EROM202108007Crestron Video Bar with WIFI and Bluetooth

Quick Start M202108007 Crestron Flex Large Room Conference Solution with All-In-One Videobar 70 for Zoom Rooms® Software The UC-B70-A-Z Crestron Flex tabletop conferencing system provides a medium to large room video conference solution for use with Zoom Rooms® software. The UC-B70-A-Z features a 10.1 in. tabletop touch screen, Crestron Videobar 70 with intelligent high- definition video and audio, a PoE injector, and cables. The UC- B70-A-Z also supports up to three video displays (not included). The latest firmware must be loaded onto the touch screen prior to operation. Refer to the touch screen's product page (resources tab) to download the latest device firmware. The latest UC-B70-A-Z and UC- B70-A-Z-I firmware is installed using the auto update feature. Mount Devices Mount the Crestron Videobar 70 The Videobar 70 can be placed on a flat surface or mounted on a wall. Mount on a Wall The Videobar 70 includes anchors that are suitable for mounting it on sheetrock walls up to 1/2 in. (13 mm) thickness. Masonry and other materials may require additional installer-supplied mounting hardware. In the Box Tabletop Touch Screen Device 10.1 in. Tabletop Touch Screen (6510821) Grommet, Cable, Closed (2055455) Grommet, Cable, Open (2055456) Cover, Cable compartment (2055457) 1 1 1 1 Smart Soundbar and Camera Crestron Videobar 70 (6512358) 1 Additional Items Cable, CAT5e, RJ-45 - RJ-45, 7 ft (2.1 m) (6509924) Cable, CAT6a, RJ-45 - RJ-45, 20 ft (6.1 m) (6507640) Cable, HDMI® 2.1, 6 ft (1.8 m) (6512150) Cable, HDMI 2.1, 22 ft (6.7 m) (6512761) PoE injector (6502429) 1 1 2 1 1 The following tools are required to mount Videobar 70:  Drywall saw (not included) Drill with 5/16 in. bit (not included)  A template is included to provide drill hole locations for the included mounting hardware. 1 NOTE: When mounting on a wall beneath a display device, leave 3/4 in. (minimum) clearance above the top of Videobar 70. Use the included template to allow for sufficient clearance between Videobar 70 and display device. NOTES:  For optimal viewing results, Videobar 70 should be mounted in a location that places the camera approximately 12 in. (305 mm) above the plane of the room’s conference table.  When mounting on a wall beneath a display device, leave 3/4 in. (19 mm) (minimum) clearance above the top of Videobar 70. Use the included template to allow for sufficient clearance between Videobar 70 and display device. Quick Start M202108007 Crestron Flex Large Room Conference Solution with All-In-One Videobar 70 for Zoom Rooms® Software 1 . Attach the template to the desired mounting location with the template's center reference line at the center of the desired location. Drill two pilot holes on each side of the center reference line. Each side should have one pilot hole drilled in each row of the template. Use a drywall saw to make a cutout in the wall for Videobar 70 cables. The cutout in the center of the template provides adequate access for all of the required cabling. Install the four included anchors and screws into the drilled pilot holes. Place Videobar 70 face down, and pivot the wall bracket away from Videobar 70. Place the wall bracket over the screws, and hand tighten the screws until the wall bracket is secured to the wall. Route the cables through the cable cutout, and connect the cables. 2 . 3. 4. 5. 6. 7 . 2 NOTE: The included power pack's cord is typically routed from the wall opening, through the cable cutout, to the soundbar. Quick Start M202108007 Crestron Flex Large Room Conference Solution with All-In-One Videobar 70 for Zoom Rooms® Software Connect System Overview 3 Quick Start M202108007 Crestron Flex Large Room Conference Solution with All-In-One Videobar 70 for Zoom Rooms® Software Make Connections 1 . Make a direct connection for simple installation and setup by connecting the touch screen's PoE injector to the video bar. 4 Quick Start M202108007 Crestron Flex Large Room Conference Solution with All-In-One Videobar 70 for Zoom Rooms® Software 2 . Connect displays to the video bar. 5 Quick Start M202108007 Crestron Flex Large Room Conference Solution with All-In-One Videobar 70 for Zoom Rooms® Software 3. Connect a laptop to the video bar. 6 Quick Start M202108007 Crestron Flex Large Room Conference Solution with All-In-One Videobar 70 for Zoom Rooms® Software 6. 7 . 8. Tap Microphone and select the videobar as the source. Tap Speaker and select the videobar as the source. Tap Meet Now to exit. Configure Apply power Apply power to the video bar and all of the other devices in the system. The connected display device will show a pairing code. The conference device will show a prompt to enter a pairing code. Configure the System Connect a USB keyboard and mouse (sold separately) to a USB port on the video bar to configure system features. For detailed information on using Zoom Rooms, refer to the Zoom Rooms Help Center. Log In to the Zoom Rooms Service 1 . Tap Touch Here to Enable a Specific Application on the bottom of the screen. A list of applications is displayed. Tap Zoom Rooms and then tap Confirm. The touch screen will reboot. Enter the pairing code shown on the display to pair the touch screen with the UC Engine. The Zoom Rooms controller app is displayed. Log in to the Zoom Rooms service with an activation code or Zoom Rooms Credentials (email and password). 2 . 3. 4. Activation Code: a. Tap Enter Activation Code. b. Enter the 16-digit activation code provided by the administrator to activate the Zoom Room that is assigned to the activation code. The Zoom Rooms Conference Room screen is shown on the display.  Sign In:  a. b. c. Tap Sign In. Enter the Zoom Room credentials and tap Sign In. Select the conference room name from the list and tap Next. The Zoom Rooms Conference Room screen is shown on the display. 5. Tap Settings. If a password is required, enter the password (the default password is "1234"). The Settings screen is displayed. 7 Quick Start M202108007 Crestron F…

Text truncated - open the document above for the full version.

Crestron Electronics Inc. Certification Designating a U.S. Agent for Service of Process Date: 2023-09-08 Ref: Section 2.911(d)(7) filing FCC ID: EROM202108007 FRN: 0005022819 To: Federal Communications Commission 7435 Oakland Mills Road Columbia, MD 21046 USA Crestron Electronics Inc.as required by section 2.911(d)(7), will also serve as the agent for service of process for the above referenced FCC ID. The applicant acknowledges that they will maintain an agent for no less than one year after the grantee has terminated all marketing and importation or the conclusionofany Commission-related proceeding involving the equipment. The applicant further acknowledges their responsibility to inform the FCC whenever the agent information changes. U. S. Agent Information: Contact Person: Chirag Patel Company Name: Crestron Electronics Inc. Company Address: 15 Volvo Drive, Rockleigh, NJ 07647, USA Email: [email protected] Sincerely yours, Applicant Company (grantee) Contact Person: Chirag Patel Company Name: Crestron Electronics Inc. Company Address: 15 Volvo Drive, Rockleigh, NJ 07647, USA Email: [email protected]

Crestron Electronics Inc. To: Federal Communications CommissionDate: 2023/09/08 7435 Oakland Mills Road Columbia, MD 21046 USA Attestation Section2.911(d)(5)(i)andSection2.911(d)(5)(ii) (KDB986446D01CoveredEquipment) Section2.911(d)(5)(i) Crestron Electronics Inc.certifies that the equipment for which authorization is sought is not “covered” equipment prohibited from receiving an equipment authorization pursuant to section 2.903 of the FCC rules. Section2.911(d)(5)(ii) Crestron Electronics Inc.certifies that, as of the date of the filing of the application, the applicantis notidentified on the Covered List (as a specifically named entity or any of its subsidiaries or affiliates)as an entity producing “covered” equipment. Type of Equipment subject to FCC Certification:Crestron Video Bar FCC ID:EROM202108007 If you have any questions, please feel free to contact me Contact Person:Chirag Patel Position in the Company: Lead Compliance Engineer Date of Signature:2023-09-08 ___________________________ Signatory (signature of the applicant)

Crestron Electronics Inc. Date: 2023-09-08 To: Federal Communications Commission, Authorization & Evaluation Division, 7435 Oakland Mills Road, Columbia, MD 21046 To Whom It May Concern: The Crestron Electronics Inc., the undersigned, hereby authorizesMiss. Wendy Zhan from Shenzhen Morlab Communications Technology Co., Ltd.,toact on the behalf of the Crestron Electronics Inc. solely in matters relating tothe application for an FCC equipment authorization for FCC ID: EROM202108007 including the signing of documents in connection with this Application. Necessary acts carried outShenzhen Morlab Communications Technology Co., Ltd.on our behalf of the Crestron Electronics Inc. in connection with the Application shall have the same effect as acts of the Crestron Electronics Inc.. Crestron Electronics Inc. also hereby certify that no partyto this application is subject to a denial of benefits, including FCC benefits, pursuant to Section 5301 of the Anti-DrugAbuse Act of 1988, 21 U.S.C. 862. Thank you for your attention to this matter. Yours Sincerely, Signatory: Contact name:Chirag Patel Title: Lead Compliance Engineer Tel: 201-750-7004 Email:[email protected] Company name: Crestron Electronics Inc.

CrestronElectronicsInc. Date:2023-09-08 To: Federal Communications Commission, Authorization & Evaluation Division, 7435 Oakland Mills Road, Columbia, MD 21046 Re: Request of Confidentiality forFCC ID: EROM202108007 To Whom it may concern: Pursuant to sections 0.457 and 0.459 of Commission’s Rules(CFR 47), and Section 552(b)(4) of the Freedom of Information Act,Crestron Electronics Inc.hereby requests confidentiality and treatment of certain information accompanying this application. The materials contain trade secrets and proprietary information not customarily released to the public. The public disclosure of these matters might beharmful to the Applicant and provide unjustified benefits to its competitors. We are also hereby request Short-TermConfidentiality for 180 days after the grant as outlined in Public Notice DA04-1705. This provision will giveCrestron Electronics Inc.temporary confidentiality of commercially sensitive information prior to product release. The requested Permanent and Short-Term Confidential exhibits are listedas follows: PERMANENT AND SHORT-TERM CONFIDENTIAL LIST ExhibitDescription PERMANENT 1Block Diagram 2Operational Description 3Schematics 4BOM SHORT-TERM 5External Photos 6Internal Photos 7Test-Setup Photos 8User Manual The Applicant understands that pursuantto Rule 0.457, disclosure of this application and all accompanying documentations, where applicable, will not be made public before the date of the Grant for this application. Signatory: Name:Chirag Patel Company name:Crestron Electronics Inc. Address:15 Volvo Drive, Rockleigh, NJ 07647, USA Tel: 201-750-7004 Email: [email protected]

Crestron Electronics Inc. UNII Declaration Letter We have declared below featured for FCC equipment authorization, device FCC ID:EROM202108007 (1) DFS Device -- Master,Client with Radar detection capability , Client without radar detection capability,N/A (2) Active / Passive Scanning , adhoc mode access point capability Frequency Band (MHz) Active Scanning (the device can transmit a probe (beacon)) passive scanning (where the device is can listen only with no probes) Ad Hoc Mode capability Access point capability 2412 –2462 MHzYes,NoYes,NoYes,NoYes,No 2422 –2452 MHzYes,NoYes,NoYes,NoYes,No 5745 –5825 MHzYes,NoYes,NoYes,NoYes,No 5755 –5795 MHzYes,NoYes,NoYes,NoYes,No 5180 –5240 MHzYes,NoYes,NoYes,NoYes,No 5190 –5230 MHzYes,NoYes,NoYes,NoYes,No 5260 –5320 MHzYes,NoYes,NoYes,NoYes,No 5270 –5310 MHzYes,NoYes,NoYes,NoYes,No 5500 –5700 MHzYes,NoYes,NoYes,NoYes,No 5510 – 5670 MHz Yes,NoYes,NoYes,NoYes,No (3) Country code selection ability -Yes ,No If no, pls explain how was implemented : Country is selected as US by defaultand user can not change the country code. (4) Meet 15.202 requirement - Yes ,No , pls check below : A master device is defined as a device operating in a mode in which it has the capability to transmit without receiving an enabling signal. In this mode it is able to select a channel and initiate a network by sending enabling signals to other devices A client device is defined as a device operating in a mode in which the transmissions of the device are under control of the master. A device in client mode is not able to initiate a network. (5) For client devices that have software configuration control to operate in different modes (active scanning in some and passive scanning in others) in different bands (devices with multiple equipment classes or those that operate on non-DFS frequencies) or modular devices which configure the modes of operations through software, the application must provide software and operations description on how the software and / or hardware is implemented to ensure that proper operations modes can not be modified by end user or an installer. Apply ,No Apply, (If apply , pls help to provide explanation on how it was implement (By hardware or software , and how software was controlled) The device configuration can not be modified by user as program is not exposed to user by any means. Hardware does not allow USB connection for user which is must to change the configuration. If you have any questions, please feel free to contact me at the address shown below. Yours sincerely, Signatory: Printed Name : Chirag Patel Position : Lead Compliance Engineer

Declaration To whom it may concern: We have declared below featured for FCC equipment authorization, Device FCC ID: EROM202108007 Don't operate on Channels 12 and 13. US 2.4G channel 12-13 and Country code selection are disabled through proprietary software and are not user changeable Should you have any questions, please feel free to contact me. Signature : Date:2023/09/08 Contact name:Chirag Patel Title: Lead Compliance Engineer Company name: Crestron Electronics Inc.

CrestronElectronicsInc. Supplier’sDeclarationOfConformity fortheFCCSDoCProcedure ThefollowingEquipmentadaptFCCSDoCProcedureaccordingtoFCCpart2.906: ProductName:CrestronVideoBar BrandName:CRESTRON ModelNumber:M202108007 ReportNumber:SZ23040374E01 It’sherewithconfirmedtocomplywiththerequirementsofFCCPart15Rules. Operationissubjecttothefollowingtwoconditions: (1)Thisdevicemaynotcauseharmfulinterference,and (2)Thisdevicemustacceptanyinterferencereceived,includinginterferencethat maycauseundesiredoperation. Itisunderstoodthateachunitmarketedisidenticaltothedeviceastested,andanychangestothe devicethatcouldadverselyaffecttheemissioncharacteristicswillrequireretest. Thefollowingimporter/responsiblepartyinUnitedStates: NotAvailableatCertificationStage CompanyName:N/A CompanyAddress:N/A Telephone:N/A Fax:N/A Personisresponsibleformarkingthisdeclaration: ChiragPatelLeadComplianceEngineer __________________________________________________________________________ Name(Fullname)Position/Title 2023‐09‐08 __________________________________________________________________________ LegalSignatureDate

FCC ID: EROM202108007 IC: 5683C-M202108007 External Photos 1. EUT front view 2. EUT rear view 3. EUT left side view 4. EUT right side view 5. EUT top view 6. EUT bottom view 7. Accessories

Label: Location：

FCC ID: EROM202108007 IC: 5683C-M202108007 Internal Photos 1. EUT uncover view
