EMJMN60Lenovo Wireless Optical Mouse N60

Features Front ViewBack View ## 11 22 33 55 66 88 To use your mouse: turns off switched on and pairing when the mouse is The LED indicator orange light about 3 seconds then The LED indicator continuously flashes orange 1 minute level is low. Replace the batteries Using your mouse LED Indicator Component Left mouse button Right mouse button Scroll wheel Battery compartment USB dongle Optical sensor Power button 77 44 LED indicator 1. Use the scroll wheel to scroll up and down the screen. 2. Press and hold the scroll wheel down, then move the mouse up and down to scroll up and down the page. Connecting your mouse 1. Open the battery cover. 2. Remove the USB dongle from the back of the mouse. To connect your mouse: 4. Plug the USB dongle into an open USB port on your laptop. 5. Switch the power button on the bottom of your mouse to the ON position. The laptop automatically detects the mouse. 3. Insert one AA battery, then replace the battery cover. 11 Quick Start Guide Lenovo Wireless Mouse N60 Quick Start Guide 特征 左键 右键 滚轮 LED指示灯 电池盖 USB接收器 光学感应器 电源开关 组件 1. 移动滚轮以向上﹐向下移动屏 幕图像 2. 按住滚轮向上向下移动可以 滚动页面 Lenovo 无线光学鼠标N60 使用鼠标 使用鼠标: LED提示 当打开电源开关或配对成功后﹐LED指示显示桔光 约3秒后息灭 5.把鼠标底部的电源开关推至ON位置电脑会自动连 接鼠标 1.打开电池盖 2.从鼠标底部取出USB 接收器 3.装入一节AA电池然后盖好电池盖 4.把USB接收器插到电脑的USB接口 连接鼠标方法: 连接鼠标 俯视图 仰视图 快速使用指南 when the battery immediately. 当电池电量不足时﹐LED指示灯会连续闪烁1分钟 桔光﹐请及时更换电池 1 2 3 7 5 6 8 4 1 2 3 7 5 6 8 4 ON OFF 2 ON OFF 2 is established. Lenovo Wireless Mouse N60 FCC ID:EMJMN60 Lenovo Ultraslim Plus Wireless Dongle FCC ID:EMJDMORFFHL-D For use only with UL Listed I.T.E. computer Mouse CMIIT ID:XXXXXXXX Dongle CMIIT ID:2011DJ0776

No. 669, Ruey Kuang Road Neihu Taipei, Taiwan, R.O.C. Tel: 883-2-2798-9008 Fax: 886-2-8798-1565 Date: February 17, 2012 Federal Communications Commission Authorization and Evaluation Division Confidentiality Request FCC ID: EMJMN60 Pursuant to Sections 0.457 and 0.459 of the Commission’s Rules, the Applicant hereby requests confidential treatment of information accompanying this Application as outlined below: Schematics Block Diagram The above materials contain trade secrets and proprietary information not customarily released to the public. The public disclosure of these matters might be harmful to the Applicant and provide unjustified benefits to its competitors. The Applicant understands that pursuant to Rule 0.457, disclosure of this Application and all accompanying documentation will not be made before the date of the Grant for this application. Sincerely yours, ------------------------------------------------------------------- C.T. Huang Compliance Dept. / Director Phone: 886-2-2798-9008 ext.1710 Fax: 886-2-8797-1565 Email: [email protected]

No. 669, Ruey Kuang Road Neihu Taipei, Taiwan, R.O.C. Tel: 883-2-2798-9008 Fax: 886-2-8798-1565 Power of Attorney Date: February 17, 2012 To whom it may concern: We, the undersigned PRIMAX ELECTRONICS LTD. hereby authorize Bureau Veritas Consumer Products Services (H.K.) Ltd., Taoyuan Branch (BV CPS Taoyuan Branch) of Taiwan to act on our behalf in all matters relating to all processes required in the FCC Part 15 approval and any communication needed with the national authority. Any and all acts carried out by BV CPS Taoyuan Branch on our behalf shall have the same effects as acts of our own. If you have any questions regarding the authorization, please don’t hesitate to contact us. Thank you! Sincerely yours, ----------------------------- C.T. Huang Compliance Dept. / Director Phone: 886-2-2798-9008 ext.1710 Fax: 886-2-8797-1565 Email: [email protected]

Page 1 CONSTRUCTION PHOTOS OF EUT

39 mm 2 3 m m 产品名称: 联想光学鼠标 M60 产品名称: 联想无线光学鼠标 N60 联想 (北京) 有限公司 联想 (北京) 有限公司 中国制造 Made in China 中国制造 Made in China XX XX For use only with UL Listed I.T.E. computer For use only with UL Listed I.T.E. computer 型号/Model: M60 型号/Model: N60 S/N:OL13398YWWXXXXX S/N:OL13397YWWXXXXX CLASS 1 LED PRODUCT CLASS 1 LED PRODUCT This device complies with Canada This device complies with Canada ICES-003,Class B 输入/Rating: 5V 100mA 输入/Rating: 1.5V 40mA 被粘底盖材质: ABS 被粘底盖材质: ABS P/N: 888013398 P/N: 888013397 ETA: XXXX/2012/ WRLO CMIIT ID:XXXXXXXXXX FCC ID:EMJMN60 ICES-003,Class B M60 bottom labelN60 bottom label 40 mm 1 8 m m E134780 2G55 I.T.E. ACCESSORY E134780 2G55 I.T.E. ACCESSORY

LABEL LOCATION Label Location

Page 2 Page 3 Page 4

FCC ID: EMJMN60 Report No.: RF120210D05 Operational Description The transmitter of the EUT (Lenovo Wireless Optical Mouse N60) is powered by 1.5Vdc from battery. The type of antenna is Printed antenna. The output power of this device is very low. Under normal use condition, the transmitter and the receiver are quite close, so high EIRP power is neither necessary nor allowed because of interference.

Report No.: RF120210D05 1 Report Format Version 4.0.0 FCC TEST REPORT REPORT NO.: RF120210D05 MODEL NO.: N60 FCC ID: EMJMN60 RECEIVED: Feb. 10, 2012 TESTED: Feb. 13, 2012 ISSUED: Feb. 21, 2012 APPLICANT: PRIMAX ELECTRONICS LTD. ADDRESS: No. 669, Ruey Kuang Road, Neihu, Taipei, Taiwan, R.O.C. ISSUED BY: Bureau Veritas Consumer Products Services (H.K.) Ltd., Taoyuan Branch LAB LOCATION: No. 47, 14th Ling, Chia Pau Vil., Lin Kou Dist., New Taipei City, Taiwan ( R.O.C. ) This test report consists of 24 pages in total. It may be duplicated completely for legal use with the approval of the applicant. It should not be reproduced except in full, without the written approval of our laboratory. The client should not use it to claim product endorsement by TAF or any government agencies. The test results in the report only apply to the tested sample. Report No.: RF120210D05 2 Report Format Version 4.0.0 Table of Contents RELEASE CONTROL RECORD..............................................................................3 1. CERTIFICATION...........................................................................................4 2. SUMMARY OF TEST RESULTS...................................................................5 2.1 MEASUREMENT UNCERTAINTY................................................................5 3. GENERAL INFORMATION...........................................................................6 3.1 GENERAL DESCRIPTION OF EUT..............................................................6 3.2 DESCRIPTION OF TEST MODES................................................................7 3.2.1 CONFIGURATION OF SYSTEM UNDER TEST...........................................7 3.2.2 TEST MODE APPLICABILITY AND TESTED CHANNEL DETAIL:...............8 3.3 GENERAL DESCRIPTION OF APPLIED STANDARDS...............................9 3.4 DESCRIPTION OF SUPPORT UNITS..........................................................9 4. TEST TYPES AND RESULTS.....................................................................10 4.1 CONDUCTED EMISSION MEASUREMENT..............................................10 4.2 RADIATED EMISSION MEASUREMENT...................................................10 4.2.1 LIMITS OF RADIATED EMISSION MEASUREMENT.................................10 4.2.2 TEST INSTRUMENTS................................................................................11 4.2.3 TEST PROCEDURES.................................................................................12 4.2.4 DEVIATION FROM TEST STANDARD.......................................................12 4.2.5 TEST SETUP..............................................................................................13 4.2.6 EUT OPERATING CONDITIONS................................................................13 4.2.7 TEST RESULTS..........................................................................................14 4.3 BAND EDGES MEASUREMENT................................................................19 4.3.1 LIMITS OF BAND EDGES MEASUREMENT.............................................19 4.3.2 TEST INSTRUMENTS................................................................................19 4.3.3 TEST PROCEDURE...................................................................................19 4.3.4 DEVIATION FROM TEST STANDARD.......................................................19 4.3.5 EUT OPERATING CONDITION..................................................................19 4.3.6 TEST RESULTS..........................................................................................19 5. PHOTOGRAPHS OF THE TEST CONFIGURATION..................................22 6. INFORMATION ON THE TESTING LABORATORIES................................23 7. APPENDIX A – MODIFICATIONS RECORDERS FOR ENGINEERING CHANGES TO THE EUT BY THE LAB.......................................................24 Report No.: RF120210D05 3 Report Format Version 4.0.0 RELEASE CONTROL RECORD ISSUE NO. REASON FOR CHANGE DATE ISSUED RF120210D05 Original release Feb. 21, 2012 Report No.: RF120210D05 4 Report Format Version 4.0.0 1. CERTIFICATION PRODUCT: Lenovo Wireless Optical Mouse N60 BRAND NAME: lenovo MODEL NO.: N60 APPLICANT: PRIMAX ELECTRONICS LTD. TESTED: Feb. 13, 2012 TEST ITEM: ENGINEERING SAMPLE STANDARDS: FCC Part 15, Subpart C (Section 15.249) ANSI C63.10-2009 The above equipment has been tested by Bureau Veritas Consumer Products Services (H.K.) Ltd., Taoyuan Branch, and found compliance with the requirement of the above standards. The test record, data evaluation & Equipment Under Test (EUT) configurations represented herein are true and accurate accounts of the measurements of the sample’s EMC characteristics under the conditions specified in this report. PREPARED BY : , DATE: ( Annie Chang / Senior Specialist ) APPROVED BY : , DATE: ( Ken Liu / Manager ) Report No.: RF120210D05 5 Report Format Version 4.0.0 2. SUMMARY OF TEST RESULTS The EUT has been tested according to the following specifications: APPLIED STANDARD: FCC Part 15, Subpart C (Section 15.249) STANDARD SECTION TEST TYPE AND LIMIT RESULT REMARK 15.207 Conducted Emission Test N/A Power supply is 1.5Vdc from battery 15.209 15.249 15.249 (d) Radiated Emission Test Band Edge Measurement Limit: 50dB less than the peak value of fundamental frequency or meet radiated emission limit in section 12.209 PASS Minimum passing margin is –9.1dB at 2390.00MHz 2.1 MEASUREMENT UNCERTAINTY Where relevant, the following measurement uncertainty levels have been estimated for tests performed on the EUT as specified in CISPR 16-4-2: This uncertainty represents an expanded uncertainty expressed at approximately the 95% confidence level using a coverage factor of k=2. Measurement Frequency Uncertainty 30MHz ~ 1GHz 3.87 dB Radiated emissions Above 1GHz 3.36 dB Report No.: RF120210D05 6 Report Format Version 4.0.0 3. GENERAL INFORMATION 3.1 GENERAL DESCRIPTION OF EUT EUT Lenovo Wireless Optical Mouse N60 MODEL NO. N60 FCC ID EMJMN…
