EZSDEI1510Transmitter

ONE - WA Y F M A U T OMA T IC/MA NUA L T R A NS MI SSION R E MOT E S T A R T E R Doc#: 120709 Rev:1.4 © © 2012 D irected. All Rights R es erved Model: ASRF-1510 User G uide Designed & Engin eered in Canada P. 2 User Guide WARNING! It is the responsibility of the vehicle operator to ensure that their vehicle is parked in a safe and responsible manner. 1. a) Manual Transmission: When leaving the vehicle, it is the user’s responsibility to ensure that the gearshift lever is in the NEUTRAL position and the parking brake is engaged in order to avoid accidents upon remote starting. b) Automatic Transmission: When leaving the vehicle, it is the user’s responsibility to ensure that the gearshift lever is in “Park” in order to avoid accidents upon remote starting. (Note: Make sure that the automatic vehicle cannot start in "Drive".) 2. It is the user's responsibility to ensure that the remote starter is disabled or put into valet mode before servicing. INDUSTRY CANADA USER NOTICE Operation is subject to the following two conditions: (1) this device may not cause interference, and (2) this device must accept any interference, including interference that may cause undesired operation of the device. To reduce potential radio interference to other users, the antenna type and its gain should be so chosen that the equivalent isotropically radiated power (EIRP) is not more than that required for successful communication. NOTE: The manufacturer is not responsible for any radio or TV interference caused by unauthorized modifications to this equipment. Such modifications could void the user's authority to operate the equipment. User Guide P.3 Table of Contents Government regulations .................................................................................... 4 Introduction with SmartStart™ ........................................................................ 5 Using the Remote Control ................................................................................. 6 Vehicle Presets ................................................................................................... 7 Heater .............................................................................................................. 7 Windshield Wipers & Radio & Headlights ........................................................ 7 Arming and disarming the starter kill (if installed) .......................................... 7 Remote-Starting Your Vehicle ........................................................................... 9 Setting Your Vehicle in to Ready Mode ........................................................... 9 Remote-starting ............................................................................................. 10 Driving Off ...................................................................................................... 10 Remote Starter Features .................................................................................. 11 Remote Door Locks ....................................................................................... 11 Remote Trunk Release .................................................................................. 11 Idle Mode ....................................................................................................... 12 Valet Mode .................................................................................................... 13 Panic Mode .................................................................................................... 14 Quick Lockout TM ............................................................................................ 15 Cold Weather Mode ....................................................................................... 15 Extended Run Time ....................................................................................... 16 Disable/Enable LED flashing ......................................................................... 16 Constant output ............................................................................................. 16 Advanced Features: Installation-programmable Options ............................. 17 Ignition-controlled Door Locks ....................................................................... 17 Secure Lock ................................................................................................... 17 Safe Start ....................................................................................................... 17 Engine Run Time ........................................................................................... 18 Turbo Mode ................................................................................................... 18 “Home Valet TM ” Mode .................................................................................... 19 AUX 1 ............................................................................................................ 20 Horn Chirp Timing ......................................................................................... 20 Multi-car Operation ........................................................................................ 20 AUX 2 ............................................................................................................ 21 OEM-Style Alarm ........................................................................................... 21 Intrusion Codes via horn ................................................................................ 21 Troubleshooting Poor Transmitting Range ................................................... 22 Diagnostics – Parking Light Flash Table........................................................ 23 Battery Replacement ........................................................................................ 24 P.4 User Guide Government regulations This device complies with part 15 of the FCC Rules. Operation is subject to the following two conditions: (1) This device may not…

Text truncated - open the document above for the full version.

SCS-F18: Project and Product Certification Representative Authorization Letter Page 1 of 2 Rev 3.0 775 Montague Expressway Milpitas, CA 95035 Tel: 408-526-1188 Fax: 408-526-1088 Email: [email protected] Project and Product Certification Representative Authorization Letter Revision History Reason for Amendment (current / obsolete) From To Approved Date Initial Release (obsolete) 1.0 1.0 Nov-14-2006 Revised wording (obsolete) 1.0 2.0 Sept–25-2007 Updated company template (current) 2.0 3.0 Jan-31-2012 SCS-F18: Project and Product Certification Representative Authorization Letter Page 2 of 2 Rev 3.0 September 4, 2012 To: SIEMIC, INC. 775 Montague Expressway, Milpitas, CA 95035 USA Dear Sir/Madam, Re: Project and Product Certification Representative Authorization Letter We, DEI Headquarters, Inc. hereby authorize SIEMIC, INC. to act as a Certification Body for certifying for the following project(s): Product: Transmitter Model No.: ASRF-1510; GSRF-1510 FCC ID: EZSDEI1510 We affirm that between SIEMIC and DEI Headquarters, any difference in understanding, including test plan, measurement methods, applicable standards and relevant procedures and processes have been resolved prior to commencement of testing activities. Sincerely, Minas Minassian Director of Engineering [email protected] Directed Electronics 1 Viper Way Vista, CA 92081 Ph: (760) 599-1331 Fax: (760)598-6400 www.directed.com

SCS-F19: Confidentiality Request Letter Page 1 of 2 Rev 3.0 775 Montague Expressway Milpitas, CA 95035 Tel: 408-526-1188 Fax: 408-526-1088 Email: [email protected] Confidentiality Request Letter Revision History Reason for Amendment (current / obsolete) From To Approved Date Initial Release (obsolete) 1.0 1.0 Nov-14-2006 Adding CFR 2.459 (obsolete) 1.0 2.0 August – 11 - 2008 Updated company template & Added text box (current) 2.0 3.0 Jan-31-2012 SCS-F19: Confidentiality Request Letter Page 2 of 2 Rev 3.0 September 4, 2012 To: Federal Communications Commission Authorization and Evaluation Division 7435 Oakland Mills Road Columbia, MD Subject: Permanent Confidentiality Request for FCC ID: EZSDEI1510 We hereby request confidential treatment of information accompanying this application as outlined below: - e.g. Block Diagram - e.g. Schematics - e.g. Operational Description The above materials contain trade secrets and proprietary information not customarily released to the public. The public disclosure of these materials may be harmful to the applicant and provide unjustified benefits to its competitors. The applicant understands that pursuant to Section 0.457 & 0.459 of the Rules, disclosure of this application and all accompanying documentation will not be made before the date of the Grant for this application. Sincerely, Minas Minassian Director of Engineering [email protected] Directed Electronics 1 Viper Way Vista, CA 92081 Ph: (760) 599-1331 Fax: (760)598-6400 www.directed.com

Power of Attorney Date: 2012/09/20 To whom it may concern Dear Sir / Madam, I hereby have entrusted the following person to be a proxy regarding application for FCC Certification. I am therefore responsible for the contents of the application. Project Information Product : Transmitter Model No. : ASRF-1510; GSRF-1510 FCC ID : EZSDEI1510 Company Name : Interocean EMC Technology Corp. Company Address : No., 5-2, Lin 1, Tin-Fu, Lin-Kou Dist., New Taipei City, Taiwan 244, R.O.C. Name : Jerry Liu Job Title : Manager Applicant’s Company Name : DEI Headquarters, Inc. Company Address : 1 Viper Way, Vista, CA 92081 Signature : Name : Minas Minassian Job Title : Director of Engineering E-mail : [email protected]

Report No.：12A052305R-FR FCC ID： EZSDEI1510 Page 23 of 27 Interocean EMC Technology Corp. Test Report 7 Photographs of EUT Front View of EUT Rear View of EUT Report No.：12A052305R-FR FCC ID： EZSDEI1510 Page 24 of 27 Interocean EMC Technology Corp. Test Report Label

Report No.：12A052305R-FR FCC ID： EZSDEI1510 Page 25 of 27 Interocean EMC Technology Corp. Test Report Inner View of EUT Antenna Location Report No.：12A052305R-FR FCC ID： EZSDEI1510 Page 26 of 27 Interocean EMC Technology Corp. Test Report Component View of PCB Board Solder View of PCB Board Report No.：12A052305R-FR FCC ID： EZSDEI1510 Page 27 of 27 Interocean EMC Technology Corp. Test Report Front View of Battery Rear View of Battery

Report No.：12A052305R-FR FCC ID： EZSDEI1510 Page 1 of 27 Interocean EMC Technology Corp. Test Report CFR 47 FCC Part 15.231 TEST REPORT Product： Transmitter Trade Name： N/A Model Number： ASRF-1510; GSRF-1510 FCC ID： EZSDEI1510 Prepared for DEI Headquarters, Inc. One Viper Way, Vista CA 92081 Prepared by Interocean EMC Technology Corp. No. 5-2, Lin 1, Tin-Fu, Lin-Kou Dist., New Taipei City, Taiwan 244, R.O.C. TEL.: +886 2 2600 6861 FAX.: +886 2 2600 6859 Remark: The test report consists of 27 pages in total. It shall not be reproduced except in full, without the written approval of IETC. This document may be altered or revised by IETC only, and shall be noted in the revision section of the document. The test result in the report is only subjected to the test sample. Report No.：12A052305R-FR FCC ID： EZSDEI1510 Page 2 of 27 Interocean EMC Technology Corp. Test Report Statement of Compliance Applicant: DEI Headquarters, Inc. Manufacturer: Nutek Corporation Product: Transmitter Model No.: ASRF-1510; GSRF-1510 Tested Power Supply: 6Vdc Battery Date of Final Test: Jun.08, 2012 Revision of Report: Rev. 05 Configuration of Measurements and Standards Used： FCC Rules and Regulations Part 15 Subpart C 1. The result of the testing report relate only to the item tested. 2. The testing report shall not be reproduced expect in full, without the written approval of IETC. Report Issued: 2012/08/21 Project Engineer: Approved: Elli Chang Jerry Liu Report No.：12A052305R-FR FCC ID： EZSDEI1510 Page 3 of 27 Interocean EMC Technology Corp. Test Report Table of Contents 1 Summary of Measurement 4 2 General Information 5 2.1 Description of Equipment Under Test 5 2.2 Details of tested peripheral equipment 6 2.3 Test Facility 7 3 Test specifications 8 3.1 Test standard 8 3.2 Operation mode 8 3.3 Test Equipment 9 4 Radiated emission test 10 4.1 Limits 10 4.2 Calculation of Average Factor 11 4.3 Configuration of Measurement 15 4.4 Test Procedure 15 4.5 Test Result 15 5 Emission bandwidth 19 5.1 Limits 19 5.2 Test Result 19 6 Photographs of Test 21 6.1 Radiated Emission Measurement 21 7 Photographs of EUT 23 Report No.：12A052305R-FR FCC ID： EZSDEI1510 Page 4 of 27 Interocean EMC Technology Corp. Test Report 1 Summary of Measurement Report Clause Test Parameter Reference Document CFR47 Part15 Results 4 Timing requirement §15.231(a) Pass 4 Radiated Emission §15.231(b), 15.209 Pass 5 Emission bandwidth §15.231(c) Pass Report No.：12A052305R-FR FCC ID： EZSDEI1510 Page 5 of 27 Interocean EMC Technology Corp. Test Report 2 General Information 2.1 Description of Equipment Under Test Product : Transmitter Model Number : ASRF-1510; GSRF-1510 Applicant : DEI Headquarters, Inc. One Viper Way, Vista CA 92081 Manufacturer : Nutek Corporation No.167, Lane 235, Bauchiau Rd., Xindian District, New Taipei City 23145, Taiwan Power Supply : 6Vdc Battery Operating Frequency : 433.92MHz Type of Modulation : FSK Antenna description : This device uses Helix antenna. The antenna is integral to the device, thereby meeting the requirement of FCC 15.203. Date of Test : Jun. 01~ 08, 2012 Additional Description : 1) The Model Number “ASRF-1510” is representative selected in the test and included in this report. 2) These models (ASRF-1510 and GSRF-1510) share a common schematic, BOM and PCB. The only differences are the model numbers and cosmetics which are targeted for marketing purposes. 3) For more detail specification about EUT, please refer to the user’s manual. Report No.：12A052305R-FR FCC ID： EZSDEI1510 Page 6 of 27 Interocean EMC Technology Corp. Test Report 2.2 Details of tested peripheral equipment N/A Report No.：12A052305R-FR FCC ID： EZSDEI1510 Page 7 of 27 Interocean EMC Technology Corp. Test Report 2.3 Test Facility Site Description : OATS 2 Name of Firm : Interocean EMC Technology Corp. Company web : http://www.ietc.com.tw Site 1, 2, 3 Location : No. 5-2, Lin 1, Tin-Fu, Lin-Kou Dist., New Taipei City, Taiwan 244, R.O.C. Site Filing : z Federal Communication Commissions – USA Registration No.: 96399 (OATS 1 & 2) Registration No.: 518958 (OATS 3) Designation No.: TW1020 z Voluntary Control Council for Interference by Information Technology Equipment (VCCI) – Japan Member No.: 1349 Registration No. (Conducted Room): C-1094 Registration No. (Conducted Room): T-1562 Registration No. (OATS 1): R-1040; G-274 Registration No. (OATS 2): R-1041 z Industry Canada (IC) OUR FILE: 46405-4437 Submission: 145171 Registration No. (OATS 1): Site# 4437A-1 Registration No. (OATS 2): Site# 4437A-2 Registration No. (OATS 3): Site# 4437A-3 Site Accreditation : z Bureau of Standards and Metrology and Inspection (BSMI) – Taiwan, R.O.C. Accreditation No.: SL2-IN-E-0026 for CNS13438 / CISPR22 SL2-R1-E-0026 for CNS13439 / CISPR13 SL2-R2-E-0026 for CNS13439 / CISPR13 SL2-A1-E-0026 for CNS13783-1 / CISPR14-1 SL2-L1-E-0026 for CNS 14115 / CISPR 15 z Taiwan Accreditation Foundation (TAF) Accreditation No.: 1113 z TüV NORD Certificate No: TNTW0801R-04 Report No.：12A052305R-FR FCC ID： EZSDEI1510 Page 8 of 27 Interocean EMC Technology Corp. Test Report 3 Test specifications 3.1 Test standard The EUT was performed according to FCC Part 15 Subpart C Section 15.231 procedure and setup followed by ANSI C63.4, 2003 requirements. 3.2 Operation mode By preliminary testing and verifying three axis (X, Y and Z) position of EUT transmitted status, it was found that “X axis” position was the worst, then the final test was executed the worst condition and test data were recorded in this report The EUT was operated in continuous transmission mode during all of the tests. X axis mode Y axis mode Z axis mode Report No.：12A052305R-FR FCC ID： EZSDEI1510 Page 9 of 27 Interocean EMC Technology Corp. Test Report 3.3 Test Equipment Instrument ManufacturerModel Serial No. Next Cal. Date Spectrum Analyzer R&S FSP40 100478 2013/05/29 Preamplifier Agilent 8449B 3008A01434 2013/05/02 Horn Antenna Schwarzbeck BBHA 9120 9120D-583 2013/05/01 Horn Antenna COM-POWER AH-118 10081 2014/05/29 Cable HARB…

Text truncated - open the document above for the full version.

Report No.：12A052305R-FR FCC ID： EZSDEI1510 Page 21 of 27 Interocean EMC Technology Corp. Test Report 6 Photographs of Test 6.1 Radiated Emission Measurement Front View of Below 1GHz Rear View of Below 1GHz Report No.：12A052305R-FR FCC ID： EZSDEI1510 Page 22 of 27 Interocean EMC Technology Corp. Test Report Front View of Above 1GHz Rear View of Above 1GHz
