EMJM8B401Wireless Twister Laser Mouse

- 1 - Setting Up Your Mouse Hardware Installation Important: Before connecting your mouse or installing the software, be sure to identify the type of mouse port you are using (USB). Refer to the diagrams below if you are having difficulty determining what kind of port your mouse uses. USB Prot Connecting the USB Mouse Note: To use the USB mouse, you need to have Windows 98 / 2000 / ME / XP installed on your computer. ∑ You don’t need to turn off your computer before connect your USB mouse. ∑ Plug the rectangular USB mouse connector into the USB port (normally in the back of the PC). ∑ Insert the software diskette into your disk drive and follow the onscreen instructions to install the device driver. - 2 - Installing Mouse Suite ™ Software To use all of the features of your new mouse, you must install the Mouse Suite ™ software on your computer. Uses the following guide to properly install the Mouse Suite ™ software. ∑ Start Windows and insert the Mouse Suite ™ installation disk into the disk drive. ∑ Click the Start button and then select Run. ∑ From the Run dialog box, enter <drive>: Setup and click OK. For example, if the disk is in drive A, enter A:\Setup. ∑ Follow the onscreen instructions. - 3 - Using the Wheel Note: This section is for wheel mouse only. Your new mouse may have a wheel that can be used in two ways: ∑ Rotate it to use it as the wheel. ∑ Click it to use it as the wheel button. Important: Universal Scrolling must be enabled in order to use scrolling functions in applications not compatible with Microsoft Office 97. Scrolling The wheel on your mouse can be used to scroll through most applications with a scroll bar. ∑ To scroll with your mouse, simply rotate the wheel on your mouse forward or backward. AutoScrolling AutoScroll allows you to automatically scroll through a document without having to move the mouse or mouse wheel constantly. ∑ To AutoScroll while in a document, click the mouse button designated as AutoScroll. An origin mark ( ) will appear at your pointer position. To start AutoScrolling, move your pointer vertically, horizontally, or diagonally away from the origin mark. AutoScroll speed increases as the pointer is moved away from the origin mark. To stop AutoScrolling, press any mouse button or rotate the wheel. Zooming In some Microsoft Office 97 compatible applications (e.g. Microsoft Word 97), additional zooming functions are available. You can use the zooming function to “zoom in” for a closer look at a page or “zoom out” to see more of a page. ∑ To zoom in, hold the Ctrl key down and rotate the mouse wheel forward. ∑ To zoom out, hold the Ctrl key down and rotate the mouse wheel backward. - 4 - Mouse Sutie ™ Features Mouse Suite ™ includes a lot of exciting features or functions that help you to increase your productivity with your new mouse. l To find your Mouse Control Panel, follow these steps: Click the Start button, click Settings, and click on the Control Panel. In the Control Panel, double-click on the Mouse icon. Button Functions Accessing the Buttons page allows you to customize the function of each mouse button. The default settings for your mouse buttons are as follows: ∑ Left Button Primary Mouse Button (standard click and drag action) ∑ Middle or Wheel Button Quick / Auto Scroll ∑ Right Button Context Menu ∑ Fourth Button Start Button (If have) ∑ Fifth Button Double-Click (if have) Magnifier With Magnifier designated as a button function, you can magnify the screen area around your pointer with the click of a button. HyperLink With HyperLink designated as a button function, you can open the application or document of your choice with a simple click. HyperGrid HyperGrid incorporates nine common Windows tasks on one easy to use grid so you don’t have to move to various screen areas to perform a task. To use the HyperGrid, press and hold the assigned mouse button to display the grid. Without releasing the button, move the pointer to an icon on the grid. Release the button to execute the command associated with that icon. - 5 - Minimize Minimizes the active window. Recall Restores / Maximizes the active window. Close Closes the active window. Next Window Makes the next window active. Context Menu Emulates the Right Mouse Button action. Vertical Scroll Jumps to the vertical scroll bar. Start Activates the Windows Start menu. Horizontal Scroll Jumps to the horizontal scroll bar. Resize Jumps to the size grip to resize the active window. Orientation The Orientation feature allows you to recalibrate your mouse so you can use it in a more comfortable position. Pointer Wrap With Pointer Wrap enabled, when the pointer reaches the edge of the screen, it will automatically ‘go through’ and appear on the other side. Pointer Vanish When Pointer Vanish is enabled, the pointer will be conveniently hidden from view while you are typing text. The pointer will automatically reappear when your mouse is used again. Sonar The Sonar function helps you locate your pointer if you are having difficulty finding it. Press and release the Ctrl key to activate the Sonar function. This function does not interfere with other Ctrl key functions. Slow Motion Enabling Slow Motion allows you to temporarily slow down pointer movement for increased precision by pressing and holding the Shift key. This function does not interfere with other Shift key functions. X Focus With X Focus enabled, you can make an open window active simply by moving the pointer over its title bar. This function is useful if you want to alternate between several open windows without clicking. Auto Jump When Auto Jump is enabled, the pointer will automatically appear on the default button (e.g. OK) whenever a dialog box is opened. - 6 - Battery and Channel ID Note: This section applies for Wireless varoamt mouse only. l Symble in the task bar provide information on the charge staus of the batteries. The symble means that the batteries are full. The symble means that the batteries are discharged. l The W…

Text truncated - open the document above for the full version.

Date: January 16, 2007 Federal Communications Commission Authorization and Evaluation Division Confidentiality Request FCC ID: EMJM8B401 Pursuant to Sections 0.457 and 0.459 of the Commission’s Rules, the Applicant hereby requests confidential treatment of information accompanying this Application as outlined below: Schematics Block Diagram The above materials contain trade secrets and proprietary information not customarily released to the public. The public disclosure of these matters might be harmful to the Applicant and provide unjustified benefits to its competitors. The Applicant understands that pursuant to Rule 0.457, disclosure of this Application and all accompanying documentation will not be made before the date of the Grant for this application. Sincerely yours, ------------------------------------------------------------------- C.T. Huang Compliance Dept. / Director Phone: 886-2-2798-9008 ext.1710 Fax: 886-2-8797-1565 Email: [email protected]

Power of Attorney Date: January 16, 2007 To whom it may concern: We, the undersigned PRIMAX ELECTRONICS LTD. hereby authorize Advance Data Technology Corporation (ADT) of Taiwan to act on our behalf in all matters relating to all processes required in the FCC Part 15C approval and any communication needed with the national authority. Any and all acts carried out by ADT on our behalf shall have the same effects as acts of our own. If you have any questions regarding the authorization, please don’t hesitate to contact us. Thank you! Sincerely yours, ------------------------------------------------------------------- C.T. Huang Compliance Dept. / Director Phone: 886-2-2798-9008 ext.1710 Fax: 886-2-8797-1565 Email: [email protected]

Page 1 CONSTRUCTION PHOTOS OF EUT Page 2

FCC ID: EMJM8B401 FCC LABEL LOCATION The label will be permanently affixed at a conspicuous location on the device. LABEL

Page 3 Page 4 Page 5

FCC ID: EMJM8B401 Report No.: RF960110A02 Operational Description The transmitter of the EUT (Wireless Twister Laser Mouse) is powered by 3.0Vdc batteries. The type of antenna is Printed antenna. The output power of this device is very low. Under normal use condition, the transmitter and the receiver are quite close, so high EIRP power is neither necessary nor allowed because of interference.

Report No: SA960110A02 1 RF EXPOSURE REPORT REPORT NO.: SA960110A02 MODEL NO.: MORFB4UL, RF-TWIST ACCORDING: FCC Guidelines for Human Exposure IEEE C95.1 APPLICANT : PRIMAX ELECTRONICS LTD. ADDRESS : No. 669, Ruey Kuang Road, Neihu, Taipei, Taiwan, R.O.C. ISSUED BY : Advance Data Technology Corporation LAB ADDRESS : No. 47, 14th Ling, Chia Pau Tsuen, Lin Kou Hsiang 244, Taipei Hsien, Taiwan, R.O.C. Report No: SA960110A02 2 Conclusion No Evaluation Required if power is below this threshold: F(GHz) mW Low 2.402 High 2.474 24.73 Maximum measured transmitter power: Pout (dBm) Pout (mW) Conducted Power -2.41 0.574 EIRP Power -3.56 0.441 *Note: The antenna is Printed antenna with –1.15dBi gain Threshold for no SAR evaluation is 24.73mW Transmitter power is 0.574mW Conclusion: No SAR evaluation required since Transmitter Pout is below FCC threshold

Report No.: RF960110A02 1 Report Format Version 2.0.5 FCC TEST REPORT REPORT NO.: RF960110A02 MODEL NO.: MORFB4UL, RF-TWIST RECEIVED: Sep. 7, 2006 TESTED: Sep. 7 ~ Oct. 27, 2006 ISSUED: Jan. 16, 2007 APPLICANT: PRIMAX ELECTRONICS LTD. ADDRESS: No. 669, Ruey Kuang Road, Neihu, Taipei, Taiwan, R.O.C. ISSUED BY: Advance Data Technology Corporation LAB LOCATION: No. 47, 14th Ling, Chia Pau Tsuen, Lin Kou Hsiang 244, Taipei Hsien, Taiwan, R.O.C. This test report consists of 35 pages in total. It may be duplicated completely for legal use with the approval of the applicant. It should not be reproduced except in full, without the written approval of our laboratory. The client should not use it to claim product endorsement by CNLA, A2LA or any government agencies. The test results in the report only apply to the tested sample. Report No.: RF960110A02 2 Report Format Version 2.0.5 Table of Contents 1. CERTIFICATION..........................................................................................4 2. SUMMARY OF TEST RESULTS..................................................................5 2.1 MEASUREMENT UNCERTAINTY...............................................................5 3. GENERAL INFORMATION..........................................................................6 3.1 GENERAL DESCRIPTION OF EUT............................................................6 3.2 DESCRIPTION OF TEST MODES..............................................................7 3.2.1 CONFIGURATION OF SYSTEM UNDER TEST.........................................7 3.2.2 TEST MODE APPLICABILITY AND TESTED CHANNEL DETAIL:.............8 3.3 GENERAL DESCRIPTION OF APPLIED STANDARDS.............................9 3.4 DESCRIPTION OF SUPPORT UNITS........................................................9 4. TEST TYPES AND RESULTS....................................................................10 4.1 CONDUCTED EMISSION MEASUREMENT............................................10 4.2 RADIATED EMISSION MEASUREMENT.................................................10 4.2.1 LIMITS OF RADIATED EMISSION MEASUREMENT...............................10 4.2.2 TEST INSTRUMENTS..............................................................................11 4.2.3 TEST PROCEDURES...............................................................................12 4.2.4 DEVIATION FROM TEST STANDARD.....................................................12 4.2.5 TEST SETUP ...........................................................................................13 4.2.6 EUT OPERATING CONDITIONS..............................................................13 4.2.7 TEST RESULTS........................................................................................14 4.3 6dB BANDWIDTH MEASUREMENT.........................................................18 4.3.1 LIMITS OF 6dB BANDWIDTH MEASUREMENT......................................18 4.3.2 TEST INSTRUMENTS..............................................................................18 4.3.3 TEST PROCEDURE.................................................................................18 4.3.4 DEVIATION FROM TEST STANDARD.....................................................18 4.3.5 TEST SETUP ...........................................................................................18 4.3.6 EUT OPERATING CONDITIONS..............................................................18 4.3.7 TEST RESULTS........................................................................................19 4.4 MAXIMUM PEAK OUTPUT POWER........................................................21 4.4.1 LIMITS OF MAXIMUM PEAK OUTPUT POWER MEASUREMENT.........21 4.4.2 INSTRUMENTS.........................................................................................21 4.4.3 TEST PROCEDURES...............................................................................21 4.4.4 DEVIATION FROM TEST STANDARD.....................................................21 4.4.5 TEST SETUP ...........................................................................................22 4.4.6 EUT OPERATING CONDITIONS..............................................................22 4.4.7 TEST RESULTS........................................................................................22 4.5 POWER SPECTRAL DENSITY MEASUREMENT....................................25 4.5.1 LIMITS OF POWER SPECTRAL DENSITY MEASUREMENT..................25 4.5.2 TEST INSTRUMENTS..............................................................................25 4.5.3 TEST PROCEDURE.................................................................................25 4.5.4 DEVIATION FROM TEST STANDARD.....................................................25 4.5.5 TEST SETUP ...........................................................................................25 4.5.6 EUT OPERATING CONDITION................................................................25 Report No.: RF960110A02 3 Report Format Version 2.0.5 4.5.7 TEST RESULTS........................................................................................26 4.6 BAND EDGES MEASUREMENT..............................................................28 4.6.1 LIMITS OF BAND EDGES MEASUREMENT............................................28 4.6.2 TEST INSTRUMENTS..............................................................................28 4.6.3 TEST PROCEDURE.................................................................................28 4.6.4 DEVIATION FROM TEST STANDARD.....................................................28 4.6.5 EUT OPERATING CONDITION................................................................28 4.6.6 TEST RESULTS........................................................................................29 4.7 ANTENNA REQUIREMENT......................................................................33 4.7.1 STANDARD APPLICABLE........................................................................33 4.7.2 A…

Text truncated - open the document above for the full version.

1 PHOTOGRAPHS OF THE TEST CONFIGURATION RADIATED EMISSION TEST
