EMJMMORFF2ULAWIRELESS LASER MOUSE

ENGLISH Knowing your mouse Installing the battery Connecting to PC Installing the tilt wheel driver WX470 Laser Mouse Your package includes: a. ASUS WX470 Laser Mouse b. Nano USB 2.4 GHz receiver c. 3 x AAA batteries d. Quick Start Guide Mouse dimension (mm): 105(L)x66(w)x37(H) Mouse weight: 82g (without battery) Resolution: 1100/1600dpi a b c d Quick Start Guide 1. Remove the USB receiver from the USB compartment and then turn the power switch to 1100dpi for normal use or to 1600dpi for better performance. 2. Insert the USB receiver into your computer's USB port. NOTES: • You can store the USB receiver inside the mouse. • To save power, turn off the power when you are not using the mouse. 2 1 OFF 1600 1100 USB dongle compartment Off 1100dpi 1600dpi T-CHINESES-CHINESEFRENCHGERMANITALIANSPANISHJAPANESERUSSIAN 1 2 3 1. Back and Forward buttons 2. • Tilt wheel (4-Way Scrolling, driver installation required) • DPI and battery indicator 3. Aero Flip 3D button Use this button to instantly switch between tabs in Windows® 7. NOTE: This mouse can work on almost any surface, even on 4mm or thicker clean glass. 1. Remove the cover from under the notch as shown. 2. Insert up to three batteries into the slots, taking note of the correct polarity. 3. Press the cover in the direction of the arrows to replace it. 3 1 2 CAUTION: • The bundled batteries are not chargeable. • If you do not use the mouse for a long time, remove the batteries. • Use new or similar-type batteries. Go to ASUS website at www.asus.com to download the latest driver for the 4-Way Scrolling tilt wheel and install it to use the 4-Way Scrolling feature. Federal Communications Commission Statement This device complies with Part 15 of the FCC Rules. Operation is subject to the following two conditions: • This device may not cause harmful interference, and • This device must accept any interference received including interference that may cause undesired operation. This equipment has been tested and found to comply with the limits for a Class B digital device, pursuant to Part 15 of the FCC Rules. These limits are designed to provide reasonable protection against harmful interference in a residential installation. This equipment generates, uses and can radiate radio frequency energy and, if not installed and used in accordance with manufacturer’s instructions, may cause harmful interference to radio communications. However, there is no guarantee that interference will not occur in a particular installation. If this equipment does cause harmful interference to radio or television reception, which can be determined by turning the equipment off and on, the user is encouraged to try to correct the interference by one or more of the following measures: • Reorient or relocate the receiving antenna. • Increase the separation between the equipment and receiver. • Connect the equipment to an outlet on a circuit different from that to which the receiver is connected. • Consult the dealer or an experienced radio/TV technician for help. CAUTION: Any changes or modifications not expressly approved by the grantee of this device could void the user’s authority to operate the equipment. Knowing your mouse Installing the battery Connecting to PC Installing the tilt wheel driver Your package includes: a. ASUS WX470 Laser Mouse / b. Nano USB 2.4 GHz receiver / c. 3 x AAA batteries / d. Quick Start Guide Mouse dimension (mm): 105(L)x66(w)x37(H) Mouse weight: 82g (without battery) Resolution: 1100/1600dpi 1. Remove the cover from under the notch as shown. 2. Insert up to three batteries into the slots, taking note of the correct polarity. 3. Press the cover in the direction of the arrows to replace it. CAUTION: • The bundled batteries are not chargeable. • If you do not use the mouse for a long time, remove the batteries • Use new or similar-type batteries. 1. Remove the USB receiver from the USB compartment and then turn the power switch to 1100dpi for normal use or to 1600dpi for better performance. 2. Insert the USB receiver into your computer's USB port. NOTES: • You can store the USB receiver inside the mouse. • To save power, turn off the power when you are not using the mouse. Go to ASUS website at www. asus.com to download the latest driver for the 4-Way Scrolling tilt wheel and install it to use the 4-Way Scrolling feature. 1. Back and Forward buttons 2. • Tilt wheel (4-Way Scrolling, driver installation required) • DPI and battery indicator 3. Aero Flip 3D button Use this button to instantly switch between tabs in Windows® 7. NOTE: This mouse can work on almost any surface, even on 4mm or thicker clean glass. Knowing your mouse Installing the battery Connecting to PC Installing the tilt wheel driver Your package includes: a. ASUS WX470 Laser Mouse / b. Nano USB 2.4 GHz receiver / c. 3 x AAA batteries / d. Quick Start Guide Mouse dimension (mm): 105(L)x66(w)x37(H) Mouse weight: 82g (without battery) Resolution: 1100/1600dpi 1. Remove the cover from under the notch as shown. 2. Insert up to three batteries into the slots, taking note of the correct polarity. 3. Press the cover in the direction of the arrows to replace it. CAUTION: • The bundled batteries are not chargeable. • If you do not use the mouse for a long time, remove the batteries • Use new or similar-type batteries. 1. Remove the USB receiver from the USB compartment and then turn the power switch to 1100dpi for normal use or to 1600dpi for better performance. 2. Insert the USB receiver into your computer's USB port. NOTES: • You can store the USB receiver inside the mouse. • To save power, turn off the power when you are not using the mouse. Go to ASUS website at www. asus.com to download the latest driver for the 4-Way Scrolling tilt wheel and install it to use the 4-Way Scrolling feature. 1. Back and Forward buttons 2. • Tilt wheel (4-Way Scrolling, driver installation required) • DPI and battery indicator 3. Aero Flip 3D button Use this button to instantly switch between tabs in Windo…

Text truncated - open the document above for the full version.

No. 669, Ruey Kuang Road Neihu Taipei, Taiwan, R.O.C. Tel: 883-2-2798-9008 Fax: 886-2-8798-1565 Date: April 16, 2012 Federal Communications Commission Authorization and Evaluation Division Confidentiality Request FCC ID: EMJMMORFF2ULA Pursuant to Sections 0.457 and 0.459 of the Commission’s Rules, the Applicant hereby requests confidential treatment of information accompanying this Application as outlined below: Schematics Block Diagram The above materials contain trade secrets and proprietary information not customarily released to the public. The public disclosure of these matters might be harmful to the Applicant and provide unjustified benefits to its competitors. The Applicant understands that pursuant to Rule 0.457, disclosure of this Application and all accompanying documentation will not be made before the date of the Grant for this application. Sincerely yours, ------------------------------------------------------------------- C.T. Huang Compliance Dept. / Director Phone: 886-2-2798-9008 ext.1710 Fax: 886-2-8797-1565 Email: [email protected]

No. 669, Ruey Kuang Road Neihu Taipei, Taiwan, R.O.C. Tel: 883-2-2798-9008 Fax: 886-2-8798-1565 Power of Attorney Date: April 16, 2012 To whom it may concern: We, the undersigned PRIMAX ELECTRONICS LTD. hereby authorize Bureau Veritas Consumer Products Services (H.K.) Ltd., Taoyuan Branch (BV CPS Taoyuan Branch) of Taiwan to act on our behalf in all matters relating to all processes required in the FCC Part 15C approval and any communication needed with the national authority. Any and all acts carried out by BV CPS Taoyuan Branch on our behalf shall have the same effects as acts of our own. If you have any questions regarding the authorization, please don’t hesitate to contact us. Thank you! Sincerely yours, -------------------------------------- C.T. Huang Compliance Dept. / Director Phone: 886-2-2798-9008 ext.1710 Fax: 886-2-8797-1565 Email: [email protected]

Page 1 CONSTRUCTION PHOTOS OF EUT

1234567 1234567 A B C D E A B C D E PRIMAX ELECTRONICS LTD. 致伸資訊電子有限公司 USED FINISH SCALE TITLE DWG NO . FILE NAMESHEET REV. SIZE A4 DR. CHKD. APPD. UNIT mm 1 1 1 DO NOT SCALE DRAWING THESE DRAWINGS AND SPECIFICATIONS ARE THE PROPERTY OF PRIMAX ELECTRONICS LTD. AND SHALL NOT BE REPRODUCED COPIED OR USED IN ANY MANNER WITHOUT THE PRIOR WRITTEN CONSENT OF PRIMAX ELECTRONICS LTD. DIMENSIONS 0.00 TO 30.00mm +0.10mm 30.01 TO 80.00mm +0.13mm 80.01 TO 150.00mm +0.15mm 150.01 +0.20mm TOLERANCE MATERIAL REV. DESCRIPTION ENG. APPROVAL UNLESS OTHERWISE SPECIFIED: DIMENSIONS ARE IN MILLIMETERS ANGULAR TOLERANCE:+1.0 20-8F204A902 Sarah.Lee 2012/03/29 80P合成紙+霧膜 Ruby Ai BOTTOM LABEL Ruby Ai 304007903060 304007903060 1.印刷：黑底白字,具體請參考承認樣品 2. 3. 4. 5. -0.2/0mm 3.Follow Halogen- Free requirement : Br<900 ppm, Cl<900 ppm, Br+Cl< 1500 ppm if required S/N: C 3 BMHC G XXXXX 流水碼（00001～99999）,每月更新 年( 2012年=C,2013年=D,2014年=E......) 月( 1月=1,2月=2,3月=3......9月=9,10月=A,11月=B,12月=C ) ASUS M/N/品名:WIRELESS LASER MOUSE *61.3 mm * 4 5 . 7 m m 1:1 Rating:1.5V 40mA (额定)額定/ FCC ID:EMJMMORFF2ULA M/N (型号):MORFF2ULA型號/ ASUS P/N:90-XB3800MU00010- CLASS 1 LASER PRODUCT Made in China 中國製造/中国制造 Complies with 21 CFR 1040.10 and 1040.11 except for deviations pursuant to Laser Notice No. 50, dated June 24, 2007 S/N: C3BMHCGXXXXX 6. CMIIT ID:XXXXXXXXX XXXXXXXXXXXX N13219 2:1 30400790306X和30400714413X的流水號需對應,由採購提供 致伸科技股份有限公司 ASUS M/N/品名:WIRELESS LASER MOUSE Rating:1.5V 40mA (额定)額定/ FCC ID:EMJMMORFF2ULA M/N (型号):MORFF2ULA型號/ ASUS P/N:90-XB3800MU00010- CLASS 1 LASER PRODUCT Made in China 中國製造/中国制造 Complies with 21 CFR 1040.10 and 1040.11 except for deviations pursuant to Laser Notice No. 50, dated June 24, 2007 S/N: C3BMHCGXXXXX CMIIT ID:XXXXXXXXX XXXXXXXXXXXX N13219 致伸科技股份有限公司 1 2345 67 1 234567 A B C D E A B C D E REV. DESCRIPTION ENG. APPROVAL PRIMAX ELECTRONICS LTD. 致伸資訊電子有限公司 USED FINISH SCALE TITLE DWG NO . FILE NAMESHEET REV. SIZE A4 DR. CHKD. APPD. UNIT mm 1 1 DO NOT SCALE DRAWING DIMENSIONS 0.00 TO 30.00mm +0.10mm 30.01 TO 80.00mm +0.13mm 80.01 TO 150.00mm +0.15mm 150.01 +0.20mm TOLERANCE MATERIAL UNLESS OTHERWISE SPECIFIED: DIMENSIONS ARE IN MILLIMETERS ANGULAR TOLERANCE:+1.0 1 THESE DRAWINGS AND SPECIFICATIONS ARE THE PROPERTY OF PRIMAX ELECTRONICS LTD. AND SHALL NOT BE REPRODUCED COPIED OR USED IN ANY MANNER WITHOUT THE PRIOR WRITTEN CONSENT OF PRIMAX ELECTRONICS LTD. 背膠 Sarah.Lee 2012/03/29 BOX BARCODE LABEL 20-8F204A902 Ruby.Ai 80P銅板紙 5. Requirement of Primax Green Part: 1.Comply with Primax QW-5Q002 "Green Product Chemical Substances Specification 2.Follow customer's specification as required 1.尺寸:參見上圖,*號為重要尺寸 2.公差:-0.5/+ mm 0 3.普通壓克力膠,T=0.03mm,粘著力:3.0kg/cm 4.印刷：白底黑字 2 304007144130 304007144130 Ruby.Ai S/N BMHC00001 S/N C3BMHCG00001 碼型:Code 39 *80mm * 3 0 m m 3.Follow Halogen- Free requirement : Br<900 ppm, Cl<900 ppm, Br+Cl< 1500 ppm if required. 0884840046073 流水號：新月份從00001開始 此為固定碼﹐不需變更 此為月代碼﹐ 1~9月用數字﹐10=A,11=B,12=C 此為年代碼﹐ (2012=C,2013=D,2014=E.....) 6. 30400790306X和30400714413X的流水號需對應,由採購提供 ASUS M/N:WX470 MOUSE/BK/CN ASUS P/N:90-XB3800MU00010- ASUS S/N:C3BMHCG00001 EAN 884840046073 UPC MADE IN CHINA 內容:90-XB3800MU00010- 碼型:Code 39 內容:C3BMHCG00001 碼型:UPC 內容:884840046073 碼型:EAN 內容:884840046073 1 2345 67 1 234567 A B C D E A B C D E REV. DESCRIPTION ENG. APPROVAL PRIMAX ELECTRONICS LTD. 致伸資訊電子有限公司 USED FINISH SCALE TITLE DWG NO . FILE NAMESHEET REV. SIZE A4 DR. CHKD. APPD. UNIT mm 1 1 DO NOT SCALE DRAWING DIMENSIONS 0.00 TO 30.00mm +0.10mm 30.01 TO 80.00mm +0.13mm 80.01 TO 150.00mm +0.15mm 150.01 +0.20mm TOLERANCE MATERIAL UNLESS OTHERWISE SPECIFIED: DIMENSIONS ARE IN MILLIMETERS ANGULAR TOLERANCE:+1.0 THESE DRAWINGS AND SPECIFICATIONS ARE THE PROPERTY OF PRIMAX ELECTRONICS LTD. AND SHALL NOT BE REPRODUCED COPIED OR USED IN ANY MANNER WITHOUT THE PRIOR WRITTEN CONSENT OF PRIMAX ELECTRONICS LTD. 背膠 Sarah.Lee 2012/03/29 Carton barcode label 20-8F204A902 Ruby.Ai 80P銅板紙 5. Requirement of Primax Green Part: 1.Comply with Primax QW-5Q002 "Green Product Chemical Substances Specification 2.Follow customer's specification as required 1.尺寸:參見上圖,*號為重要尺寸 2.公差:-0.5/+ mm 0 3.普通壓克力膠,T=0.03mm,粘著力:3.0kg/cm 4.印刷：黑色 2 304007146880 304007146880 Ruby.Ai BMHC00001C3BMHCG00001 ASUS M/N:WX470 MOUSE/BK/CN ASUS P/N:90-XB3800MU00010- ASUS S/N:C3BMHCG00001 Made in China 數量 Q’TY: 12 PCS 淨重 N.W: KGS 毛重 G.W: KGS ASUSTek COMPUTER INC. 15,Li-Te Rd.,Peitou,Taipei 112,Taiwan *105 mm * 1 0 7 m m ASUS S/N:C3BMHCG00012 EAN ~ 碼型:Code 39 讀數:90-XB3800MU00010- 碼型:Code 39 讀數:12 3.Follow Halogen- Free requirement : Br<900 ppm, Cl<900 ppm, Br+Cl< 1500 ppm if required. 流水號：新月份從00001開始 此為固定碼﹐不需變更 此為月代碼﹐ 1~9月用數字﹐10=A,11=B,12=C 此為年代碼﹐ (2012=C,2013=D,2014=E.....) 6.SN#: 1 0884840046073 此LABEL兩份內容完成相同 因Carton兩個正麥上需貼相同流水號的LABEL,因此每兩份相同流水號的LABEL為1個用量 此S/N號碼12號一跳，例如：C3BMHCG00001，C3BMHCG00012 UPC 884840046073 碼型:EAN 讀數:884840046073 碼型:EAN 讀數:884840046073 ASUS M/N:WX470 MOUSE/BK/CN ASUS P/N:90-XB3800MU00010- ASUS S/N:C3BMHCG00001 Made in China 數量 Q’TY: 12 PCS 淨重 N.W: KGS 毛重 G.W: KGS ASUSTek COMPUTER INC. 15,Li-Te Rd.,Peitou,Taipei 112,Taiwan ASUS S/N:C3BMHCG00012 EAN ~ 0884840046073 UPC 884840046073 碼型:Code 39 讀數:C3BMHCG00001 碼型:Code 39 讀數:C3BMHCG00012 1 2345 67 1 234567 A B C D E A B C D E REV. DESCRIPTION ENG. APPROVAL PRIMAX ELECTRONICS LTD. 致伸資訊電子有限公司 USED FINISH SCALE TITLE DWG NO . FILE NAMESHEET REV. SIZE A4 DR. CHKD. APPD. UNIT mm 1 1 DO NOT SCALE DRAWING DIMENSIONS 0.00 TO 30.00mm +0.10mm 30.01 TO 80.00mm +0.13mm 80.01 TO 150.00mm +0.15mm 150.01 +0.20mm TOLERANCE MATERIAL UNLESS OTHERWISE SPECIFIED: DIMENSIONS ARE IN MILLIMETERS ANGULAR TOLERANCE:+1.0 THESE DRAWINGS AND SPECIFICATIONS ARE THE PROPERTY OF PRIMAX ELECTRONICS LTD. AND SHALL NOT BE REPRODUCED COPIED OR USED IN ANY MANNER WITHOUT THE PRIOR WRITTEN CONSENT OF PRIMAX ELECTRONICS LTD. 背膠 Sarah.Lee 2012/03/29 Carton barcode label 20-8F204A902 Ruby.Ai 80P銅板紙 5. Requirement of Primax Green Part: 1.Comply with Primax QW-5Q002 "Green Product Chemical Substances Specification 2.Follow customer's specification as require…

Text truncated - open the document above for the full version.

LABEL LOCATION Label Location

Page 2 Page 3 Page 4 Page 5 Page 6

FCC ID: EMJMMORFF2ULA Report No.: RF120320D12 Operational Description The transmitter of the EUT (Wireless Laser Mouse) is powered by 1.5Vdc from battery. The type of antenna is Printed antenna. The output power of this device is very low. Under normal use condition, the transmitter and the receiver are quite close, so high EIRP power is neither necessary nor allowed because of interference.

Report No.: RF120320D12 1 Report Format Version 4.0.0 FCC TEST REPORT REPORT NO.: RF120320D12 MODEL NO.: MORFF2ULA FCC ID: EMJMMORFF2ULA RECEIVED: Mar. 20, 2012 TESTED: Mar. 27 ~ 28, 2012 ISSUED: Apr. 11, 2012 APPLICANT: PRIMAX ELECTRONICS LTD. ADDRESS: No. 669, Ruey Kuang Road, Neihu, Taipei, Taiwan, R.O.C. ISSUED BY: Bureau Veritas Consumer Products Services (H.K.) Ltd., Taoyuan Branch LAB LOCATION: No. 47, 14th Ling, Chia Pau Vil., Lin Kou Dist., New Taipei City, Taiwan ( R.O.C. ) This test report consists of 24 pages in total. It may be duplicated completely for legal use with the approval of the applicant. It should not be reproduced except in full, without the written approval of our laboratory. The client should not use it to claim product endorsement by TAF or any government agencies. The test results in the report only apply to the tested sample. Report No.: RF120320D12 2 Report Format Version 4.0.0 Table of Contents RELEASE CONTROL RECORD..............................................................................3 1. CERTIFICATION...........................................................................................4 2. SUMMARY OF TEST RESULTS...................................................................5 2.1 MEASUREMENT UNCERTAINTY................................................................5 3. GENERAL INFORMATION...........................................................................6 3.1 GENERAL DESCRIPTION OF EUT..............................................................6 3.2 DESCRIPTION OF TEST MODES................................................................7 3.2.1 CONFIGURATION OF SYSTEM UNDER TEST...........................................7 3.2.2 TEST MODE APPLICABILITY AND TESTED CHANNEL DETAIL:...............8 3.3 GENERAL DESCRIPTION OF APPLIED STANDARDS...............................9 3.4 DESCRIPTION OF SUPPORT UNITS..........................................................9 4. TEST TYPES AND RESULTS.....................................................................10 4.1 CONDUCTED EMISSION MEASUREMENT..............................................10 4.2 RADIATED EMISSION MEASUREMENT...................................................10 4.2.1 LIMITS OF RADIATED EMISSION MEASUREMENT.................................10 4.2.2 TEST INSTRUMENTS................................................................................11 4.2.3 TEST PROCEDURES.................................................................................12 4.2.4 DEVIATION FROM TEST STANDARD.......................................................12 4.2.5 TEST SETUP..............................................................................................13 4.2.6 EUT OPERATING CONDITIONS................................................................13 4.2.7 TEST RESULTS..........................................................................................14 4.3 BAND EDGES MEASUREMENT................................................................14 4.3.1 LIMITS OF BAND EDGES MEASUREMENT.............................................19 4.3.2 TEST INSTRUMENTS................................................................................19 4.3.3 TEST PROCEDURE...................................................................................19 4.3.4 DEVIATION FROM TEST STANDARD.......................................................19 4.3.5 EUT OPERATING CONDITION..................................................................19 4.3.6 TEST RESULTS..........................................................................................19 5. PHOTOGRAPHS OF THE TEST CONFIGURATION..................................22 6. INFORMATION ON THE TESTING LABORATORIES................................23 7. APPENDIX A – MODIFICATIONS RECORDERS FOR ENGINEERING CHANGES TO THE EUT BY THE LAB.......................................................24 Report No.: RF120320D12 3 Report Format Version 4.0.0 RELEASE CONTROL RECORD ISSUE NO. REASON FOR CHANGE DATE ISSUED RF120320D12 Original release Apr. 11, 2012 Report No.: RF120320D12 4 Report Format Version 4.0.0 1. CERTIFICATION PRODUCT: WIRELESS LASER MOUSE BRAND NAME: ASUS MODEL NO.: MORFF2ULA APPLICANT: PRIMAX ELECTRONICS LTD. TESTED: Mar. 27 ~ 28, 2012 TEST ITEM: ENGINEERING SAMPLE STANDARDS: FCC Part 15, Subpart C (Section 15.249) ANSI C63.10-2009 The above equipment has been tested by Bureau Veritas Consumer Products Services (H.K.) Ltd., Taoyuan Branch, and found compliance with the requirement of the above standards. The test record, data evaluation & Equipment Under Test (EUT) configurations represented herein are true and accurate accounts of the measurements of the sample’s EMC characteristics under the conditions specified in this report. PREPARED BY : , DATE: ( Celia Chen / Senior Specialist ) APPROVED BY : , DATE: ( Ken Liu / Manager ) Report No.: RF120320D12 5 Report Format Version 4.0.0 2. SUMMARY OF TEST RESULTS The EUT has been tested according to the following specifications: APPLIED STANDARD: FCC Part 15, Subpart C (Section 15.249) STANDARD SECTION TEST TYPE AND LIMIT RESULT REMARK 15.207 Conducted Emission Test N/A Power supply is 1.5Vdc from battery 15.209 15.249 15.249 (d) Radiated Emission Test Band Edge Measurement Limit: 50dB less than the peak value of fundamental frequency or meet radiated emission limit in section 12.209 PASS Minimum passing margin is –10.3dB at 2390.00MHz 2.1 MEASUREMENT UNCERTAINTY Where relevant, the following measurement uncertainty levels have been estimated for tests performed on the EUT as specified in CISPR 16-4-2: This uncertainty represents an expanded uncertainty expressed at approximately the 95% confidence level using a coverage factor of k=2. Measurement Frequency Uncertainty 30MHz ~ 1GHz 3.78 dB Radiated emissions Above 1GHz 3.36 dB Report No.: RF120320D12 6 Report Format Version 4.0.0 3. GENERAL INFORMATION 3.1 GENERAL DESCRIPTION OF EUT EUT WIRELESS LASER MOUSE MODEL NO. MORFF2ULA FCC ID…

Text truncated - open the document above for the full version.

Report No.: RF120320D12 1 Report Format Version 4.0.0 PHOTOGRAPHS OF THE TEST CONFIGURATION RADIATED EMISSION TEST
