Wireless Optical Mouse User’s Guide 1 Introduction Package Contents • 2.4G Wireless Receiver x 1 • AA Battery x 1 pc • User’s Guide x 1 System Requirements • Pentium processor or equivalent • At least one USB port (USB 2.0 or 1.1) • Operating System: Windows ® XP with Service Pack 1 or higher, Windows ® Vista, Windows ® 7 2 Feature It is a mobile size mouse with Nordic new technolog y 2.4G wireless optical mouse. The RF distance is mor e than 10 meter. Button uses magnetic face plate design for battery change and dongle storage for an easier operation. It provides user to more choice to have different c olor or pattern key as per personal preference as an add -on value to users. It uses the nano dongle can storage in mouse with good portable for users. It uses only one AA battery as less weight for more portable and the battery life is more than 4 month s. It also provides a low battery indicator on top of the mouse to warning user for battery change. 3 Function introduction 4 Regulatory Compliance Federal Communication Commission Interference State ment This equipment has been tested and found to comply with the limits for a Class B digital device, pursuant to Part 15 of the FCC Rule s. These limits are designed to provide reasonable protection against harmful in terference in a residential installation. This equipment generates, uses and c an radiate radio frequency energy and, if not installed and used in accordance with the instructions, may cause harmful interference to radio communications. However, there is no guarantee that interference will not occur in a par ticular installation. If this equipment does cause harmful interference to radio or television reception, which can be determined by turning the equipment off and on, the user is encouraged to try to correct the interference by one of the fo llowing measures: - Reorient or relocate the receiving antenna. - Increase the separation between the equipment and receiver. - Connect the equipment into an outlet on a circuit different from that to which the receiver is connected. - Consult the dealer or an experienced radio/TV tec hnician for help. FCC Caution: Any changes or modifications not expressly approve d by the party responsible for compliance could void the user's au thority to operate this equipment. This device complies with Part 15 of the FCC Rules. Operation is subject to the following two conditions: (1) This device may not c ause harmful interference, and (2) this device must accept any interference receiv ed, including interference that may cause undesired operation.

No. 669, Ruey Kuang Road Neihu Taipei, Taiwan, R.O.C. Tel: 883-2-2798-9008 Fax: 886-2-8798-1565 Date: April 6, 2011 Federal Communications Commission Authorization and Evaluation Division Confidentiality Request FCC ID: EMJMMORFFLUO Pursuant to Sections 0.457 and 0.459 of the Commission’s Rules, the Applicant hereby requests confidential treatment of information accompanying this Application as outlined below: Schematics Block Diagram The above materials contain trade secrets and proprietary information not customarily released to the public. The public disclosure of these matters might be harmful to the Applicant and provide unjustified benefits to its competitors. The Applicant understands that pursuant to Rule 0.457, disclosure of this Application and all accompanying documentation will not be made before the date of the Grant for this application. Sincerely yours, ------------------------------------------------------------------- C.T. Huang Compliance Dept. / Director Phone: 886-2-2798-9008 ext.1710 Fax: 886-2-8797-1565 Email: [email protected]

No. 669, Ruey Kuang Road Neihu Taipei, Taiwan, R.O.C. Tel: 883-2-2798-9008 Fax: 886-2-8798-1565 Power of Attorney Date: April 6, 2011 To whom it may concern: We, the undersigned PRIMAX ELECTRONICS LTD. hereby authorize Bureau Veritas Consumer Products Services (H.K.) Ltd., Taoyuan Branch (BV CPS Taoyuan Branch) of Taiwan to act on our behalf in all matters relating to all processes required in the FCC Part 15C approval and any communication needed with the national authority. Any and all acts carried out by BV CPS Taoyuan Branch on our behalf shall have the same effects as acts of our own. If you have any questions regarding the authorization, please don’t hesitate to contact us. Thank you! Sincerely yours, -------------------------------------- C.T. Huang Compliance Dept. / Director Phone: 886-2-2798-9008 ext.1710 Fax: 886-2-8797-1565 Email: [email protected]

Page 1 CONSTRUCTION PHOTOS OF EUT

1 Acer Cheery.Qiao 2011-03-23 304007891070 BOTTOM LABEL 2. 3. 4. 5. 1.白底黑字 （+0/-0.5mm) 印刷內容依承認樣品, "*" 爲重點尺寸. 80#合成紙+霧膜 3 .Follow Halogen- Free requirement : Br<900 ppm, Cl<900 ppm, Br+Cl< 1500 ppm if required 6. Dongle 鐳雕, 30400789107X, 30400747744X,30400747837X, 30400747940X的流水號,日期及周別需對應． 304007891070 *44 mm AIM/N: AM07LH2 AIP/N: LC.MCE0A.035 Wireless Optical Mouse Model : MORFFLUO Rating : 1.5V 40mA FCC ID: EMJMMORFFLUO S/N: LCMCE0A03510900001K701 * 3 7 m m REV: 01 Made in China 7. S/N號碼及日期,周別,由生管/採購提供 流水號(16進制,0~9.A,B,C,D,E,F) 周別 年份 (2010=0,2011=1...) (01~53) LCMCE0A035 1 09 00001 K7 01 固定碼 工廠代碼 版本代碼 AA-0000/0000

LABEL LOCATION Label

Page 2 Page 3 Page 4

FCC ID: EMJMMORFFLUO Report No.: RF110407D03 Operational Description This device is a Wireless Optical Mouse. The transmitter of the EUT is powered by 1.5Vdc from battery. The antenna is Printed antenna without antenna connector. For more detailed instruction, please take a look at the user’s manual.

Report No.: RF990406D20F 1 Report Format Version 4.0.0 Reference No.: 990406D20, 110330D14 FCC TEST REPORT REPORT NO.: RF990406D20F MODEL NO.: MORFFLUO FCC ID: EMJMMORFFLUO RECEIVED: Apr. 6, 2010 TESTED: Apr. 8, 2010 ISSUED: Apr. 6, 2011 APPLICANT: PRIMAX ELECTRONICS LTD. ADDRESS: No. 669, Ruey Kuang Road, Neihu, Taipei, Taiwan, R.O.C. ISSUED BY: Bureau Veritas Consumer Products Services (H.K.) Ltd., Taoyuan Branch LAB LOCATION: No. 47, 14th Ling, Chia Pau Tsuen, Lin Kou Hsiang, Taipei Hsien, 244 Taiwan This test report consists of 24 pages in total. It may be duplicated completely for legal use with the approval of the applicant. It should not be reproduced except in full, without the written approval of our laboratory. The client should not use it to claim product endorsement by TAF or any government agencies. The test results in the report only apply to the tested sample. Report No.: RF990406D20F 2 Report Format Version 4.0.0 Reference No.: 990406D20, 110330D14 Table of Contents RELEASE CONTROL RECORD..............................................................................3 1. CERTIFICATION...........................................................................................4 2. SUMMARY OF TEST RESULTS...................................................................5 2.1 MEASUREMENT UNCERTAINTY...............................................................5 3. GENERAL INFORMATION...........................................................................6 3.1 GENERAL DESCRIPTION OF EUT............................................................6 3.2 DESCRIPTION OF TEST MODES..............................................................7 3.2.1 CONFIGURATION OF SYSTEM UNDER TEST.........................................7 3.2.2 TEST MODE APPLICABILITY AND TESTED CHANNEL DETAIL:.............8 3.3 GENERAL DESCRIPTION OF APPLIED STANDARDS.............................9 3.4 DESCRIPTION OF SUPPORT UNITS........................................................9 4. TEST TYPES AND RESULTS.....................................................................10 4.1 CONDUCTED EMISSION MEASUREMENT............................................10 4.2 RADIATED EMISSION MEASUREMENT.................................................10 4.2.1 LIMITS OF RADIATED EMISSION MEASUREMENT...............................10 4.2.2 TEST INSTRUMENTS..............................................................................11 4.2.3 TEST PROCEDURES...............................................................................12 4.2.4 DEVIATION FROM TEST STANDARD.....................................................12 4.2.5 TEST SETUP............................................................................................13 4.2.6 EUT OPERATING CONDITIONS..............................................................13 4.2.7 TEST RESULTS........................................................................................14 4.3 BAND EDGES MEASUREMENT..............................................................19 4.3.1 LIMITS OF BAND EDGES MEASUREMENT............................................19 4.3.2 TEST INSTRUMENTS..............................................................................19 4.3.3 TEST PROCEDURE.................................................................................19 4.3.4 DEVIATION FROM TEST STANDARD.....................................................19 4.3.5 EUT OPERATING CONDITION................................................................19 4.3.6 TEST RESULTS........................................................................................19 5. PHOTOGRAPHS OF THE TEST CONFIGURATION..................................22 6. INFORMATION ON THE TESTING LABORATORIES................................23 7. APPENDIX A – MODIFICATIONS RECORDERS FOR ENGINEERING CHANGES TO THE EUT BY THE LAB.......................................................24 Report No.: RF990406D20F 3 Report Format Version 4.0.0 Reference No.: 990406D20, 110330D14 RELEASE CONTROL RECORD ISSUE NO. REASON FOR CHANGE DATE ISSUED Original release N/A Apr. 6, 2011 Report No.: RF990406D20F 4 Report Format Version 4.0.0 Reference No.: 990406D20, 110330D14 1. CERTIFICATION PRODUCT: Wireless Optical Mouse BRAND NAME: acer MODEL NO.: MORFFLUO APPLICANT: PRIMAX ELECTRONICS LTD. TESTED: Apr. 8, 2010 TEST SAMPLE: ENGINEERING SAMPLE STANDARDS: FCC Part 15, Subpart C (Section 15.249) ANSI C63.4-2003 ANSI C63.10-2009 The above equipment has been tested by Bureau Veritas Consumer Products Services (H.K.) Ltd., Taoyuan Branch, and found compliance with the requirement of the above standards. The test record, data evaluation & Equipment Under Test (EUT) configurations represented herein are true and accurate accounts of the measurements of the sample’s EMC characteristics under the conditions specified in this report. PREPARED BY : , DATE: ( Annie Chang / Senior Specialist ) APPROVED BY : , DATE: ( Ken Liu / Manager ) Report No.: RF990406D20F 5 Report Format Version 4.0.0 Reference No.: 990406D20, 110330D14 2. SUMMARY OF TEST RESULTS The EUT has been tested according to the following specifications: APPLIED STANDARD: FCC Part 15, Subpart C (Section 15.249) STANDARD SECTION TEST TYPE AND LIMIT RESULT REMARK 15.207 Conducted Emission Test N/A Power supply is 1.5Vdc from battery 15.209 15.249 15.249 (d) Radiated Emission Test Band Edge Measurement Limit: 50dB less than the peak value of fundamental frequency or meet radiated emission limit in section 12.209 PASS Minimum passing margin is –9.3dB at 2390.00MHz 2.1 MEASUREMENT UNCERTAINTY Where relevant, the following measurement uncertainty levels have been estimated for tests performed on the EUT as specified in CISPR 16-4-2: This uncertainty represents an expanded uncertainty expressed at approximately the 95% confidence level using a coverage factor of k=2. Measurement Frequency Uncertainty 30MHz ~ 1GHz 3.67 dB Radiated emissions Above 1GHz 2.89 dB Report No.: RF990406D20F 6 Repo…
