EMJMMORFG9ULHP Wireless Mouse x5500

無線滑鼠 x5500 快速使用手冊 Wireless Mouse x5500 Quick Setup 1 2 3 Please download and install software fromhttp://www.hp.com/support http://www.hp.com/jp/support/からソフトウェアをダウンロードおよびインストールして A B Software zum Herunterladenund Installieren finden Sie auf http://www.hp.com/support 에서 und Installieren finden Sie aufhttp://www.hp.com/support 소프트웨어를 다운로드하고 설치하십시오 . Descargue e instale el softwareen: http://www.hp.com/support 请至 http://www.hp.com/support下载并安装软件 Veuillez télécharger puis installerle logiciel à partir dehttp://www.hp.com/support 請自 http://www.hp.com/support下載並安裝軟體 Scaricare e installare il softwaredal sito Internet:http://www.hp.com/support Lütfen yaz ı l ı m ı http://www. hp.com/support adresinden indirin ve yükleyinЗагрузите и установите Download en installeer softwarevia http://www.hp.com/support Загрузите и установите программное обеспечение с веб - страницы http://www. hp.com/support Baixe e instale o software emhttp://www.hp.com/support Pull off the battery insulation tap 開始使用前請拉開電池絕緣膠帶 turn on the power switch 打開電源開關 4 NOTE(提示) NOTE(提示) A B A B Insert the dongle(attch inside mouse) into USB port 將滑鼠內附的無線接收器插入USB槽 A B A B Insert dongle into component when usingfinished avoid to lose使用完成後請將無線接收器歸回插槽，以免遺失 Pushing back top cover to keepproduct entirety並將上蓋蓋回，以保持產品的完整性 Hiper speed scrolling 高速滾輪卷軸 Normal speed scrolling 正常速度滾輪卷軸 The dongle will be drive by windows, moving mouse and cheecking cursor as your wish 系統將自動驅動無線接收器。移動滑鼠，並檢查游標是否到達您希望的位置 ©Copyright 2012Hewlett-Packard Development Company, L.P.www.hp.comVersion 1.0 ● ●●● Turkiye Cumhuriyeti: EEE Yonetmeligine Uygundur ● 低功率電波輻射性電機管理辦法 第十二條經型式認証合格之低功率射頻電機，非經許可，公司、商號或使用者均不得擅自變更頻 率 ● This device complies with RSS-210 of the Industry Canada Rules. Operation is subject to the following two condition s: (1) This device may not cause harmful interference, and (2) this de vice must accept any interference received, including interference t hat may cause undesired operation. ● La operación de este equipo está sujeta a las sigu ientes dos condiciones: (1) es posible que este equ ipo o dispositivo no cause interferencia perjudicial y (2) este equipo o dispo sitivo debe aceptar cualquier interferencia, incluy endo la que pueda causar su operació n no deseada● Bu ürünün Türkçe uygunluk beyanını yükleyebilmek i çin lütfen www.hp.com/support sitesine tıklayın ve haritadan Türkiye seçenegini ● 당해 무선설비는 운용중 전파혼신 가능성이 있음 이 기기는 가정용 (B 급 ) 전자파적합기기로서 주로 가정에서 사용하는 것을 목적으로 하며 , 모든 지역에서 사용할 수 있습니다 . Printed in ChinaImprime enChinaStampato inCina中 国 印刷 Complies with IDA Standards DB100427 Svenska Kassering av förbrukningsmaterial, för hem- och pri vatanvändare i EU Produkter eller produktförpackningar med den här sy mbolen får inte kasseras med vanligt hushållsavfall . I stället har du ansvar för att produkten lämnas till en behö rig återvinningsstation för hantering av el- och elektronikprodukter. Genom att lämna kasserade prod ukter till återvinning hjälper du till att bevara v åra ● Ce dispositif est conforme à la norme CNR-210 d'In dustrie Canada applicable aux appareils radio exempts de licence. Son fonctionnement est sujet aux deux conditions suivantes: 1) le disp ositif ne doit pas produire de brouillage préjudiciable, et 2) ce disp ositif doit accepter tout brouillage reçu, y compris un brouillage susce ptible de provoquer un fonctionnement indésirable● Industry Canada, Class B "This Class "B" digital a pparatus complies with Canadian ICES-003. ● Cet appareil numérique de la classe "B" est confor me à la norme ● Este equipamento opera em caráter secundário, isto é, não tem direito a proteção contra interferência prejudicial, mesmo de esta ções do mesmo tipo, e não pode causar interferência a sistemas operando em caráter primário ● Обладнання відповідає вимогам Технічного регламенту щодо обмеження використання деяких небезпечних речовин в ел ектричному та електронному обладнанні , затвердженого постановою Кабінету Міністрів . України від 3 грудня 2008 No 1057 Hävitettävien laitteiden käsittely kotitalouksissa Euroopan unionin alueella Tämä tuotteessa tai sen pakkauksessa oleva merkintä osoittaa, että tuotetta ei saa hävittää talousjätt eiden mukana. Käyttäj än velvollisuus on huolehtia siitä, että hävitettäv ä laite toimitetaan sähkö- ja elektroniikkalaiterom unkeräyspisteeseen. Hä vitettävien laitteiden erillinen keräys ja kierräty s säästää luonnonvaroja. Näin toimimalla varmisteta an myös, että kierrätys ● Changes or modifications not expressly approved by the part responsible for compliance could void the user's authority to operate the equipment. This symbol on the product or on its packaging indi cates that this product must not be disposed of wit h your other household waste. Instead, it is your responsibility to dispos e of your waste equipment by handing it over to a d esignated collection point for the recycling of waste electrical and electronic eq uipment. The separate collection and recycling of y our waste equipment at the English Suomi Instructions for Disposal of Waste Equipment by Use rs in Private Household 使用者均不得擅自變更頻率、加大功率或變更原設計之特性及功能。第十四條 低功率射頻電機之使用不得影響飛航安 全及干擾合法通 信，經發現有干擾現象時，應立即停用，，並改善至無干擾時方得繼續使用。前項合法通信，指依電信法規定作業之 無線電通信。低 須忍受合法通信或工業、科學及醫療用電波輻射性電機設備之干擾。● 發射功率:0 dBm 使用頻道數:78ch Ελληνικά Deutschfrançais 歐盟國家地區用戶在一般住宅中對廢棄設備之處理 產品或包裝上印有此回收標誌是表示此產品不得作爲一膽娜處理。您有責任將廢棄之設備 送到指定之回收點，透過 Svenska elektronikprodukter. Genom att lämna kasserade prod ukter till återvinning hjälper du till att bevara v åra gemensamma naturresurser. Dessutom skyddas både män niskor och miljön när produkter återvinns på rätt s ätt. Kommunala myndigheter, sophanteringsföretag eller b utiken där varan köptes kan ge mer information om v ar du l ämnar kasserade produkter för återvinning. 欧 盟 国 家/地 区 用戶在私人住宅 对废弃设备 的 处 理 产品或包装上包括此标志表示此产品不得做为一般住宅垃圾来处理。而且您有责任将废弃之设备 送到指定的废弃电力电子设备回收点，通过这种废弃设备的分类收集与回收，有助于节约自然资源，有利于人类健康。有关废弃设备回收的详细信息，请与当地市政机关、家庭垃圾处理站或购买此产品的商店联系。 简体中文 ● Cet appareil numérique de la classe "B" est confor me à la norme NMB-003 du Canada. 繁體中文 vitettävien laitteiden…

Text truncated - open the document above for the full version.

No. 669, Ruey Kuang Road Neihu Taipei, Taiwan, R.O.C. Tel: 883-2-2798-9008 Fax: 886-2-8798-1565 Date: June 28, 2012 Federal Communications Commission Authorization and Evaluation Division Confidentiality Request FCC ID: EMJMMORFG9UL Pursuant to Sections 0.457 and 0.459 of the Commission’s Rules, the Applicant hereby requests confidential treatment of information accompanying this Application as outlined below: Schematics Block Diagram The above materials contain trade secrets and proprietary information not customarily released to the public. The public disclosure of these matters might be harmful to the Applicant and provide unjustified benefits to its competitors. The Applicant understands that pursuant to Rule 0.457, disclosure of this Application and all accompanying documentation will not be made before the date of the Grant for this application. Sincerely yours, ------------------------------------------------------------------- C.T. Huang Compliance Dept. / Director Phone: 886-2-2798-9008 ext.1710 Fax: 886-2-8797-1565

No. 669, Ruey Kuang Road Neihu Taipei, Taiwan, R.O.C. Tel: 883-2-2798-9008 Fax: 886-2-8798-1565 Power of Attorney Date: June 28, 2012 To whom it may concern: We, the undersigned PRIMAX ELECTRONICS LTD. hereby authorize Bureau Veritas Consumer Products Services (H.K.) Ltd., Taoyuan Branch (BV CPS Taoyuan Branch) of Taiwan to act on our behalf in all matters relating to all processes required in the FCC Part 15C approval and any communication needed with the national authority. Any and all acts carried out by BV CPS Taoyuan Branch on our behalf shall have the same effects as acts of our own. If you have any questions regarding the authorization, please don’t hesitate to contact us. Thank you! Sincerely yours, -------------------------------------- C.T. Huang Compliance Dept. / Director Phone: 886-2-2798-9008 ext.1710 Fax: 886-2-8797-1565 Email: [email protected]

Page 1 CONSTRUCTION PHOTOS OF EUT

2 ** ** Dim 1 1 3 . 6 5 72.5 Complies with IDA Standards XXXXXXXX Complies with IDA Standards XXXXXXXX XXXXXXXXXXXXXX XXXXXXXXXXXXXX xx xx XX-XX/XXX XX-XX/XXX XXXX/SDPPI/XXXX XXXX XXXX/SDPPI/XXXX XXXX XXXX XXXX R41108 R41108 KCC-HPK-XXXXXX KCC-HPK-XXXXXX HP Wireless Mouse x5500 HP 無線滑鼠 / HP 无线鼠标 HP Wireless Mouse x5500 HP 無線滑鼠 / HP 无线鼠标 Product of China(中國製造/中国制造) REV. A HP Product Number : H2W15AA Model(型號/型号) : MORFG9UL HP Spare Part No. : XXXXXX Rating(額定/额定) : 3V 40mA CLASS 1 LASER PRODUCT FCC ID : EMJMMORFG9UL IC : 4251A-MMORFG9UL CMIIT ID : XXXXXXXX ETA : XXXX/XXXX/WRLO S/N : CNPYWWXXXX Manufactured : MMMMYYYY Site : P Hewlett Packard Company 3000 Hanover Street, Palo Alto, CA 94304, U.S.A. Product of China(中國製造/中国制造) REV. A HP Product Number : H2W15AA Model(型號/型号) : MORFG9UL HP Spare Part No. : XXXXXX Rating(額定/额定) : 3V 40mA CLASS 1 LASER PRODUCT FCC ID : EMJMMORFG9UL IC : 4251A-MMORFG9UL CMIIT ID : XXXXXXXX ETA : XXXX/XXXX/WRLO S/N : CNPYWWXXXX Manufactured : MMMMYYYY Site : P Hewlett Packard Company 3000 Hanover Street, Palo Alto, CA 94304, U.S.A. HP,HQ-TRE,71004 Boeblingen,Germany HP,HQ-TRE,71004 Boeblingen,Germany 廠商的UL代碼 被貼底蓋材質:ABS 流水碼具體如下: 0001,0002,...0009,000B,000C,000D,000F,...000Z 0010,0011,.....0019,001B,001C,001D,001F...001Z 0020...009Z,00B0,00B1...00BB..00ZY,00ZZ,... 1000,1001,...1009,100B...100Z,1010,1011...9999, 999B,999C,....999Y,999Z,99B0,99B1...99ZZ...9ZZZ, B000......ZZZZ P代表Primax 固定碼 YEAR(2012=2,2013=3....) WEEK(01,02,.....) 流水碼(0001~ZZZZ, 其中A,E,I,O,U不能使用),31進制 S/N: CN P Y WW XXXX 1:1 2:1

Page 2 Page 3 Page 4 Page 5

FCC ID: EMJMMORFG9UL Report No.: RF120619D05 Operational Description The transmitter of the EUT (HP Wireless Mouse x5500) is powered by 3.0Vdc from batteries. The type of antenna is Printed antenna. The output power of this device is very low. Under normal use condition, the transmitter and the receiver are quite close, so high EIRP power is neither necessary nor allowed because of interference.

Report No.: RF120619D05 1 of 21 Report Format Version 5.0.0 FCC TEST REPORT REPORT NO.: RF120619D05 MODEL NO.: MORFG9UL FCC ID: EMJMMORFG9UL RECEIVED: Jun. 5, 2012 TESTED: Jun. 5, 2012 ISSUED: Jun. 27, 2012 APPLICANT: PRIMAX ELECTRONICS LTD. ADDRESS: No. 669, Ruey Kuang Road, Neihu, Taipei, Taiwan, R.O.C. ISSUED BY: Bureau Veritas Consumer Products Services (H.K.) Ltd., Taoyuan Branch LAB LOCATION: No. 47, 14th Ling, Chia Pau Vil., Lin Kou Dist., New Taipei City, Taiwan ( R.O.C. ) This report is for your exclusive use. Any copying or replication of this report to or for any other person or entity, or use of our name or trademark, is permitted only with our prior written permission. This report sets forth our findings solely with respect to the test samples identified herein. The results set forth in this report are not indicative or representative of the quality or characteristics of the lot from which a test sample was taken or any similar or identical product unless specifically and expressly noted. Our report includes all of the tests requested by you and the results thereof based upon the information that you provided to us. You have 60 days from date of issuance of this report to notify us of any material error or omission caused by our negligence, provided, however, that such notice shall be in writing and shall specifically address the issue you wish to raise. A failure to raise such issue within the prescribed time shall constitute your unqualified acceptance of the completeness of this report, the tests conducted and the correctness of the report contents. Unless specific mention, the uncertainty of measurement has been explicitly taken into account to declare the compliance or non-compliance to the specification This report should not be used by the client to claim product certification, approval, or endorsement by TAF or any government agencies. Report No.: RF120619D05 2 of 21 Report Format Version 5.0.0 Table of Contents RELEASE CONTROL RECORD..............................................................................3 1. CERTIFICATION...........................................................................................4 2. SUMMARY OF TEST RESULTS...................................................................5 2.1 MEASUREMENT UNCERTAINTY...............................................................5 3. GENERAL INFORMATION...........................................................................6 3.1 GENERAL DESCRIPTION OF EUT............................................................6 3.2 DESCRIPTION OF TEST MODES..............................................................7 3.2.1 CONFIGURATION OF SYSTEM UNDER TEST.........................................7 3.2.2 TEST MODE APPLICABILITY AND TESTED CHANNEL DETAIL:.............8 3.3 GENERAL DESCRIPTION OF APPLIED STANDARDS.............................9 3.4 DESCRIPTION OF SUPPORT UNITS........................................................9 4. TEST TYPES AND RESULTS.....................................................................10 4.1 CONDUCTED EMISSION MEASUREMENT............................................10 4.2 RADIATED EMISSION AND BAND EDGE MEASUREMENT...................10 4.2.1 LIMITS OF RADIATED EMISSION MEASUREMENT...............................10 4.2.2 TEST INSTRUMENTS..............................................................................11 4.2.3 TEST PROCEDURES...............................................................................12 4.2.4 DEVIATION FROM TEST STANDARD.....................................................12 4.2.5 TEST SETUP............................................................................................13 4.2.6 EUT OPERATING CONDITIONS..............................................................13 4.2.7 TEST RESULTS........................................................................................14 5. PHOTOGRAPHS OF THE TEST CONFIGURATION..................................19 6. INFORMATION ON THE TESTING LABORATORIES................................20 7. APPENDIX A – MODIFICATIONS RECORDERS FOR ENGINEERING CHANGES TO THE EUT BY THE LAB.......................................................21 Report No.: RF120619D05 3 of 21 Report Format Version 5.0.0 RELEASE CONTROL RECORD ISSUE NO. REASON FOR CHANGE DATE ISSUED RF120619D05 Original release Jun. 27, 2012 Report No.: RF120619D05 4 of 21 Report Format Version 5.0.0 1. CERTIFICATION PRODUCT: HP Wireless Mouse x5500 BRAND NAME: HP MODEL NO.: MORFG9UL APPLICANT: PRIMAX ELECTRONICS LTD. TESTED: Jun. 5, 2012 TEST ITEM: ENGINEERING SAMPLE STANDARDS: FCC Part 15, Subpart C (Section 15.249) ANSI C63.10-2009 The above equipment has been tested by Bureau Veritas Consumer Products Services (H.K.) Ltd., Taoyuan Branch, and found compliance with the requirement of the above standards. The test record, data evaluation & Equipment Under Test (EUT) configurations represented herein are true and accurate accounts of the measurements of the sample’s EMC characteristics under the conditions specified in this report. PREPARED BY : , DATE: ( Annie Chang / Supervisor ) APPROVED BY : , DATE: ( Ken Liu / Manager ) Report No.: RF120619D05 5 of 21 Report Format Version 5.0.0 2. SUMMARY OF TEST RESULTS The EUT has been tested according to the following specifications: APPLIED STANDARD: FCC Part 15, Subpart C (Section 15.249) STANDARD PARAGRAPH TEST TYPE RESULT REMARK 15.207 Conducted Emission Test N/A Power supply is 3.0Vdc from batteries 15.209 15.249 15.249 (d) Radiated Emission Test Band Edge Measurement Limit: 50dB less than the peak value of fundamental frequency or meet radiated emission limit in section 15.209 PASS Meet the requirement of limit. Minimum passing margin is -9.4dB at 2390.00MHz. 2.1 MEASUREMENT UNCERTAINTY Where relevant, the following measurement uncertainty levels have been estimated for tests performed on the EUT as specified in CISPR 16-4-2: This uncertainty represents an expanded uncertainty expressed at app…

Text truncated - open the document above for the full version.

Report No.: RF120619D05 1 of 1 Report Format Version 5.0.0 PHOTOGRAPHS OF THE TEST CONFIGURATION RADIATED EMISSION TEST
