F8I-PSM0850MFlexWave Prism HDM 850 MHz MIMO

Dual-Band Dual-Slot RF Module Single-Slot RF Module Legacy Dual-Slot 40W RF Module HDM RF Module FlexWave Prism and Spectrum Software Release 8.1.4.7 Release Notes TECP‐77‐141 ∙ Issue 6 ∙ July 2014 TE Connectivity, TE and TE connectivity (logo) FlexWave, InterReach, InterReach Fusion and InterReach Unison are trademarks. All other logos, products and/or company names referred to herein might be trademarks of their respective owners. The information given herein, including drawings, illustrations and schematics which are intended for illustration purposes only, is believed to be rel iable. However, TE Connectivity makes no warranties as to its accuracy or completeness and disclaims any liability in connection with its use. TE Connectivity's obligations shall only be as set forth in TE Connectivity's Standard Terms and Conditions of Sale for this product and in no case will TE Co nnectivity be liable for any incidental, indirect or consequential damages arising out of the sale, resale, use or misuse of the product. Users of TE Connectivity products should make their own evaluation to determine the suitability of each such product for the specific application. This manual provides the information you need to install TE Connectivity FlexWave Prism ® RF Modules into a Prism Remote Unit (PRU). Installation instructions are provide d for the following Prism Remote Unit RF Modules: •Single‐Bay R F Modules, which includes the HDM RF Modules •Dual‐Bay RF Modules –Dual‐Band RF Modules –Legacy 40W RF Modules. Page 2FlexWave Prism Remote Unit RF Module Installation Guide ©2014 TE ConnectivityTECP‐77‐141 Issue 6 • 300001744178 Rev F • July 2014 TABLE OF CONTENTS Document Overview ...........................................................................................................................................................................................3 Revision History.......................................................................................................................................................................................................5 Document Cautions and Notes ...............................................................................................................................................................................5 Abbreviations Used in this Guide............................................................................................................................................................................5 Overview of RF Modules for Prism Remote Units ................................................................................................................................................6 RF Module DARTs....................................................................................................................................................................................................7 RF Module Types.....................................................................................................................................................................................................8 Single‐ and Dual‐Bay RF Modules with Classic or SuperDARTs.......................................................................................................................8 HDM RF Modules ............................................................................................................................................................................................9 Legacy Dual‐Bay 40W RF Modules................................................................................................................................................................10 RF Module Components....................................................................................................................................................................................11 Duplexer and Low Noise Amplifier........................................................................................................................................................................12 Linear Power Amplifiers........................................................................................................................................................................................12 Digital Processing Module.....................................................................................................................................................................................13 Understanding the RF Module Cables................................................................................................................................................................13 Power Cable Connection.......................................................................................................................................................................................13 LVDS Cable Connections........................................................................................................................................................................................13 RF Cable Connections............................................................................................................................................................................................14 RF Cable Rules ...............................................................................................................................................................................................14 RF Module Cables for Single‐Card, Dual‐Card, and HDM RF Modules..........................................................................................................15 RF Module Cables for Dual‐Bay Installations ................................................................................................................................................16 RF Group Assignments for PRUs .......................................…

Text truncated - open the document above for the full version.

Mailing Address: P.O. Box 1101, Minneapolis, Minnesota 55440-1101 World Headquarters: Minneapolis, Minnesota USA +1.952.938.8080 www.adc.com July 7, 2014 Attn: Application Examiner, Reviewing Engineer Re: Attestation Statement I, the undersigned, attest that all testing done under my supervision was done in accordance with the Federal Communications Commission’s CFR 47 Part 22 and the EUT fulfills the requirements of the Federal Communications Commission’s CFR 47 Part 22. Sincerely, Joshua J. Wittman Compliance Engineer Tele: 952 403-8322 Fax: 952 403-8858 Email: [email protected]

1(1) Attention: Application Examiner Re: Request for confidentiality Applicant: ADC Telecommunications, Inc. FCC ID: F8I-PSM0850M To whom it may concern, Permanent Confidentiality Request is hereby submitted by ADC Telecommunications, Inc. to withhold permanently from public review certain portions of the application for equipment certification for the referenced FCC identifiers. This request for confidentiality is made pursuant to 47 CFR 0.457(d) and 0.459 of the FCC Rules. In particular, the following sections of the application are to be kept permanently confidential: • Schematics • Detailed Block diagrams • Detailed Operational/Functional Description • Parts list Rationale for request for confidentiality: ADC Telecommunications, Inc. has invested considerable time and materials in research and development to produce the referenced product. Disclosure of the permanently confidential portions of this application to competitors would not only give them significant competitive advantages in developing similar products, but would also disclose successful implementation of unpublished, leading edge technology developed by us. The fee for confidentiality has been submitted along with the fee for certification. If you have questions or need further information, please contact the undersigned. Sincerely, Joshua J. Wittman Compliance Engineer ADC Telecommunications, Inc.

FWP-B4MT000MOD External Photos RF Module Assembly #1 FCC/IC Label Location FWP-B4MT000MOD External Photos RF Module Assembly #2 FWP-B4MT000MOD External Photos RF Module Assembly #3 Location of “Industrial Signal Booster Warning Label” FWP-B4MT000MOD External Photos RF Module Assembly #4 FWP-B4MT000MOD External Photos RF Module Assembly #5 FWP-B4MT000MOD External Photos RF Module Assembly #6 FCC/IC Label Location FWP-B4MT000MOD External Photos RF Module Assembly #7 FWP-B4MT000MOD External Photos RF Module Assembly #8

INFORMATION ON THIS DOCUMENT IS PROPRIETARY TO ADC AND SHALL NOT BE USED, COPIED, REPRODUCED OR DISCLOSED IN WHOLE OR IN PART WITHOUT WRITTEN CONSENT OF ADC TITLE FlexWave™ Prism – HDM 20W 850 MHz MIMO FCC/IC Identification Label TOLERANCE UNLESS .XX NA OTHERWISE SPECIFIED .XX NA DRAWING NUMBER None A REV DO NOT SCALE DRAWING ENGR. Joshua J. Wittman SIZE A SHEET 1 OF 1 REV ECO DWN DATE A JJW 7-8-2014 Model: FWP-B4MT000MOD FCC ID: F8I-PSM0850M IC: 1208G-PSM0850M 2 1.500 REF R.075 (4) DIE CUT LABEL .750 REF 1 NOTES: 1 PRINTING TYPE: TRANSFER METHOD. COLOR: BLACK TEXT 8 PT ARIAL NON-BOLD LOCATED APPROXIMATELY AS SHOWN. 2 PRINTING TYPE: TRANSFER METHOD. COLOR: BLACK TEXT 6 PT ARIAL NON-BOLD LOCATED APPROXIMATELY AS SHOWN. MATERIAL: ADC PART NUMBER 1215140 3 FCC ID and Industrial Booster Warning Label Location on Chassis Industrial Booster Label Chassis Location FCC/IC Label Chassis Location

FWP-B4MT000MOD Internal Photos Motherboard – Front #1 FWP-B4MT000MOD Internal Photos Motherboard – Front #2 FWP-B4MT000MOD Internal Photos Motherboard – Front #3 FWP-B4MT000MOD Internal Photos Motherboard – Back #1 FWP-B4MT000MOD Internal Photos Motherboard – Back #2 FWP-B4MT000MOD Internal Photos Motherboard – Back #3 FWP-B4MT000MOD Internal Photos Tx Board – Front Tx Radio FWP-B4MT000MOD Internal Photos Tx Board – Back FWP-B4MT000MOD Internal Photos Rx Board – Front FWP-B4MT000MOD Internal Photos Rx Board – Back FWP-B4MT000MOD Internal Photos Duplexer #1 FWP-B4MT000MOD Internal Photos Duplexer #2 Antenna port FWP-B4MT000MOD Internal Photos Duplexer #3 FWP-B4MT000MOD Internal Photos LPA #1 FWP-B4MT000MOD Internal Photos LPA #2 FWP-B4MT000MOD Internal Photos LPA #3

Mailing Address: P.O. Box 1101, Minneapolis, Minnesota 55440-1101 World Headquarters: Minneapolis, Minnesota USA +1.952.938.8080 www.adc.com July 8, 2014 Attn: Application Examiner, Reviewing Engineer Re: Tune-up Procedure The FlexWave™ Prism – HDM 850 MIMO model number FWP-B4MT000MOD employs a solid- state design that does not require a tune-up procedure. Sincerely, Joshua J. Wittman Compliance Engineer Tele: 952 403-8322 Fax: 952 403-8858 Email: [email protected]

Mailing Address: 501 Shenandoah Drive, Shakopee, Minnesota 55379 www.te.com July 14, 2014 Attn: Application Examiner, Reviewing Engineer The following is the SAR calculation for the FlexWave™ Prism – HDM 850 MIMO, FCC ID: F8I-PSM0850M, using the system’s maximum RF emission. The calculation is based on FCC 47CFR Part 2 and OET 65. Per OET 65: Maximum Permissible Exposure is Freq. (MHz)/1500 = MPE mW/cm 2 881.5 MHz/1500= 0.5877 mW/cm 2 The following equations determine the distance from the antenna that the power density is ≤ 0.5877 mW/cm 2 . +47.10 dBm Transmitter Power (Max) 12.90 dBi Antenna Gain (Max) 47.10 dBm + 12.90 dBi= +60 dBm EIRP +60 dBm EIRP = 1000 Watts EIRP 1000 Watts EIRP = 1000*10 3 mWatts EIRP 0.5877 mW/cm 2 = 1000*10 3 mW/(4*π*r 2 ) r= SQR(1000*10 3 /4*π 0.5877) r= 368.06 cm or 3.68 Meters In addition, the following statement will be added to our installation/operation manual: To comply with Maximum Permissible Exposure (MPE) requirements, the maximum composite output from the antenna cannot exceed 1000 Watts EIRP and the antenna must be permanently installed in a fixed location that provides at least 6 meters (20 feet) of separation from all persons. Sincerely, Joshua J. Wittman Compliance Engineer Tele: 952 403-8322 Fax: 952 403-8858 Email: [email protected]

M N 1 2 1 1 1 4 _ F C C _ P r i s m _ H D M _ 8 5 0 _ M I M O _ F C C - I D : F 8 I - P S M 0 8 5 0M Page 1 Test Report Summary FCC CFR 47, Part 22 Subpart H Cellular Radiotelephone Service Manufacturer: ADC Telecommunications, Inc Name of Equipment: FlexWave™ Prism – HDM 850 MIMO Model Number(s): FWP-B4MT000MOD Manufacturer’s Address: P.O. Box 1101 Minneapolis, MN 55440-1101 Test Report Number: MN140711_FCC_Prism_HDM_850 MIMO FCC-ID: F8I-PSM0850M Test Date(s): 9 July, 2014 (Intertek) 25, 30, 31 October & 1, 2, 6, 7, 8 November (ADC) According to testing performed at Intertek, the above-mentioned unit is in accordance with the applicable electromagnetic compatibility (EMC) portions of the requirements defined in FCC Part 22. It is the manufacturer’s responsibility to assure that additional production units of this model are manufactured with identical electrical and mechanical characteristics. Any modifications necessary for compliance made during testing on the above mentioned date(s) must be implemented in all production units for compliance to be maintained. All testing was done in accordance with the Federal Communications Commission’s CFR 47 Part 22. The EUT fulfills the requirements of the Federal Communications Commission’s CFR 47 Part 22. Date: 11 July, 2014 Location: Intertek Testing Services (INTERTEK) ADC Telecommunications 7250 Hudson Blvd., Suite 100 1187 Park Place Oakdale, MN 55128 Shakopee, MN 55379 Phone: (651) 730-1188 Phone: (952) 403-8322 Fax: (651) 730-1282 Testing Conducted by (ADC): And Report Written by: Joshua J. Wittman Compliance Engineer M N 1 2 1 1 1 4 _ F C C _ P r i s m _ H D M _ 8 5 0 _ M I M O _ F C C - I D : F 8 I - P S M 0 8 5 0M Page 2 EMC Emission – T E S T R E P O R T Test Report File Number: MN140711_FCC_Prism_HDM_850 MIMO FCC-ID: F8I-PSM0850M Date of Issue: 11 July, 2014 Model Number(s): FWP-B4MT000MOD Product Name: FlexWave™ Prism – HDM 850 MHz MIMO Product Type: Industrial Booster/Repeater Applicant: ADC Telecommunications, Inc Manufacturer: ADC Telecommunications, Inc License Holder: ADC Telecommunications, Inc Address: P.O. Box 1101 Minneapolis, MN 55440-1101 Test Result: ▪ Positive ▫ Negative Test Project Number: 101716480MIN-001 Reference(s) Total pages including Appendices: 77 M N 1 2 1 1 1 4 _ F C C _ P r i s m _ H D M _ 8 5 0 _ M I M O _ F C C - I D : F 8 I - P S M 0 8 5 0M Page 3 1.0 TABLE OF CONTENTS 1.0 Table of Contents .................................................................................................... 3 2.0 Revision Description ................................................................................................ 4 3.0 Documentation ....................................................................................................... 4 3.1 Test Regulations .................................................................................................. 4 3.2 Summary: ........................................................................................................... 5 3.3 Test Operation Mode ............................................................................................. 5 3.4 Configuration of the Device Under Test: .................................................................. 5 3.5 Product Options: .................................................................................................. 5 3.6 Chassis Specifications and Requirements: ............................................................... 5 3.7 Cables: ............................................................................................................... 5 3.8 Power Requirements: ........................................................................................... 6 3.9 Typical Installation and/or Operating Environment: .................................................. 6 3.10 Other Special Requirements: .............................................................................. 6 3.11 EUT Software: ................................................................................................... 6 3.12 EUT System Components ................................................................................... 6 3.13 Deviations from Standard: .................................................................................. 6 3.14 General Remarks: ............................................................................................. 7 4.0 Test Set-Up Drawings and Photos ............................................................................. 8 4.1 Test Set-up Photo, Radiated Emissions ................................................................... 8 4.2 Test Set-up Drawings ........................................................................................... 9 5.0 Test Equipment .................................................................................................... 11 6.0 Test Results ......................................................................................................... 12 6.1 FCC 22.917 Emissions Limits – Band Edge............................................................. 12 6.2 FCC 2.1049, 22.917 – Occupied Bandwidth ........................................................... 20 6.3 FCC 2.1046, 22.913 Power Limits – Output Power .................................................. 28 6.4 FCC 2.1051, 22.917 Emissions Limits – Spurious Emissions at Antenna .................... 30 6.5 FCC 2.1055, 22.355 – Frequency Stability ............................................................. 73 7.0 Appendix B .......................................................................................................... 75 8.0 Appendix C .......................................................................................................... 77 M N 1 2 1 1 1 4 _ F C C _ P r i s m _ H D M _ 8 5 0 _ M I M O _ F C C - I D : F 8 I - P S M 0 8 5 0M Page 4 2.0 REVISION DESCRIPTION Rev Total Pages Date Description A 77 11 July, 2014 Original Release 3.0 DOCUMENTATI…

Text truncated - open the document above for the full version.

TEST REPORT Report Number: 101716480MIN-001 Project Number: G101716480 Testing performed on the FWP – B4MT000MOD to 47 CFR, Part 22:2010, Enclosure Spurious Radiated Emissions RSS-132 Issue 3, 2013 For TE Connectivity Company / ADC Telecommunications Inc Test Performed by: Test Authorized by: Intertek Testing Services NA, Inc. 7250 Hudson Blvd., Suite 100 Oakdale, MN 55128 USA TE Connectivity Company / ADC Telecommunications Inc 541 E Trimble Road San Jose, CA 95131 USA Prepared by: Date: July 9, 2014 Simon Khazon Reviewed by: Date: July 9, 2014 Norman Shpilsher This report is for the exclusive use of Intertek's Client and is provided pursuant to the agreement between Intertek and its Client. Intertek's responsibility and liability are limited to the terms and conditions of the agreement. Intertek assumes no liability to any party, other than to the Client in accordance with the agreement, for any loss, expense or damage occasioned by the use of this report. Only the Client is authorized to permit copying or distribution of this report and then only in its entirety. Any use of the Intertek name or one of its marks for the sale or advertisement of the tested material, product or service must first be approved in writing by Intertek. The observations and test results in this report are relevant only to the sample tested. This report by itself does not imply that the material, product, or service is or has ever been under an Intertek certification program. EMC Report No: 101716480MIN-001 Page 2 of 18 TABLE OF CONTENTS 1.0 DESCRIPTION OF THE SAMPLE (EUT).................................................................................3 2.0 TEST SUMMARY..........................................................................................................................4 2.1 Statement of the Measurement Uncertainty.............................................................................. 4 3.0 EQUIPMENT UNDER TEST.......................................................................................................5 3.1 Power Configuration..................................................................................................................... 5 3.2 EUT Configuration......................................................................................................................... 5 3.3 Environmental conditions............................................................................................................. 6 4.0 TEST CONDITIONS AND RESULTS........................................................................................7 4.1 Enclosure Spurious Radiated Emissions................................................................................... 7 5.0 TEST EQUIPMENT.....................................................................................................................18 EMC Report No: 101716480MIN-001 Page 3 of 18 1.0 DESCRIPTION OF THE SAMPLE (EUT) Model: FWP – B4MT000MOD Type of EUT: 850 CELL MIMO Serial Number / Intertek Sample ID: 869-894MHz Company: TE Connectivity Company / ADC Telecommunications Inc Customer: Sue Cyr Address: 541 E. Trimble Road San Jose, CA 95131 USA Phone: 408-952-2445 Fax: 408-952-2645 e-mail: [email protected] Test Standards: EN 55022:2006 +A1:2007, Class EN 55011:2007 +A2:2007, Group , Class 47 CFR, Part 22:2010, Enclosure Spurious Radiated Emissions RSS-132 Issue 3, 2013 EN 55014-1:2006 EN 61326-1:2006 Class for Radiated and Conducted Emissions Basic Immunity Test Requirements Immunity Test Requirements for Industrial Locations EN 60601-1-2:2001 +A1:2006 EN 61000-6-3:2007 EN 61000-6-4:2007 EN 61000-3-2:2006 EN 61000-3-3:1995 +A1:2001 +A2:2006 EN 61000-6-1:2007 EN 61000-6-2:2005 EN 55024:1998 + A1:2001 + A2:2003 Date Sample Submitted: July 9, 2014 Test Work Started: July 9, 2014 Test Work Completed: July 9, 2014 Test Sample Conditions: Damaged Poor (Usable) Good Prototype Production Used EMC Report No: 101716480MIN-001 Page 4 of 18 2.0 TEST SUMMARY Referring to the performance criteria and the operating mode during the tests specified in this report, the equipment complies with the requirements according to the following standards. TEST STANDARD TEST RESULT Part 22 Enclosure Spurious Radiated Emissions Pass 2.1 Statement of the Measurement Uncertainty Note 1: The measured result in this report is within the specification limits by more than the measurement uncertainty; the measured result indicates that the product tested complies with the specification limit. The expanded uncertainty (k = 2) for radiated emissions from 30 to 1000 MHz has been determined to be: ±4 dB at 10m and ±5.4 dB at 3m The expanded uncertainty (k = 2) for conducted emissions from 150 kHz to 30 MHz has been determined to be: ±2.6 dB EMC Report No: 101716480MIN-001 Page 5 of 18 3.0 EQUIPMENT UNDER TEST 3.1 Power Configuration Rated voltage: 120VAC 230VAC 400VAC Supply Other: Rated current: Amp. Rated frequency: 50Hz 60Hz Number of phases: 1 Phase 3 Phases 3.2 EUT Configuration The equipment under test was operated during the measurement under the following conditions: - Standby - Test program (H - Pattern) - Continuous Operation (see details below) - Specific test program Operating modes of the EUT: No. Description 1 Continuous transmission of RF signals at 870MHz, 881MHz and 893MHz into two paths. 2 The EUT antenna ports were terminated. Cables: No. Type Length Designation Note 1 Two RF coax 10m each RF signal cables to the Support Equipment Support equipment/Services: No. Item Description 1 Agilent E4421B (located outside Test site) Signal Generator 2 Prism Host Unit 3 Prism Host 28VDC Power Supply 4 30dB Attenuator (2) 5 Prism Remote Chassis FPI – 10000002121R4 General notes: None EMC Report No: 101716480MIN-001 Page 6 of 18 3.3 Environmental conditions During the measurement the environmental conditions were within the listed ranges: Temperature: 15-35 ° C Humidity: 30-60 % Atmospheric pressure: 86-106 kPa EMC Report No: 101716480MIN-001 Page…

Text truncated - open the document above for the full version.
