Wireless Laser Mouse User’s Guide Introduction Package Contents □ 2.4G Wireless Receiver x 1 □ AA Battery x 2 pc □ User’s Guide x 1 System Requirements □ Pentium processor or equivalent □ At least one USB port (USB 2.0 or 1.1) □ Operating System: Windows® XP with Service Pack 1 or higher, Windows® Vista, Windows® 7 Feature It is a mobile size mouse with new technology 2.4G wireless optical mouse. The RF distance is more than 10 meter. Button uses magnetic face plate design for battery change and dongle storage for an easier operation. It provides user to more choice to have different color or pattern key as per personal preference as an add- on value to users. It uses the nano dongle can storage in mouse with good portable for users. It uses only one AAA battery as less weight for more portable and the battery life is more than 4 months. It also provides a low battery indicator on top of the mouse to warning user for battery change Regulatory Compliance Federal Communication Commission Interference Statement This equipment has been tested and found to comply with the limits for a Class B digital device, pursuant to Part 15 of the FCC Rules. These limits are designed to provide reasonable protection against harmful interference in a residential installation. This equipment generates, uses and can radiate radio frequency energy and, if not installed and used in accordance with the instructions, may cause harmful interference to radio communications. However, there is no guarantee that interference will not occur in a particular installation. If this equipment does cause harmful interference to radio or television reception, which can be determined by turning the equipment off and on, the user is encouraged to try to correct the interference by one of the following measures: - Reorient or relocate the receiving antenna. - Increase the separation between the equipment and receiver. - Connect the equipment into an outlet on a circuit different from that to which the receiver is connected. - Consult the dealer or an experienced radio/TV technician for help. FCC Caution: Any changes or modifications not expressly approved by the party responsible for compliance could void the user's authority to operate this equipment. This device complies with Part 15 of the FCC Rules. Operation is subject to the following two conditions: (1) This device may not cause harmful interference, and (2) this device must accept any interference received, including interference that may cause undesired operation. IC Statement This Class B digital apparatus complies with Canadian ICES-003. Cet appareil numérique de la classe B est conforme à la norme NMB-003 du Canada. This device complies with RSS-210 of the Industry Canada Rules. Operation is subject to the following two conditions: 1) this device may not cause interference and 2) this device must accept any interference, including interference that may cause undesired operation of the device. Ce dispositif est conforme à la norme CNR-210 d'Industrie Canada applicable aux appareils radio exempts de licence. Son fonctionnement est sujet aux deux conditions suivantes: (1) le dispositif ne doit pas produire de brouillage préjudiciable, et (2) ce dispositif doit accepter tout brouillage reçu, y compris un brouillage susceptible de provoquer un fonctionnement indésirable.

No. 669, Ruey Kuang Road Neihu Taipei, Taiwan, R.O.C. Tel: 883-2-2798-9008 Fax: 886-2-8798-1565 Date: October 18, 2011 Federal Communications Commission Authorization and Evaluation Division Confidentiality Request FCC ID: EMJMMORFFUUL Pursuant to Sections 0.457 and 0.459 of the Commission’s Rules, the Applicant hereby requests confidential treatment of information accompanying this Application as outlined below: Schematics Block Diagram The above materials contain trade secrets and proprietary information not customarily released to the public. The public disclosure of these matters might be harmful to the Applicant and provide unjustified benefits to its competitors. The Applicant understands that pursuant to Rule 0.457, disclosure of this Application and all accompanying documentation will not be made before the date of the Grant for this application. Sincerely yours, ------------------------------------------------------------------- C.T. Huang Compliance Dept. / Director Phone: 886-2-2798-9008 ext.1710 Fax: 886-2-8797-1565 Email: [email protected]

No. 669, Ruey Kuang Road Neihu Taipei, Taiwan, R.O.C. Tel: 883-2-2798-9008 Fax: 886-2-8798-1565 Power of Attorney Date: October 18, 2011 To whom it may concern: We, the undersigned PRIMAX ELECTRONICS LTD. hereby authorize Bureau Veritas Consumer Products Services (H.K.) Ltd., Taoyuan Branch (BV CPS Taoyuan Branch) of Taiwan to act on our behalf in all matters relating to all processes required in the FCC Part 15C approval and any communication needed with the national authority. Any and all acts carried out by BV CPS Taoyuan Branch on our behalf shall have the same effects as acts of our own. If you have any questions regarding the authorization, please don’t hesitate to contact us. Thank you! Sincerely yours, -------------------------------------- C.T. Huang Compliance Dept. / Director Phone: 886-2-2798-9008 ext.1710 Fax: 886-2-8797-1565 Email: [email protected]

Page 1 CONSTRUCTION PHOTOS OF EUT

LABEL LOCATION Label Location

5 2 . 0 m m 9 6 . 4 m m xx CNC : X-XXXX SCT : XXXXXXXXX-XXXX CMIIT ID : YYYYAASSSS N279 TA-2010/XXXX R33001 Complies with IDA Standards DBXXXXXX XXXXX/SDPPI/2010 XXXX XXXXXXXXXX 당해 무선설비는 운용 중 전파혼선 가능성이 있음 KCC-CRI-HPK-XXXXXXXX XXXX-XX-XXXX CCAIXXLPXXXXXX HP Product Number : AOX36AA Model Number : MORFFUUL Rating(額定電壓電流/额定电压电流) : 3V 40mA CLASS 1 LASER PRODUCT FCC ID : EMJMMORFFUUL IC : 4251A-MMORFFUUL S/N : CNPYWWXXXX Hewlett Packard Company 3000 Hanover Street, Palo Alto, CA 94304, U.S.A. Product of China(中國製造/中国制造) Rev. A Complies with 21 CFR 1040.10 and 1040.11 except for deviations pursuant to Laser Notice No. 50, dated June 24, 2007. HP Wireless Mouse HP 無線滑鼠 HP 无线鼠标

Page 2 Page 3 Page 4 Page 5 Page 6

FCC ID: EMJMMORFFUUL Report No.: RF110930D06 Operational Description The transmitter of the EUT (Wireless Mouse) is powered by 3Vdc from batteries. The type of antenna is Printed antenna. The output power of this device is very low. Under normal use condition, the transmitter and the receiver are quite close, so high EIRP power is neither necessary nor allowed because of interference.
