EUGDR-135TVHF Scanning Receiver

VHF FM Mobile Transceiver DR-135T DR-135E Instruction Manual Thank you for purchasing your new Alinco transceiver. This instruction manual contains important safety and operating instructions. Please read this manual carefully before using the product and keep it for the future reference. NOTICE This equipment has been tested and found to comply with the limits for a Class B digital device, pursuant to part 15 of the FCC Rules. These limits are designed to provide reasonable protection against harmful interference in a residential installation. This equipment generates, uses, and can radiate radio frequency energy and, if not installed and used in accordance with the instruction manual, may cause harmful interference to radio communi- cations. However, there is no guarantee that interference will not occur in a particular installation. If this equipment does cause harmful interference to radio or television reception, which can be deter- mined by turning the equipment off and on, the user is encouraged to try to correct the interference by one or more of the following measures: • Reorient or relocate the receiving antenna. • Increase the separation between the equipment and receiver. • Connect the equipment into an outlet on a circuit different from that to which the receiver is con- nected. • Consult the dealer or an experienced radio/TV technician for help. Tested to Comply With FCC Standards FOR HOME OR OFFICE USE Information in this document is subject to change without notice or obligation. All brand names and trademarks are the property of their respective owners. Alinco cannot be liable for pictorial or typo- graphical inaccuracies. Some parts, options and/or accessories are unavailable in certain areas. Changes or modifications not expressly approved by the party responsible for compliance could void the user's authority to operate the equipment. Copyright @ 2000 All rights reserved. No part of this document may be reproduced, copied, translated or transcribed in any form or by any means without the prior written permission of Alinco. Inc., Osaka, Japan. English Edition Printed in Japan. 1 Contents Before operating the transceiver...................................... 3 Introduction........................................................................ 3 1. New and Innovative Features........................................ 4 2. Standard Accessories.................................................... 5 3. Initial Installation............................................................ 6 For a base station set up ....................................................................... 6 For a mobile station set up .................................................................... 7 External power supply control & Power lamp functions ......................... 8 Power supply voltage display function ................................................... 8 4. Part Names and Functions............................................ 9 Front Panel ............................................................................................ 9 Rear Panel ........................................................................................... 10 Display ................................................................................................. 11 Microphone .......................................................................................... 12 5. Basic Operations.......................................................... 13 Turning the unit on and off ................................................................... 13 Audio Volume level setting ................................................................... 13 Squelch level setting ............................................................................ 13 VFO mode ........................................................................................... 14 [Change frequency by the channel step] ................................ 14 [Change frequency by 1 MHz step] ........................................ 14 Changing the channel step .................................................................. 15 REPEATER (DUPLEX) Operation ....................................................... 15 CTCSS / DCS setting .......................................................................... 16 Memory Mode ...................................................................................... 17 [Memory programming] ........................................................... 17 [Programmable data in the memory channel] ......................... 18 CALL mode .......................................................................................... 19 To receive signals ................................................................................ 19 To transmit ........................................................................................... 20 6. Parameter Setting Mode.............................................. 21 Channel Step setting ........................................................................... 22 Scan Type ............................................................................................ 22 Beep Sound ......................................................................................... 22 Time-Out-Timer ................................................................................... 23 TOT Penalty ......................................................................................... 23 APO - Auto Power OFF ....................................................................... 24 Tone-Burst-Frequency ......................................................................... 24 Busy-Channel-Lock-Out ...................................................................... 24 Theft Alarm .......................................................................................... 24 Alphanumeric Tag ................................................................................ 25 Dimmer ..…

Text truncated - open the document above for the full version.

COMPANY NAME: ALINCO, INC. EUT: DJ-135T CLIENT REFERENCE NUMBER: QRTL00- WORK ORDER NUMBER: 2000197 FCC ID: EUG DJ-135T Scanning Receiver Certification Report Page 35 of 36 APPENDIX K: AGENT AUTHORIZATION LETTER COMPANY NAME: ALINCO, INC. EUT: DJ-135T CLIENT REFERENCE NUMBER: QRTL00- WORK ORDER NUMBER: 2000197 FCC ID: EUG DJ-135T Scanning Receiver Certification Report Page 36 of 36

COMPANY NAME: ALINCO, INC. EUT: DR-135T C LIENT REFERENCE NUMBER: QRTL00- W ORK ORDER NUMBER: 2000197 FCC ID: EUG DR-135T Scanning Receiver Certification Report Page 22 of 36 APPENDIX A: LABEL INFORMATION COMPANY NAME: ALINCO, INC. EUT: DR-135T C LIENT REFERENCE NUMBER: QRTL00- W ORK ORDER NUMBER: 2000197 FCC ID: EUG DR-135T Scanning Receiver Certification Report Page 23 of 36 F IGURE 1: FCC ID F IGURE 2: LOCATION OF LABELS ON EUT Alinco, Inc. DR-135T FCC ID: EUG DR-135T This device complies with part 15 of the FCC Rules. Operation is subject to the following two conditions: 1) This device may not cause harmful interference, and 2) this device must accept any interference received, including interference that may cause undesired operation. WARNING: Modification of this device to receive cellular radio-telephone service signals is prohibited under FCC rules and federal law.

COMPANY NAME: ALINCO, INC. EUT: DR-135T CLIENT REFERENCE NUMBER: QRTL00- WORK ORDER NUMBER: 2000197 / 2000373 FCC ID: EUG DR-135T Scanning Receiver Certification Report Page 23 of 50 FIGURE 1: FCC ID FIGURE 2: LOCATION OF LABELS ON EUT Alinco, Inc. DR-135T Industry Canada: XXXXX FCC ID: EUGDR-135T This device complies with part 15 of the FCC Rules. Operation is subject to the following two conditions: 1) This device may not cause harmful interference, and 2) this device must accept any interference received, including interference that may cause undesired operation. WARNING: Modification of this device to receive cellular radio-telephone service signals is prohibited under FCC rules and federal law.

COMPANY NAME: ALINCO, INC. EUT: DR-135T C LIENT REFERENCE NUMBER: QRTL00- W ORK ORDER NUMBER: 2000197 FCC ID: EUG DR-135T Scanning Receiver Certification Report Page 19 of 36 4.1 38dB R EJECTION TEST A signal generator was connected to the receiver under test, and the output of the receiver was connected to an audio analyzer. A FM signal was applied to the receiver antenna input with a 1kHz tone modulated at 8 kHz deviation, and adjusted with the audio analyzer to produce a 12 dB SINAD. This was done across the receiver bands to determine a reference level. The reference level used was that with the highest sensitivity in all of the bands. The output of the signal generator was then adjusted to a level 40 dB above the reference level established and set to a low, medium and high frequency in both the mobile and base cellular bands. (mobile = 824.04 MHz through 848.97 MHz, base = 869.04 MHz through 893. 97 MHz). The squelch of the receiver was then set to a minimum threshold level and scanning began from the lowest to the highest channel. Whenever the receiver stopped and “unsquelched” that frequency was noted as a response. After all the frequencies of responses were noted, the signal generator was set to measure the sensitivity at each of these response frequencies. This measurement was the reference sensitivity for the particular received frequency measured. The audio analyzer measurement was used to measure the 12 dB SINAD and that is the spurious value. The difference between the reference sensitivity and the spurious value is the rejection ratio and must be at least 38 dB. Frequencies used on the Signal Generator were 824.04, 836.505, 848.97 MHz for the Mobile and 869.04, 881.505, 893.97 MHz for the Base. Frequencies used on the Signal Generator were 824.04, 836.505, 848.97 MHz for the Mobile and 869.04, 881.505, 893.97 MHz for the Base. The DR-135T unit reference level used was –75.2 dBm from the signal generator, this was determined from the highest sensitivity from 136 MHz at –115.2 dBm measurement of 12dB SINAD. The DR-135T unit reference level used was –79.7 dBm from the signal generator, this was determined from the highest sensitivity from 118 MHz at –119.7 dBm measurement of 12 dB SINAD. The DJ-135T unit was scanned from 118-135.995 and from 136-173.995 MHz for all six channels (manufacturers spec.) Conclusion: The device is compliant with the 38 dB rejection test. Signals which were noted as responses were checked with the signal generator off and if they still existed as a response were determined as ambient signals and removed from the response list. Only ambient signals un-squelched the receiver; therefore, no signals were available for 38 dB rejection test requirements. Marconi Signal Generator (1kHz tone/8kHz FM deviation) Antenna Input EUT Audio out HP 8903B Audio Analyzer External 13VDC power adapter COMPANY NAME: ALINCO, INC. EUT: DR-135T C LIENT REFERENCE NUMBER: QRTL00- W ORK ORDER NUMBER: 2000197 FCC ID: EUG DR-135T Scanning Receiver Certification Report Page 20 of 36 38 dB rejection setup

Engineering and Testing for EMC and Safety Compliance 360 Herndon Parkway, Suite 1400 Herndon, VA 20170 Phone: 703-689-0368; Fax: 703-689-2056; Metro: 703-471-6441  APPLICATION FOR FCC CLASS B CERTIFICATION SCANNING RECEIVER Alinco, Inc. 438 Amapola Ave. Suite 130 Torrance, CA 90501 MODEL: DR-135T FCC ID: EUG DR-135T July 29, 2000 This report concerns (check one): Original Grant: X Class II Change: Equipment Type: Scanning Receiver Deferred grant requested per 47 CFR 0.457 (d) (1) (ii)? Yes: No: X If yes, defer until: Company name agrees to notify the Commission by: (date) of the intended date of announcement of the product so that the grant can be issued on that date. Transition Rules Request per 15.37? Yes: No: X If no, assumed Part 15, subpart B for unintentional radiators - the new 47 CFR. [10-1-90 Edition] provision. I, the undersigned, hereby declare that the equipment tested and referenced in this report conforms to the identified standard(s) as described above. No modifications were made during testing to the equipment in order to achieve compliance with these standards. Furthermore, there was no deviation from, additions to or exclusions from the ANSI C63.4 test methodology. REPORT PREPARED BY: Supervising Engineer: Desmond A. Fraser EMC Emission Technician: K. Franck Schuppius Administrative Writer: Melissa Fleming Rhein Tech Laboratories, Inc. Document Number: 2000197 No part of this report may be reproduced without the full written approval of Rhein Tech Laboratories, Inc. COMPANY NAME: ALINCO, INC. EUT: DR-135T C LIENT REFERENCE NUMBER: QRTL00- W ORK ORDER NUMBER: 2000197 FCC ID: EUG DR-135T Scanning Receiver Certification Report Page 3 of 36 TABLE OF CONTENTS 1.0 GENERAL INFORMATION....................................................................................................................4 1.1 STANDARDS REFERENCED.....................................................................................................................4 1.2 BASIC INFORMATION ON THE EUT..........................................................................................................4 1.3 MODIFICATIONS.....................................................................................................................................5 1.4 RELATED SUBMITTAL(S)/GRANT(S)........................................................................................................5 1.5 TEST METHODOLOGY.............................................................................................................................5 1.6 TEST FACILITY.......................................................................................................................................5 2.0 SYSTEM TEST CONFIGURATION.......................................................................................................6 2.1 JUSTIFICATION.......................................................................................................................................6 2.2 EXERCISING THE EUT............................................................................................................................6 2.3 TEST SYSTEM DETAILS..........................................................................................................................6 2.5 EMISSIONS EQUIPMENT LIST..................................................................................................................7 2.6 RADIATED TEST METHODOLOGY............................................................................................................8 3.0 CONDUCTED EMISSION DATA...........................................................................................................9 4.0 RADIATED EMISSION DATA.............................................................................................................13 4.1 38DB REJECTION TEST.......................................................................................................................19 5.0 CONFORMANCE STATEMENT.........................................................................................................21 APPENDIX LISTING APPENDIX A: LABEL INFORMATION..........................................................................................................22 APPENDIX B: PRODUCT DESCRIPTION....................................................................................................24 APPENDIX C: SCHEMATICS........................................................................................................................25 APPENDIX D: BLOCK DIAGRAM OF DJ-196T............................................................................................26 APPENDIX E: EXTERNAL PHOTOS............................................................................................................27 APPENDIX F: INTERNAL PHOTOS..............................................................................................................28 APPENDIX G: SERVICE MANUAL................................................................................................................29 APPENDIX H: INSTRUCTION MANUAL......................................................................................................30 APPENDIX I: TEST PICTURES.....................................................................................................................31 APPENDIX J: ATTESTATION LETTER........................................................................................................34 APPENDIX K: AGENT AUTHORIZATION LETTER.....................................................................................35 F IGURE INDEX F IGURE 1: FCC ID AND DOC LABEL................................................................................................................23 FIGURE 2: LOCATION OF LABELS ON EUT...............................................................................................…

Text truncated - open the document above for the full version.

COMPANY NAME: ALINCO, INC. EUT: DJ-135T CLIENT REFERENCE NUMBER: QRTL00- WORK ORDER NUMBER: 2000197 FCC ID: EUG DJ-135T Scanning Receiver Certification Report Page 20 of 36 38 dB rejection setup
