© 2013 Directed. All Rights Reserved GASRS7504 2013-07 Auto Start ASRS-7504BK 2-Way LCD Remote User Guide Thank you for purchasing this Auto Start Remote Transmitter. This guide provides a general description of operations for Auto Start Remote Start and Security Systems. LOCK: Locks the DOORS and arms the STARTER KILL (if installed). UNLOCK: Unlocks the DOORS and disarms the STARTER KILL (if installed). Activates the AUX 1 output if Priority Door Access is configured. TRUNK: Opens the TRUNK or activates the AUX 3 output. Note: Trunk option must be installed. START: Remote starts or stops the engine. Gets the system into Cold Weather mode by pressing the AUX button and then pressing and holding the START/STOP button for 3 seconds. “F”: This button serves as a second function button. This button allows assigning different functions to any of the other four buttons and allows access to the menu. Remote Pairing Procedure Confirmations 1. Setting the remote into pairing mode: Press and hold “F” button until the “PAIR MODE” appears on the remote’s LCD screen. “PAIR MODE” text is displayed on the remote’s LCD screen for a period of 30seconds. 2. Turn the key to IGN ON. 3. Press release and then press and hold the antenna programming button until the LED start flashing rapidly. The Parking lights will stay ON for 20 seconds. From this point, the installer has 20seconds to complete steps 4-5. 4. Turn the key from IGN ON to IGN OFF and then OFF. The parking light should turn OFF. 5. Press and release lock button. The remote’s LCD screen will display “PASSED “and the parking lights will start flashing to confirm successful learning of the remote. FAILED PAIRING: The remote’s LCD screen will display “FAILED”. First verify if the antenna is still flashing rapidly, if yes, simply redo step4. Otherwise, repeat the whole process from STEP1. 6. Press “F” button once OR leave the remote inactive for 30 seconds. Note: To learn the remote to a second car that has the same system, in STEP4, press the TRUNK button instead of the LOCK button. Government Regulations This device complies with Part 15 of FCC rules. Operation is subject to the following two conditions: (1) This device may not cause harmful interference, and (2) This device must accept any interference received, including interference that may cause undesirable operation. This equipment has been tested and found to comply with the limits for a class B digital device, pursuant to Part 15 of the FCC Rules. These limits are designed to provide reasonable protection against harmful interference in a residential installation. This equipment generates and can radiate radio frequency energy and, if not installed and used in accordance with the instruction manual, may cause harmful interference to radio communications. However, there is no guarantee that interference will not occur in a particular installation. If this equipment does cause harmful interference to radio or television, which can be determined by turning the equipment OFF and ON, the user is encouraged to try to correct the interference by one or more of the following measures: • Reorient or relocate the receiving antenna. • Increase the separation between the equipment and receiver. • Connect the equipment into an outlet on a circuit different from that to which the receiver is connected. • Consult the dealer or an experienced radio / TV technician for help. To satisfy FCC RF exposure compliance requirements, this device should be used in hand-held, hand operated configurations only. The device and its antenna must maintain a separation distance of 20 cm or more from the person’s body, except for the hand and wrists, to satisfy RF exposure compliance. This device is designed to be used in a person’s hands and its operating configurations do not support normal transmissions while it is carried in pockets or holsters next to a person’s body. Canada Statements This device complies with Industry Canada licence-exempt RSS standard(s). Operation is subject to the following two conditions: (1) this device may not cause interference, and (2) this device must accept any interference, including interference that may cause undesired operation of the device. Le présent appareil est conforme aux CNR d'Industrie Canada applicables aux appareils radio exempts de licence. L'exploitation est autorisée aux deux conditions suivantes : (1) l'appareil ne doit pas produire de brouillage, et (2) l'utilisateur de l'appareil doit accepter tout brouillage radioélectrique subi, même si le brouillage est susceptible d'en compromettre le fonctionnement. Any changes or modifications not expressly approved by the party responsible for compliance could void the user’s authority to operate the equipment. Les changements ou modifications non approuvés expressément par la partie responsable de la conformité pourrait annuler l'autorité de l'utilisateur à faire fonctionner l'équipement.

© 2013 Directed. All Rights Reserved GGSRS7504 2013-07 Auto Start GSRS-7504BK 2-Way LCD Remote User Guide Thank you for purchasing this Auto Start Remote Transmitter. This guide provides a general description of operations for Auto Start Remote Start and Security Systems. LOCK: Locks the DOORS and arms the STARTER KILL (if installed). UNLOCK: Unlocks the DOORS and disarms the STARTER KILL (if installed). Activates the AUX 1 output if Priority Door Access is configured. TRUNK: Opens the TRUNK or activates the AUX 3 output. Note: Trunk option must be installed. START: Remote starts or stops the engine. Gets the system into Cold Weather mode by pressing the AUX button and then pressing and holding the START/STOP button for 3 seconds. “F”: This button serves as a second function button. This button allows assigning different functions to any of the other four buttons and allows access to the menu. Remote Pairing Procedure Confirmations 1. Setting the remote into pairing mode: Press and hold “F” button until the “PAIR MODE” appears on the remote’s LCD screen. “PAIR MODE” text is displayed on the remote’s LCD screen for a period of 30seconds. 2. Turn the key to IGN ON. 3. Press release and then press and hold the antenna programming button until the LED start flashing rapidly. The Parking lights will stay ON for 20 seconds. From this point, the installer has 20seconds to complete steps 4-5. 4. Turn the key from IGN ON to IGN OFF and then OFF. The parking light should turn OFF. 5. Press and release lock button. The remote’s LCD screen will display “PASSED “and the parking lights will start flashing to confirm successful learning of the remote. FAILED PAIRING: The remote’s LCD screen will display “FAILED”. First verify if the antenna is still flashing rapidly, if yes, simply redo step4. Otherwise, repeat the whole process from STEP1. 6. Press “F” button once OR leave the remote inactive for 30 seconds. Note: To learn the remote to a second car that has the same system, in STEP4, press the TRUNK button instead of the LOCK button. Government Regulations This device complies with Part 15 of FCC rules. Operation is subject to the following two conditions: (1) This device may not cause harmful interference, and (2) This device must accept any interference received, including interference that may cause undesirable operation. This equipment has been tested and found to comply with the limits for a class B digital device, pursuant to Part 15 of the FCC Rules. These limits are designed to provide reasonable protection against harmful interference in a residential installation. This equipment generates and can radiate radio frequency energy and, if not installed and used in accordance with the instruction manual, may cause harmful interference to radio communications. However, there is no guarantee that interference will not occur in a particular installation. If this equipment does cause harmful interference to radio or television, which can be determined by turning the equipment OFF and ON, the user is encouraged to try to correct the interference by one or more of the following measures: • Reorient or relocate the receiving antenna. • Increase the separation between the equipment and receiver. • Connect the equipment into an outlet on a circuit different from that to which the receiver is connected. • Consult the dealer or an experienced radio / TV technician for help. To satisfy FCC RF exposure compliance requirements, this device should be used in hand-held, hand operated configurations only. The device and its antenna must maintain a separation distance of 20 cm or more from the person’s body, except for the hand and wrists, to satisfy RF exposure compliance. This device is designed to be used in a person’s hands and its operating configurations do not support normal transmissions while it is carried in pockets or holsters next to a person’s body. Canada Statements This device complies with Industry Canada licence-exempt RSS standard(s). Operation is subject to the following two conditions: (1) this device may not cause interference, and (2) this device must accept any interference, including interference that may cause undesired operation of the device. Le présent appareil est conforme aux CNR d'Industrie Canada applicables aux appareils radio exempts de licence. L'exploitation est autorisée aux deux conditions suivantes : (1) l'appareil ne doit pas produire de brouillage, et (2) l'utilisateur de l'appareil doit accepter tout brouillage radioélectrique subi, même si le brouillage est susceptible d'en compromettre le fonctionnement. Any changes or modifications not expressly approved by the party responsible for compliance could void the user’s authority to operate the equipment. Les changements ou modifications non approuvés expressément par la partie responsable de la conformité pourrait annuler l'autorité de l'utilisateur à faire fonctionner l'équipement.

© 2013 Directed. All Rights Reserved GPDRS7504 2013-07 Premier Defense PDRS-7504BKR 2-Way LCD Remote User Guide Thank you for purchasing this Premier Defense Remote Transmitter. This guide provides a general description of operations for Premier Defense Remote Start and Security Systems. LOCK: Locks the DOORS and arms the STARTER KILL (if installed). UNLOCK: Unlocks the DOORS and disarms the STARTER KILL (if installed). Activates the AUX 1 output if Priority Door Access is configured. TRUNK: Opens the TRUNK or activates the AUX 3 output. Note: Trunk option must be installed. START: Remote starts or stops the engine. Gets the system into Cold Weather mode by pressing the AUX button and then pressing and holding the START/STOP button for 3 seconds. “F”: This button serves as a second function button. This button allows assigning different functions to any of the other four buttons and allows access to the menu. Remote Pairing Procedure Confirmations 1. Setting the remote into pairing mode: Press and hold “F” button until the “PAIR MODE” appears on the remote’s LCD screen. “PAIR MODE” text is displayed on the remote’s LCD screen for a period of 30seconds. 2. Turn the key to IGN ON. 3. Press release and then press and hold the antenna programming button until the LED start flashing rapidly. The Parking lights will stay ON for 20 seconds. From this point, the installer has 20seconds to complete steps 4-5. 4. Turn the key from IGN ON to IGN OFF and then OFF. The parking light should turn OFF. 5. Press and release lock button. The remote’s LCD screen will display “PASSED “and the parking lights will start flashing to confirm successful learning of the remote. FAILED PAIRING: The remote’s LCD screen will display “FAILED”. First verify if the antenna is still flashing rapidly, if yes, simply redo step4. Otherwise, repeat the whole process from STEP1. 6. Press “F” button once OR leave the remote inactive for 30 seconds. Note: To learn the remote to a second car that has the same system, in STEP4, press the TRUNK button instead of the LOCK button. Government Regulations This device complies with Part 15 of FCC rules. Operation is subject to the following two conditions: (1) This device may not cause harmful interference, and (2) This device must accept any interference received, including interference that may cause undesirable operation. This equipment has been tested and found to comply with the limits for a class B digital device, pursuant to Part 15 of the FCC Rules. These limits are designed to provide reasonable protection against harmful interference in a residential installation. This equipment generates and can radiate radio frequency energy and, if not installed and used in accordance with the instruction manual, may cause harmful interference to radio communications. However, there is no guarantee that interference will not occur in a particular installation. If this equipment does cause harmful interference to radio or television, which can be determined by turning the equipment OFF and ON, the user is encouraged to try to correct the interference by one or more of the following measures: • Reorient or relocate the receiving antenna. • Increase the separation between the equipment and receiver. • Connect the equipment into an outlet on a circuit different from that to which the receiver is connected. • Consult the dealer or an experienced radio / TV technician for help. To satisfy FCC RF exposure compliance requirements, this device should be used in hand-held, hand operated configurations only. The device and its antenna must maintain a separation distance of 20 cm or more from the person’s body, except for the hand and wrists, to satisfy RF exposure compliance. This device is designed to be used in a person’s hands and its operating configurations do not support normal transmissions while it is carried in pockets or holsters next to a person’s body. Canada Statements This device complies with Industry Canada licence-exempt RSS standard(s). Operation is subject to the following two conditions: (1) this device may not cause interference, and (2) this device must accept any interference, including interference that may cause undesired operation of the device. Le présent appareil est conforme aux CNR d'Industrie Canada applicables aux appareils radio exempts de licence. L'exploitation est autorisée aux deux conditions suivantes : (1) l'appareil ne doit pas produire de brouillage, et (2) l'utilisateur de l'appareil doit accepter tout brouillage radioélectrique subi, même si le brouillage est susceptible d'en compromettre le fonctionnement. Any changes or modifications not expressly approved by the party responsible for compliance could void the user’s authority to operate the equipment. Les changements ou modifications non approuvés expressément par la partie responsable de la conformité pourrait annuler l'autorité de l'utilisateur à faire fonctionner l'équipement.

May 7, 2013 Nemko Canada Inc 303 River Road Ottawa, Ontario, Canada K1V 1H2 Attn: Director of Certification FCC ID: EZSDEI7756 Authority to Act as Agent On our behalf, I appoint Alan Laudani of Nemko USA Inc., 2210 Faraday Ave, STE 150, Carlsbad, CA, USA to act as our agent in the preparation of this application for equipment certification. I certify that submitted documents properly describe the device or system for which equipment certification is sought. I also certify that each unit manufactured, imported or marketed, as defined in Federal Communication Commission’s regulations will have affixed to it a label identical to that submitted for approval with this application. For instances where our authorized agent signs the application for certification on our behalf, I acknowledge that all responsibility for complying with the terms and conditions for certification, as specified by Nemko USA Inc, still resides with Minas Minassian, DEI Headquarters, Inc 1Viper way, Vista CA 92081, USA. This appointment is in effect until May 7, 2014. Sincerely, Minas Minassian Sr. director, hw/rf systems

May 7, 2013 Nemko Canada Inc 303 River Road Ottawa, Ontario, Canada K1V 1H2 Attn: Director of Certification IC: 1513A-6816 FCC ID: EZSDEI7756 Models: 6816T, TW150 Family letter This letter explain that Directed are using different models (Viper/ Clifford Model 6816T and Autostart Model TW150 ) on this product. All this models uses the same (PCB, HW/RF), the only change is that each model use different data to communicated with the brain system in the car and that the cases are cosmetically different. All the RF frames in the air are the same with same duty cycle and RF parameters. Sincerely, Minas Minassian Sr. director, hw/rf systems

May 7, 2013 Nemko Canada Inc 303 River Road Ottawa, Ontario, Canada K1V 1H2 Attn: Director of Certification Re: Request of Confidentiality Pursuant to Sections 0.457(d)(1)(ii) and 0.459 of the Commission’s Rules, the Applicant hereby requests confidential treatment of information accompanying as outlined below: Schematics Block diagram Operational description Parts List All the above for EZSDEI7756 The above materials contain trade secrets and proprietary information not customarily released to the public. The public disclosure of these matters might be harmful to the Applicant and provide unjustified benefits to its competitors. The Applicant understands that pursuant to Rule 0.457(d)(1)(ii), disclosure of this Application and all accompanying documentation will not be made before the date of the Grant for this Application. Sincerely, Minas Minassian Sr. director, hw/rf systems

GSRS‐7504 ASRS‐7504 PDRS‐7504 7756V 7756X

C01 yarG looC U9 YARG LOOC :GNISUOH MOTTOB/POT HCUOT TFOS KCALB TNIAP REBBUR POOL LATEM：EMORHC ETTAM KCALB:ROLOC SNEL :TNIRP OGOL U5 YARG LOOC :ROLOC REBBUR KCALB ETTAM :ROLOC SNOCI U5 YARG LOOC C624 enotnaP:GNITNIRP C934 enotnaP AA12GDAN 0000NDTN 2*0008GDTN 00C1HDTN 0003GWTN 9 9 ROLOC YFIDOM SYY31'/02/3 LIAM 11/21 7 ROLOC EGNAHC SYY21'/11/21 75 5 LIAM 92/01 EROC EGNAHC EVOMER SYY21'/92/01 21'/52/01SYY SSENKCIHT ESAERCNI 3 LIAM 42/01 .deificeps ton fi eb lliw suoidaR .2 sa emas si erutxeT .1 CP+SBA : LAIRETAM YDOB 01011-TM 2.0 08.0 03.0 04.0 00.2 EDARG 6 REDNU NOISNEMID 03~6 021~03 003~021 80.0 01.002.0 61.0 02.0 04.0 04.0 08.0 LAIRETAM :ELACS HSINIF EDOC 1:1 M/M :TINU KETUN TPED 2/01/2102 ETAD YB NRD YB DPPA YB KHC nosaE SYY FO TEEHS rotciV ELTIT EZIS 4A NOITAROPROC UHH DCL V6577 0520I101 ON GNIWARDVER 9 TRAP POOL LATEM ESAC 0A02MWKN WERCS 00S1MWDM 10M1MWAI N/P NIAHC YEK TRAP REMOTSALE 54410PIM 000D61AM N/P YEK EDIS IED .VER.CCA NOITPIRCSED SNOISIVER .NRD ETAD 02/3 02/3 )9(0520I101 0A01MWRISNEL YEK POT0A01MWKN0001MWCMTCATNOC)+( 1LIAM 11/01 .VER YFIDOM SYY21'/11/01 2 LIAM 61/01 .VER YFIDOM SYY21'/11/01 0020-472-008-1 V6577 :LEDOM 6577-A3151 :CI 6577IEDSZE :DI CCF 21'/62/01SYY EROC EGNAHC EVOMER LIAM 62/01 4 4 EPYT RALYM 21'/1/11SYY N/P EPAT MAOF DDA6 RALYM EVISEHDA .TAB EPAT NOROP 31'/72/2SYY N/P YFIDOM 8

GNITAOC SSOLG U9 YARG LOOC:GNITNIRP C624 SMP :GNITNIRP KCALB:ROLOC SNEL :TNIRP OGOL U5 YARG LOOC :ESAC RETNEC GNITAOC REBBUR+KCALB :GNISUOH MOTTOB/POT HCUOT TFOS KCALB TNIAP REBBUR :ROLOC SNOCI U5 YARG LOOC :ROLOC REBBUR KCALB ETTAM C934 SMP 2 2 2 liam-E 31'-12/3 ROLOC GNITNIRP & HSINIF YFIDOM cirE31'-12/3 1 0020-472-008-1 X6577 :LEDOM 6577-A3151 :CI 6577IEDSZE :DI CCF 1 ETAD.NRD NOITPIRCSED .CCA.VER SNOISIVER VERTPEDON GNIWARD NOITAROPROC EZIS ELTIT KETUN ETAD YB NRD :ELACS:TINU FO TEEHS YB KHC YB DPPA EDOC LAIRETAM HSINIF 03.0 00.2 04.0 08.0 61.0 08.0 02.0 04.0 6 REDNU NOISNEMID EDARG 021~03 003~021 03~6 80.0 04.0 02.0 01.0 SBA/CP : LAIRETAM YDOB 01011-TM sa emas si erutxeT .1 .deificeps ton fi 2.0 eb lliw suoidaR .2 liam-E 31'-2/1 ROLOC GNITNIRP .TOB YFIDOM XILEF31'-2/1 2

August 28, 2013 Nemko Canada Inc 303 River Road Ottawa, Ontario, Canada K1V 1H2 Attn: Director of Certification FCC ID: EZSDEI7756 Models: 7756X 7756V ASRS‐7504 GSRS‐7504 PDRS‐7504 HHU LCD Distance between antenna and hand user The distance from the user’s hand on the button on the remote and the antenna is 35mm. The user holds the remote from the keychain side, if not he will not see the LED display. 447498 D01 General 10 RF Exposure Guidance v05r01 4.3.1. Standalone SAR test exclusion considerations The minimum test separation distance is determined by the smallest distance from the antenna and radiating structures or outer surface of the device, according to the host form factor, exposure conditions and platform requirements, to any part of the body or extremity of a user or bystander. LCD Maximum peak output power --conducted:108mW Minimum Test Separation Distance:35mm Evaluation frequency:0.923GHz Square Root of Frequency in GHz:0.961 10-g Extremity test threshold:3.0< 7.5 1-g Body test threshold:3.0 < 3 Sincerely, Minas Minassian Sr. director, hw/rf systems

Nemko-CCL, Inc. 1940 West Alexander Street Salt Lake City, UT 84119 801-972-6146 Test Report Certification Test Of: 7756V, 7756X, PDRS-7504, GSRS-7504, & ASRS-7504 FCC ID: EZSDEI7756 Test Specification: FCC PART 15, Subpart C Test Report Serial No: 230383-9-2.2 Applicant: DEI Headquarters Inc. 1 Viper Way Vista, CA 92081 U.S.A Dates of Test: May 29 - June 7, 2013 Report Issue Date: July 11, 2013 Accredited Testing Laboratory By: NVLAP Lab Code 100272-0 Nemko-CCL, Inc. TEST REPORT: 230383-9-2.2 REPORT ISSUE DATE: 07/11/2013 Page 2 of 46 CERTIFICATION OF ENGINEERING REPORT This report has been prepared by Nemko-CCL, Inc. to document compliance of the device described below with the requirements of Federal Communications Commission (FCC) Part 15, Subpart C. This report may be reproduced in full; partial reproduction may only be made with the written consent of the laboratory. The results in this report apply only to the sample tested. - Applicant: DEI Headquarters Inc. - Manufacturer: DEI Headquarters Inc. - Brand Name: DEI Headquarters Inc. - Model Numbers: 7756V, 7756X, PDRS-7504, GSRS-7504, & ASRS-7504 - FCC ID Number: EZSDEI7756 On this 11 th day of July 2013, I, individually and for Nemko-CCL, Inc., certify that the statements made in this engineering report are true, complete, and correct to the best of my knowledge, and are made in good faith. Although NVLAP has recognized that the Nemko-CCL, Inc. EMC testing facilities are in good standing, this report must not be used to claim product certification, approval, or endorsement by NVLAP, NIST, or any agency of the federal government. Nemko-CCL, Inc. Tested by: Mark M. Feil EMC Engineer Reviewed by: Thomas C. Jackson General Manager Nemko-CCL, Inc. TEST REPORT: 230383-9-2.2 REPORT ISSUE DATE: 07/11/2013 Page 3 of 46 TABLE OF CONTENTS PAGE SECTION 1.0 CLIENT INFORMATION .................................................................................4 SECTION 2.0 EQUIPMENT UNDER TEST (EUT) ..................................................................5 SECTION 3.0 TEST SPECIFICATION, METHODS & PROCEDURES .............................9 SECTION 4.0 OPERATION OF EUT DURING TESTING ..................................................14 SECTION 5.0 SUMMARY OF TEST RESULTS ...................................................................15 SECTION 6.0 MEASUREMENTS, EXAMINATIONS AND DERIVED RESULTS ..........16 APPENDIX 1 TEST PROCEDURES AND TEST EQUIPMENT ..........................................36 APPENDIX 2 PHOTOGRAPHS ................................................................................................39 APPENDIX 3 AVERAGE FACTOR CALCULATION ..........................................................46 Nemko-CCL, Inc. TEST REPORT: 230383-9-2.2 REPORT ISSUE DATE: 07/11/2013 Page 4 of 46 SECTION 1.0 CLIENT INFORMATION 1.1 Applicant: Company Name: DEI Headquarters Inc. 1 Viper Way Vista, CA 92081 Contact Name: Minas Minassian Title: Sr. Director, HW/RF Systems 1.2 Manufacturer: Company Name: DEI Headquarters Inc. 1 Viper Way Vista, CA 92081 Contact Name: Minas Minassian Title: Sr. Director, HW/RF Systems Nemko-CCL, Inc. TEST REPORT: 230383-9-2.2 REPORT ISSUE DATE: 07/11/2013 Page 5 of 46 SECTION 2.0 EQUIPMENT UNDER TEST (EUT) 2.1 Identification of EUT: Brand Name: DEI Headquarters Inc. Model Numbers: 7756V, 7756X, PDRS-7504, GSRS-7504, & ASRS-7504 Dimensions: 6.7 cm x 3.6 cm x 0.8 cm 2.2 Description of EUT: The 7756V was tested as a representative of models 7756X, PDRS-7504, GSRS-7504, & ASRS-7504. The differences in the models are cosmetic only. The 7756V, only, will be referred to throughout the remainder of this report. The 7756V is a handheld key fob, exercised by push buttons to arm/disarm, lock/unlock, start vehicle systems, etc. A continuous transmit mode was configured by the applicant for RF testing. The device is powered by a 3.7 V battery. The 7756V transceiver operates using 25 channels, spaced 620 KHz apart, in the 902 MHz to 928 MHz frequency band. The 7756V transceiver uses a helical antenna extending from a trace on the PCB. Testing was performed at the upper channel (923.835 MHz), the middle channel (916.395 MHz), and the lower channel (907.095 MHz). See the plots of the channels below. Nemko-CCL, Inc. TEST REPORT: 230383-9-2.2 REPORT ISSUE DATE: 07/11/2013 Page 6 of 46 Nemko-CCL, Inc. TEST REPORT: 230383-9-2.2 REPORT ISSUE DATE: 07/11/2013 Page 7 of 46 This report covers the circuitry of the devices subject to FCC Part 15, Subpart C. The circuitry of the device subject to FCC Part 15, Subpart B has been tested and found to comply. See Nemko-CCL report #230383-9-1.1. Nemko-CCL, Inc. TEST REPORT: 230383-9-2.2 REPORT ISSUE DATE: 07/11/2013 Page 8 of 46 2.3 EUT and Support Equipment: The EUT and support equipment used during the test are listed below: Brand Name Model Number Serial Number FCC ID Number or Compliance Description Name of Interface Ports / Interface Cables BN: DEI Headquarters Inc. MN: 7756V (Note 1) EZSDEI7756 Key fob remote None Note: (1) EUT The support equipment listed above was not modified in order to achieve compliance with this standard. 2.4 Modification Incorporated/Special Accessories on EUT: No modifications were made during testing to comply with the specification. Nemko-CCL, Inc. TEST REPORT: 230383-9-2.2 REPORT ISSUE DATE: 07/11/2013 Page 9 of 46 SECTION 3.0 TEST SPECIFICATION, METHODS & PROCEDURES 3.1 Test Specification: Title: FCC PART 15, Subpart C (47 CFR 15) 15.203 and 15.247 Limits and methods of measurement of radio interference characteristics of radio frequency devices Purpose of Test: The tests were performed to demonstrate initial compliance 3.2 Methods & Procedures: 3.2.1 §15.203 Antenna Requirement An intentional radiator shall be designed to ensure that no antenna other than that furnished by the responsible party shall be used with the device. The use of a permanently attached antenna or of an antenna that uses a unique coupling to the intentional radiator shall be conside…
