F8I-DCXSMR1ADigivance� CXD SMR 800/900 MHz System)

ADC Telecommunications Inc

Click to zoom

Application Details

Equipment Class: TNB - Licensed Non-Broadcast Station Transmitter
Date of Grant: Dec 27, 2005
Application Purpose: Original Equipment
Date of Application: Dec 27, 2005
Equipment Note: Digivance� CXD SMR 800/900 MHz System)
Frequency Range: 935.00000000 - 940.00000000
Company: ADC Telecommunications Inc
Country: United States

Documents & Files

Select a file to view

Document Text

Text extracted from the exhibit documents filed with the FCC. Open a document above to read the original.

Users Manual

ADCP-75-192 Preliminary Issue D October 2005 Digivance    CXD Multi-Band Distributed Antenna System Installation and Operation Manual 1343155 Rev 1 ADCP-75-192 Preliminary Issue D October 2005 Digivance    CXD Multi-Band Distributed Antenna System Installation and Operation Manual 1343155 Rev 1 ADCP-75-192 • Issue D • October 2005 • Preface Page ii COPYRIGHT  2005, ADC Telecommunications, Inc. All Rights Reserved Printed in the U.S.A. REVISION HISTORY ISSUE DATE REASON FOR CHANGE Issue D 10/2005 Original release LIST OF CHANGES The technical changes incorporated into this issue are listed below. SECTION IDENTIFIER DESCRIPTION OF CHANGE - - Original release TRADEMARK INFORMATION ADC and Digivance are registered trademarks of ADC Telecommunications, Inc. DISCLAIMER OF LIABILITY Contents herein are current as of the date of publication. ADC reserves the right to change the contents without prior notice. In no event shall ADC be liable for any damages resulting from loss of data, loss of use, or loss of profits and ADC further disclaims any and all liability for indirect, incidental, special, consequential or other similar damages. This disclaimer of liability applies to all products, publications and services during and after the warranty period. This publication may be verified at any time by contacting ADC’s Technical Assistance Center at 1-800-366-3891, extension 73476 (in U.S.A. or Canada) or 952-917-3476 (outside U.S.A. and Canada), or by e-mail to [email protected]. ADC Telecommunications, Inc. P.O. Box 1101, Minneapolis, Minnesota 55440-1101 In U.S.A. and Canada: 1-800-366-3891 Outside U.S.A. and Canada: (952) 917-3475 Fax: (952) 917-1717 ADCP-75-192 • Issue D • October 2005 • Preface Page iii  2005, ADC Telecommunications, Inc. TABLE OF CONTENTS Content Page FRONT MATTER ABOUT THIS MANUAL.......................................................................v RELATED PUBLICATIONS.....................................................................v ADMONISHMENTS........................................................................vi GENERAL SAFETY PRECAUTIONS...............................................................vi SAVE WORKING DISTANCES..................................................................vii COMPLIANCE STATEMENT..................................................................viii ACRONYMS AND ABBREVIATIONS.............................................................viii SECTION 1 OVERVIEW 1 INTRODUCTION....................................................................1-1 2 DIGIVANCE CXD SYSTEM OVERVIEW......................................................1-1 2.1 Basic Components.............................................................1-2 2.2 General Description............................................................1-2 2.3 Local Service Interface..........................................................1-3 2.4 Remote NOC Interface..........................................................1-4 3 SYSTEM FUNCTIONS AND FEATURES......................................................1-4 3.1 Fiber Optic Transport...........................................................1-4 3.2 Control and Monitoring Software...................................................1-5 3.3 Fault Detection and Alarm Reporting.................................................1-5 3.4 Powering...................................................................1-5 3.5 Equipment Mounting and Configuration...............................................1-6 3.6 RAN Subsystem Assemblies......................................................1-6 3.7 HUB Subsystem Assemblies......................................................1-9 3.8 Communication Interfaces.......................................................1-12 SECTION 2 DESCRIPTION 1 INTRODUCTION....................................................................2-1 1.1 Digital Chassis...............................................................2-1 1.2 RF Chassis..................................................................2-3 1.3 Radio Access Node............................................................2-4 2 ELEMENTS COMMON TO HUB AND RAN....................................................2-5 2.1 CPU.......................................................................2-5 2.2 STF2......................................................................2-7 2.3 SIF.......................................................................2-9 3 RAN...........................................................................2-11 3.1 RDC.....................................................................2-11 3.2 RUC.....................................................................2-13 3.3 RF Assembly Module..........................................................2-14 ADCP-75-192 • Issue D • October 2005 • Preface Page iv  2005, ADC Telecommunications, Inc. TABLE OF CONTENTS Content Page 3.4 CompactPCI Power Supply.......................................................2-16 4 HUB............................................................................2-16 4.1 Full Band HDC (FBHDC) ........................................................2-16 4.2 Forward Simulcast Module, FSC...................................................2-18 4.3 Hub Upconverter Module, HUC....................................................2-20 4.4 Reverse Simulcast Module, RSC...................................................2-21 4.5 Hub Reference Module, HRM.....................................................2-23 4.6 Ethernet Switch..............................................................2-25 4.7 BTS Interface Module, BIM.......................................................2-25 4.8 Attenuator Shelf .............................................................2-26 4.9 Specifications...............................................................2-27 SECTION 3 NETWORK AND SYSTEM INSTALLATION AND SETUP 1 INTRODUCTION...............................…

Text truncated - open the document above for the full version.

Cover Letter(s)

Attn: Director of Certification

Cover Letter(s)

American Telecommunications Certification Body Inc. 6731 Whittier Ave, McLean, VA 22101 December 20, 2005 RE: FCC ID: F8I-DCXSMR1A_ATCB003034 Attention: Joel T Schneider I have a few comments on this Application. Please note that further comments may arise in response to answers provided to the questions below. 1. Please note that there appears to be tape on the device in one of the external photos. This appears to be duct tape, but it is not clear if this is for the purpose of EMC compliance or not. Please explain. 2. Please note that the emissions designators for this device as listed on the 731 are only D7W. However, the report also shows CDMA, which is F9W. If the CDMA is also desired to be on the grant, please revise the 731 form to include this emission designator. Dennis Ward mailto:[email protected] The items indicated above must be submitted before processing can continue on the above referenced application. Failure to provide the requested information may result in application termination. Correspondence should be considered part of the permanent submission and may be viewed from the Internet after a Grant of Equipment Authorization is issued. Please do not respond to this correspondence using the email reply button. In order for your response to be processed expeditiously, you must submit your documents through the AmericanTCB.com website. Also, please note that partial responses increase processing time and should not be submitted. Any questions about the content of this correspondence should be directed to the sender.

Cover Letter(s)

American Telecommunications Certification Body Inc. 6731 Whittier Ave, McLean, VA 22101 December 22, 2005 RE: FCC ID: F8I-DCXSMR1A_ATCB003034 Attention: Joel T Schneider Supplemental comments I have a few comments on this Application. Please note that further comments may arise in response to answers provided to the questions below. 1. Please note that there appears to be tape on the device in one of the external photos. This appears to be duct tape, but it is not clear if this is for the purpose of EMC compliance or not. Please explain. 2. Please note that the emissions designators for this device as listed on the 731 are only D7W. However, the report also shows CDMA, which is F9W. If the CDMA is also desired to be on the grant, please revise the 731 form to include this emission designator. 3. Please note that the FCC ID number on the 731 does not match the FCC ID on the label and other information. Please correct the appropriate documentation so the FCC ID numbers are consistent. 4. Please note that the documentation calls this device an antenna system. The 731 calls this device an amplifier and a CDX SMR system. This appears to be what the FCC refers to as a fiber optic distribution system, which is considered a signal booster or repeater. A booster retransmits signals on the same channel while repeaters retransmit on different channels. From the report this appears to be a booster. Please verify. 5. The manual says this device also has PCS frequencies. If this device operates in the part 24 PCS bands please explain and please provide the appropriate data. Dennis Ward mailto:[email protected] The items indicated above must be submitted before processing can continue on the above referenced application. Failure to provide the requested information may result in application termination. Correspondence should be considered part of the permanent submission and may be viewed from the Internet after a Grant of Equipment Authorization is issued. Please do not respond to this correspondence using the email reply button. In order for your response to be processed expeditiously, you must submit your documents through the AmericanTCB.com website. Also, please note that partial responses increase processing time and should not be submitted. Any questions about the content of this correspondence should be directed to the sender.

Cover Letter(s)

TÜV America Inc. Phone: (651) 631-2487 1775 Old Highway 8 NW Fax: (651) 638-0285 Suite 104 E-mail: [email protected] New Brighton, MN 55112 www.TUVamerica.com Management Service • Product Service • Industry Service • Automotive • BABT TÜV America Inc. is a subsidiary of TÜV SÜD Group. 22 December 2005 American TCB 6731 Whittier Avenue McLean VA 22101 RE: ADC Telecommunicaitons Inc Response to December 22 2005 Comments FCC ID: F8I-DCXSMR1A In response to your comments on the above submittal. 1. Please note that there appears to be tape on the device in one of the external photos. This appears to be duct tape, but it is not clear if this is for the purpose of EMC compliance or not. Please explain. RESPONSE: The tape was only a water ingress issue and nothing to do with EMC. 2. Please note that the emissions designators for this device as listed on the 731 are only D7W. However, the report also shows CDMA, which is F9W. If the CDMA is also desired to be on the grant, please revise the 731 form to include this emission designator. RESPONSE: The Form 731 has been revised to list all of the modulations and emission designators. In addition, the Test Report has been revised replacing the EIRP test data (page 3) for all modulations. 3. Please note that the FCC ID number on the 731 does not match the FCC ID on the label and other information. Please correct the appropriate documentation so the FCC ID numbers are consistent. RESPONSE: I apologize for my oversight. The ID had changed part way through the project and I apparently missed updating the Form 731. This has been corrected. 4. Please note that the documentation calls this device an antenna system. The 731 calls this device an amplifier and a CDX SMR system. This appears to be what the FCC refers to as a fiber optic distribution system, which is considered a signal booster or repeater. A booster retransmits signals on the same channel while repeaters retransmit on different channels. From the report this appears to be a booster. Please verify. RESPONSE: The device is a repeater The form 731 has been revised to indicate frequency tolerance. 5. The manual says this device also has PCS frequencies. If this device operates in the part 24 PCS bands please explain and please provide the appropriate data. RESPONSE: The top-level product that is sold to the customer to operate within the various frequency blocks pertaining to the systems respect approvals. Each system is approved specifically. In this case we approving the SMR 800/900 MHz System. A separate approval for the PCS 1900 MHz (1930-1965) was issued 11-2-05 (FCC ID F8I-DCX1902A). Each system is approved separately, though documentation has been combined for the ease of customer convenience. The following statement can be found on page 13 of the manual: Each respective SMR, Cellular, and PCS system in this CXD platform is singularly FCC and IC approved. Information in this manual explains applicable portions of these systems. TÜV America Inc. Phone: (651) 631-2487 1775 Old Highway 8 NW Fax: (651) 638-0285 Suite 104 E-mail: [email protected] New Brighton, MN 55112 www.TUVamerica.com Management Service • Product Service • Industry Service • Automotive • BABT TÜV America Inc. is a subsidiary of TÜV SÜD Group. The above referenced documents, Form 731 and Test Report, have been uploaded to the website at the same time as this response. Please let us know if anything further is required. Jolene Murphy, Senior Technical Writer TÜV America Inc Tel: 651 638 0271 / Fax: 651 638 0285 [email protected]

Cover Letter(s)

Digital Power Corporation 41920 Christy Street Fremont California 94538-3158 Tel: 510.657.2635 Fax: 510.657.6634 www.digipwr.com 10-Oct-2005 Ű Director of Certification Pursuant to RSP-100, Paragraph 10, we, Digital Power Corporation, at 41920 Christy Street, Fremont, CA 94538, hereby requests confidential treatment of information accompanying as outlined below: - Schematics - Parts List The above materials contain trade secrets and proprietary information not customarily released to the public. The public disclosure of these matters might be harmful to the Applicant and provide unjustified benefits to its competitors. Digital Power Corporation requests that Schematics and Parts List be held confidential not only from the public, but also the applicant (ADC Telecommunications). Sincerely, Robert H. Doe 41920 Christy St. Fremont, CA 94538 Direct: 1.510.824.0151 Cell: 1.510.499.8157 Fax: 1.510.657.6634 [email protected]

External Photos

HUB Top, Front and left view HUB Top, Front and right view HUB Rear view RAN Front View RAN Right View RAN Back View RAN Left View RAN Top View RAN Bottom View RF Assembly Front and Left View RF Assembly Front and Right View RF Assembly Back View LPA Top View RF Assembly Bottom View XD Front and Left View XD Front and Right View XD Back View XD Top View XD Bottom View

ID Label/Location Info

INFORMATION ON THIS DOCUMENT IS PROPRIETARY TO ADC AND SHALL NOT BE USED, COPIED, REPRODUCED OR DISCLOSED IN WHOLE OR IN PART WITHOUT WRITTEN CONSENT OF ADC TITLE CXD SMR 800/900 FCC / IC Identification Label TOLERANCE UNLESS .XX NA OTHERWISE SPECIFIED .XX NA DRAWING NUMBER None A REV DO NOT SCALE DRAWING ENGR. Mark F. Miska SIZE A SHEET 1 OF 1 REV ECO DWN DATE A MFM 11-2-2005 FCC ID: F8I-DCXSMR1A IC: 1208G-DCXSMR1A 1 2 1.500 REF R.075 (4) DIE CUT LABEL .750 REF NOTES: 1 PRINTING TYPE: TRANSFER METHOD. COLOR: BLACK TEXT 8 PT ARIAL NON-BOLD LOCATED APPROXIMATELY AS SHOWN. 2 PRINTING TYPE: TRANSFER METHOD. COLOR: BLACK TEXT 6 PT ARIAL NON-BOLD LOCATED APPROXIMATELY AS SHOWN. MATERIAL: ADC PART NUMBER 1215140 3 Location of Label

Internal Photos

HUB Disassembly HUB Disassembly - Closeup View 1 HUB Disassembly - Closeup View 2 RAN Disassembly - Open View RAN Disassembly - Empty View RAN Disassembly - Empty View - Closeup CPU Front CPU back – View 1 CPU back – View 2 Forward Simulcast Card (FSC) Front – View 1 Forward Simulcast Card (FSC) Front – View 2 Forward Simulcast Card (FSC) Back Hub Down Converter (HDC) Front – View 1 Hub Down Converter (HDC) Front – View 2 Hub Down Converter (HDC) Back

Internal Photos

HUB System Interface Card (HUBSTF) Front HUB System Interface Card (HUBSTF) Back Hub Up Converter (HUC) Front Hub Up Converter (HUC) back Radio Access Node System Interface Card (RANSTF) Front Radio Access Node System Interface Card (RANSTF) Back RAN Downconverter (RDC) Front RAN Downconverter (RDC) Back Reverse Simulcast Card (RSC) Front Reverse Simulcast Card (RSC) Back RAN Up Converter (RUC) Front RAN Up Converter (RUC) Back Sonet Interface Module (SIF) Front Sonet Interface Module (SIF) Back Base Station Interface Module (BIM) AG003 Top - Right Base Station Interface Module (BIM) AG003 Top - Left Base Station Interface Module (BIM) AG003 Bottom - Right Base Station Interface Module (BIM) AG003 Bottom - Left Base Station Interface Module (BIM) BG007 Top - Right Base Station Interface Module (BIM) BG007 Top - Left Base Station Interface Module (BIM) BG007 Bottom - Right Base Station Interface Module (BIM) BG007 Bottom - Left

Internal Photos

Broadband LPA Photos Broadband LPA Photos Broadband LPA Photos Broadband LPA Photos Cherokee Power Supply - Top, Front and Right View Cherokee Power Supply - Top, Back and Left View Cherokee Power Supply - Disassembly View 1 Cherokee Power Supply - Disassembly View 2 Cherokee Power Supply - Board Top Cherokee Power Supply - Board Bottom Digital Power - Power Supply - eFO306-1XX, Top View Digital Power - Power Supply - eFO306-1XX, Output Digital Power - Power Supply - eFO306-1XX, Input Digital Power - Power Supply - eFO306-1XX, ¾ View Digital Power - Power Supply - Board Bottom

Test Report

TÜV AMERICA INC 19333 Wild Mountain Road Taylors Falls MN 55084-1758 Tel: 651 638 0297 Fax: 651 638 0298 Rev.No 1.0 America TEST RESULT SUMMARY FCC PART 90 MANUFACTURER ADC, Incorporated P. O. Box 1101 Minneapolis MN 55440-1101 NAME OF EQUIPMENT Digivance® CXD TYPE OF EQUIPMENT Transports RF between a remote antenna and base station MODEL NUMBER DGVF -01000000XXCRN TEST REPORT NUMBER WC503856 REV B TEST DATES July 26 & 27, 2005 (TUV), August 10 & 11, 2005 (ADC) According to testing performed at TÜV America Inc., and ADC Inc., the above-mentioned unit is in compliance with the electromagnetic compatibility requirements defined in FCC Part 90. It is the manufacturer's responsibility to assure that additional production units of this model are manufactured with identical electrical and mechanical characteristics. Any modifications necessary for compliance made during testing on the above mentioned date(s) must be implemented in all production units for compliance to be maintained. TÜV America Inc, as an independent testing laboratory, declares that the equipment tested as specified above conforms to the requirements of FCC Part 90 “Private Land Mobile Radio Services” . Date: 10 December 2005 Location: Taylors Falls MN J. C. Sausen G. Jakubowski USA Test Engineer Technical Writer TÜV America Inc is a subcontractor to TÜV America, GmbH according to the principles outlined in ISO/IEC Guide 25 and EN 45001. TÜV America Inc reports apply only to the specific samples tested under stated test conditions. It is the manufacturer's responsibility to assure that additional production units of this model are manufactured with identical electrical and mechanical components. TÜV America Inc shall have no liability for any deductions, inferences or generalizations drawn by the client or others from TÜV America Inc issued reports. This report is the confidential property of the client. As a mutual protection to our clients, the public and ourselves, extracts from the test report shall not be reproduced except in full without our written approval. This report shall not be used by the client to claim product endorsement by NVLAP or any agency of the US government. TÜV America Inc and its professional staff hold government and professional organization certifications and are members of AAMI, ACIL, AEA, ANSI, IEEE, NVLAP, and VCCI Not Transferable File No. NC503856 Rev BPage 1 of 114 TÜV AMERICA INC 19333 Wild Mountain Road Taylors Falls MN 55084-1758 Tel: 651 638 0297 Fax: 651 638 0298 Rev.No 1.0 America EMC EMISSION - T E S T R E P O R T Test Report File Number: WC503856 REV B Date of Issue: 10 December 2005 D I R E C T O R Y Page(s) 2.1046 RF Power Output – complies with 90.635 3 2.1049 Occupied Bandwidth – complies with 90.210 4 - 10 2.1051 Spurious Emissions at Antenna Terminals - complies with 90.210 11 - 35 Intermodulation 36 - 72 2.1053 Field Strength of Spurious Emissions – complies with 90.210 73 - 84 Conducted Emissions – Line Cord 85 - 89 20 dB Passband 90 - 91 2.1055 Frequency Stability Test Data - complies with 90.213 92 - 93 Test Equipment List 94 - 95 Product Information 96 - 102 Test Setups, Drawings & Photos 103 - 112 Measurement Protocol 113 - 114 REVISION RECORD REVISION TOTAL NUMBER OF PAGES DATE DESCRIPTION 100 27 Sep 05 Initial Release A 109 05 Oct 05 Revisions include: Replace run 1 radiated emissions data with run 3 data. Replace run 1 radiated emissions test set-up photos with run 3 photos. B 114 10 Dec 05 Revised to include additional Conducted Emissions Band Edge Test Data for all modulations and revised EIRP data. File No. NC503856 Rev BPage 2 of 114 Effective Isotropic Radiated Power Test for ADC Inc. Digivance CXD Model Number DGVF-211100SYS *Note: The EUT is a fixed repeater and not a base station. This measurement was made as a direct conducted emission measurement. The output from the EUT antenna connector was connected to the spectrum analyzer. The carrier output, below, was conducted using a single CW/FM, 16QAM, and CDMA signal generator. The spectrum analyzer level was offset to compensate for attenuators and cable loss between the EUT and the analyzer. For the CDMA modulation types, the average value of the measured frequency will be 16.23 dB down from the CW peak power. A signal was used at the low, mid and high parts of the selected band. The spectrum analyzer level was offset by 51.4 dB to compensate for attenuators and cable loss between the EUT and the analyzer. CW / FM – 7.71 Watts 16QAM – 5.71 Watts Band SMR (800 MHz) Band SMR (800 MHz) Carrier Frequency Carrier Output Carrier Frequency Carrier Output 851.0 MHz 38.83 dBm 851.0 MHz 36.23 dBm 858.5 MHz 38.87 dBm 858.5 MHz 37.27 dBm 866.0 MHz 38.47 dBm 866.0 MHz 37.57 dBm CW / FM – 7.19 Watts 16QAM – 8.07 Watts Band SMR (900 MHz) Band SMR (900 MHz) Carrier Frequency Carrier Output Carrier Frequency Carrier Output 935.0 MHz 38.57 dBm 935.0 MHz 36.57 dBm 937.5 MHz 37.97 dBm 937.5 MHz 36.97 dBm 940.0 MHz 38.57 dBm 940.0 MHz 39.07 dBm CDMA – 5.62 Watts Band SMR (800 MHz) Carrier Frequency Carrier Output 851.0 MHz 20.11 dBm 858.5 MHz 21.27 dBm 866.0 MHz 20.74 dBm CDMA – 7.36 Watts Band SMR (900 MHz) Carrier Frequency Carrier Output 935.0 MHz 20.64 dBm 937.5 MHz 21.10 dBm 940.0 MHz 22.44 dBm File No. NC503856 Rev BPage 3 of 114 Occupied Bandwidth Modulation Test for ADC Inc. Digivance CXD Model Number DGVF-01000000XXCRN An input/output Occupied Bandwidth test was done with modulation types: FM, 16 QAM, and CDMA. The purpose was to determine the amount of distortion added to different types of modulation schemes by the EUT. The following plots show input signals vs. output signals. Results: Pass (see plots) File No. NC503856 Rev BPage 4 of 114 File No. NC503856 Rev BPage 5 of 114 File No. NC503856 Rev BPage 6 of 114 File No. NC503856 Rev BPage 7 of 114 File No. NC503856 Rev BPage 8 of 114 File No. NC503856 Rev BPage 9 of 114 File No. NC503856 Rev BPage 10 of 114 Conducted Emission Limits Test for ADC Inc. Digivance CXD Mo…

Text truncated - open the document above for the full version.

Test Report

RADIATED EMISSIONS Test Report #: WC503856 Run 3 Test Area: LTS EUT Model #: CXD 800\900 SMR Date: 7/27/2005 EUT Serial #: 001 EUT Power: 60 Hz / 120 VAC Temperature: 24.0 °C Test Method: FCC Part 90 Air Pressure: 99.0 kPa Customer: ADC Telecom Rel. Humidity: 50.0 % EUT Description: SMR (800\900 MHZ ) repeater Notes: Remote and host units in test setup. Data File Name: 3856.dat Page: 1of 12 Tested by: J. C. Sausen Printed Signature Reviewed by: G. Jakubowski Printed Signature List of measurements for run #: 3 FREQ LEVEL (dBuV) CABLE / ANT / PREAMP / ATTEN (dB) FINAL (dBuV / m) POL / HGT / AZ (m)(DEG) ERP dBm LIMIT dBm 30.42 MHz 41.15 Qp 0.43 / 20.22 / 27.4 / 0.0 34.4 V / 1.00 / 0 -61.10 -13.0 42.912 MHz 47.5 Qp 0.6 / 16.23 / 27.0 / 0.0 37.33 V / 1.00 / 0 -58.17 -13.0 44.73 MHz 43.8 Qp 0.6 / 15.72 / 27.06 / 0.0 33.06 V / 1.00 / 0 -62.44 -13.0 45.63 MHz 46.15 Qp 0.6 / 15.46 / 27.09 / 0.0 35.12 V / 1.00 / 0 -60.38 -13.0 46.53 MHz 44.45 Qp 0.6 / 15.2 / 27.1 / 0.0 33.15 V / 1.00 / 0 -62.35 -13.0 54.582 MHz 45.1 Qp 0.6 / 12.95 / 27.0 / 0.0 31.65 V / 1.00 / 0 -63.85 -13.0 69.72 MHz 52.4 Qp 0.7 / 9.33 / 27.0 / 0.0 35.43 V / 1.00 / 0 -60.07 -13.0 128.7 MHz 71.65 Qp 0.99 / 8.5 / 27.01 / 0.0 54.12 V / 1.00 / 0 -41.38 -13.0 118.002 MHz 57.9 Qp 0.9 / 9.25 / 27.1 / 0.0 40.95 V / 1.00 / 0 -54.55 -13.0 120.678 MHz 58.3 Qp 0.9 / 9.01 / 27.1 / 0.0 41.11 V / 1.00 / 0 -54.39 -13.0 123.36 MHz 57.45 Qp 0.92 / 8.77 / 27.08 / 0.0 40.07 V / 1.00 / 0 -55.43 -13.0 131.406 MHz 57.8 Qp 1.0 / 8.42 / 27.0 / 0.0 40.22 V / 1.00 / 0 -55.28 -13.0 139.458 MHz 50.4 Qp 1.0 / 9.0 / 27.0 / 0.0 33.4 V / 1.00 / 0 -62.10 -13.0 139.452 MHz 50.55 Qp 1.0 / 9.0 / 27.0 / 0.0 33.55 V / 1.00 / 0 -61.95 -13.0 142.146 MHz 42.7 Qp 1.0 / 9.45 / 26.97 / 0.0 26.18 V / 1.00 / 0 -69.32 -13.0 168.96 MHz 48.8 Qp 1.08 / 8.84 / 27.0 / 0.0 31.72 V / 1.00 / 0 -63.78 -13.0 171.642 MHz 54.6 Qp 1.1 / 8.94 / 27.0 / 0.0 37.64 V / 1.00 / 0 -57.86 -13.0 179.682 MHz 55.85 Qp 1.1 / 9.43 / 27.07 / 0.0 39.31 V / 1.00 / 0 -56.19 -13.0 182.37 MHz 48.85 Qp 1.1 / 9.64 / 27.09 / 0.0 32.5 V / 1.00 / 0 -63.00 -13.0 257.454 MHz 57.9 Qp 1.39 / 12.39 / 27.2 / 0.0 44.47 V / 1.00 / 0 -51.03 -13.0 265.506 MHz 58.85 Qp 1.43 / 12.31 / 27.26 / 0.0 45.33 V / 1.00 / 0 -50.17 -13.0 273.546 MHz 53.3 Qp 1.47 / 12.23 / 27.35 / 0.0 39.65 V / 1.00 / 0 -55.85 -13.0 300.366 MHz 63.0 Qp 1.5 / 13.22 / 27.5 / 0.0 50.22 V / 1.00 / 0 -45.28 -13.0 311.094 MHz 59.05 Qp 1.5 / 13.54 / 27.5 / 0.0 46.59 V / 1.00 / 0 -48.91 -13.0 343.278 MHz 58.85 Qp 1.6 / 14.61 / 27.6 / 0.0 47.46 V / 1.00 / 0 -48.04 -13.0 358.861 MHz 52.6 Qp 1.6 / 14.82 / 27.6 / 0.0 41.42 V / 1.00 / 0 -54.08 -13.0 File No. NC503856 Rev BPage 73 of 114 RADIATED EMISSIONS Test Report #: WC503856 Run 3 Test Area: LTS EUT Model #: CXD 800\900 SMR Date: 7/27/2005 EUT Serial #: 001 EUT Power: 60 Hz / 120 VAC Temperature: 24.0 °C Test Method: FCC Part 90 Air Pressure: 99.0 kPa Customer: ADC Telecom Rel. Humidity: 50.0 % EUT Description: SMR (800\900 MHZ ) repeater Notes: Remote and host units in test setup. Data File Name: 3856.dat Page: 2of 12 Tested by: J. C. Sausen Printed Signature Reviewed by: G. Jakubowski Printed Signature List of measurements for run #: 3 FREQ LEVEL (dBuV) CABLE / ANT / PREAMP / ATTEN (dB) FINAL (dBuV / m) POL / HGT / AZ (m)(DEG) ERP dBm LIMIT dBm 386.185 MHz 62.05 Qp 1.67 / 15.39 / 27.74 / 0.0 51.37 V / 1.00 / 0 -44.13 -13.0 395.293 MHz 49.9 Qp 1.7 / 16.0 / 27.8 / 0.0 39.79 V / 1.00 / 0 -55.71 -13.0 429.109 MHz 58.25 Qp 1.72 / 16.31 / 27.9 / 0.0 48.38 V / 1.00 / 0 -47.12 -13.0 472.009 MHz 54.1 Qp 1.86 / 16.7 / 27.9 / 0.0 44.76 V / 1.00 / 0 -50.74 -13.0 501.121 MHz 59.3 Qp 1.9 / 17.53 / 27.95 / 0.0 50.78 V / 1.00 / 0 -44.72 -13.0 557.834 MHz 50.25 Qp 2.0 / 18.4 / 28.1 / 0.0 42.55 V / 1.00 / 0 -52.95 -13.0 600.74 MHz 46.9 Qp 2.1 / 18.89 / 28.11 / 0.0 39.78 V / 1.00 / 0 -55.72 -13.0 643.652 MHz 48.9 Qp 2.12 / 19.34 / 28.18 / 0.0 42.18 V / 1.00 / 0 -53.32 -13.0 686.57 MHz 46.4 Qp 2.3 / 20.33 / 27.9 / 0.0 41.13 V / 1.00 / 0 -54.37 -13.0 729.488 MHz 45.35 Qp 2.3 / 21.01 / 27.99 / 0.0 40.67 V / 1.00 / 0 -54.83 -13.0 772.388 MHz 49.2 Qp 2.37 / 21.56 / 27.86 / 0.0 45.28 V / 1.00 / 0 -50.22 -13.0 777.578 MHz 45.45 Qp 2.38 / 21.51 / 27.84 / 0.0 41.5 V / 1.00 / 0 -54.00 -13.0 815.306 MHz 49.75 Qp 2.45 / 21.54 / 27.8 / 0.0 45.94 V / 1.00 / 0 -49.56 -13.0 824.426 MHz 36.9 Qp 2.46 / 21.55 / 27.8 / 0.0 33.12 V / 1.00 / 0 -62.38 -13.0 901.13 MHz 52.5 Qp 2.59 / 22.4 / 27.61 / 0.0 49.88 V / 1.00 / 0 -45.62 -13.0 902.03 MHz 42.55 Qp 2.59 / 22.4 / 27.61 / 0.0 39.93 V / 1.00 / 0 -55.57 -13.0 944.025 MHz 60.7 Qp 2.66 / 22.87 / 27.6 / 0.0 58.63 V / 1.00 / 0 -36.87 -13.0 986.943 MHz 51.4 Qp 2.72 / 23.33 / 27.58 / 0.0 49.88 V / 1.00 / 0 -45.62 -13.0 42.9 MHz 53.0 Qp 0.6 / 16.24 / 27.0 / 0.0 42.84 V / 1.00 / 180 -52.66 -13.0 44.73 MHz 44.75 Qp 0.6 / 15.72 / 27.06 / 0.0 34.01 V / 1.00 / 180 -61.49 -13.0 45…

Text truncated - open the document above for the full version.

Contact Information

Applicant

Joshua Wittman(Compliance Engineer)

[email protected]952-403-8322Fax: 952-403-8858

Technical Contact

TUV America IncJoel Schneider

[email protected]

19333 Wild Mountain Road · Taylors Falls, Minnesota · United States

Technical Specifications

#	Rule Parts	Frequency Range	Power Output	Emission	Tolerance
6	9	935 MHz - 940 MHz	7.36 W	F9W	Amp

Confidentiality

Long Term

Grant Notes

Power output listed for this repeater is composite at the antenna connector. To comply with rf exposure requirements, the maximum composite power output from the antenna may not exceed 1000 watts EIRP and the antenna(s) used for this transmitter must be installed to provide a separation distance of at least 6m from all persons. Users and installers must be provided with antenna installation instructions and transmitter operating conditions for satisfying RF exposure compliance.
