FCC ID: ESCCRMN!!()^ _ July 11, 2014 To whom it may concern, We, Guidant Corporation (a wholly owned subsidiary of Boston Scientific Corporation doing business as Boston Scientific Cardiac Rhythm Management), located at 4100 Hamline Avenue North, Arden Hills, MN 55112-5798, hereby authorize Greg Snyder of PCTest Engineering Laboratory, Inc. to act on our behalf as our agent in the following matters related to the FCC and/or Industry Canada approval of our products: report submittal, related correspondence, the signing of all documents relating to these matters, and any other lawful activity necessary to obtain such certification. Any act carried out by Greg Snyder within the scope of this authorization shall have the same effect as our own. This authorization shall expire 12 months from original date. Sincerely, James Kippola Electrical Engineer Engineering Compliance Boston Scientific Corporation 651-581-3635 [email protected]

Applicant/Grantee Boston Scientific Corporation FCC ID: ESCCRM70514 Section 15.212 Modular Transmitters Request for Modular Approval Request for Limited Modular Approval X Requirements EUT Conditions Comply (Y/N) Single Modular Approval Requirements 1 The radio elements of the modular transmitter must have their own shielding. The physical crystal and tuning capacitors may be located external to the shielded radio elements. The Bluetooth Radio transmitter (in the SCH- I705 tablet) shielding is not changed/affected by placing the tablet into the Boston Scientific Model 3200 Programmer. Y 2 The modular transmitter must have buffered modulation/data inputs (if such inputs are provided) to ensure that the module will comply with Part 15 requirements under conditions of excessive data rates or over-modulation. The Bluetooth Radio transmitter (in the SCH- I705 tablet) modulation/data inputs are not changed/affected by placing the tablet into the Boston Scientific Model 3200 Programmer. Y 3 The modular transmitter must have its own power su pply regulation. The Bluetooth Radio transmitter (in the SCH- I705 tablet) power supply regulation is not changed/affected by placing the tablet into the Boston Scientific Model 3200 Programmer. Y 4 The modular transmitter must comply with the antenna and transmission system requirements of Sections 15.203, 15.204(b) and 15.204(c). The antenna must either be permanently attached or employ a “unique” antenna coupler (at all connections between the module and the antenna, including the cable). The “professional installation” provision of Section 15.203 is not applicable to modules but can apply to limited modular approvals under paragraph (b) of this section. The Bluetooth Radio transmitter (in the SCH- I705 tablet) antenna is not changed/affected by placing the tablet into the Boston Scientific Model 3200 Programmer. Y 5 The modular transmitter must be tested in a stand-alone configuration, i.e. , the module must not be inside another device during testing for compliance with Part 15 requirements. Unless the transmitter module will be battery powered, it must comply with the AC line conducted requirements found in Section 15.207. AC or DC power lines and data input/output lines connected to the module must not contain ferrites, unless they will be marketed with the module (see Section 15.27(a)). The length of these lines shall be the length typical of actual use or, if that length is unknown, at least 10 centimeters to insure that there is no coupling between the case of the module and supporting equipment. Any accessories, peripherals, or support equipment connected to the module during testing shall be unmodified and commercially available (see Section 15.31(i)). The Bluetooth Radio transmitter (in the SCH- I705 tablet) was tested as installed in the 3200 Programmer. N 6 The modular transmitter must be equipped with either a permanently affixed label or must be capable of electronically displaying its FCC identification number. (A) If using a permanently affixed label, the modular transmitter must be labeled with its own FCC identification number, and, if the FCC identification number is not visible when the module is installed inside another device, then the outside of the device into which the module is The Bluetooth Radio transmitter (in the SCH- I705 tablet) is installed in the plastic enclosure of the Boston Scientific Model 3200 Programmer. The plastic enclosure includes a label that includes “Contains FCC ID ESCCRM70514”. The Boston Scientific Model 3200 Programmer label content and location is included in this application for equipment authorization. Y installed must also display a label referring to the enclosed module. This exterior label can use wording such as the following: “Contains Transmitter Module FCC ID: XYZMODEL1” or “Contains FCC ID: XYZMODEL1.” Any similar wording that expresses the same meaning may be used. The Grantee may either provide such a label, an example of which must be included in the application for equipment authorization, or, must provide adequate instructions along with the module which explain this requirement. In the latte r case, a copy of these instructions must be included in the application for equipment authorization. (B) If the modular transmitter uses an electronic display of the FCC identification number, the information must be readily accessible and visible on the modular transmitter or on the device in which it is installed. If the module is installed inside another device, then the outside of the device into which the module is installed must display a label referring to the enclosed module. This exterior label can use wording such as the following: “Contains FCC certified transmitter module(s).” Any similar wording that expresses the same meaning may be used. The user manual must include instructions on how to access the electronic display. A copy of these instructions must be included in the application for equipment authorization. 7 The modular transmitter must comply with any specific rules or operating requirements that ordinarily apply to a complete transmitter and the manufacturer must provide adequate instructions along with the module to explain any such requirements. A copy of these instructions must be included in the application for equipment authorization. The Bluetooth Radio transmitter (in the SCH- I705 tablet) compliance to specific rules and operating requirements is not changed/affected by placing the tablet into the Boston Scientific Model 3200 Programmer. The Boston Scientific Model 3200 Programmer operating instructions are included in this application for equipment authorization. Y 8 The modular transmitter must comply with any applicable RF exposure requirements in its final configuration. The Bluetooth Radio transmitter (in the SCH- I705 tablet) compliance RF exposure requirements is not changed/affected by placing the tablet into the Boston Scientific Model 3200 Programmer. Y A limi…

Text truncated - open the document above for the full version.

Boston Scientific Corporation Boston Scientific Corporation 4100 Hamline Ave. N. Arden Hills, MN 55112 Date: August 13, 2014 Federal Communications Commission Authorization and Evaluation Division 7435 Oakland Mills Road, Columbia, MD 21046 RE: Request of Confidentiality for FCC ID: ESCCRM70514 To Whom It May Concern: Pursuant to Sections 0.457 and 0.459 of the Commission’s Rules (CFR 47), and Section 552 (b) (4) of the Freedom of Information Act, Boston Scientific Corporation hereby requests confidentiality and treatment of certain information accompanying this application. The materials contain trade secrets and proprietary information not customarily released to the public. The public disclosure of these matters might be harmful to the Applicant and provide unjustified benefits to its competitors. We are also hereby request Short-Term Confidentiality for 180 days after the grant as outlined in Public Notice DA 04- 1705. This provision will give Boston Scientific Corporation temporary confidentiality of commercially sensitive information prior to product release. The requested Permanent and Temporary Confidential exhibits are listed as follows: PERMANENT AND SHORT-TERM CONFIDENTIAL LIST Exhibit Description PERMANENT 1 Block Diagram 2 Operational Descriptions 3 Schematics SHORT-TERM CONFIDENTIAL 4 External Photos 5 Internal Photos 6 Test-Setup Photos 7 User’s Manual The Applicant understands that pursuant to Rule 0.457, disclosure of this application and all accompanying documentations, where applicable, will not be made public before the date of the Grant for this application. Sincerely, Peter Musto Electrical Engineer Boston Scientific Corporation

FCC ID: ESCCRMN!!()^ _ Boston Scientific Corporation CONFIDENTIAL Date: 9/17/2014 Re: Bluetooth Limited Modular Approval: Internal and External Photos The Guidant Corporation (a wholly owned subsidiary of Boston Scientific Corporation doing business as Boston Scientific Cardiac Rhythm Management) Model 3200 Emblem S-ICD Programmer includes an embedded Samsung Model SCH-I705 tablet computer. The S-ICD system uses the Bluetooth radio of the tablet computer for connectivity with an external printer. This authorization request is for a “Limited Modular Approval” of the embedded Bluetooth radio for use in the Model 3200 Programmer. The following pages include internal and external photos of the Model 3200 Programmer. Boston Scientific Corporation CONFIDENTIAL Figure 1 Model 3200 Programmer - Front View Figure 2 Model 3200 Programmer - Back View (for reference only) Note: The labels shown are prototypes only. Label information is shown in the ID Label and Location Exhibit. Boston Scientific Corporation CONFIDENTIAL Figure 3 Model 3200 Programmer - Left View Figure 4 Model 3200 Programmer - Right View Boston Scientific Corporation CONFIDENTIAL Figure 5 Model 3200 Programmer - Top View Figure 6 Model 3200 Programmer - Bottom View Boston Scientific Corporation CONFIDENTIAL Figure 7 Model 3200 Programmer – Internal (Top) Figure 8 Model 3200 Programmer – Internal (Bottom) Boston Scientific Corporation CONFIDENTIAL Figure 9 Model 3200 Programmer – Power Adapter (top) Figure 10 Model 3200 Programmer – Power Adapter (bottom) Boston Scientific Corporation The Model 3200 Programmer label locations is shown below: Figure 2 BSC Model 3200 Programmer Label Location (Reference Only) The 3200 Programmer label materials are defined as: Description Part Number Manufacturer Label Material 7879FL 3M Industrial Tape and Specialties Division Overlaminating Film 7737FL 3M Industrial Tape and Specialties Division Label Adhesive #350 3M Industrial Tape and Specialties Division Label Color: Black text with white fill Model 3200 Label Location

FCC ID: ESCCRMN!!()^ _ Boston Scientific Corporation Date: 8/13/2014 Re: Bluetooth Limited Modular Approval: Label and Location The Guidant Corporation (a wholly owned subsidiary of Boston Scientific Corporation doing business as Boston Scientific Cardiac Rhythm Management) Model 3200 Emblem S-ICD Programmer includes an embedded Samsung Model SCH-I705 tablet computer. The S-ICD system uses the Bluetooth radio of the tablet computer for connectivity with an external printer. This authorization request is for a “Limited Modular Approval” of the embedded Bluetooth radio for use in the Model 3200 Programmer. The following information describes the FCC ID label information for this product approval. The Model 3200 programmer also includes a MedRadio band transmitter that is approved separately under FCC ID SDYCHI2020. The Model 3200 Programmer label is shown below. Figure 1 BSC Model 3200 Programmer Label

Samsung Electronics Co., Ltd. FCC ID: A3LSCHI705 Model: SCH-I705 Internal Photos EUT Type: Portable Tablet Computer Page 1 of 8 © 2012 PCTEST Engineering Laboratory Inc. INTERNAL PHOTOGRAPHS Samsung Electronics Co., Ltd. FCC ID: A3LSCHI705 Model: SCH-I705 Internal Photos EUT Type: Portable Tablet Computer Page 2 of 8 © 2012 PCTEST Engineering Laboratory Inc. Samsung Electronics Co., Ltd. FCC ID: A3LSCHI705 Model: SCH-I705 Internal Photos EUT Type: Portable Tablet Computer Page 3 of 8 © 2012 PCTEST Engineering Laboratory Inc. Samsung Electronics Co., Ltd. FCC ID: A3LSCHI705 Model: SCH-I705 Internal Photos EUT Type: Portable Tablet Computer Page 4 of 8 © 2012 PCTEST Engineering Laboratory Inc. Samsung Electronics Co., Ltd. FCC ID: A3LSCHI705 Model: SCH-I705 Internal Photos EUT Type: Portable Tablet Computer Page 5 of 8 © 2012 PCTEST Engineering Laboratory Inc. Samsung Electronics Co., Ltd. FCC ID: A3LSCHI705 Model: SCH-I705 Internal Photos EUT Type: Portable Tablet Computer Page 6 of 8 © 2012 PCTEST Engineering Laboratory Inc. Samsung Electronics Co., Ltd. FCC ID: A3LSCHI705 Model: SCH-I705 Internal Photos EUT Type: Portable Tablet Computer Page 7 of 8 © 2012 PCTEST Engineering Laboratory Inc. Samsung Electronics Co., Ltd. FCC ID: A3LSCHI705 Model: SCH-I705 Internal Photos EUT Type: Portable Tablet Computer Page 8 of 8 © 2012 PCTEST Engineering Laboratory Inc.

FCC ID: ESCCRM70514 RF EXPOSURE REPORT Reviewed by: Quality Manager Document S/N: Test Dates: DUT Type: Page 1 of 3 0Y1411042071-R2.ESC 12/17/14 Portable Tablet © 2014 PCTEST Engineering Laboratory, Inc. REV 14.0 M 07/21/2014 Applicant Name: Date of Testing: Boston Scientific Corporation 12/17/2014 4100 Hamline Avenue North M/S 10-203 Test Site/Location: St. Paul, Minnesota 55112-5798, USA PCTEST Lab, Columbia, MD, USA Document Serial No.: 0Y1411042071-R2.ESC FCC ID: ESCCRM70514 APPLICANT: BOSTON SCIENTIFIC CORPORATION DUT Type: Portable Tablet Application Type: Certification FCC Rule Part(s): Model(s): CFR §2.1093 3200 Note: This revised test report (S/N: 0Y1411042071-R2.ESC) supersedes and replaces the previously issued test report on the same subject DUT for the same type of testing indicated. Please discard or destroy the previously issued tests report(s) and dispose of accordingly. I attest to the accuracy of data. All measurements reported herein were performed by me or were made under my supervision and are correct to the best of my knowledge and belief. I assume full responsibility for the completeness of these measurements and vouch for the qualifications of all persons taking them. Test results reported herein relate only to the item(s) tested. The SAR Tick is an initiative of the Mobile Manufacturers Forum (MMF). While a product may be considered eligible, use of the SAR Tick logo requires an agreement with the MMF. Further details can be obtained by emailing: [email protected]. PCTEST ENGINEERING LABORATORY, INC. 7185 Oakland Mills Road, Columbia, MD 21046 USA Tel. +1.410.290.6652 / Fax +1.410.290.6654 http://www.pctestlab.com RF EXPOSURE REPORT FCC ID: ESCCRM70514 RF EXPOSURE REPORT Reviewed by: Quality Manager Document S/N: Test Dates: DUT Type: Page 2 of 3 0Y1411042071-R2.ESC 12/17/14 Portable Tablet © 2014 PCTEST Engineering Laboratory, Inc. REV 14.0 M 07/21/2014 TABLE OF CONTENTS 1 DEVICE UNDER TEST ................................................................................................................... 3 FCC ID: ESCCRM70514 RF EXPOSURE REPORT Reviewed by: Quality Manager Document S/N: Test Dates: DUT Type: Page 3 of 3 0Y1411042071-R2.ESC 12/17/14 Portable Tablet © 2014 PCTEST Engineering Laboratory, Inc. REV 14.0 M 07/21/2014 1 DEVICE UNDER TEST 1.1 Device Overview BluetoothData2402 - 2480 MHz Band & ModeTx FrequencyOperating Modes 1.2 Nominal and Maximum Output Power Specifications This device operates using the following maximum and nominal output power specifications. Maximum Nominal Mode / Band Modulated Average (dBm) Bluetooth 10.50 10.00 1.3 DUT Antenna Locations Exact antenna dimensions and separation distances are shown in the Technical Descriptions in the FCC Filing. 1.4 SAR Test Exclusions Per FCC KDB 447498 D01v05, the 1g SAR exclusion threshold for distances <50mm is defined by the following equation: Based on the maximum conducted power of Bluetooth (rounded to the nearest mW) and the antenna to user separation distance, Bluetooth SAR was not required; [(11/13.2)* √2.480] = 1.3 < 3.0. Per KDB Publication 447498 D01v05, the maximum power of the channel was rounded to the nearest mW before calculation. © 2014 PCTEST Engineering Laboratory, Inc. APPENDIX A: SAR TEST DATA PCTEST ENGINEERING LABORATORY, INC. DUT: ESCCRM70514; Type: Bluetooth Module Integrated Into Portable Tablet; Serial: 1103 Communication System: UID 0, Bluetooth; Frequency: 2480 MHz; Duty Cycle: 1:1 Medium: 2450 Body, Medium parameters used (interpolated): f = 2480 MHz; σ = 2.064 S/m; εr = 51.567; ρ = 1000 kg/m3 Phantom section: Flat Section; Space: 0.0 cm Test Date: 11-06-2014; Ambient Temp: 23.8°C; Tissue Temp: 22.8°C Probe: ES3DV3 - SN3332; ConvF(4.31, 4.31, 4.31); Calibrated: 9/18/2014; Sensor-Surface: 3mm (Mechanical Surface Detection) Electronics: DAE4 Sn1323; Calibrated: 9/17/2014 Phantom: SAM 5.0 front; Type: QD000P40CD; Serial: TP:-1648 Measurement SW: DASY52, Version 52.8 (8); SEMCAD X Version 14.6.10 (7331) Mode: Bluetooth, Body SAR, Ch 78, 1 Mbps, Front Side Area Scan (10x13x1): Measurement grid: dx=12mm, dy=12mm Zoom Scan (7x7x7)/Cube 0: Measurement grid: dx=5mm, dy=5mm, dz=5mm Reference Value = 5.721 V/m; Power Drift = 0.06 dB Peak SAR (extrapolated) = 0.146 W/kg SAR(1 g) = 0.059 W/kg A1 © 2014 PCTEST Engineering Laboratory, Inc. APPENDIX B: SYSTEM VERIFICATION PCTEST ENGINEERING LABORATORY, INC. DUT: Dipole 2450 MHz; Type: D2450V2; Serial: 797 Communication System: UID 0, CW; Frequency: 2450 MHz; Duty Cycle: 1:1 Medium: 2450 Body, Medium parameters used: f = 2450 MHz; σ = 2.025 S/m; ε r = 51.714; ρ = 1000 kg/m 3 Phantom section: Flat Section; Space: 1.0 cm Test Date: 11-06-2014; Ambient Temp: 23.8°C; Tissue Temp: 22.8°C Probe: ES3DV3 - SN3332; ConvF(4.31, 4.31, 4.31); Calibrated: 9/18/2014; Sensor-Surface: 3mm (Mechanical Surface Detection) Electronics: DAE4 Sn1323; Calibrated: 9/17/2014 Phantom: SAM 5.0 front; Type: QD000P40CD; Serial: TP:-1648 Measurement SW: DASY52, Version 52.8 (8); SEMCAD X Version 14.6.10 (7331) 2450 MHz System Verification Area Scan (8x9x1): Measurement grid: dx=12mm, dy=12mm Zoom Scan (7x7x7)/Cube 0: Measurement grid: dx=5mm, dy=5mm, dz=5mm Input Power = 20.0 dBm (100 mW) Peak SAR (extrapolated) = 10.5 W/kg SAR(1 g) = 5.11 W/kg Deviation = 3.44% 0 dB = 6.66 W/kg = 8.23 dBW/kg B1 © 2014 PCTEST Engineering Laboratory, Inc. APPENDIX C: PROBE CALIBRATION FCC ID: ESCCRM70514 SAR EVALUATION REPORT Reviewed by: Quality Manager Test Dates: DUT Type: APPENDIX D: Page 1 of 1 11/06/14 Bluetooth Module Integrated Into Portable Tablet © 2014 PCTEST Engineering Laboratory, Inc. REV 14.0 M 07/21/2014 APPENDIX D: SAR TISSUE SPECIFICATIONS Measurement Procedure for Tissue Verification: 1) The network analyzer and probe system was configured and calibrated. 2) The probe was immersed in the tissue. The tissue was placed in a nonmetallic container. Trapped air bubbles beneath the flange were minimized by placing the probe at a slight angle. 3) The complex admitt…
