EMJTRFEX7Bluetooth Headset

1 Rocketsh RF-EX7 Bluetooth headset 1 charger 1 USB charging cable 1 Quick Setup Guide (what you’re looking at) 4 round earbuds 3 tted earbuds (medium size is pre-attached) 1 ear loop 1 Lift the charging port cover, then connect the charger. When, the indicator changes from red to green, and you can disconnect the charger.(See no.11 and no. 36) Use one of the tted earbuds for the most convenient and comfortable t, or alternatively use a round earbud in combination with the ear loop. To use a rounded earbud: 1 Remove the tted earbud that's already attached, then press the round earbud onto the headset. 2 Attach the ear loop for a secure t. 3 Activate Bluetooth on your phone, then set your phone to search for nearby Bluetooth devices. For help with this step, see your cell phone’s user guide. 4 When your phone detects the RF-EX7, select it on the list, then enter “0000” (zeros) for the PIN. The headset beeps and the indicator turns green. To turn o the headset, press and hold the power button for about two seconds. 2 Press and hold the power button for 3 seconds to turn on your headset. It will automatically enter pairing mode when you turn it on for the rst time. When in pairing mode, the LED light will blink Green.(on conrmation) 1 Power & Pair 2 Get the perfect t What’s in the box: LED light Ear bud Charging port with cover On/O (reverse side) Volume touch pad Send/end button Bottom view To use a tted earbud: 1 Attach the appropriate size of tted earbud onto the headset. The medium tted earbud is already attached. 2 Insert the headset vertically in your ear (shown in step 2) 3 Rotate the headset up towards your mouth. The exible portion of the ear bud should t securely towards the back of your outer ear. You may need to guide it to a comfortable position with your nger. Ear loop Round earbuds Fitted earbuds Charger Headset LED light What is PureSpeech®? PureSpeech is a state-of-the-art noise cancelation and signal processing technology created by SRS Labs and CSR. Your EX7 headset incorporates PureSpeech so that you can hear your calls in amazing clarity, but also so you can be heard clearly by your callers. PureSpeech is always activated on the EX7 so you will "Hear and Be Heard Like Never Before." 3 To Call To dial a number, make sure that your headset is turned on, then dial the number from your phone. Your headset will activate as soon as the number is dialed. To voice dial a number (not supported on all phones), press send/end. A tone plays, which is your signal to speak the command or number. Know the facts Recharge time: About two hours Talk time: Up to eight hours Standby time: Up to 300 hours Phone pairing: Up to eight phones at the same time LEDs To... Do this... End a call Press send/end. Answer a call Press send/end. Redial a number Double-press send/end. Reject a call Double-press send/end. Switch a call between the headset and the phone. Mute a call Double-press send/end. 10-0723 4 Maintaining Press and hold the power button and send/end for about two seconds. To... Do this... Increase the volume Decrease the volume Swipe upward (toward the ear) on the touch pad.You will hear a dierent "beep" for each level change in volume. Swipe downward (away from the ear) on the outside of the headset. To... Enable or disable the indicator Check the battery level (method 1) Check the battery level (method 2) Erase paired device information Multipoint pairing (pairing the headset to multiple phones) Reset Disconnect from the phone (un-pair) Do this... Press the power button and send/end together. Turn the headset on, then press and release the power button. Green = Between 1/2 and full charge Green then red = Between 1 hour talk time remaining and 1/2 charge Red = Less than 1 hour talk time remaining. Turn the headset on. If the indicator ashes red and green, or if it beeps every 300 seconds, the battery level is low. Turn the headset o, then press and hold the power button and send/end together for about two seconds. Pair each phone with the headset. When you are in a call with one phone but the other phone rings, press send/end to switch to the second call. Connect the charger to reset the headset, then user can power on headset after remove the charger. Turn the headset o, then use the phone’s Bluetooth menu to disconnect it. For help with this step, see your cell phone’s user guide. Green Power On Green (fast ashing) Pairing State Red (ashing) Low Battery RF-EX7 EX7 WITH PURE SPEECH® Hear and be heard like never before © 2010 Best Buy Enterprise Services, Inc. Distributed by Best Buy Purchasing, LLC • 7601 Penn Avenue South, Richfield, MN USA 55423-3645 RFEX7 QUICK SETUP GUIDE FCC Part 15 This device complies with Part 15 of the FCC Rules. Operation is subject to the following two conditions: (1) this device may not cause harmful interference, and (2) this device must accept any interference received, including interference that may cause undesired operation. FCC ID: EMJTRFEX7 “You are cautioned that changes or modications not expressly approved by the part responsible for compliance could void the user’s authority to operate the equipment”. Canada IC-RSS210 statement IC: 4251A-HRFEX7 Operation is subject to the following two conditions: (1) this device may not cause interference, and (2) this device must accept any interference, including interference that may cause undesired operation of the device.

PRl MAX 叫l叫 恥。e叫Communicalions Commi s$ion 7435 Oakland Mi !ls Road Columbi~岫叫 Re: FCC 10: E恥1JTRFEX1 To Whom it May Conccm I'rimax E叫ronics Lld.. cenifies山ut neitlw:r Il>e apç州晦lJ11 nor any pa吋loll>is applic3lion, llS definoo in 47 CFR Ch. 1.2咽2(b). is到何制10 a dcnia llo Fedcral benefil5, 的al includc FCC bcnc fils, p咽U30110 seclion 530自 oflhc Anti.Orug Al>u sc Acl of 1998 21 U.S.C . 835(a). S~:iiJ~ H剖咽訂閱而F布 l'rima.~ F.le...Lld.­ “9 RII"y Kb失11g Roa凶 Ncihu 114. Tft啊，T...

Page 1 of 2 Type Designation: RF-EX7 External Photo Report Number: 17017065 001 Page 2 of 2 Type Designation: RF-EX7 External Photo Report Number: 17017065 001

RF-EX7 Sunger Lee TYPE LABEL 0.3 東聚電子電訊制品有限公司 NOTE: 1. SN FORMAT: YMDDASSSSSS YY is a code for manufacturing year (10=2010) M is a code for manufacturing mouth (Jan=A, Feb=B, May=C,......Del=L) DD is a code for manufacturing day of the mouth (01,02,03,......31) A is code for factory(Dongguan=A) SSSSSS (6 digits) is a serial number ( 000001~999999) MODEL NO.: RF-EX7 FCC ID: EMJTRFEX7 IC: 4251A-HRFEX7 S/N: YYMDDASSSSSS 1：11：1 MADE IN CHINA 5 0 . 5 1 m m 18.14 mm MADE IN CHINA 1 0 . 5 m m 15.5 mm 2. Product must be Halogen Free Requirement of PRIMAX Green Part: 1. Comply with PRIMAX QW-5Q002“Green Product Chemical Substances Specification“. 2. Follow customer's specification as required. 3. Follow Halogen- Free requirement : Br<900 ppm, Cl<900 ppm, Br+Cl< 1500 ppm if required MODEL NO.: RF-EX7 FCC ID: EMJTRFEX7 IC: 4251A-HRFEX7 S/N: YYMDDASSSSSS Hongmin Hu 2010/07/13 Quanyu Chang RF-EX7-T Sunger Lee TYPE LABEL 0.1 東聚電子電訊制品有限公司 NOTE: 1. SN FORMAT: YMDDASSSSSS YY is a code for manufacturing year (10=2010) M is a code for manufacturing mouth (Jan=A, Feb=B, May=C,......Del=L) DD is a code for manufacturing day of the mouth (01,02,03,......31) A is code for factory(Dongguan=A) SSSSSS (6 digits) is a serial number ( 000001~999999) MODEL NO.: RF-EX7-T FCC ID: EMJTRFEX7 IC: 4251A-HRFEX7 S/N: YYMDDASSSSSS 1：11：1 MADE IN CHINA 5 0 . 5 1 m m 18.14 mm MADE IN CHINA 1 0 . 5 m m 15.5 mm 2. Product must be Halogen Free Requirement of PRIMAX Green Part: 1. Comply with PRIMAX QW-5Q002“Green Product Chemical Substances Specification“. 2. Follow customer's specification as required. 3. Follow Halogen- Free requirement : Br<900 ppm, Cl<900 ppm, Br+Cl< 1500 ppm if required MODEL NO.: RF-EX7-T FCC ID: EMJTRFEX7 IC: 4251A-HRFEX7 S/N: YYMDDASSSSSS Hongmin Hu 2010/08/24 Quanyu Chang RF-GPS31126 TYPE LABEL 0.1 東聚電子電訊制品有限公司 Quanyu Chang 2010/07/22 MODEL NO.: RF-GPS31126 FCC ID: EMJTRFEX7 IC: 4251A-HRFEX7 S/N: YYMDDASSSSSS 1：11：1 MADE IN CHINA 5 0 . 5 1 m m 18.14 mm 1 0 . 5 m m 15.5 mm 2. Product must be Halogen Free Requirement of PRIMAX Green Part: 1. Comply with PRIMAX QW-5Q002“Green Product Chemical Substances Specification“. 2. Follow customer's specification as required. 3. Follow Halogen- Free requirement : Br<900 ppm, Cl<900 ppm, Br+Cl< 1500 ppm if required MODEL NO.: RF-GPS31126 FCC ID: EMJTRFEX7 IC: 4251A-HRFEX7 S/N: YYMDDASSSSSS MADE IN CHINA Hongmin Hu Sunger Lee NOTE: 1. SN FORMAT: YYMDDASSSSSS YY is a code for manufacturing year (10=2010) M is a code for manufacturing mouth( Jan=A, Feb=B, May=C,......Del=L) DD is a code for manufacturing day of the mouth (01,02,03,......31) A is a code for factory (Dongguan=A) SSSSSS(6 digits) is a serial number (000001~999999)

Page 1 of 5 Type Designation: RF-EX7 Internal Photo Report Number: 17017065 001 Page 2 of 5 Type Designation: RF-EX7 Internal Photo Report Number: 17017065 001 Page 3 of 5 Type Designation: RF-EX7 Internal Photo Report Number: 17017065 001 Page 4 of 5 Type Designation: RF-EX7 Internal Photo Report Number: 17017065 001 Page 5 of 5 Type Designation: RF-EX7 Internal Photo Report Number: 17017065 001

Produkte Products Prüfbericht - Nr.: Test Report No. 17017065 001 Seite 2 von 44 P age 2 of 44 TEST SUMMARY 5.1.1 ANTENNA REQUIREMENT RESULT: Passed 5.1.2 PEAK OUTPUT POWER RESULT: Passed 5.1.3 20DB BANDWIDTH RESULT: Passed 5.1.4 CONDUCTED SPURIOUS EMISSIONS MEASURED IN 100KHZ BANDWIDTH RESULT: Passed 5.1.5 SPURIOUS EMISSIONS RESULT: Passed 5.1.6 FREQUENCY SEPARATION RESULT: Passed 5.1.7 NUMBER OF HOPPING FREQUENCY RESULT: Passed 5.1.8 TIME OF OCCUPANCY RESULT: Passed 5.1.9 RADIATED EMISSIONS RESULT: Passed 5.1.10 CONDUCTED EMISSIONS RESULT: Passed Produkte Products Prüfbericht - Nr.: Test Report No. 17017065 001 Seite 3 von 44 P age 3 of 44 Contents 1. GENERAL REMARKS.........................................................................................................4 1.1 COMPLEMENTARY MATERIALS...........................................................................................4 2. TEST SITES.......................................................................................................................4 2.1 TEST FACILITIES...............................................................................................................4 2.2 LIST OF TEST AND MEASUREMENT INSTRUMENTS...............................................................5 2.3 TRACEABILITY..................................................................................................................6 2.4 CALIBRATION....................................................................................................................6 2.5 MEASUREMENT UNCERTAINTY...........................................................................................6 2.6 LOCATION OF ORIGINAL DATA...........................................................................................6 2.7 STATUS OF FACILITY USED FOR TESTING...........................................................................6 3. GENERAL PRODUCT INFORMATION....................................................................................7 3.1 PRODUCT FUNCTION AND INTENDED USE...........................................................................7 3.2 RATINGS AND SYSTEM DETAILS.........................................................................................7 3.3 INDEPENDENT OPERATION MODES.....................................................................................8 3.4 NOISE GENERATING AND NOISE SUPPRESSING PARTS........................................................9 3.5 SUBMITTED DOCUMENTS...................................................................................................9 4. TEST SET-UP AND OPERATION MODES...............................................................................9 4.1 PRINCIPLE OF CONFIGURATION SELECTION........................................................................9 4.2 TEST OPERATION AND TEST SOFTWARE............................................................................9 4.3 SPECIAL ACCESSORIES AND AUXILIARY EQUIPMENT........................................................10 4.4 COUNTERMEASURES TO ACHIEVE EMC COMPLIANCE.......................................................10 4.5 TEST SETUP DIAGRAM....................................................................................................10 5. TEST RESULTS...............................................................................................................12 5.1 TRANSMITTER REQUIREMENT & TEST SUITES...................................................................12 5.1.1 Antenna Requirement................................................................................................................ 12 5.1.2 Peak Output Power ................................................................................................................... 13 5.1.3 20dB Bandwidth ........................................................................................................................ 17 5.1.4 Conducted Spurious Emissions measured in 100kHz Bandwidth ............................................ 24 5.1.5 Spurious Emissions ................................................................................................................... 27 5.1.6 Frequency Separation ............................................................................................................... 28 5.1.7 Number of hopping frequency ................................................................................................... 31 5.1.8 Time of Occupancy.................................................................................................................... 33 5.1.9 Radiated Emissions ................................................................................................................... 39 5.1.10 Conducted Emissions ........................................................................................................... 40 6. PHOTOGRAPHS OF THE TEST SET-UP..............................................................................41 7. LIST OF TABLES..............................................................................................................44 8. LIST OF PHOTOGRAPHS...................................................................................................44 Produkte Products Prüfbericht - Nr.: Test Report No. 17017065 001 Seite 4 von 44 P age 4 of 44 1. General Remarks 1.1 Complementary Materials All attachments are integral parts of this test report. This applies especially to the following appendix: Appendix 1: Test Result 2. Test Sites 2.1 Test Facilities TÜV Rheinland (Guangdong) Ltd. EMC Laboratory ( FCC Registration No.: 833845 & Test Site Industry Canada No.: 2932C11) Guangzhou Auto Market, Yuan Gang Section of Guangshan Road, Guangzhou, P.R. China Produkte Products Prüfbericht - Nr.: Test Report No. 17017065 001 Seite 5 von 44 P age 5 of 44 2.2 List of Test and Measurement Instruments Table 1: List of Test and Measurement Equipment Kind of Equipment Manufacture…
