EZSDEI7816Two way transceiver SST car remote starter

OWNER’S GUIDE MODEL The company behind Viper ® Auto Security Systems is Directed. Since its inception, Directed has had one purpose, to provide consumers with the fin- est vehicle security and accessories avail- able. The recipient of nearly 100 patents and Innovations Awards in the field of advanced electronic technology. Quality Directed products are sold and ser- viced throughout North America and around the world. Call (800) 876-0800 for more information about our products and ser vic es. Directed is committed to delivering world class quality products and services that excite and delight our customers. ® NO ONE DARES COME CLOSE ® 4816V 4616V © 2015 Directed. All rights reserved. G4816VML 2015-02 Vista, CA 92081 www.viper.com i © 2015 Directed. All rights reserved. Congratulations Congratulations on the purchase of your remote start system. Reading this Owner’s Guide prior to using your system will help maximize the use of your system and its many features. For any additional questions please contact your authorized Directed dealer or contact Directed at 1-800-753-0600. (U.S. only) or 1-800-361-7271 (Canada only) Additional support is also available at: http://support.directed.com Important Information Government Regulations and Safety information Read the Government Regulations and Warning! Safety First sections of this manual prior to operating this system. Warning! Failure to heed this information can result in death, personal injury or property damage and may also result in the illegal use of the system beyond its intended purpose. Your Warranty Your system comes with a warranty. The warranty terms are detailed at the end of this guide. Make sure that you receive the proof of purchase from your dealer, indicating the product was installed by an authorized Directed dealer. Replacement remote controls Please see your authorized dealer or visit us at www.directedstore.com to order additional remote controls. Your 2-way remote control model / part number is 7816, and your 1-way is 7616. ii © 2015 Directed. All rights reserved. Battery Information The remote controls are powered by coin cell batteries (CR-2016) that can be purchased at most retailers. Your 2-way remote uses two bat- teries, and the 1-way only uses one. The operating range diminishes as the battery charge depletes. Replacing the Battery 1. If present, remove the small screw on the back of the remote. 2. Use a small flat blade screw driver and insert it into the slot located along the bottom of the remote, near the key ring. Carefully pry open the case. 3. Gently slide out the used batteries to remove them from the holding clip. Orient the new batteries for the correct polarity and insert into holding clip. 4. Reposition case parts, and snap together by pressing firmly and evenly on the front and back. Reinstall screw (if applicable). Battery Disposal Directed cares about the environment. If you need to dispose of the battery, please do so in accordance with your munici- pal requirements for battery disposal or return to Directed. Contents Congratulations .................................................................................................i Important Information .........................................................................................i Government Regulations and Safety information ............................................i Your Warranty ...........................................................................................i Replacement remote controls .......................................................................i Battery Information ............................................................................................ii Replacing the Battery ................................................................................ii Battery Disposal .......................................................................................ii Using Your System ...........................................................................................2 Commands At a Glance ............................................................................2 Start Engine .............................................................................................2 Unlock Doors ...........................................................................................2 Stop Engine .............................................................................................2 Car Finder ...............................................................................................3 Using Remote Start ............................................................................................3 Key Takeover............................................................................................3 Safety Features .........................................................................................4 Pit Stop ....................................................................................................4 Optional Rear Defogger ............................................................................5 Optional Starter Anti-Grind Circuitry ...........................................................5 Disabling the Remote Start System ..............................................................5 Rapid Resume Logic .........................................................................................5 Remote Programming ........................................................................................6 Programming Options ........................................................................................6 Patent Information .............................................................................................7 Government Regulations ....................................................................................8 Warning! Safety first .........................................................................................9 Installation ..............................…

Text truncated - open the document above for the full version.

March 25, 2015 Nemko Canada Inc 303 River Road Ottawa, Ontario, Canada K1V 1H2 Attn: Director of Certification FCC ID: EZSDEI7816 Authority to Act as Agent On our behalf, I appoint Alan Michelle Furrow of Nemko USA Inc., 2652 FM 407, Suite 215A, Bartonville, TX 76226 USA to act as our agent in the preparation of this application for equipment certification. I certify that submitted documents properly describe the device or system for which equipment certification is sought. I also certify that each unit manufactured, imported or marketed, as defined in Federal Communication Commission’s regulations will have affixed to it a label identical to that submitted for approval with this application. For instances where our authorized agent signs the application for certification on our behalf, I acknowledge that all responsibility for complying with the terms and conditions for certification, as specified by Nemko USA Inc, still resides with Minas Minassian, DEI Headquarters, Inc 1 Viper way, Vista CA 92081, USA. This appointment is in effect until March 25, 2016 Sincerely, Minas Minassian Sr. director, hw/rf systems

March 25, 2015 Nemko Canada Inc 303 River Road Ottawa, Ontario, Canada K1V 1H2 Re: FCC ID: EZSDEI7816 Attn: Director of Certification Re: Request of Confidentiality Pursuant to Sections 0.457(d)(1)(ii) and 0.459 of the Commission’s Rules, the Applicant hereby requests confidential treatment of information accompanying as outlined below: Schematics Block diagram Operational description Parts List The above materials contain trade secrets and proprietary information not customarily released to the public. The public disclosure of these matters might be harmful to the Applicant and provide unjustified benefits to its competitors. The Applicant understands that pursuant to Rule 0.457(d)(1)(ii), disclosure of this Application and all accompanying documentation will not be made before the date of the Grant for this Application. Sincerely, Minas Minassian Sr. director, hw/rf systems

ONE WORLD  OUR APPROVAL www.nemko.com KDB 447498 D01 General RF Exposure Guidance v05r02 (February 7, 2014) 1. Declaration of RF exposure compliance for exemption from routine evaluation limits FCC ID: 1513A Model number: 7816V Manufacturer: DEI Headquarters, Inc. 4.3.1. Standalone SAR test exclusion considerations: During normal operation, user extremities can come within 20 cm of the internal antenna and therefore product is considered as “Portable”. The 1-g and 10-g SAR test exclusion thresholds for 100 MHz to 6 GHz at Test separation distances ≤ 50 mm are determined by: [(max. power of channel, including tune-up tolerance, mW) ÷ (min. test separation distance, mm)] × [ � 퐹(퐺퐺퐺)] ≤ 3.0 for 1-g SAR and ≤ 7.5 for 10-g extremity SAR, where f(GHz) is the RF channel transmit frequency in GHz Power and distance are rounded to the nearest mW and mm before calculation The result is rounded to one decimal place for comparison The test exclusions are applicable only when the minimum test separation distance is ≤ 50 mm and for transmission frequencies between 100 MHz and 6 GHz. When the minimum test separation distance is < 5 mm, a distance of 5 mm according to 5) in section 4.1 is applied to determine SAR test exclusion Calculation based on the above formula: Separation Distance = 5 mm Conducted Output Power =14.67 dBm = 29.3 mW Frequency = 0.9071 GHz Calculation = ( 29 .3 ÷ 5 ) 5.86 × √ 0.9071 = 5.58 < 7.5 The calculation is below the threshold, therefore the product exempt from the SAR test requirements 2. Attestation ATTESTATION: I attest that the testing was performed or supervised by me; that the test measurements were made in accordance with the above-mentioned departmental standard(s), and that the radio equipment identified in this application has been subject to all applicable test conditions specified in the departmental standards and all of the requirements of the standards have been met. Signature: Date: May 20, 2015 Name: Kevin Rose Wireless/EMC Specialist Test report cover sheet

www.nemko.com Nemko Canada Inc., a testing laboratory, is accredited by the Standards Council of Canada. The tests included in this report are within the scope of this accreditation FCC 15.247 and RSS-210 A8.docx; Date: May 2013 SCC Accredited LAB LAB Accrédité CCN TM ONE WORLDOURAPPROVAL Test report 279529-2TRFWL Date of issue: May 21, 2015 Applicant: DEI Headquarters, Inc. Product: Remote Control Model: 7816V FCC ID: IC Registration number: EZSDEI7816 1513A-7816 Specifications:  FCC 47 CFR Part 15 Subpart C, §15.247 Operation in the 902–928 MHz, 2400–2483.5 MHz, 5725–5850 MHz  RSS-210, Issue 8, December 2010, Annex 8 Frequency Hopping and Digital Modulation Systems Operating in the 902–928 MHz, 2400–2483.5 MHz, and 5725–5850 MHz Bands Report reference ID: 279529-2TRFWL Page 2 of 23 Test location Company name: Nemko Canada Inc. Address: 303 River Road City: Ottawa Province: Ontario Postal code: K1V 1H2 Country: Canada Telephone: +1 613 737 9680 Facsimile: +1 613 737 9691 Toll free: +1 800 563 6336 Website: www.nemko.com Site number: FCC: 176392; IC: 2040A-4 (3 m semi anechoic chamber) Tested by: Kevin Rose, Wireless/EMC Specialist and Daniel Hynes, Senior EMC Specialist Reviewed by: Andrey Adelberg, Senior Wireless/EMC Specialist Date: May 21, 2015 Signature: Limits of responsibility Note that the results contained in this report relate only to the items tested and were obtained in the period between the date of initial receipt of samples and the date of issue of the report. This test report has been completed in accordance with the requirements of ISO/IEC 17025. All results contain in this report are within Nemko Canada’s ISO/IEC 17025 accreditation. Copyright notification Nemko Canada Inc. authorizes the applicant to reproduce this report provided it is reproduced in its entirety and for use by the company’s employees only. Any use which a third party makes of this report, or any reliance on or decisions to be made based on it, are the responsibility of such third parties. Nemko Canada Inc. accepts no responsibility for damages, if any, suffered by any third party as a result of decisions made or actions based on this report. © Nemko Canada Inc. Report reference ID: 279529-2TRFWL Page 3 of 23 Table of contents Table of contents .......................................................................................................................................................................................................... 3 Section 1. Report summary ................................................................................................................................................................................. 4 1.1 Applicant and manufacturer .................................................................................................................................................................................... 4 1.2 Test specifications .................................................................................................................................................................................................... 4 1.3 Test methods ............................................................................................................................................................................................................ 4 1.4 Statement of compliance ......................................................................................................................................................................................... 4 1.5 Exclusions ................................................................................................................................................................................................................. 4 1.6 Test report revision history ...................................................................................................................................................................................... 4 Section 2. Summary of test results ....................................................................................................................................................................... 5 2.1 FCC Part 15 Subpart C, general requirements test results ........................................................................................................................................ 5 2.2 FCC Part 15 Subpart C, intentional radiators test results.......................................................................................................................................... 5 2.3 IC RSS-GEN, Issue 4, test results ............................................................................................................................................................................... 5 2.4 IC RSS-210, Issue 8, test results ................................................................................................................................................................................ 6 Section 3. Equipment under test (EUT) details ..................................................................................................................................................... 7 3.1 Sample information .................................................................................................................................................................................................. 7 3.2 EUT information ....................................................................................................................................................................................................... 7 3.3 Technical information .............................................................................................................................................................................................. 7 3.4 Product description and theory of operation ...............................................…
