EROWPR-48Waterproof wireless Handheld Remote

Crestron WPR-48 Waterproof Wireless Handheld Remote Operations Guide This document was prepared and written by the Technical Documentation department at: Crestron Electronics, Inc. 15 Volvo Drive Rockleigh, NJ 07647 1-888-CRESTRON WARNING: The WPR-48 Waterproof Wireless Handheld Remote has been tested and found to be waterproof when submerged to a maximum depth of 1 meter, and for a maximum duration of 30 minutes, per IEC 60529 IPX7 standards. Exceeding these limits may result in damage to the equipment, possible personal injury, and void the product warranty. WARNING: The WPR-48 is shipped from the factory partially assembled. That is, the eight screws that secure the rear cover to the button faceplate are not fully tightened, to simplify the process of installing button labels, as described in this Operations Guide. As such, the unit is not waterproof; exposing it to water may result in damage to the equipment, possible personal injury, and void the product warranty. WARNING: After installing button labels, as described in this Operations Guide, tighten all eight screws that secure the rear cover to the button faceplate evenly just until the gasket is no longer visible between the button faceplate and the rear cover (from 1.5 to 2 in/lbs torque, maximum). Do not overtighten the screws. To do so may damage the gasket such that the unit is no longer waterproof. Exposing such a unit to water may result in damage to the equipment, possible personal injury, and void the product warranty. WARNING: The lanyard, supplied with the lanyard foot, poses a possible strangulation hazard. Crestron does not recommend placing the lanyard around the neck as a means of carrying the WPR-48. Do not leave the lanyard, or the WPR-48 with lanyard foot and lanyard attached, unattended in any area where children or pets may be present. WARNING: This product contains small parts and is not intended for children. This product is intended for adult use only. All brand names, product names, and trademarks are the property of their respective owners. ©2004 Crestron Electronics, Inc. Crestron WPR-48 Waterproof Wireless Handheld Remote Contents Waterproof Wireless Handheld Remote: WPR-48 1 Introduction...............................................................................................................................1 Features and Functions................................................................................................1 Specifications..............................................................................................................2 Physical Description....................................................................................................2 Industry Compliance...................................................................................................5 Setup..........................................................................................................................................5 Applying Power...........................................................................................................5 Configuring the WPR-48.............................................................................................5 Setting RF/IR ID via Button Presses...........................................................................9 User-Printable Customized Button Labels................................................................10 Installing/Replacing Button Labels...........................................................................12 Installing Alternate Foot............................................................................................13 Programming the WPR-48.......................................................................................................14 Earliest Version Software Requirements for the PC.................................................14 Programming with SIMPL Windows........................................................................14 Uploading and Upgrading........................................................................................................18 Communication Settings...........................................................................................18 Firmware Upgrade.....................................................................................................20 Problem Solving ......................................................................................................................21 Troubleshooting.........................................................................................................21 Further Inquiries ........................................................................................................22 Future Updates..........................................................................................................22 Return and Warranty Policies..................................................................................................23 Merchandise Returns / Repair Service......................................................................23 CRESTRON Limited Warranty.................................................................................23 Operations Guide – DOC. 6254A Contents • i Crestron WPR-48 Waterproof Wireless Handheld Remote Waterproof Wireless Handheld Remote: WPR-48 Introduction Features and Functions The Crestron ® WPR-48 waterproof wireless handheld remote can be configured to transmit either RF or IR signals, making it perfect for controlling music, television, lighting and more. The unit is safe to use in the shower or hot tub. The rubberized, immersible case is easy to grip, and will not slip from moist hands. A streamlined user interface of multi-function pushbuttons makes the WPR-48 simple to use under a variety of conditions. The nine three-position pushbuttons may be configured in any of four arrangements, providing 9, 18, 27, or 48 possible functions. Large customizable labels with electr…

Text truncated - open the document above for the full version.

To: Federal Communications Commission Date: 01/20/2005 445 12 th street, SW Washington, DC 20554 Subject: Request for Confidentiality EROWRP-48 We would like to request that the documents contained herein be accorded confidentiality and be restricted from public and competitive exposure as per FCC Rules 47 CFR Subpart C, Section 0.459: 1. Schematic 2. Block Diagram Thank you for your cooperation. Sam Yogasuntharam Electrical Engineer Crestron Electronics Inc.

04-0960 Pg 1 TABLE OF CONTENTS Subject Paragraph Page No. Abstract 1.0 2 References 2.0 2 Administrative Information 3.0 3 Test Program Outline 4.0 3 General Test Information 5.0 3 Enclosures Number of Pages Number of Photos (1) Physical Inspection Forms 6 - (2) Conducted Emission, 150 kHz to 30 MHz 7 1 (3) Radiated Emission, Intentional Radiator, 30 MHz to 5 GHz 12 3 (4) Occupied Bandwidth 4 - 04-0960 Pg 2 1.0 ABSTRACT This report details the results of the FCC Code of Federal Regulations, 47 CFR, Part 15, Sub-Part C testing on two Waterproof Remotes, Model No. WPR-48, Serial Nos. X100419 and 1468551 and one Waterproof Remote Docking Station, Model No. WPR-DS, Serial No. X100385, manufactured by Crestron Electronics, Incorporated. The conducted emission test was performed using two separate Waterproof Remotes, Serial No. X100419 (programmed for 418 MHz operation) and Serial No. 1468551 (programmed for 433 MHz operation). The radiated emission and occupied bandwidth tests were performed using one Waterproof Remote, Serial No. X100419. When using only one Waterproof Remote, Serial No. X100419, the Remote was programmed for 418 MHz operation and then reprogrammed for 433 MHz operation. The Waterproof Remote and the Waterproof Remote Docking Station were found to be in compliance with the Conducted Emission, Radiated Emission, and Occupied Bandwidth portions of the FCC Code of Federal Regulations, 47 CFR, Part 15, Sub-Part C, specification limits. Detailed test results can be observed in Enclosures 2, 3, and 4 of this report. The test results recorded in this report relate only to those items tested. This report shall not be reproduced, except in full, without the written approval of Dayton T. Brown, Inc. 2.0 REFERENCES (a) Customer Purchase Order No.: 17519 (b) Dayton T. Brown, Inc. Job No.: 401219-01-000 (c) Test Specification: Code of Federal Regulations, 47 CFR, Part 15, Sub-Part C (d) Test Procedure: American National Standard for Methods of Measurement of Radio-Noise Emissions from Low- Voltage Electrical and Electronic Equipment in the Range of 9 kHz to 40 GHz, ANSI C63.4-2003 04-0960 Pg 3 3.0 ADMINISTRATIVE INFORMATION Customer Crestron Electronics, Inc. 15 Volvo Drive Rockleigh, NJ 07647 Test Item Description Quantity Received Model No. Serial No. Waterproof Remote Waterproof Remote Docking Station One One One WPR-48 WPR-48 WPR-DS X100419 1468551 X100385 Date Received 1 December 2004 Dates Tested 1 and 2 December 2004 Date Shipped 2 December 2004 Customer Representative Present During Testing Name Affiliation Mr. Sam Yogasuntharam Crestron Electronics, Inc. 4.0 TEST PROGRAM OUTLINE Test Description Results Conducted Emission, 150 kHz to 30 MHz Met the specification requirements. Radiated Emission, Intentional Radiator, 30 MHz to 5 GHz Met the specification requirements. Occupied Bandwidth Met the specification requirements. 5.0 GENERAL TEST INFORMATION Setup For the conducted emission test in the frequency range of 150 kHz to 30 MHz, the test samples were set up in a GTEM Cell. The Waterproof Remotes were mounted in the Waterproof Remote Docking Station and were operated in the Charge/Transmit mode. For the radiated emission test in the frequency range of 30 MHz to 1 GHz, the test samples were set up in a climate controlled open field site that measures 44 feet long by 24 feet wide by 24 feet high. The Waterproof Remote was mounted in the Waterproof Remote Docking Station and was operated in the Charge/Transmit mode at 418.0 MHz and then at 433.95 MHz. 04-0960 Pg 4 For the radiated emission test in the frequency range of 1 to 5 GHz, the test samples were set up in an anechoic chamber that measures 20 feet wide by 20 feet long by 10 feet high. The Waterproof Remote was mounted in the Waterproof Remote Docking Station and was operated in the Charge/Transmit mode at 418.0 MHz and then at 433.95 MHz. For the occupied bandwidth test, the test samples were set up in a GTEM Cell. The Waterproof Remote was mounted in the Waterproof Remote Docking Station and was operated in the Charge/Transmit mode at 418.0 MHz and then at 433.95 MHz. 04-0960 Enclosure 1 Physical Inspection Forms 04-0960 Enc 1 Pg 1 PHYSICAL INSPECTION FORM JOB NUMBER 401219-01-000 DATE 1 December 2004 CUSTOMER Crestron Electronics, Inc. TECHNICIAN M, Sheehy TEST EMI SPECIFICATION FCC Rules and Regulations, Part 15 ITEM Waterproof Remote SERIAL NO. X100419 A PRE-TEST INSPECTION REVEALED: X NO ANOMALIES NO ANOMALIES DUE TO TESTING THE FOLLOWING Photograph Taken? No If Yes, Photo Number N/A LAB FORM NO. 40 REV 11/03 04-0960 Enc 1 Pg 2 PHYSICAL INSPECTION FORM JOB NUMBER 401219-01-000 DATE 1 December 2004 CUSTOMER Crestron Electronics, Inc. TECHNICIAN M, Sheehy TEST EMI SPECIFICATION FCC Rules and Regulations, Part 15 ITEM Waterproof Remote SERIAL NO. 1468551 A PRE-TEST INSPECTION REVEALED: X NO ANOMALIES NO ANOMALIES DUE TO TESTING THE FOLLOWING Photograph Taken? No If Yes, Photo Number N/A LAB FORM NO. 40 REV 11/03 04-0960 Enc 1 Pg 3 PHYSICAL INSPECTION FORM JOB NUMBER 401219-01-000 DATE 1 December 2004 CUSTOMER Crestron Electronics, Inc. TECHNICIAN M, Sheehy TEST EMI SPECIFICATION FCC Rules and Regulations, Part 15 ITEM Waterproof Remote Docking Station SERIAL NO. X100385 A PRE-TEST INSPECTION REVEALED: X NO ANOMALIES NO ANOMALIES DUE TO TESTING THE FOLLOWING Photograph Taken? No If Yes, Photo Number N/A LAB FORM NO. 40 REV 11/03 04-0960 Enc 1 Pg 4 PHYSICAL INSPECTION FORM JOB NUMBER 401219-01-000 DATE 2 December 2004 CUSTOMER Crestron Electronics, Inc. TECHNICIAN M, Sheehy TEST EMI SPECIFICATION FCC Rules and Regulations, Part 15 ITEM Waterproof Remote SERIAL NO. X100419 A POST-TEST INSPECTION REVEALED: X NO ANOMALIES NO ANOMALIES DUE TO TESTING THE FOLLOWING Photograph Taken? No If Yes, Photo Number N/A LAB FORM NO. 40 REV 11/03 04-0960 Enc 1 Pg 5 PHYSICAL INSPECTION FORM JOB NUMBER 401219-01-000 DATE 2 December 2004 CUSTOMER Crestron Electronics, Inc. TECHNICIAN M, Sheehy TEST EMI SPECIFICATION FCC Rules and Regulations,…
