ADCP-75-192 Preliminary Issue D October 2005 Digivance    CXD Multi-Band Distributed Antenna System Installation and Operation Manual 1343155 Rev 1 ADCP-75-192 Preliminary Issue D October 2005 Digivance    CXD Multi-Band Distributed Antenna System Installation and Operation Manual 1343155 Rev 1 ADCP-75-192 • Issue D • October 2005 • Preface Page ii COPYRIGHT  2005, ADC Telecommunications, Inc. All Rights Reserved Printed in the U.S.A. REVISION HISTORY ISSUE DATE REASON FOR CHANGE Issue D 10/2005 Original release LIST OF CHANGES The technical changes incorporated into this issue are listed below. SECTION IDENTIFIER DESCRIPTION OF CHANGE - - Original release TRADEMARK INFORMATION ADC and Digivance are registered trademarks of ADC Telecommunications, Inc. DISCLAIMER OF LIABILITY Contents herein are current as of the date of publication. ADC reserves the right to change the contents without prior notice. In no event shall ADC be liable for any damages resulting from loss of data, loss of use, or loss of profits and ADC further disclaims any and all liability for indirect, incidental, special, consequential or other similar damages. This disclaimer of liability applies to all products, publications and services during and after the warranty period. This publication may be verified at any time by contacting ADC’s Technical Assistance Center at 1-800-366-3891, extension 73476 (in U.S.A. or Canada) or 952-917-3476 (outside U.S.A. and Canada), or by e-mail to [email protected]. ADC Telecommunications, Inc. P.O. Box 1101, Minneapolis, Minnesota 55440-1101 In U.S.A. and Canada: 1-800-366-3891 Outside U.S.A. and Canada: (952) 917-3475 Fax: (952) 917-1717 ADCP-75-192 • Issue D • October 2005 • Preface Page iii  2005, ADC Telecommunications, Inc. TABLE OF CONTENTS Content Page FRONT MATTER ABOUT THIS MANUAL.......................................................................v RELATED PUBLICATIONS.....................................................................v ADMONISHMENTS........................................................................vi GENERAL SAFETY PRECAUTIONS...............................................................vi SAVE WORKING DISTANCES..................................................................vii COMPLIANCE STATEMENT..................................................................viii ACRONYMS AND ABBREVIATIONS.............................................................viii SECTION 1 OVERVIEW 1 INTRODUCTION....................................................................1-1 2 DIGIVANCE CXD SYSTEM OVERVIEW......................................................1-1 2.1 Basic Components.............................................................1-2 2.2 General Description............................................................1-2 2.3 Local Service Interface..........................................................1-3 2.4 Remote NOC Interface..........................................................1-4 3 SYSTEM FUNCTIONS AND FEATURES......................................................1-4 3.1 Fiber Optic Transport...........................................................1-4 3.2 Control and Monitoring Software...................................................1-5 3.3 Fault Detection and Alarm Reporting.................................................1-5 3.4 Powering...................................................................1-5 3.5 Equipment Mounting and Configuration...............................................1-6 3.6 RAN Subsystem Assemblies......................................................1-6 3.7 HUB Subsystem Assemblies......................................................1-9 3.8 Communication Interfaces.......................................................1-12 SECTION 2 DESCRIPTION 1 INTRODUCTION....................................................................2-1 1.1 Digital Chassis...............................................................2-1 1.2 RF Chassis..................................................................2-3 1.3 Radio Access Node............................................................2-4 2 ELEMENTS COMMON TO HUB AND RAN....................................................2-5 2.1 CPU.......................................................................2-5 2.2 STF2......................................................................2-7 2.3 SIF.......................................................................2-9 3 RAN...........................................................................2-11 3.1 RDC.....................................................................2-11 3.2 RUC.....................................................................2-13 3.3 RF Assembly Module..........................................................2-14 ADCP-75-192 • Issue D • October 2005 • Preface Page iv  2005, ADC Telecommunications, Inc. TABLE OF CONTENTS Content Page 3.4 CompactPCI Power Supply.......................................................2-16 4 HUB............................................................................2-16 4.1 Full Band HDC (FBHDC) ........................................................2-16 4.2 Forward Simulcast Module, FSC...................................................2-18 4.3 Hub Upconverter Module, HUC....................................................2-20 4.4 Reverse Simulcast Module, RSC...................................................2-21 4.5 Hub Reference Module, HRM.....................................................2-23 4.6 Ethernet Switch..............................................................2-25 4.7 BTS Interface Module, BIM.......................................................2-25 4.8 Attenuator Shelf .............................................................2-26 4.9 Specifications...............................................................2-27 SECTION 3 NETWORK AND SYSTEM INSTALLATION AND SETUP 1 INTRODUCTION...............................…

Text truncated - open the document above for the full version.

Attn: Director of Certification

American Telecommunications Certification Body Inc. 6731 Whittier Ave, McLean, VA 22101 October 28, 2005 RE: FCC ID: F8I--DCX1902A_ATCB002891 Attention: Joel Schneider I have a few comments on this Application. Please note that further comments may arise in response to answers provided to the questions below. 1. Please note that the manual and operational description describe this device as a multi-band device operating in the 850MHz and 1900MHz bands. Please note that this application is only for the 1900MHz system. Please note that the manual and other documentation does not clearly separate the 850MHz from the 1900MHz versions. Please explain and please clearly identify the separate systems. Please confirm that this device does not have capability of operating at 850MHz. If the device does operate in the 850MHz band, please correct the 731 and please provide all appropriate test data. If this device does not operate in the 850MHz band, then the manual and other documentation must appropriately address this specific device (i.e. a table of models and their specific operating range). 2. Please note that the manual also indicates that this device operates in the Part 90 iDEN service. Please explain and please clearly identify this device and the FCC rules under which it operates.If the device does operate in the iDEN service, please provide a corrected 731 and all appropriate test data. If this device does not operate in the iDEN service, then the manual and othe documentation must appropriately address this specific device. 3. The operational description indicates that this device works not only with conventional CDMA but has CDMA200 capabilities. Please note that CDMA2000 has both 1x EV-DO and cdma2000 3x standards. Cdma2000 3x as part of what the ITU has termed IMT-2000 CDMA MC (Multi Carrier). It uses less that 5 MHz spectrum (3x 1.25 MHz channels) to give speeds of over 2 Mbps. Cdma2000 1x with lower data speed is considered to be a 2.5G technology Please note that the type CDMA2000 modulation scheme used in this device has not been defined. Please note also that the device in question needs to provide the appropriate CDMA200 occupied bandwidths commensurate with the modulation types available in in the device. Please provide the appropriate CDMA2000 occupied bandwidth plots. Alternately, this device would not be approved for CDMA2000 operation and the operational description would have to be changed to remove this option. Please advise as to how the applicant wishes to proceed. 4. Please note that the manual and other documentation indicates CDMA2000. If the CDMA2000 modulation is for the EU version, please clearly specify. Alternately additional testing as mentioned the items below. 5. Please note that section 7.1 of the manual indicates that AMPS is also an available modulation. If AMPS is a modulation type, please provide that necessary data for AMPS mode; alternately, please explain how the provided data meets AMPS requirements. 6. Please note that the output power for each type emissions designator is required to be on the grant. Please note that only a CW signal was used to measure output power for this device. While this may be OK for FM, it is not appropriate for GSM or CDMA type modulations. Please provide the conducted antenna terminal output powers for all emissions types. 7. As the device accepts multiple inputs, please clarify if the power out of the device listed on the 731 is a composite of multichannels or per carrier. 8. Please note that the FCC has designated F9W as the appropriate emissions designator for CDMA and W-CDMA. Please correct the 731 to reflect the accepted emissions designators. 9. Please note that band edge compliance and out of band compliance must be shown for each emissions type. Please note that CW is only acceptable for FM modulation and is not acceptable for GSM or CDMA type modulations. Please provide the appropriate band edge compliance data for the type modulations requested. 10. Please note that compliance is unclear on the conducted emissions plots as the trace from 10GHz to 20GHz appears to show frequencies that are over the limit in places. It is not possible to tell if z Page 2 October 28, 2005 these are signals from the EUT and thus making the EUT is non-compliant, or if these signals are actually noise floor. Please clearly show compliance of the EUT at these frequencies. 11. Please note that as long as there are no radiated spurious emissions within 20dB of the limit field strength data from an OATS can be used to justify not making antenna substitution measurements. Please note that the radiated spurious emissions test data on pages 31 through 46 of the test report are ambiguous as they do not provide information as to the modulation type used. Please also note that all modulation types must be tested. Please provide measured data for all modulation types used in the device. If any emissions from the OATS field strength data is within 20dB of the limit (-13dBm) please provide antenna substitution data for those emissions in accordance with TIA603. 12. Please note that the email form the applicant stated that this system was to be used with a maximum antenna gain of 5.5dBi. Please note that the MPE report state that the maximum gain is 16.87dBi. Please explain and please provide an MPE report that represents the actual device and antenna. 13. Please note that based on the responses to the above comments, further questions may arise. Dennis Ward mailto:[email protected] The items indicated above must be submitted before processing can continue on the above referenced application. Failure to provide the requested information may result in application termination. Correspondence should be considered part of the permanent submission and may be viewed from the Internet after a Grant of Equipment Authorization is issued. Please do not respond to this correspondence using the email reply button. In order for your response to be processe…

Text truncated - open the document above for the full version.

TÜV America Inc. Phone: (651) 631-2487 1775 Old Highway 8 NW Fax: (651) 638-0285 Suite 104 E-mail: [email protected] New Brighton, MN 55112 www.TUVamerica.com Management Service • Product Service • Industry Service • Automotive • BABT TÜV America Inc. is a subsidiary of TÜV SÜD Group. 01 November 2005 American TCB 6731 Whittier Avenue McLean VA 22101 RE: ADC Telecommunications Response to 10282005 Comments FCC ID: F8I-DCX1902A In response to your comments on the above submittal from October 28, 2005. 1. Please note that the manual and operational description describe this device as a multi-band device operating in the 850MHz and 1900MHz bands. Please note that this application is only for the 1900MHz system. Please note that the manual and other documentation does not clearly separate the 850MHz from the 1900MHz versions. Please explain and please clearly identify the separate systems. Please confirm that this device does not have capability of operating at 850MHz. If the device does operate in the 850MHz band, please correct the 731 and please provide all appropriate test data. If this device does not operate in the 850MHz band, then the manual and other documentation must appropriately address this specific device (i.e. a table of models and their specific operating range). RESPONSE: New Theory of Operation and Block Diagrams submitted. The following statement has been added to the manual: Each respective SMR, Cellular, and PCS system in this CXD platform is singularly FCC and IC approved. Information in this manual explains applicable portions of these systems. 2. Please note that the manual also indicates that this device operates in the Part 90 iDEN service. Please explain and please clearly identify this device and the FCC rules under which it operates.If the device does operate in the iDEN service, please provide a corrected 731 and all appropriate test data. If this device does not operate in the iDEN service, then the manual and othe documentation must appropriately address this specific device. RESPONSE: The top-level product that is sold to the customer to operate within the various frequency blocks pertaining to the systems respect approvals. Each system is approved specifically, in this case we approving the PCS 1900 MHz (1930-1965) system. A separate approval for the Cellular 800 MHz (869-880 MHz) is in progress as well. Each system is approved separately, though documentation has been combined for the ease of customer convenience. The Part 90 system has previously been approved and is not applicable to this submittal. The following statement has been added to the manual: Each respective SMR, Cellular, and PCS system in this CXD platform is singularly FCC and IC approved. Information in this manual explains applicable portions of these systems. 3. The operational description indicates that this device works not only with conventional CDMA but has CDMA200 capabilities. Please note that CDMA2000 has both 1x EV-DO and cdma2000 3x standards. Cdma2000 3x as part of what the ITU has termed IMT-2000 CDMA MC (Multi Carrier). It uses less that 5 MHz spectrum (3x 1.25 MHz channels) to give speeds of over 2 Mbps. Cdma2000 1x with lower data speed is considered to be a 2.5G technology Please note that the type CDMA2000 modulation scheme used in this device has not been defined. Please note also that the TÜV America Inc. Phone: (651) 631-2487 1775 Old Highway 8 NW Fax: (651) 638-0285 Suite 104 E-mail: [email protected] New Brighton, MN 55112 www.TUVamerica.com Management Service • Product Service • Industry Service • Automotive • BABT TÜV America Inc. is a subsidiary of TÜV SÜD Group. device in question needs to provide the appropriate CDMA200 occupied bandwidths commensurate with the modulation types available in in the device. Please provide the appropriate CDMA2000 occupied bandwidth plots. Alternately, this device would not be approved for CDMA2000 operation and the operational description would have to be changed to remove this option. Please advise as to how the applicant wishes to proceed. RESPONSE: Additional CDMA2000 test information provided. The CDMA2000 modulation used is 1xRTT. See attached “1900 MHz Conducted Emissions CDMA2000” 4. Please note that the manual and other documentation indicates CDMA2000. If the CDMA2000 modulation is for the EU version, please clearly specify. Alternately additional testing as mentioned the items below. RESPONSE: Additional CDMA2000 test information is provided in “1900 MHz Conducted Emissions CDMA2000” 5. Please note that section 7.1 of the manual indicates that AMPS is also an available modulation. If AMPS is a modulation type, please provide that necessary data for AMPS mode; alternately, please explain how the provided data meets AMPS requirements. RESPONSE: AMPS signal testing is conducted using the FM modulation shown in the test data and report. The patented technology of this equipment digitizes the entire designated RF band, digitally transports it over fiber, and reconstructs the signal at full bandwidth, regardless of modulation technology. The EUT is a repeater device, therefore no specific mode is required for operation. F3E modulation designation has been added to the Form 731 and the Operating Description revised. 6. Please note that the output power for each type emissions designator is required to be on the grant. Please note that only a CW signal was used to measure output power for this device. While this may be OK for FM, it is not appropriate for GSM or CDMA type modulations. Please provide the conducted antenna terminal output powers for all emissions types. RESPONSE: Additional ERP test information is provided in “1900 Updated EIRP Limit Test” 7. As the device accepts multiple inputs, please clarify if the power out of the device listed on the 731 is a composite of multichannels or per carrier. RESPONSE: The output power of the equipment is composite. When additional signals are input to the equipment, the gain of each signa…

Text truncated - open the document above for the full version.

TÜV America Inc. Phone: (651) 631-2487 1775 Old Highway 8 NW Fax: (651) 638-0285 Suite 104 E-mail: [email protected] New Brighton, MN 55112 www.TUVamerica.com Management Service • Product Service • Industry Service • Automotive • BABT TÜV America Inc. is a subsidiary of TÜV SÜD Group. 26 October 2005 American TCB 6731 Whittier Avenue McLean VA 22101 RE: ADC Telecommunications Response to 10252005 Comments FCC ID: F8I-DCX1902A In response to your comments on the above submittal from October 25, 2005. 1.) The RF Pout listed on Form 731 does not match the maximum noted in either the Test Report or the RF Exposure evaluation. Please correct. RESPONSE: Both the RF Exposure letter and Form 731 indicate 43.13 dBm (20.56 Watts). The Test Report shows 41.97 dBm (15.74 Watts). The reason the FCC report for EIRP (Effective Isotropic Radiated Power) states 41.97 is because the FCC tests the output power with a single carrier through the system in a "max input = max output" format. The number used in the RF Exposure letter and Form 731 was taken from the Industry Canada method, per RSS-131 Section 4.3 (noted below). Set the two generator frequencies f1 and f2 such that they and their third-order intermodulation product frequencies, f3= 2f1-f2 and f4 = 2f2 - f1, are all within the passband of the DUT. For enhancers rated 500 watts or less: Raise the input level to the DUT until the greater level of the intermodulation products at the enhancer output terminals, Po3 or Po4, equals -43 dBW. Record all signal levels and their frequencies. Calculate the mean output power (Pmean) under this testing condition using Pmean = Po1 + 3 dB. Pmean = +43.13 dBm or 20.56 Watts 2.) FYI: I await your photos, schematics and parts list. RESPONSE: Photo, Schematic, and Parts List files have been uploaded. 3.) Please note that all Licensed radio transmitters must include a Tune Up procedure. If no user or field serviceable controls are available, then a description of how the equipment is adjusted in the factory is required. FCC is concerned with how RF power and frequency will be maintained and controlled. If desired, this Tune Up procedure can be held Confidential, but must be included on the Confidentiality Request letter RESPONSE: Our apologies. This was overlooked on the initial upload. The Tune-Up Procedure information has now been uploaded. Please let us know if further information is required. Jolene Murphy Senior Technical Writer TÜV America Inc Tel: 651 638 0271 Fax: 651 638 0285 [email protected]

HUB Top, Front and left view HUB Top, Front and right view HUB Rear view RAN Front View RAN Right View RAN Back View RAN Left View RAN Top View RAN Bottom View

INFORMATION ON THIS DOCUMENT IS PROPRIETARY TO ADC AND SHALL NOT BE USED, COPIED, REPRODUCED OR DISCLOSED IN WHOLE OR IN PART WITHOUT WRITTEN CONSENT OF ADC TITLE CXD 1900 ADB Band FCC / IC Identification Label TOLERANCE UNLESS .XX NA OTHERWISE SPECIFIED .XX NA DRAWING NUMBER None A REV DO NOT SCALE DRAWING ENGR. Mark F. Miska SIZE A SHEET 1 OF 1 REV ECO DWN DATE A MFM 10-23-2005 FCC ID: F8I-DCX1902A IC: 1208G-DCX1902A 1 2 1.500 REF R.075 (4) DIE CUT LABEL .750 REF NOTES: 1 PRINTING TYPE: TRANSFER METHOD. COLOR: BLACK TEXT 8 PT ARIAL NON-BOLD LOCATED APPROXIMATELY AS SHOWN. 2 PRINTING TYPE: TRANSFER METHOD. COLOR: BLACK TEXT 6 PT ARIAL NON-BOLD LOCATED APPROXIMATELY AS SHOWN. MATERIAL: ADC PART NUMBER 1215140 3 LABEL LOCATION

HUB Disassembly HUB Disassembly - Closeup View 1 HUB Disassembly - Closeup View 2 RAN Disassembly - Open View RAN Disassembly - Empty View RAN Disassembly - Empty View - Closeup CPU Front CPU back – View 1 CPU back – View 2 Forward Simulcast Card (FSC) Front – View 1 Forward Simulcast Card (FSC) Front – View 2 Forward Simulcast Card (FSC) Back Hub Down Converter (HDC) Front – View 1 Hub Down Converter (HDC) Front – View 2 Hub Down Converter (HDC) Back

HUB System Interface Card (HUBSTF) Front HUB System Interface Card (HUBSTF) Back Hub Up Converter (HUC) Front Hub Up Converter (HUC) back Radio Access Node System Interface Card (RANSTF) Front Radio Access Node System Interface Card (RANSTF) Back RAN Downconverter (RDC) Front RAN Downconverter (RDC) Back Reverse Simulcast Card (RSC) Front Reverse Simulcast Card (RSC) Back RAN Up Converter (RUC) Front RAN Up Converter (RUC) Back Sonet Interface Module (SIF) Front Sonet Interface Module (SIF) Back Base Station Interface Module (BIM) G002 Top Right Base Station Interface Module (BIM) G002 Top Left Base Station Interface Module (BIM) G002 Bottom Right Base Station Interface Module (BIM) G002 Bottom Left

Broadband 20W LPA - 0072-1300 - Top View Broadband 20W LPA - 0072-1300 - Bottom View Broadband 20W LPA - Board 2 - Top View Broadband 20W LPA - Board 2 - Bottom View Cherokee Power Supply - Top, Front and Right View Cherokee Power Supply - Top, Back and Left View Cherokee Power Supply - Disassembly View 1 Cherokee Power Supply - Disassembly View 2 Cherokee Power Supply - Board Top Cherokee Power Supply - Board Bottom Digital Power - Power Supply - eFO306-1XX, Top View Digital Power - Power Supply - eFO306-1XX, Output Digital Power - Power Supply - eFO306-1XX, Input Digital Power - Power Supply - eFO306-1XX, ¾ View Digital Power - Power Supply - Board Bottom

TEST RESULT SUMMARY FCC Part 24 Subpart E MANUFACTURER ADDRESS ADC Inc. P.O. Box 1101 Minneapolis, MN 55440-1101 NAME OF EQUIPMENT Digivance® CXD 1900 MHz ADB Band MODEL NUMBERS DGVF-04000000XXCRN TEST REPORT NUMBER WC505364 TEST DATES 18 October, 2005 (TÜV) 20 October, 2005 (ADC) According to testing performed at TÜV America Inc, the above-mentioned unit is in compliance with the electromagnetic compatibility (EMC) portions of the requirements defined in FCC Part 24 Subpart E. It is the manufacturer's responsibility to assure that additional production units of this model are manufactured with identical electrical and mechanical characteristics. Any modifications necessary for compliance made during testing on the above mentioned date(s) must be implemented in all production units for compliance to be maintained. TÜV America Inc, as an independent testing laboratory, declares that the equipment tested as specified above conforms to the EMC requirements of FCC Part 24 Subpart E “Broadband PCS”. Date: 25 October 2005 Tested By Technical Writer J. C. Sausen G. S. Jakubowski Not Transferable File No. WC505364, Page 1 of 130 TÜV AMERICA INC 19333 Wild Mountain Road Taylors Falls MN 55084-1758 Tel: 651 638 0297 Fax: 651 638 0298 EMC EMISSION - T E S T R E P O R T Test Report File No. : WC505364 Date of issue: 25 October 2005 Model / Serial Nos. : DGVF-04000000XXCRN Product Name : Digivance® CXD 1900 MHz ADB Band Applicant : ADC Inc. Manufacturer : ADC Inc. Address : P.O. Box 1101 : Minneapolis, MN 55440-1101 Test Result : „ Positive † Negative Test Project Number : Reference(s) WC505364 Total pages including Appendices 146 TÜV America Inc reports apply only to the specific samples tested under stated test conditions. It is the manufacturer's responsibility to assure that additional production units of this model are manufactured with identical electrical and mechanical components. TÜV America Inc shall have no liability for any deductions, inferences or generalizations drawn by the client or others from TÜV America Inc issued reports. This report is the confidential property of the client. As a mutual protection to our clients, the public and ourselves, extracts from the test report shall not be reproduced except in full without our written approval. This report shall not be used by the client to claim product endorsement by NVLAP, NIST, or any agency of the US government. TÜV America Inc and its professional staff hold government and professional organization certifications and are members of AAMI, ACIL, AEA, ANSI, IEEE, NVLAP, and VCCI File No. WC505364, Page 2 of 130 TÜV AMERICA INC 19333 Wild Mountain Road Taylors Falls MN 55084-1758 Tel: 651 638 0297 Fax: 651 638 0298 D I R E C T O R Y - EMISSIONS Page(s) Documentation Test report 1 – xx Emissions Test Regulations 3 Test Operation Mode 129 Configuration of the device under test 129 Deviations from Standard 130 General Remarks 130 Summary 130 Test data 24.232 Power and Antenna Height Limits 4 - 5 24.235 Frequency Stability 6 - 19 24.238 Emission Limits 20 - 64 Intermodulation Data 65 - 120 Test Setup Photos & Drawings 121 - 128 Appendix A Constructional Data Form & Block Diagrams A1 – A13 Appendix B Measurement Protocol B1 – B3 File No. WC505364, Page 3 of 130 TÜV AMERICA INC 19333 Wild Mountain Road Taylors Falls MN 55084-1758 Tel: 651 638 0297 Fax: 651 638 0298 Sign Explanations: † - not applicable „ - applicable EMISSIONS TEST REGULATIONS : The emissions tests were performed according to following regulations: -------------------------------------------------------------------------------- † - EN 50081-1 / 1991 † - EN 55011 / 1991 † - Group 1 † - Group 2 † - Class A † - Class B † - EN 55013 / 1990 † - EN 55014 / 1987 † - Household appliances and similar † - Portable tools † - Semiconductor devices † - EN 55014 / A2:1990 † - EN 55014 / 1993 † - Household appliances and similar † - Portable tools † - Semiconductor devices † - EN 55015 / 1987 † - EN 55015 / A1:1990 † - EN 55015 / 1993 † - EN 55022 / 1987 † - Class A † - Class B † - EN 55022 / 1994 † - Class A † - Class B † - BS † - VCCI † - Class A † - Class B „ - FCC Part 24 Subpart E † - FCC Part 15 Subpart B † - Class A † - Class B † - CISPR 11 (1990) † - Group 1 † - Group 2 † - Class A † - Class B † - CISPR 22 (1993) † - Class A † - Class B File No. WC505364, Page 4 of 130 TÜV AMERICA INC 19333 Wild Mountain Road Taylors Falls MN 55084-1758 Tel: 651 638 0297 Fax: 651 638 0298 24.232 Power and antenna height limits The transmit power measurements were tested at the following test location: † - Test not applicable † - Wild River Lab Large Test Site (Open Area Test Site) † - Wild River Lab Small Test Site (Open Area Test Site) „ - ADC facility ADC’s Test equipment used: Manufacturer Model Description ADC Serial No. Cal Due Aeroflex 49-30-33 Attenuator n/a CNR HP HP8563E Spectrum Analyzer MC27690 6-22-06 HP EPM-441A Power Meter MC27670 9-28-06 Equipment used in testing that has a Calibration Not Required (CNR) listing is verified and compensated for with NIST traceable calibrated equipment. Transmit power data on next page: Effective Isotropic Radiated Power Test for ADC Inc. Digivance CXD Model Number DGVF-04000000CRN *Note: The EUT is a fixed repeater and not a base station. This measurement was made as a direct conducted emission measurement. The output from the EUT antenna connector was connected to the spectrum analyzer. The carrier output, below, was conducted using a single CW signal generator. The spectrum analyzer level was offset to compensate for attenuators and cable loss between the EUT and the analyzer. A CW signal was used at the low, mid and high parts of the selected band. The spectrum analyzer level was offset by 51.3 dB to compensate for attenuators and cable loss between the EUT and the analyzer. Band A (1900 MHz) Carrier Frequency Carrier Output 1930.0 MHz 40.97 dBm 1937.5 MHz 41.47 dBm 1945.0 MHz 41.13 dBm Band D (1900 MHz) Carrier Frequency Carrier Output 1945.0 MHz…
