Bluetooth ® Headset Badge BHS -608 User Guide k a n s i l e h t i _ 6 0 8 . i n d d 1 kansilehti_608.indd 1 1 9 . 6 . 2 0 0 5 2 0 : 5 5 : 5 9 19.6.2005 20:55:59 1 EN ENGLISHAbout Bluetooth ® Technology ............................................................................................... 2 Introduction .................................................................................................................. ......... 3 Getting Started ............................................................................................................... ....... 6 Charging the Battery .......................................................................................................... ... 7 Pairing Smart Badge with Your Mobile Phone ....................................................................... 7Disconnecting Smart Badge from a Phone ........................................................................... 9Reconnecting the paired Smart Badge to a Phone ............................................................... 9Erasing paired phone information from a Smart Badge ......................................................... 9Powering Up ................................................................................................................... ..... 10 Making Calls .................................................................................................................. ...... 10 Answering and Ending a Call .............................................................................................. 10Rejecting a Call .............................................................................................................. ..... 11 Redialing the Last Dialed Number ....................................................................................... 11Muting an on-going Call ...................................................................................................... 1 1 Voice Dialing (Phone-dependent) ........................................................................................ 11Adjusting the earphone volume ........................................................................................... 11Switching the Call between Phone and Headset Mode ....................................................... 12Switching between on-going calls and waiting calls ............................................................ 12Three-way conference calls ................................................................................................ 12Warning ....................................................................................................................... ........ 13 Product Specifications ........................................................................................................ .14 BHS-608_UG_en.fm Page 1 Wednesday, August 10, 2005 4:27 PM 2 About Bluetooth ® Technology Bluetooth is a technology for wireless communication between devices.Bluetooth technology is based on a radio with a receiver and a transmitter that have been built into a tiny microchip. One of these microchips is incorporated in the Wireless Headset, while the other is integrated into the compatible mobile phone.Bluetooth offers the possibility of creating wireless connections between a headset and a mobile phone within a radius of up to 10 meters without a physical cable or line-of-sight connection.Iqua Bluetooth ® Smart Badge BHS-608 can be used with any brand of Bluetooth mobile phones that support Headset or Handsfree profiles. For the latest compatibility information, please visit us at www.iqua.com. The Bluetooth word mark and logos are owned by the Bluetooth SIG, Inc. and any use of such marks by IQUA is licensed. Other trademarks and trade names belong to their respective owners. BHS-608_UG_en.fm Page 2 Wednesday, August 10, 2005 4:27 PM 3 EN IntroductionThanks for purchasing a Iqua Bluetooth Smart Badge BHS-608. Your Smart Badge is a stylish product that enables comfortable hands-free communication with compatible mobile phones that supports Bluetooth wireless technology.The Smart Badge contains the following parts, as shown in Fig. 1. Figure 1 1 2 3 4 5 6 7 BHS-608_UG_en.fm Page 3 Wednesday, August 10, 2005 4:27 PM 4 (1) Power key Power on/off and mute button, switches the headset on and off or mutes the on-going call. (2) Indicator Light • Power on - green light flashes 5 times and beeps once • Pairing state - green and red lights flash in turns, the flashing continues for approximately 10 minutes or until the headset is connected to a compatible phone. If the Smart Badge cannot be connected to the phone during this time, the headset is switched off. • Connectable - green light flashes every 3 sec • Connection active - blue light flashes every 3 sec • Call end - beeps once • Power off - red light flashes 5 times and beeps once • Low battery - red light flashes every 3 sec • Charging - red light is continually lit (3) Volume up Increases the earpiece volume during a call. (4) Volume down Decreases the earpiece volume during a call. (5) Charger connector For charging the battery BHS-608_UG_en.fm Page 4 Wednesday, August 10, 2005 4:27 PM 5 EN (6) Send / End key • Answer incoming call • Switch between the headset and phone mode by pressing the button for a long time • Redial the last number dialed by pressing the button twice when no call is being made • Voice dial is activated by pressing the button for a long time (phone-dependent) when no call is being made • End active call • Reject incoming call by pressing the button twice (7) Earpiece Relays the caller's voice. BHS-608_UG_en.fm Page 5 Wednesday, August 10, 2005 4:27 PM 6 Getting StartedRemove all of the components from the package:1. Smart Badge 2. USB cable 3. Plastic window 4. Carrying Case 5. Travel Charger 6. User Guide Figure 2 1. 2. 3. 4. 5. BHS-608_UG_en.fm Page 6 Wednesday, August 10, 2005 4:27 PM 7 EN Charging the BatteryBefore using Smart Badge, you must…

Text truncated - open the document above for the full version.

Dongguan Primax Electronic Products Ltd. Industrial Zone Yuhong, Mingzhu west Rd. Shek Kit Town East zone, Dong Guan City, Guang Dong, China Tel:+86-769-6633120 FAX:+86-769-6316141 Date: 2005/10/08 Compliance Certification Services Certification Division 561F Monterey Road Morgan Hill, CA 95037 To whom it may concern: We, the undersigned, hereby authorize the Shenzhen office of Compliance Engineering Services, Inc., d.b.a. Compliance Certification Services and hereafter referred to as CCS SZ, to act on our behalf in all manners relating to application for equipment authorization, including signing of all documents relating to these matters. Any and all acts carried out by CCS SZ on our behalf shall have the same effect as acts of our own. In authorizing CCS SZ as our agent, we still recognize that we are responsible to: a) comply with the relevant provisions of the certification program; b) make all necessary arrangements for the conduct of the evaluation, including provision for examining documentation and access to all areas, records (including internal audit reports) and personnel for the purposes of evaluation (e.g. testing, inspection, assessment, surveillance, reassessment) and resolution of complaints; c) make claims regarding certification only in respect of the scope for which certification has been granted; d) do not use our product certification in such a manner as to bring the Certification Division into disrepute and not make any statement regarding our product certification which the Certification Division may consider misleading or unauthorized; e) upon suspension or cancellation of certification, discontinue use of all advertising matter that contains any reference thereto and return any certification documents as required by the Certification Division; f) use certification only to indicate the products are certified as being in conformity with specified standards; g) endeavor to ensure that no certificate or report nor any part thereof is used in a misleading manner; h) ensure that any reference to our product certification in communication media such as documents, brochures or advertising, complies with the requirements of the Certification Division; i) keep a record of all complaints made known to the us relating to the product’s compliance with requirements of the relevant standard and to make these records available to the Certification Division when requested; j) take appropriate action with respect to such complaints and any deficiencies found in products or services that affect compliance with the requirements for certification; k) document the actions taken. This authorization is valid until further written notice from the applicant. Sincerely Yours,

Dongguan Primax Electronic Products Ltd. Industrial Zone Yuhong, Mingzhu west Rd. Shek Kit Town East zone, Dong Guan City, Guang Dong, China Tel:+86-769-6633120 FAX:+86-769-6316141 Federal Communications Commission 7435 Oakland Mills Road Columbia MD 21046 Subject: Request for Confidentiality FCC ID: EMJPHB-2 To Whom It May Concern: Pursuant to the provisions of Sections 0.457 and 0.459 of the Commission’s rules (47 CFR §§ 0.457, 0.459), we are requesting the Commission to withhold the following attachments as confidential document from public disclosure indefinitely. Schematic Diagram Block Diagram Theory of Operation Above mentioned document contains detailed system and equipment description are considered as proprietary information in operation of the equipment. The public disclosure of above documents might be harmful to our company and would give competitor an unfair advantage in the market. Best Regards

Walsin Technology Corporation Page 1 of 9 ASC_RFANT5220110A0T_06 Jan. -2005 MULTILAYER CERAMIC ANTENNA RFANT Series 2.4 GHz ISM Band Working Frequency



*Contents in this sheet are subject to change without prior notice. Walsin Technology Corporation Page 2 of 9 ASC_RFANT5220110A0T_06 Jan. -2005 REVISION HISTORY Rev P/N Description Date V01 RFANT5220110A0T First Version 2004-07-13 V05 RFANT5220110A0T Increase the condition of Infrared soldering profile. 2004-11-25 V06 RFANT5220110A0T Delete Original Approval Sheet "P8~P14" of RFANT5220110A0T. Please refer to Application Note of RFANT5220110A0T for identical information. 2005-01-20 Walsin Technology Corporation Page 3 of 9 ASC_RFANT5220110A0T_06 Jan. -2005 L= 2.0 ±0.2 mm T= 1.15 ±0.10 mm W = 5.2 ± 0.2 mm B = 0.40 ± 0.25 mm A = 0.40 ± 0.25 mm
 L= 2.0 ±0.2 mm T= 1.15 ±0.10 mm W = 5.2 ± 0.2 mm B = 0.40 ± 0.25 mm A = 0.40 ± 0.25 mm
 FEATURES
 Surface Mounted Devices with a small dimension of 5.2 x 2.0 x 1.1 mm 3 meet future miniaturization trend.
Embedded and LTCC (Low Temperature Co-fired Ceramic) technology is able to future integrate with system design as well as beautifying the housing of final product.
High Stability in Temperature / Humidity Change APPLICATIONS
Bluetooth
Wireless LAN
 HormRF
ISM band 2.4GHz wireless applications DESCRIPTION Walsin Technology Corporation develops a new ceramic embedded antenna specified for 2.4 GHz ISM Band application, as shown in below “CONSTRUCTION”. Both of Wireless LAN IEEE 802.11b and Bluetooth TM typically located on this unlicensed frequency band which range covers from 2.4GHz to 2.4835GHz. To fulfil the friendly usage for antenna, this antenna has been designed to a typical 150MHz bandwidth through Walsin’s advanced LTCC (Low Temperature Co-fired Ceramic) technology and superior product design via 3D EM Simulation Skill. This antenna has a rectangular ceramic body with a tiny dimension of 5.2x 2.0 x 1.1 mm 3 meet the future SMT automation and miniaturization requirements on modern portable devices. CONSTRUCTION Fig 1. Outline of 2.4GHz Antenna – RFANT5220110A0T Fig 2. Dimension W T C W T C            W T C W T C            Walsin Technology Corporation Page 4 of 9 ASC_RFANT5220110A0T_06 Jan. -2005 SOLDER LAND PATTERN DESIGN Figure ELECTRICAL CHARACTERISTICS Item Specification Working Frequency Range 2.4 GHz Д 2.5GHz Gain 2 dBi (Typical) VSWR 2 max. Polarization Linear Azimuth Beamwidth Omni-directional Impedance 50 W Rated Power (max.) 3 Watts Maximum Input Power 5 Watts for 5 minutes Operation Temperature -40 ̓ C ~ +85 ̓ C Remark: The specification is defined based on the test board dimension as in below W

          W         W


          W         Walsin Technology Corporation Page 5 of 9 ASC_RFANT5220110A0T_06 Jan. -2005 Antenna on Test Board ( FR4 Thickness 0.8mm) Antenna S11 on Test Board                !" W WW W# $
 %!  !"! "
 #" $         !" W WW W# $
 %!  !"! "

 #" $ Walsin Technology Corporation Page 6 of 9 ASC_RFANT5220110A0T_06 Jan. -2005 RADIATION PATTERN Radiation Pattern and Gain were dependent on measurement board design. The specification of RFANT5220110A0T antenna was measured based on the PCB size and installation position as shown in the below figure Test Board Vertical Horizontal Y - Z Plane Average Gain= -3.22 dBi Peak Gain = 1.69 dBi Average Gain = -0.82 dBi Peak Gain= -5.42 dBi Average Gain=-8.98 dBi X - Z Plane Average Gain= -3.24 dBi Peak Gain= -5.97 dBi Average Gain= -8.61dBi Peak Gain= 2.66 dBi Average Gain= -0.91 dBi X - Y Plane Average Gain= -3.12 dBi Peak Gain= -5.97 dBi Average Gain= -9.24dBi Peak Gain= 2.59 dBi Average Gain= -0.68 dBi
 %!
 % & '
 %!

 % & ' % & ' Y Z WTC X Y Z WTC X Y Z WTC X Y Z WTC X Y Z WTC X Y Z WTC X z Y z Y z X z X X Y X Y Walsin Technology Corporation Page 7 of 9 ASC_RFANT5220110A0T_06 Jan. -2005  RELIABILITY TEST Mechanical performance Test item Test condition / Test method Specification Solderability Solder temp. : 235 ± 5∞C Immersion time: 2 ± 1 sec Solder: SN63 95% min. coverage of all metabolised area Resistance to soldering heat Solder: Sn63 Preheating temperature: 150 ± 10∞C Solder Temperature: 260 ± 5∞C Immersion time: 10 ± 1 sec Measurement to be made after keeping at room temp. for 24 ± 2 hrs. No mechanical damage. Ceramic surface shall not be exposed in the middle of the termination or on the terminated product edge by leaching. Drop test Height : 75 cm Direction : 3 directions Times : 3 times. No mechanical damage. Samples shall satisfy electrical specification after test.. Environmental characteristics Test item Test condition / Test method Specification Humidity Resistance Humidity:90% to 95% R.H. Tempertaure:40±2∞C Time: 500±24 hours. Measurement: After placing for 24 hours Minimum. No mechanical damage. Samples shall satisfy electrical specification after test. Temperature cycle 1. 30±3 minutes at -40∞C±3∞C, 2. 10~15 minutes at room temperature, 3. 30 ± 3 minutes at +85 ∞± 3 ∞ C, 4. 10~15 minutes at room temperature, Total 100 continuous cycles Measurement after placing for 48±2 hrs min. No mechanical damage. Samples shall satisfy electrical specification after test. High temperature Temperature: 85 ∞ C ± 2 ∞ C Test duration: 24 hours Measurement must be taken after subjection to the above conditions, followed by exposure in room environment for 1 to 2 hours. No mechanical damage. Samples shall satisfy electrical specification after test. Low temperature Temperature: -40 ∞ C ± 3 ∞ C Test duration: 24 hours Measurement must be taken after subjection to the above conditions, followed by exposure in room environment for 1 to 2 hours. No mechanical damage.…

Text truncated - open the document above for the full version.

Compliance Certification Services (Shenzhen) Inc. Report No: SZ051011B01-RP FCC ID: EMJPHB-2 Date of Issue: November 11, 2005 Note: This report shall not be reproduced except in full, without the written approval of Compliance Certification Services Inc. This document may be altered or revised by Compliance Certification Services Inc. personnel only, and shall be noted in the revision section of the document Page 1 of 48 FCC 47 CFR PART 15 SUBPART C TEST REPORT For BLUETOOTH HEADSET BADGE Model: PHB-2 Trade Name: Primax / Iqua Prepared for PRIMAX ELECTRONICS LTD. NO.669 RUEY KYANG ROAD NEIHU TAIPEI, TAIWAN, R.O.C Prepared by COMPLIANCE CERTIFICATION SERVICES (SHENZHEN) INC. NO. 6, JINAO INDUSTRIAL PARK, NO. 35 JUKENG ROAD, DASHUIKENG VILLAGE, GUANLAN TOWN, BAOAN DISTRICT, SHENZHEN, CHINA TEL: 86-755-28055000 FAX: 86-755-28055221 LAB CODE:200577-0 Compliance Certification Services (Shenzhen) Inc. Report No: SZ051011B01-RP FCC ID: EMJPHB-2 Date of Issue: November 11, 2005 Page 2 TABLE OF CONTENTS 1. TEST RESULT CERTIFICATION............................................................................................. 3 2. EUT DESCRIPTION .................................................................................................................... 4 3. TEST METHODOLOGY ............................................................................................................. 5 3.1 EUT CONFIGURATION.............................................................................................................. 5 3.2 EUT EXERCISE......................................................................................................................... 5 3.3 GENERAL TEST PROCEDURES.................................................................................................. 5 3.4 FCC PART 15.205 RESTRICTED BANDS OF OPERATIONS .............................................. 6 3.5 DESCRIPTION OF TEST MODES................................................................................................. 6 4. INSTRUMENT CALIBRATION................................................................................................. 7 5. FACILITIES AND ACCREDITATIONS ................................................................................... 8 5.1 FACILITIES.............................................................................................................................. 8 5.2 EQUIPMENT............................................................................................................................. 8 5.3 LABORATORY ACCREDITATIONS AND LISTING....................................................................... 8 6. SETUP OF EQUIPMENT UNDER TEST .................................................................................. 9 6.1 SETUP CONFIGURATION OF EUT.............................................................................................. 9 6.2 SUPPORT EQUIPMENT ..................................................................................................... 9 7. FCC PART 15.247 REQUIREMENTS...................................................................................... 10 7.1 PEAK POWER......................................................................................................................... 10 7.2 PEAK POWER SPECTRAL DENSITY......................................................................................... 11 7.3 BAND EDGES MEASUREMENT...................................................................................... 14 7.4 FREQUENCY SEPARATION ............................................................................................ 19 7.5 NUMBER OF HOPPING FREQUENCY ............................................................................ 21 7.6 SPURIOUS EMISSIONS ...................................................................................................... 23 7.7 POWERLINE CONDUCTED EMISSIONS.................................................................................... 43 APPENDIX 1 PHOTOGRPHS OF TEST SETUP.......................................................................... 45 Compliance Certification Services (Shenzhen) Inc. Report No: SZ051011B01-RP FCC ID: EMJPHB-2 Date of Issue: November 11, 2005 Page 3 1. TEST RESULT CERTIFICATION Applicant: PRIMAX ELECTRONICS LTD. NO.669 RUEY KYANG ROAD NEIHU TAIPEI, TAIWAN, R.O.C Equipment Under Test: BLUETOOTH HEADSET BADGE Tr a d e N a m e : Primax / Iqua Model: PHB-2 Date of Test: October 11-19, 2005 APPLICABLE STANDARDS STANDARD TEST RESULT FCC Part 15 Subpart C No non-compliance noted We hereby certify that: The above equipment was tested by Compliance Certification Services Inc. The test data, data evaluation, test procedures, and equipment configurations shown in this report were made in accordance with the procedures given in ANSI C63.4 and the energy emitted by the sample EUT tested as described in this report is in compliance with conducted and radiated emission limits of FCC Rules Part 15.207, 15.209 and 15.247. The test results of this report relate only to the tested sample EUT identified in this report. Approved by: Te s t e d B y : Terry.Yang/ Engineer Reviewed By: Clinton.Kao / EMC Manager Eric.Wong / Assistant manager COMPLIANCE CERTIFICATION COMPLIANCE CERTIFICATION SERVICES (SHENZHEN) INC. SERVICES (SHENZHEN) INC.. Compliance Certification Services (Shenzhen) Inc. Report No: SZ051011B01-RP FCC ID: EMJPHB-2 Date of Issue: November 11, 2005 Page 4 2. EUT DESCRIPTION Product BLUETOOTH HEADSET BADGE Trade Name Primax / Iqua Model Number PHB-2 Model Discrepancy N/A Power Supply DC6V supplied by the adapter Frequency Range 2402 ~ 2480 MHz Transmit Power -7.66 dBm Modulation Technique FHSS Number of Channels 79 Channels Antenna Specification Multilayer Ceramic Antenna Gain: 2 dBi (max) Temperature Range 0 ~ +55°C Note: This submittal(s) (test report) is intended for FCC ID: EMJPHB-2 filing to comply with Section 15.207, 15.209 and 15.247 of the…

Text truncated - open the document above for the full version.

Compliance Certification Services (Shenzhen) Inc. Report No: SZ051011B01-RP FCC ID: EMJPHB-2 Date of Issue: October 19, 2005 Page 45 APPENDIX 1 PHOTOGRPHS OF TEST SETUP Radiated Emission Set up Photos Compliance Certification Services Inc. Report No: SZ051011B01-RP FCC ID: EMJPHB-2 Date of Issue: October 19, 2005 Page 46 Conducted Emission Set Up Photos
