EOA-WPSurfLink Programmer

InstallatIon InstructIons programmer 1 TABLE OF CONTENTS Description.......................................................................................2 Installation........................................................................................2 Operation.........................................................................................3 Safety.Precautions...........................................................................4 Regulatory.&.Service.Information..................................................5 Important.Safety.and.Usage.Information......................................6 23 This.document.contains.instructions.for.connecting.SurfLink. Programmer.into.your.laptop.or.desktop.PC.via.a.USB.connection.. SurfLink.Programmer.requires.that.Inspire ® .2011.fitting.software.or. higher.is.installed.. DESCRIPTION SurfLink.Programmer.is.a.USB.hearing.aid.programmer.functioning. as.the.interface.between.wireless.hearing.aids.and.computer.fitting. software..It.consists.of.a.USB.cable.and.SurfLink.Programmer. Physical and Performance Characteristics:. •.Indicator.lights.for.power.and.data.transfer.activity •..SurfLink.Programmer.to.PC.connection.on.USB.is.capable.of.up. to.480.Mbps.(USB.2.0.high.speed) INSTALLATION Screen.may.vary.depending.on.the.Windows.version. 1..Confirm.that.Inspire.2011.or.higher.is.installed..(SurfLink. Programmer.is.not.supported.on.earlier.versions.of.Inspire. fitting.software.). 2..Plug.the.square.end.of.the.USB.cable.into.the.back.of.SurfLink. Programmer.making.sure.it.is.inserted.fully. 3..Insert.the.rectangular.end.of.the.USB.cable.into.an.open.USB. port.on.your.PC. 4..Follow.the.on-screen.prompts.in.the.“Add.New.Hardware. Wizard”.screens..SurfLink.Programmer.is.designed.to.be. “plug.and.play”.and.does.not.require.a.CD.or.a.restart.of.. the.PC. 5...Locate.SurfLink.Programmer.at.least.5.feet/1.5.meters.from. the.patient. OPERATION Once.installed,.SurfLink.Programmer.is.ready.to.use.. . To.use: 1..Verify.SurfLink.Programmer.is.connected.to.the.PC 2..Launch.Inspire.2011 3..Search.for.SurfLink.Programmer,.if.needed 45 SAFETy PRECAuTIONS Please.read.the.following.safety.precautions.before.using.SurfLink. Programmer.for.the.first.time. Markings and Symbols The.following.markings.and.symbols.are.used.in.these.safety. precautions.and/or.on.the.device.label. Within.Europe,.dispose.of.SurfLink.Programmer.according. to.local.EU.WEEE.regulations. Class.II.equipment Power.from.USB.port Data.transfer.indicator regulatory and servIce InformatIon classification •.Classification.to.the.Medical.Device.Directive:.Class.I. •..Classification.to.EN.60950-1.Class.II.Continuous.Operation. •..Any.associated.computer.used.with.SurfLink.Programmer.must. be.an.EN.60950.(ISO.950).approved.computer. Power supply •..Operating.Voltage:.5.0.vDC.supplied.from.the.USB.port.of.an. EN.60950.(ISO.950).approved.computer. 67 ImPortant safety and usage InformatIon storage and shipping conditions: •.Temperature:.-20.to.70°.C,.-4.to.158°.F •.Humidity:.30.–.90% •.No.condensation operating conditions: •.Temperature:.15.-.35°.C,.59.-.95°.F •.Humidity:.30.–.90% •.No.condensation avoid using surflink Programmer in areas subject to the following conditions: •.Extreme.heat.or.cold •.Static.electricity •.Large.amounts.of.dust •.Rough.handling Rough.handling.or.dropping.SurfLink.Programmer.can. cause.damage..If.you.think.you.may.have.damaged.SurfLink. Programmer,.or.if.SurfLink.Programmer.is.suffering.an.obvious. malfunction,.immediately.unplug.it.from.your.computer.and. contact.your.authorized.dealer.to.request.servicing. DO NOT.continue.to.use.a.damaged.SurfLink.Programmer. . DO NOT.place.heavy.objects.on.top.of.SurfLink.Programmer. Never.insert.foreign.objects.into.the.connections. Avoid.spilling.liquid.on.SurfLink.Programmer. The.exterior.of.SurfLink.Programmer.may.be.wiped.with.a.damp. cloth.or.sterile.hand.wipe..Never.use.paint.thinner,.benzene,. cosmetics,.or.other.volatile.agents.to.clean.the.exterior.of.SurfLink. Programmer. Never.try.to.take.apart.or.modify.SurfLink.Programmer..Doing.so. creates.the.danger.of.fire.and.electrical.shock,.as.well.as.SurfLink. Programmer.malfunction..There.are.no.user-serviceable.parts. inside.SurfLink.Programmer..All.services.must.be.performed.by.the. authorized.dealer. Please.be.aware.that.portable.and.mobile.RF.communications. equipment.can.affect.medical.electrical.equipment. Caution:.SurfLink.Programmer.should.not.be.used.adjacent.to. or.stacked.with.other.equipment..If.stacked.or.adjacent.use.is. necessary,.check.to.make.sure.SurfLink.Programmer.is.operating. normally. 8 REguLATORy NOTICES FCC.ID:.EOA-WP IC:.6903A-WP FCC NOTICE This.device.complies.with.part.15.of.the.FCC.rules.and.with.. RSS-210..Operation.is.subject.to.the.following.two.conditions:.. (1).This.device.may.not.cause.harmful.interference,.and.. (2).this.device.must.accept.any.interference.received,.. including.interference.that.may.cause.undesired.operation.. of.the.device.. Note:.The.manufacturer.is.not.responsible.for.any.radio.or. TV.interference.caused.by.unauthorized.modifications.to.this. equipment..Such.modifications.could.void.the.user’s.authority.. to.operate.the.equipment. Hereby,.Paradigm.declares.that.SurfLink.Programmer.is.in. compliance.with.the.essential.requirements.and.other.relevant. provisions.of.Directive.1999/5/EC..A.copy.of.the.Declaration.of. Conformity.can.be.obtained.from.the.below.addresses.. This.Class.B.digital.apparatus.complies.with.Canadian.ICES-003. Note:.This.equipment.has.been.tested.and.found.to.comply. with.the.limits.for.a.Class.B.digital.device,.pursuant.to.part. 15.of.the.FCC.Rules..These.limits.are.designed.to.provide. reasonable.protection.against.harmful.interference.in.a. residential.installation..This.equipment.generates,.uses.and.can. radiate.radio.frequency.energy.and,.if.not.installed.and.used.in. accordance.with.the.instructions,.may.cause.harmful.interference. to.radio.communications..However,.there.is.no.guarantee. that.interfere…

Text truncated - open the document above for the full version.

SHARC external side view SHARC front side view

SHARC bottom view showing label location Label location Eden Prairie, MN, USA SurfLink Programmer Paradigm 0673 N 13634 FCC ID: EOA-WP IC: 6903A-WP 5 vDC 200 mA

SHARC topside PCB shown mounted in chassis Horizontal antenna Vertical antenna SHARC topside PCB with shields removed SHARC topside PCB

TEST REPORT Report Number: 100105325MIN-001 Project Number: G100105325 Testing performed on the Sharc FCC ID: EOA-WP Industry Canada ID: 6903A-WP to 47 CFR Part 15. 249:2009 RSS- 210, Issue 7, 2007 For Starkey Laboratories, Inc. Test Performed by: Test Authorized by: Intertek Testing Services NA, Inc. 7250 Hudson Blvd., Suite 100 Oakdale, MN 55128 Starkey Laboratories, Inc. 6700 Washington Avenue South Eden Prairie, MN 55344 Prepared by: Date: May 17, 2010 Richard Blonigen Reviewed by: Date: May 17, 2010 Uri Spector This report is for the exclusive use of Intertek's Client and is provided pursuant to the agreement between Intertek and its Client. Intertek's responsibility and liability are limited to the terms and conditions of the agreement. Intertek assumes no liability to any party, other than to the Client in accordance with the agreement, for any loss, expense or damage occasioned by the use of this report. Only the Client is authorized to copy or distribute this report and then only in its entirety. Any use of the Intertek name or one of its marks for the sale or advertisement of the tested material, product or service must first be approved in writing by Intertek. The observations and test results in this report are relevant only to the sample tested. This report by itself does not imply that the material, product, or service is or has ever been under an Intertek certification program. This report must not be used to claim product endorsement by A2LA, NIST nor any other agency of the U.S. Government. EMC Report No: 100105325MIN-001 FCC ID: EOA-WP IC ID: 6903A-WP Page 2 of 32 TABLE OF CONTENTS 1.0 GENERAL DESCRIPTION................................ ................................................................ ................................................................ ................................................................ .............................................. ............................ .............. 3 33 3 1.1 Product Description; Test Facility ....................................................................................... 4 1.3 Environmental conditions.................................................................................................... 5 1.4 Measurement uncertainty ................................................................................................... 6 1.5 Field Strength Calculation................................................................................................... 6 2.0 TEST SUMMARY................................ ................................................................ ................................................................ ................................................................ .......................................................... .................................................... .......................... 7 77 7 3.0 TEST CONDITIONS AND RESULTS................................ ................................................................ ................................................................ ................................................................ ................................. .. . 8 88 8 3.1 Field strength of fundamental ............................................................................................. 8 3.2 Field strength of harmonics and spurious emissions ....................................................... 10 3.3 Bandwidth of Emissions.................................................................................................... 15 3.4 Transmitter power line conducted emissions ................................................................... 22 3.5 Receiver/digital device radiated emissions....................................................................... 25 3.6 Digital device conducted emissions.................................................................................. 29 4.0 TEST EQUIPMENT................................ ................................................................ ................................................................ ................................................................ ....................................................... .............................................. .......................32 3232 32 EMC Report No: 100105325MIN-001 FCC ID: EOA-WP IC ID: 6903A-WP Page 3 of 32 1.0 GENERAL DESCRIPTION Model: Sharc Type of EUT: Hearing Aid Programmer Serial Number: N/A FCC ID: EOA-WP Industry Canada ID: 6903A-WP Related Submittal(s) Grants: None Company: Starkey Laboratories Inc. Customer: Mr. Ken Meyer Address: 6700 Washington Avenue South Eden Prairie, MN 55344 Phone: (952) 947-4734 Fax: (952) 828-9262 Email: [email protected] Test Standards: 47 CFR, Part 15:2009, §15.249 RSS–210, Issue 7, 2007 RSS-Gen, Issue 2, 2007 47 CFR, Part 15:2008, §15.107 and §15.109, Class B Other Type of radio: Stand -alone Module Hybrid Date Sample Submitted: May 10, 2010 Test Work Started: May 10, 2010 Test Work Completed: May 12, 2010 Test Sample Conditions: Damaged Poor (Usable) Good EMC Report No: 100105325MIN-001 FCC ID: EOA-WP IC ID: 6903A-WP Page 4 of 32 1.1 Product Description; Test Facility Product Description: Hearing Aid Programmer Operating Frequency 902-928 MHz Number of Channels 11 Channels Modulation: FSK Emission Designator: 323KFXD Antenna(s) Info: Integral Antenna Installation: User Professional Factory Transmitter Power Configuration: Internal battery External DC power from Host Computer 120VAC 230VAC 400VAC VDC Other: Amp. 50Hz 60Hz Special Test Arrangement: Test Facility Accreditation: A2LA (Certificate No. 1427.01) Test Methodology: Measurements performed according to the procedures in ANSI C63.4- 2003 EMC Report No: 100105325MIN-001 FCC ID: EOA-WP IC ID: 6903A-WP Page 5 of 32 1.2 EUT Configuration The equipment under test was operated during the measurement under the following conditions: - Standby - Continuous - Continuous un-modulated - Test program (…

Text truncated - open the document above for the full version.

Test Setup Photos
