry Ding Reviewed By: Clinton Kao/ Manager Eric Wong / Assistant manager COMPLIANCE CERTIFICATION COMPLIANCE CERTIFICATION SERVICES (SHENZHEN) INC. SERVICES (SHENZHEN) INC. Compliance Certification Services (Shenzhen) Inc. Report No.: SZ070119B05-RP FCC ID: EMJM2CB06 Date of Issue: January 22, 2007 Page 4 Rev. 00 2. EUT DESCRIPTION Product Crossbow 5030 Mouse Trade Name PRIMAX / Jasco Model Number MORFCBUOA / 98792 Model Difference All the models are identical in electronic level, different model designation applies due to marketing purpose. Power Supply TX: Powered by AAA batteries × 2 (Rating: 2 × 1.5Vdc) Frequency Range 27.045 MHz Remark: This submittal(s) (test report) is intended for FCC ID: EMJM2CB06 filing to comply with Section 15.227 of the FCC Part 15, Subpart C Rules. Compliance Certification Services (Shenzhen) Inc. Report No.: SZ070119B05-RP FCC ID: EMJM2CB06 Date of Issue: January 22, 2007 Page 5 Rev. 00 3. TEST METHODOLOGY The tests documented in this report were performed in accordance with ANSI C63.4 and FCC CFR 47 2.1046, 2.1047, 2.1049, 2.1051, 2.1053, 2.1055, 2.1057, and 15.227. 3.1 EUT CONFIGURATION The EUT configuration for testing is installed on RF field strength measurement to meet the Commissions requirement and operating in a man…
