EROCWD1013Wireless Network Thermostat

Crestron CHV-TSTATRF infiNET™ Thermostat Operations & Installation Guide This document was prepared and written by the Technical Documentation department at: Crestron Electronics, Inc. 15 Volvo Drive Rockleigh, NJ 07647 1-888-CRESTRON All brand names, product names and trademarks are the property of their respective owners. ©2006 Crestron Electronics, Inc. Crestron CHV-TSTATRF infiNET™ Thermostat Contents InfiNET™ Thermostat: CHV-TSTATRF 1 Introduction...............................................................................................................................1 Features and Functions................................................................................................1 Specifications..............................................................................................................3 Physical Description....................................................................................................4 Industry Compliance...................................................................................................7 Setup..........................................................................................................................................8 Identity Code...............................................................................................................8 Installation...................................................................................................................8 Hardware Hookup.....................................................................................................10 Setup Procedure.........................................................................................................10 Programming Software............................................................................................................13 Earliest Version Software Requirements for the PC.................................................13 Programming with Crestron D3 Pro or SystemBuilder.............................................13 Programming with SIMPL Windows........................................................................13 Example Program......................................................................................................15 Uploading and Upgrading........................................................................................................16 Establishing Communication.....................................................................................16 Programs and Firmware............................................................................................16 Operation.................................................................................................................................18 Setup Mode................................................................................................................18 System Modes...........................................................................................................20 Hold Mode.................................................................................................................21 Setpoints....................................................................................................................21 LDC Display Operation.............................................................................................22 Problem Solving......................................................................................................................24 Troubleshooting.........................................................................................................24 Bootloader.................................................................................................................25 Reference Documents................................................................................................25 Further Inquiries........................................................................................................26 Future Updates..........................................................................................................26 Software License Agreement...................................................................................................27 Return and Warranty Policies..................................................................................................29 Merchandise Returns / Repair Service......................................................................29 CRESTRON Limited Warranty.................................................................................29 Operations & Installation Guide – DOC. 6490 Contents • i Crestron CHV-TSTATRF infiNET™ Thermostat InfiNET™ Thermostat: CHV-TSTATRF Introduction Features and Functions • Wall mount heat/cool thermostat • For baseboard, forced air and heat pump HVAC systems • Crestron system integration via infiNET™ wireless network ⇒ ⇒ ⇒ ⇒ 2.4 GHz infiNET mesh network technology Range up to 150 feet indoors or 250 feet outdoors (subject to site- specific conditions) Range may be increased with the use of additional infiNET devices or C2N_MNETRPT repeaters “Wi-Fi” friendly operating frequency to avoid interference • Easy to read, backlit LCD display • Available in white, black or almond Operations & Installation Guide – DOC. 6490 infiNET™ Thermostat: CHV-TSTATRF • 1 infiNET™ Thermostat Crestron CHV-TSTATRF InfiNET™ Thermostat The CHV-TSTATRF is a wireless networked thermostat featuring infiNET wireless technology. The CHV-TSTATRF is designed to be installed easily in place of a conventional type thermostat without requiring additional control network wiring. Although it can be used as a standalone thermostat, the CHV-TSTATRF delivers enhanced functionality as part of a complete Crestron Home ® automation system communicating via the infiNET wireless control network. Heat/Cool Thermostat The CHV-TSTATRF is designed for heating and cooling control of baseboard, forced air and heat pump …

Text truncated - open the document above for the full version.

FCC CONFIDENTIALITY Date: 08/28/06 Time: 11 : 27 To: FCC Authorization & Evaluation Division 7435 Oakland Mills Road Columbia, MD 21045-0429 From: Sudharsan Sam Yogasuntharam Phone: 201-750 7004 x11350 Electrical Engineer Fax: 201-767 5771 Applicant: Crestron Electronics, Inc. E-Mail: [email protected] ______________________________________________________________________________________ Subject: Request for Non disclosure for FCC ID: EROCWD1013 To Whom It May Concern: Pursuant to 47 CFR Section 0.459, Crestron Electronics, Inc. hereby requests non disclosure and confidential treatment of the following materials submitted in support of FCC certification application for FCC ID # EROCWD1013 a. Schematic Diagrams b. Operational Description c. Block Diagram Above materials contain trade secrets, proprietary and technical information which would customarily be guarded from competitors under 47 CFR section 0.457(d)(2). Disclosure or publication of any portion of this company confidential material to other parties could cause substantial competitive harm and provide unjustified benefits for competitors. Crestron Electronics, Inc. understands that pursuant to 47 CFR section 0.457(d)(1)(ii) disclosure of the applicant and all accompanying documentation will not be made before the date of the grant. Sincerely yours, By: Sudharsan Sam Yogasuntharam Title: Electrical Engineer Crestron Electronics, Inc. Crestron Electronics, Inc. 15 Volvo Drive Rockleigh, NJ 07647 Tel: 800.237.2041/ 201.767.3400 Fax: 201.767.7576 www.crestron.com

FCC A U T H O R I Z A T I O N Date: 08/28/06 Time: 10 : 46 To: FCC Authorization & Evaluation Division 7435 Oakland Mills Road Columbia, MD 21045-0429 From: Sudharsan Sam Yogasuntharam Phone: 201-750 7004 x11350 Electrical Engineer Fax: 201-767 5772 Applicant: Crestron Electronics, Inc. E-Mail: [email protected] ______________________________________________________________________________________ Dear Ladies and/or Gentlemen: I appoint Kenneth L. Boston, James Blaha and Teresa White of LS Research, LLC, to act as an agent in the preparation of applications under Part 15 of the rules and regulations of the Federal Communications Commission. I certify that the exhibitions properly describe the device being submitted under this application and will implement any changes described in the test report. The labels described will be affixed to each item. The following statement is required by the Federal Communications Commission: By checking Yes, the applicant certifies that, in the case of an individual applicant, he or she is not subject to a denial of federal benefits, that included FCC benefits, pursuant to section 5301 of the Anti-Drug Abuse Act of 1988, 21 U.S.C 853(a), or, in the case of a non-individual applicant (e.g. corporation, partnership, or other unincorporated association), no party to the application is subject to a denial of federal benefits, that includes FCC benefits, pursuant to that section. ___X___Yes _______No By: Sudharsan Sam Yogasuntharam Title: Electrical Engineer Crestron Electronics, Inc. Crestron Electronics, Inc. 15 Volvo Drive Rockleigh, NJ 07647 Tel: 800.237.2041/ 201.767.3400 Fax: 201.767.7576 www.crestron.com

Crestron Electronics, Inc. CHV-TSTATRF FCC ID#: EROCWD1013 Photo One – External Front Side Panel Crestron Electronics, Inc. CHV-TSTATRF FCC ID#: EROCWD1013 Photo Two – External Battery Compartment Crestron Electronics, Inc. CHV-TSTATRF FCC ID#: EROCWD1013 Photo Three – External Rear Panel with I/O Cable & Showing FCC ID Label Crestron Electronics, Inc. CHV-TSTATRF FCC ID#: EROCWD1013 Photo Four – External Close-up of FCC ID Label

R .125 NOTES: 1 . MATERIAL:ULjCSAAPPROVEDGLOSSCOATED SILVERPOLYESTER,.002"THKWITHPERMANENT ACRYLICADHESIVE. 2.PRINT:TEXTANDGRAPHICS - BLACK. 3.USECOMPUTERFILE22821-AFMTFORTHE ACTUALPRODUCTIONOFTHELABEL. NAME - MW REV - A r175"---l CRESTRON MADEINTHEU5.A CHV-TSTATRF Thisdevicecomplieswithpart15ofthe FCCRules. Operationsis subjecttothefollowingtwo conditions: 1)Thisdevicemaynotcauseharmful interference,and 2)Thisdevicemustacceptany interferencereceived,includinginterference thatmaycauseundesiredoperation. FCCID:EROCWD1013 IC:5683A-CWD1013 ~ REVISIONS DESCRIPTION ECN5366 I 1.25" ~ DATE 08/31/06 APPROVED THISDRAWINGISTHEEXCLUSIVEPROPERTYOFCRESTRONELECTRONICS,INC,DISCLOSUREORREPRODUCTIONINWHOLE ORINPART,WITHOUTPRIORWRITTENPERMISSION,ISPROHIBITEDEXCEPTFORTHEMANUFACTUREOFARTICLESFORCRESTRON. UNLESSOTHERWISESPECIFIED: ALLDIMENSIONSAREININCHES TOLERANCESARE: FRACTIONS:t1/64ANGLES:tV,' DECIMALS.XXX:t.005 DEBURR&BREAKALLSHARPEDGES CRESrRONELECTRONICS.INC 15VOLVODRIVE,ROCKLEIGH,N.J.07647 (201)767-3400FAX(201)767-5772 6500665CHV-TSTATRFA NAMEDATE I LABEL,FCCCOMPLIANCE,SS#22821 6500664 CHV-TSTATRFBDESIGNEDBY MW 9/01/06 6500663 CHV-TSTATRFW DRAWNBYMW 9/01/06ISIZEI PRINTNUMBER IREV ANISI-EDGO!SORTNAME CHECKED IAI 270129 I A USEDON APPROVED IIISCALE:1:1IFilE: 270129-A.CDR ISHEET1 OF1

Crestron Electronics, Inc. CHV-TSTATRF FCC ID#: EROCWD1013 Photo One – Internal Open for Inspection-PCB Component Side Crestron Electronics, Inc. CHV-TSTATRF FCC ID#: EROCWD1013 Photo Two – Internal Close Up of RF Section – Shield Removed Crestron Electronics, Inc. CHV-TSTATRF FCC ID#: EROCWD1013 Photo Three – Internal PCB Display Flip Side & Controls Crestron Electronics, Inc. CHV-TSTATRF FCC ID#: EROCWD1013 Photo Four – Internal Chip Antenna – Close Up

Prediction of MPE limit at a given distance Equation from page 18 of OET Bulletin 65, Edition 97-01 where:S = power density P = power input to the antenna G = power gain of the antenna in the direction of interest relative to an isotropic radiator R = distance to the center of radiation of the antenna Maximum peak output power at the antenna terminal:10.92(dBm) Maximum peak output power at the antenna terminal:12.35947433(mW) Antenna gain(typical):1.2(dBi) Maximum antenna gain:1.318256739(numeric) Prediction distance:20(cm) Prediction frequency:2450(MHz) MPE limit for uncontrolled exposure at prediction frequency:1(mW/cm^2) Power densit y at prediction frequency:0.003241(mW/cm^2) Maximum allowable antenna gain:26.09269855(dBi) 2 4R PG S π =

LS Research, LLC W66 N220 Commerce Court ● Cedarburg, WI 53012 ● USA Phone: 262.375.4400 ● Fax: 262.375.4248 www.lsr.com ------------------------------------------------------------------------------------------------------------------------- TEST REPORT #: 306439 TX TCB v4 Compliance Testing of: CHV-TSTATRF Test Date(s): August 16 th , 17 th and 23 rd , 2006 Prepared For: Crestron Electronics, Inc. 6 Volvo Drive Rockleigh, NJ 07647 In accordance with: Federal Communications Commission (FCC) Part 15, Subpart C, Section 15.247 Digital Modulation Transmitters (DTS) Operating in the Frequency Band 2400 MHz – 2483.5 MHz This Test Report is issued under the Authority of: Brian E. Petted, VP of Engineering Signature: Date: August 30, 2006 Test Report Prepared by: Teresa A. White, Document Coordinator Signature: Date: August 30, 2006 Tested by: Khairul Aidi Zainal, EMC Engineer Signature: Date: August 30, 2006 This Test Report may not be reproduced, except in full, without written approval of LS Research, LLC. Prepared For: Crestron Model #: CHV-TSTATRF LS Research, LLC EUT: Thermostat Serial #: 1 Template: 15.247 DTS TX (V1 6-09-06) Test Report #: 306439 TX TCB v4 Customer FCC ID #: EROCWD1013 Page 2 of 54 TABLE OF CONTENTS (page 1 of 2) EXHIBIT 1. INTRODUCTION 4 1.1 Scope 4 1.2 Normative References 4 1.3 LS Research, LLC Test Facility 5 1.4 Location of Testing 5 1.5 Test Equipment Utilized 5 EXHIBIT 2. PERFORMANCE ASSESSMENT 6 2.1 Client Information 6 2.2 Equipment Under Test (EUT) Information 6 2.3 Associated Antenna Description 6 2.4 EUT’s Technical Specifications 7 2.5 Product Description 8 EXHIBIT 3. EUT OPERATING CONDITIONS & CONFIGURATIONS DURING TESTS 9 3.1 Climate Test Conditions 9 3.2 Applicability & Summary of EMC Emission Test Results 9 3.3 Modifications Incorporated in the EUT for Compliance Purposes 9 3.4 Deviations & Exclusions from Test Specifications 9 EXHIBIT 4. DECLARATION OF CONFORMITY 10 EXHIBIT 5. RADIATED EMISSIONS TEST 11 5.1 Test Setup 11 5.2 Test Procedure 11 5.3 Test Equipment Utilized 12 5.4 Test Results 12 5.5 Calculation of Radiated Emission Measurements 13 5.6 Radiated Emissions Data Chart 14-16 5.7 Test Setup Photo(s)-Radiated Emissions Test 17-18 5.8 Screen Captures-Radiated Emissions Testing 19-23 EXHIBIT 6. CONDUCTED EMISSIONS TEST, AC POWER LINE: 15.207 24 EXHIBIT 7. OCCUPIED BANDWIDTH: 15.247(a)(2) 25 7.1 Limits 25 7.2 Method of Measurements 25 7.3 Test Data 25 7.4 Test Equipment List 25 7.5 Screen Captures – Occupied Bandwidth 26-29 Prepared For: Crestron Model #: CHV-TSTATRF LS Research, LLC EUT: Thermostat Serial #: 1 Template: 15.247 DTS TX (V1 6-09-06) Test Report #: 306439 TX TCB v4 Customer FCC ID #: EROCWD1013 Page 3 of 54 TABLE OF CONTENTS (Page 2 of 2) EXHIBIT 8. BAND-EDGE MEASUREMENTS 30 8.1 Method of Measurements 30-31 EXHIBIT 9. PEAK OUTPUT POWER (CONDUCTED): 15.247(b) 32 9.1 Method of Measurements 32 9.2 Test Data 32 9.3 Test Equipment List 33 9.4 Screen Captures – Power Output (Conducted) 33-34 EXHIBIT 10. POWER SPECTRAL DENSITY: 15.247(e) 35 10.1 Limits 35 10.2 Test Equipment List 35 10.3 Test Data 35 10.4 Screen Captures-Power Spectral Density 36-37 EXHIBIT 11. SPURIOUS RADIATED EMISSIONS: 15.247(d) 38 11.1 Limits 38 11.2 Test Equipment List 38 11.3 Test Data 38 11.4 Screen Captures-Spurious Radiated Emissions 39-40 EXHIBIT 12. FREQUENCY & POWER STABILITY OVER VOLTAGE & TEMPERATURE VARIATIONS 41 EXHIBIT 13. CHANNEL PLAN AND SEPARATION 42 EXHIBIT 14. MPE CALCULATIONS 42 APPENDIX A TEST EQUIPMENT LIST 43 APPENDIX B ANTENNA SPECIFICATION(S) 44-49 APPENDIX C FIRMWARE AND SETUP INSTRUCTIONS 50 LSC Revision Control Date Revision # Revised By Aug 19 th 2006 Version 0 Sept. 1, 2006 Version 1 TAW Prepared For: Crestron Model #: CHV-TSTATRF LS Research, LLC EUT: Thermostat Serial #: 1 Template: 15.247 DTS TX (V1 6-09-06) Test Report #: 306439 TX TCB v4 Customer FCC ID #: EROCWD1013 Page 4 of 54 EXHIBIT 1. INTRODUCTION 1.1 SCOPE References: FCC Part 15, Subpart C, Section 15.247 Title: Telecommunication – Code of Federal Regulations, CFR 47, Part 15 Purpose of Test: To gain FCC Certification Authorization for Digital Modulation Transmitters operating in the Frequency Band of 2400 MHz – 2483.5 MHz Test Procedures: Both conducted and radiated emissions measurements were conducted in accordance with American National Standards Institute ANSI C63.4 – American National Standard for Methods of Measurement of Radio-Noise Emissions from Low-Voltage Electrical and Electronic Equipment in the Range of 9 kHz to 40 GHz. Environmental Classification: • Commercial, Industrial or Business • Residential 1.2 NORMATIVE REFERENCES Publication Year Title 47 CFR, Parts 0-15 (FCC) 2005 Code of Federal Regulations - Telecommunications ANSI C63.4 2004 American National Standard for Methods of Measurement of Radio-Noise Emissions from Low-Voltage Electrical and Electronic Equipment in the Range of 9 kHz to 40 GHz. CISPR 16-1-1 2003 Specification for radio disturbance and immunity measuring apparatus and methods. Part 1-1: Measuring Apparatus. CISPR 16-2-1 2003 Specification for radio disturbance and immunity measuring apparatus and methods. Part 201: Conducted disturbance measurement. FCC Public Notice DA 00-1407 2000 Part 15 Unlicensed Modular Transmitter Approval FCC ET Docket No. 99-231 2002 Amendment to FCC Part 15 of the Commission’s Rules Regarding Spread Spectrum Devices. FCC Procedures 2005, 03-23 Measurement of Digital Transmission Systems operating under Section 15.247. Prepared For: Crestron Model #: CHV-TSTATRF LS Research, LLC EUT: Thermostat Serial #: 1 Template: 15.247 DTS TX (V1 6-09-06) Test Report #: 306439 TX TCB v4 Customer FCC ID #: EROCWD1013 Page 5 of 54 1.3 LS Research, LLC TEST FACILITY LS Research, LLC is accredited by A2LA (American Association for Laboratory Accreditation) to conform to ISO/IEC 17025, 2005 “General Requirements for the Competence of Calibration and Testing Laboratories”. LS Research, LLC’s scope of accreditation includes all test m…

Text truncated - open the document above for the full version.

Test Setup Photos Crestron FCC ID: EROCWD1013 Page 1 of 2 Test Setup Photo(s) – Radiated Emissions Test Vertical Orientation Horizontal Orientation Test Setup Photos Crestron FCC ID: EROCWD1013 Page 2 of 2 Side Orientation
