EPKEONCLAPTWireless Fireplace Remote Control

From: David Chernomordik ES-Mpk Sent: Monday, August 02, 2004 2:10 PM To: Nicholas Abbondante ES-Box Cc: Danielle Fontaine ES-Box Subject: Certification, EPKEONCLAPT Hello Nicholas, I am reviewing the Application and have following comments: 1) The FCC ID must be written on the label. FCC ID:XXXXX is not acceptable. 2) Please also identify the report and photographs with the FCC ID 3) The limit of the field strength at fundamental frequency (report, page 7) is incorrect. It should be 77.5 dB(uV/m). The measured peak level is above the limit. You may use the average value, in this case you must justify the Duty Cycle in the report. The limit at 1050 MHz and 1400 MHz is also incorrect. These frequencies are in restricted bands, so the limit must be 54 dB(uV/m). The limit of 57.5 dB(uV/m) may be used for 700 MHz, as this frequency is not in the restricted band. 4) According to the User Manual, it looks like the device may operate (transmit) with the charger connected. If yes, the AC line conducted emissions should be tested. Please clarify. Thanks David

FCC ID: EPKEONCLAPT

FCC ID: EPKEONCLAPT

70 Codman Hill Road Boxborough MA 01719 Acumen Inc., Model No. EON/CLAPT-01Date of Test: October 2, 2003, September 2, 2004 Report # 3045840.012FCC Parts 15 B & C Certification Table of Contents 1.0Summary of Tests..................................................................................................................................................3 2.0General Description..............................................................................................................................................3 2.1Product Description................................................................................................................................3 2.2Related Submittal(s) Grants....................................................................................................................3 2.3Test Facility..............................................................................................................................................4 2.4Test Equipment and Support Equipment.............................................................................................5 3.0Bandwidth................................................................................................................................................................6 3.1Test Procedure.........................................................................................................................................6 3.2Test Results..............................................................................................................................................6 4.0 Radiated Field Strength...........................................................................................................................................6 4.1Test Procedure.........................................................................................................................................7 4.2Test Results..............................................................................................................................................8 4.3Sample Calculation..................................................................................................................................9 4.4Configuration Photographs – Radiated Emissions..........................................................................10 5.0 Line-Conducted Emissions..................................................................................................................................11 5.1Test Procedure.......................................................................................................................................11 5.2Test Results............................................................................................................................................11 5.3Sample Calculation................................................................................................................................12 5.4Configuration Photographs – Line-Conducted Emissions.............................................................13 70 Codman Hill Road Boxborough MA 01719 Acumen Inc., Model No. EON/CLAPT-01Date of Test: October 2, 2003, September 2, 2004 Report # 3045840.013FCC Parts 15 B & C Certification 1.0Summary of Tests Wireless Fireplace Remote Control Serial No.: Testing Model July 29, 2003 Model No.: EON/CLAPT-01 FCC RULEDESCRIPTION OF TESTRESULTSREPORT PAGE FCC § 15.231(c)BandwidthPassed6 FCC §2.1053, §15.109, §15.205, §15.209, §15.231(b) Radiated Field StrengthPassed7 FCC § 15.107, § 15.207Line-Conducted EmissionsPassed11 2.0General Description 2.1Product Description The EUT is a hand-held remote control used to control a fireplace. It uses a periodic transmitter to transmit command codes to turn the fireplace on or off, or to change flame height, etc. The transmitter fundamental frequency is 350 MHz. EUT activated for all testing from new batteries. The EUT has been tested at the request of Company:Acumen Inc. 101A Executive Drive Suite 200 Sterling, VA, 20166 Name of contact:George Carrigan Telephone:(703) 904-0405 Fax:(703) 904-0218 2.2Related Submittal(s) Grants None. 70 Codman Hill Road Boxborough MA 01719 Acumen Inc., Model No. EON/CLAPT-01Date of Test: October 2, 2003, September 2, 2004 Report # 3045840.014FCC Parts 15 B & C Certification 2.3Test Facility Site 2C (Middle Site) is a 3m and 10m sheltered EMI measurement range located in a light commercial environment in Boxborough, Massachusetts. It meets the technical requirements of ANSI C63.4-1992 and CISPR 22:1993/EN 55022:1994 for radiated and conducted emission measurements. The shelter structure is entirely fiberglass and plastic, with outside dimensions of 33 ft x 57 ft. The structure resembles a quonset hut with a center ceiling height of 16.5 ft. The testing floor is covered by a galvanized sheet metal groundplane that is earth-grounded via copper rods around the perimeter of the site. The joints between individual metal sheets are bridged with 2 inch wide metal strips to provide low RF impedance contact throughout. The sheets of metal are screwed in place with stainless steel round-head screws every three inches. Site illumination and HVAC are provided from beneath the ground reference plane through flush entry ports, the port covers are electrically bonded to the ground plane. A flush metal turntable with 12 ft. diameter and 5000 lb. load capacity is provided for floor-standing equipment. A wooden table 80 cm high is used for table-top equipment. The turntable is electrically connected to the ground plane with three copper straps. The straps are connected to the turntable at the center of it with ground braid. A copper strap is directly connected to the groundplane at the edges of the turntable. The turntable is located on the south end of the structure and the antennas are mounted 3 and 10 meters away to the north. The antenna mast is a non-conductive with remote control of antenn…

Text truncated - open the document above for the full version.

FCC ID: EPKEONCLAPT Radiated Spurious Test Setup, Front View Radiated Spurious Test Setup, Back View
