Wi-Fi MOUSE User Guide Introduction Thank you for your purchase of the Wi-Fi Mouse. The mouse uses Wi-Fi technology to seamlessly and securely connect to your computer Contents • Wi-Fi Mouse • 2 x AAA Energize r ® Max ® Alkaline Batteries • Installation Software • User Guide System Requirements Hardware • WIN7 Certified Wi-Fi Network Adapter Operating System • Microsoft Windows® 7 Installing the Batteries 1. Remove the battery cover from the top of the mouse by using the notch on the back. Carefully lift the cover up as shown in the diagram. 2. Insert two AAA batteries, making sure that the positive (+) and negative (-) ends match the polarity indicators inside the battery compartment. 3. Replace the battery cover. 4. The Battery Indicator will light up after it is activated. Installing the Driver 1. To Install the Wi-Fi Wireless Mouse on your PC, insert the supplied Set-up CD in your CD or DVD drive. The driver installation will start automatically. 2. The Wi-Fi Mouse - InstallShield Wizard will pop up. Select Next to continue with the installation. 3. This will start the installation of the Wi-Fi Mouse driver. Please click Install to begin the installation 5. Installation begins. 6. A message will pop up indicating that the installation process is complete. Click Finish to exit the window. Pairing Instruction Wi-Fi Mouse driver is now installed on your system. To pair your Wi-Fi Mouse with your computer: 1. Open the Wi-Fi Mouse Pairing Utility. 2. To activate the mouse in discovery mode, push the pairing button under the mouse for at least 5 seconds and release. Then the battery indicator light on the top of the mouse will flash once per second. Now the mouse is in pairing mode. 3. Click Start Discovery to pair your mouse to the computer. 4. The computer will list discovered Wi-Fi devices in the bottom box. Once your mouse is in the bottom box, highlight it and click Start Pairing. The computer will start pairing with your mouse. 5. Windows® 7 will detect the mouse and find the driver automatically. Your mouse is ready to use now. Power Saving Mode If the mouse is not used for an extended period of time, it will automatically enter power saving mode to conserve power and increase the battery life. Click on any mouse button to resume the normal operation. The mouse may take a few seconds to reconnect with your computer. To extend the life of your battery, turn the mouse off while travelling or when not in use. Battery Indicator When the mouse is switched on, the battery indicator light will light up: • When the mouse is powered on, the blue light will turn on and fade out in 2 seconds • Wi-Fi Connection: Blue light will flash 2 times per second • Pairing: Blue light will flash once per second when the pairing button is held for over 1 second • Low-Battery Warning: An amber colored light will flash once per second Mouse Keys and Functions DPI Setting and Indication The Wi-Fi mouse provides a driver-free selectable tracking resolution function so that users can tune the tracking precision of their mouse. Two kinds of DPIs, 1200dpi and1600dpi, can be toggled by pressing and holding the DPI switch button on the top of the mouse for 2 seconds. The default factory setting is 1200 dpi. The power indicator light will be leveraged to indicate the DPI setting value in two kinds of colors; 1200dpi will light up orange and 1600dpi will light up blue. As long as the DPI value is changed successfully or the mouse is woken up from sleep mode, this indicator light will turn on and then fade out in 2 seconds. Windows 7 Task Switching The Windows Task Switching button on the top of the Wi-Fi mouse supports the most efficient way to switch among the opened windows on your computer. With a single click of the Task Switching button, the mouse emulates the Ctrl+Alt+Tab command to open the application switching window showing all of the launched task windows with small thumbnails accordingly. With a double click of the Task Switching button, the mouse emulates the Ctrl+Win+Tab command to activate the Flip-3D effect showing all of the launched task windows in a 3D effect. Users can switch to the target task window by either moving the mouse cursor to the top of the task window and then clicking the right mouse button, or by scrolling the mouse wheel to move the target task window to the front and then clicking the right mouse button Warranty Mouse warrants this product to be free from defects in materials and workmanship for one year. If your Mouse accessory is found to be defective within that time, we will promptly repair or replace it. This warranty does not cover accidental damage, wear and tear, or consequential or incidental loss. Under no conditions is Mouse liable for loss of, or damage to devices; nor loss of, or damage to, programs, records, or data; nor any consequential or incidental damages, even if Mouse has been informed of their possibility. This warranty does not affect your statutory rights. Federal Communication Commission Interference Statement This equipment has been tested and found to comply with the limits for a Class B digital device, pursuant to Part 15 of the FCC Rules. These limits are designed to provide reasonable protection against harmful interference in a residential installation. This equipment generates, uses and can radiate radio frequency energy and, if not installed and used in accordance with the instructions, may cause harmful interference to radio communications. However, there is no guarantee that interference will not occur in a particular installation. If this equipment does cause harmful interference to radio or television reception, which can be determined by turning the equipment off and on, the user is encouraged to try to correct the interference by one of the following measures: - Reorient or relocate the receiving antenna. - Increase the separation between the equipment and receiver. - Connect the equipment into an outlet on a circuit different from that to wh…
