F8I-DSCSMR2PDigivance SCSSMR 800/900 MHz and 1900 MHz System

ADCP-75-187 Issue 3 September 2006 1346357 Rev B Digivance ® Street-Level Coverage Solution 800 MHz, 1900 MHz, and 800/900 MHz SMR System Operation and Maintenance Manual 20576-A ADCP-75-187 Issue 3 September 2006 1346357 Rev B Digivance ® Street-Level Coverage Solution 800 MHz, 1900 MHz, 800/900 MHz SMR System Operation and Maintenance Manual ADCP-75-187 • Issue 3 • September 2006 • Preface Page ii COPYRIGHT © 2006, ADC Telecommunications, Inc. All Rights Reserved REVISION HISTORY LIST OF CHANGES The technical changes incorporated into this issue are listed below. TRADEMARK INFORMATION ADC and Digivance are registered trademarks of ADC Telecommunications, Inc. OptiTap is a trademark of Corning Incorporated. Stargazer is a registered trademark of ADC DSL Systems, Inc. Procomm Plus is a registered trademark of Quarterdeck Corporation. Acrobat and Adobe are registered trademarks of Adobe Systems, Inc. DISCLAIMER OF LIABILITY Contents herein are current as of the date of publication. ADC reserves the right to change the contents without prior notice. In no event shall ADC be liable for any damages resulting from loss of data, loss of use, or loss of profits and ADC further disclaims any and all liability for indirect, incidental, special, consequential or other similar damages. This disclaimer of liability applies to all products, publications and services during and after the warranty period. This publication may be verified at any time by contacting ADC’s Technical Assistance Center at 1-800-366-3891, extension 73476 (in U.S.A. or Canada) or 952-917-3476 (outside U.S.A. and Canada), or by e-mail to [email protected] ISSUEDATEREASON FOR CHANGE 109/2005Original issue. 206/2006Release of single-band and dual-band remote units that support 800 and 1900 MHz operation and inclu- sion of the RLM feature in the 800 and 1900 MHz remote units. 309/2006Non-technical changes for agency approvals. PAGEIDENTIFIERDESCRIPTION OF CHANGE ixStandards Added FCC Part 15.5 statement. 2-25Table 2-7Deleted references to 1900 MHz Band G ADC Telecommunications, Inc. P.O. Box 1101, Minneapolis, Minnesota 55440-1101 In U.S.A. and Canada: 1-800-366-3891 Outside U.S.A. and Canada: (952) 938-8080 Fax: (952) 917-1717 ADCP-75-187 • Issue 3 • September 2006 • Preface Page iii © 2006, ADC Telecommunications, Inc. TABLE OF CONTENTS ContentPage ABOUT THIS MANUAL . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . vii RELATED PUBLICATIONS . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . vii ADMONISHMENTS . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . viii GENERAL SAFETY PRECAUTIONS . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . viii STANDARDS CERTIFICATION . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . ix LIST OF ACRONYMS AND ABBREVIATIONS . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . x SECTION 1: OVERVIEW 1INTRODUCTION. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 1-1 2SCS SYSTEM OVERVIEW . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 1-1 2.1Basic SCS System Components . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 1-1 2.2Enhanced Base Transceiver Station Interface. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 1-3 2.3Subscriber Unit Interface . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 1-3 2.4Local Management Interface . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 1-3 2.5Network Operations Center Interface . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 1-5 2.6SNMP Interface . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 1-6 3SYSTEM FUNCTIONS AND FEATURES. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 1-7 3.1Fiber Optic Transport . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .1-7 3.2Control and Monitoring Software . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 1-8 3.3Fault Detection and Alarm Reporting . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 1-8 3.4Powering . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 1-8 3.5Equipment Mounting and Location . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 1-8 4DUAL-BAND REMOTE UNIT SCS SYSTEMS . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 1-9 SECTION 2: DESCRIPTION 1INTRODUCTION. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 2-2 2HOST UNIT . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 2-2 2.1Primary Components . . . . . . . . . . . . . . . . . . . . . …

Text truncated - open the document above for the full version.

ADCP-75-187 • Issue 3 • September 2006 • Section 2: DESCRIPTION Page 2-19 © 2006, ADC Telecommunications, Inc. 6 SPECIFICATIONS Refer to the following tables for the system, host unit, and remote unit specifications. All specifications apply after a five minute warm-up period. Ta b l e 2 - 5 – SCS 800/900 MHz SMR system nominal specifications Ta b l e 2 - 6 – SCS 800 MHz system nominal specifications Ta b l e 2 - 7 – SCS 1900 MHz system nominal specifications Ta b l e 2 - 8 – Host Unit nominal specifications Ta b l e 2 - 9 – WDM nominal specifications Ta b l e 2 - 1 0 – Remote Unit nominal specifications ADCP-75-187 • Issue 3 • September 2006 • Section 2: DESCRIPTION Page 2-20 © 2006, ADC Telecommunications, Inc. Table 2-5. SCS 800/900 MHz SMR System Nominal Specifications PARAMETERSPECIFICATIONREMARKS Optical - Host and Remote Unit Fiber type9/125, single-mode Number of fibers required1 for single-band remote unit 2 for dual-band RU All SCS remote units include a WDM. Forward path wavelength1550 nm Reverse path wavelength1310 nm Optical transmit power output Host Unit Remote Unit 0 dBm +1.3 dBm (includes WDM inser- tion loss) Optical budget25 dB For optical BER of 10 –6 Optical Receiver Input Maximum –15 dBm Optical connectorsUPC/SC Host unit OptiTap APC/SC Remote unit RF Forward Path - 800/900 MHz System bandwidth18 MHz 5 MHz 800 MHz transmit 900 MHz transmit Frequency range851–869 MHz 935–940 MHz Gain of forward path (Host input to Remote primary antenna port) 78.1 dB (typical)At band center, room tempera- ture, and 0 dB attenuation set- ting. Includes power amplifier. Gain flatness Band flatness Channel flatness ± 2.0 dB across freq. range ± 1.5 dB variation across any 1.25 MHz channel Gain variation± 3 dB over temp and unit-to- unit Propagation delay< 6 μs (typical)Excludes fiber delay Configurable propagation delay Range Step size 0 to 63 μs 0.1μs ± 100 ns Plus standard propagation delay Spurious In-band self generated Dynamic range (noise floor) <–13 dBm at remote output <–60 dBc at 30 KHz bandwidth Transmit peak-to-average> 10 dB Two-tone Intermodulation< –52 dBctwo tones @ 5 Watts each Nominal composite RF input signal level –40 dBm at 0 dB attenuation –9 dBm at max. attenuation –20 dBm is the optimal RF input signal level. Configurable input level Range Step size 31 dB 1 ± 0.5 dB ±10% of attenuation monotonic ADCP-75-187 • Issue 3 • September 2006 • Section 2: DESCRIPTION Page 2-21 © 2006, ADC Telecommunications, Inc. Note: Per Industry Canada Section 5.3 - The rated output power of this equipment is for single carrier operation. For situations where multiple carrier signals are present, the rating would have to be reduced by 3.5 dB, especially where the output signal is re-radiated and can cause interference to adjacent band users. This power reduction is to be by means of input power or gain reduction and not by an attenuator at the output of the device. Composite RF Output power of both bands (see Note 1at end of table) 38.1 dBm (6.5 Watts) at remote antenna port with –40 dBm input 10 Watts at LPA output Configurable RF Output Range Step size 31 dB at remote unit 1 ± 0.5 dB ± 10% of attenuation monotonic Transmit path insertion loss1.9 dB typical RF Reverse Path - 800/900 MHz System bandwidth18 MHz 5 MHz 800 MHz receive 900 MHz receive Frequency range806–824 MHz 896–901 MHz Propagation delay< 8 μs (typical)Excludes fiber delay Configurable propagation delay Range Step size Up to 63 μs 0.1μs ±1 100 ns Plus standard propagation delay Gain of reverse path Overall gain Gain variation 30 ± 2 dB at band center at room temperature 3 dB over temperature Gain flatness Band flatness Channel flatness ± 2.0 dB across frequency range ± 1.5 dB variation across any 1.25 MHz channel Out-of-band rejection–40 dB at > 12.5 MHz from cen- ter of subband Spurious (in-band self gener- ated) –110 dBm referred to input Intermodulation–62 dBctwo tones @ –50 dBm System noise figure9 dB at mid-band Configurable RF output Range Step size 31 dB 1 ± 0.5 dB ± 10% of attenuation monotonic Blocking dynamic range70 dB Level limiting ALC threshold–40 dBm ± 3 dB instantaneous Level limiting ALC range27 dB Table 2-5. SCS 800/900 MHz SMR System Nominal Specifications, continued PARAMETERSPECIFICATIONREMARKS ADCP-75-187 • Issue 3 • September 2006 • Section 2: DESCRIPTION Page 2-22 © 2006, ADC Telecommunications, Inc. Table 2-6. SCS 800 MHz System Nominal Specifications PARAMETERSPECIFICATIONREMARKS Optical - Host and Remote Unit Fiber type9/125, single-mode Number of fibers required1 for single-band remote unit 2 for dual-band RU All SCS remote units include a WDM. Forward path wavelength1550 nm Reverse path wavelength1310 nm Optical transmit power output Host Unit Remote Unit 0 dBm +1.3 dBm (includes WDM inser- tion loss) Optical budget25 dB For optical BER of 10 –6 Optical Receive Input Maximum –15 dBm Optical connectorsUPC/SC Host unit OptiTap APC/SC Remote unit RF Forward Path - 800 MHz System bandwidth A band B band 11 and 1.5 MHz 10 and 2.5 MHz Frequency range A band B band 869–880 and 890–891.5 MHz 880–890 and 891.5–894 MHz Out-of-band emissions Primary–13 dBm per 1 MHz bandwidth from 10 kHz to 20 GHz Gain of forward path (Host input to Remote primary antenna port) 78.5 dB (typical)At band center, room tempera- ture, and 0 dB attenuation set- ting. Includes power amplifier. Gain flatness Band flatness Channel flatness ± 2.0 dB across freq. range ± 1 dB variation across any 1.25 MHz channel Gain variation± 3 dB over temp and unit-to- unit Out-of-band rejection–40 dB at > ±17.5 MHz from center of subband Propagation delay< 6 μs (typical)Excludes fiber delay Configurable propagation delay Range Step size Up to 63 μs 0.1μs ± 100 ns Plus standard propagation delay Spurious In-band self generated Free dynamic range <–13 dBm at remote output <–60 dBc at 30 kHz bandwidth Transmit peak-to-average> 10 dB ADCP-75-187 • Issue 3 • September 2006 • Section 2: DESCRIPTION Page 2-23 © 2006, ADC Telecommunications, Inc. Two…

Text truncated - open the document above for the full version.

American Telecommunications Certification Body Inc. 6731 Whittier Ave, McLean, VA 22101 December 18, 2006 RE: FCC ID: F8I-DSCSMR2P_ATCB004349 Attention: Joel T Schneider I have a few comments on this Application. Please note that further comments may arise in response to answers provided to the questions below. FCC 1. Please note that the 731 states that the device operates in two rule parts. Please be more specific as to which frequencies are to be assigned to which rule part. For example, the 851-869 and 935- 940MHz appear to be part 90 and the 1930-1990MHz appear to be part 24E. Please clarify. 2. The FCC ID label appears to be on a removable cover. As you are aware this is not allowed. Please explain and please show how this is not a removable cover or alternately, please show where the label will be placed on the device so as not to be on a removable cover. IC 3. Please be more specific as to which emissions designator is appropriate for which frequency band in the IC application form. Dennis Ward mailto:[email protected] The items indicated above must be submitted before processing can continue on the above referenced application. Failure to provide the requested information may result in application termination. Correspondence should be considered part of the permanent submission and may be viewed from the Internet after a Grant of Equipment Authorization is issued. Please do not respond to this correspondence using the email reply button. In order for your response to be processed expeditiously, you must submit your documents through the AmericanTCB.com website. Also, please note that partial responses increase processing time and should not be submitted. Any questions about the content of this correspondence should be directed to the sender.

TÜV America Inc. Phone: (651) 631-2487 1775 Old Highway 8 NW Fax: (651) 638-0285 Suite 104 E-mail: [email protected] New Brighton, MN 55112 www.TUVamerica.com Management Service • Product Service • Industry Service • Automotive • BABT TÜV America Inc. is a subsidiary of TÜV SÜD Group. 19 December 2006 American TCB 6731 Whittier Avenue McLean VA 22101 RE: ADC Telecommunications Response to 18 December 2006 Comments ATCB: ATCB004349 FCC ID: F8I-DSCSMR2P IC ID: 1208G-DSCSMR2P In response to your comments on the above submittal from 18 December 2006. 1. ATCB Comments: Please note that the 731 states that the device operates in two rule parts. Please be more specific as to which frequencies are to be assigned to which rule part. For example, the 851-869 and 935-940 MHz appear to be part 90 and the 1930-1990MHz appear to be part 24E. Please clarify. TÜV RESPONSE: The Form 731 has been revised to clearly indicate the frequency ranges and corresponding FCC Part. 2. ATCB Comments: The FCC ID label appears to be on a removable cover. As you are aware this is not allowed. Please explain and please show how this is not a removable cover or alternately, please show where the label will be placed on the device so as not to be on a removable cover. ADC RESPONSE: The SCS unit is not field serviceable, and there isn't a removable aspect to it once it's assembled with electronics. The SCS unit requires a specially designed mounting fixture due to the delicacy of the fully installed and wired equipment. The only way these two pieces would be separated is only when there is no equipment installed. Photos of the wiring and mounting are attached. Please let us know if you require additional information. 3. ATCB Comments: Please be more specific as to which emissions designator is appropriate for which frequency band in the IC application form. TÜV RESPONSE: The RSP-100 Application has been revised to clearly indicate the frequency ranges and corresponding emission designators. The above referenced documents have been uploaded to the website at the same time as this response. Please let us know if anything further is required. Jolene Murphy, Senior Technical Writer TÜV America Inc Tel: 651 638 0271 / Fax: 651 638 0285 [email protected] TÜV America Inc. Phone: (651) 631-2487 1775 Old Highway 8 NW Fax: (651) 638-0285 Suite 104 E-mail: [email protected] New Brighton, MN 55112 www.TUVamerica.com Management Service • Product Service • Industry Service • Automotive • BABT TÜV America Inc. is a subsidiary of TÜV SÜD Group. WIRING REFERENCE TÜV America Inc. Phone: (651) 631-2487 1775 Old Highway 8 NW Fax: (651) 638-0285 Suite 104 E-mail: [email protected] New Brighton, MN 55112 www.TUVamerica.com Management Service • Product Service • Industry Service • Automotive • BABT TÜV America Inc. is a subsidiary of TÜV SÜD Group. MOUNTING STAND TÜV America Inc. Phone: (651) 631-2487 1775 Old Highway 8 NW Fax: (651) 638-0285 Suite 104 E-mail: [email protected] New Brighton, MN 55112 www.TUVamerica.com Management Service • Product Service • Industry Service • Automotive • BABT TÜV America Inc. is a subsidiary of TÜV SÜD Group. MOUNTING STAND

Digivance Street Coverage Solution (SCS) Host Unit Front View Digivance Street Coverage Solution (SCS) Host Unit Left View Digivance Street Coverage Solution (SCS) Host Unit Right View Digivance Street Coverage Solution (SCS) Host Unit Rear View Digivance Street Coverage Solution (SCS) Host Unit Top View Digivance Street Coverage Solution (SCS) Host Unit Bottom View Digivance Street Coverage Solution (SCS) Bravo Tech Linear Power Amplifier - 10 Watt Front View Digivance Street Coverage Solution (SCS) Bravo Tech Linear Power Amplifier - 10 Watt Left View Digivance Street Coverage Solution (SCS) Bravo Tech Linear Power Amplifier - 10 Watt Right View Digivance Street Coverage Solution (SCS) Bravo Tech Linear Power Amplifier - 10 Watt Rear View Digivance Street Coverage Solution (SCS) Bravo Tech Linear Power Amplifier - 10 Watt Top View Digivance Street Coverage Solution (SCS) Bravo Tech Linear Power Amplifier - 10 Watt Bottom View Digivance LRCS 1900 MHz Host Unit Front View Digivance LRCS 1900 MHz Host Unit Left View Digivance LRCS 1900 MHz Host Unit Right View Digivance LRCS 1900 MHz Host Unit Rear View Digivance LRCS 1900 MHz Host Unit Top View Digivance LRCS 1900 MHz Host Unit Bottom View

Digivance Street Coverage Solution Remote Unit Bottom Left View Digivance Street Coverage Solution Remote Unit Bottom Right View Digivance Street Coverage Solution Remote Unit Bottom View Digivance Street Coverage Solution Remote Unit Top View Digivance Street Coverage Solution (SCS) Quadplexer (a.k.a. Power Monitor/filter) Front Left View Digivance Street Coverage Solution (SCS) Quadplexer (a.k.a. Power Monitor/filter) Front Right View Digivance Street Coverage Solution (SCS) Quadplexer (a.k.a. Power Monitor/filter) Rear View Digivance Street Coverage Solution (SCS) Quadplexer (a.k.a. Power Monitor/filter) Top View Digivance Street Coverage Solution (SCS) Quadplexer (a.k.a. Power Monitor/filter) Bottom View

INFORMATION ON THIS DOCUMENT IS PROPRIETARY TO ADC AND SHALL NOT BE USED, COPIED, REPRODUCED OR DISCLOSED IN WHOLE OR IN PART WITHOUT WRITTEN CONSENT OF ADC TITLE SCS SMR 800/900 MHz and 1900 MHz FCC / IC Identification Label TOLERANCE UNLESS .XX NA OTHERWISE SPECIFIED .XX NA DRAWING NUMBER None A REV DO NOT SCALE DRAWING ENGR. Mark F. Miska SIZE A SHEET 1 OF 1 REV ECO DWN DATE A MFM 9-6-2006 XXXX-XXXXXXXX FCC ID: F8I-DSCSMR2P IC: 1208G-DSCSMR2P 2 1.500 REF R.075 (4) DIE CUT LABEL .750 REF 1,4 NOTES: 1 PRINTING TYPE: TRANSFER METHOD. COLOR: BLACK TEXT 8 PT ARIAL NON-BOLD LOCATED APPROXIMATELY AS SHOWN. 2 PRINTING TYPE: TRANSFER METHOD. COLOR: BLACK TEXT 6 PT ARIAL NON-BOLD LOCATED APPROXIMATELY AS SHOWN. MATERIAL: ADC PART NUMBER 1215140 3 4 DGVC-901X4X1X200SYS See Note 4 below for the four possible model #s. Digivance Street Coverage Solution Remote Unit Location of FCC/IC ID Location of FCC/IC Label

Compliance Statement Label placement

Digivance LRCS 1900 MHz Host Unit Open Top View Digivance LRCS 1900 MHz Host Board Top View Digivance LRCS 1900 MHz Host Board Top View 1 Digivance LRCS 1900 MHz Host Board Top View 2 Digivance LRCS 1900 MHz Host Board Top View 3 Digivance LRCS 1900 MHz Host Board Top View 4 Digivance LRCS 1900 MHz Host Board Top View 5 Digivance LRCS 1900 MHz Host Board Top View 6 Digivance LRCS 1900 MHz Host Board Top View 7 Digivance LRCS 1900 MHz Host Board Top View 8 Digivance LRCS 1900 MHz Host Board Bottom View Digivance LRCS 1900 MHz Host Board Bottom View 1 Digivance LRCS 1900 MHz Host Board Bottom View 2 Digivance LRCS 1900 MHz Host Board Bottom View 3 Digivance LRCS 1900 MHz Host Board Bottom View 4

BravoTech Linear Power Amplifier LPA1900-010-SC01 - 4244603E Rev D1 Motherboard - Top BravoTech Linear Power Amplifier LPA1900-010-SC01 - 4244603E Rev D1 Motherboard - Bottom BravoTech Linear Power Amplifier LPA1900-010-SC01 - 4244603E Rev D1 Motherboard - Part A Top BravoTech Linear Power Amplifier LPA1900-010-SC01 - 4244603E Rev D1 Motherboard - Part A Bottom BravoTech Linear Power Amplifier LPA1900-010-SC01 - 4244603E Rev D1 Motherboard - Part B Top BravoTech Linear Power Amplifier LPA1900-010-SC01 - 4244603E Rev D1 Motherboard - Part B Bottom BravoTech Linear Power Amplifier LPA1900-010-SC01 - 4244604E Rev B Control Board - Top BravoTech Linear Power Amplifier LPA1900-010-SC01 - 4244604E Rev B Control Board - Bottom BravoTech Linear Power Amplifier LPA1900-010-SC01 - 4247601ERev E Main Board - Part A Top BravoTech Linear Power Amplifier LPA1900-010-SC01 - 4247601ERev E Main Board - Part A Bottom BravoTech Linear Power Amplifier LPA1900-010-SC01 - 4247601ERev E Main Board - Part B Top BravoTech Linear Power Amplifier LPA1900-010-SC01 - 4247601ERev E Main Board - Part B Bottom BravoTech Linear Power Amplifier LPA1900-010-SC01 - 4247602ERev E Driver Board - Part A Top BravoTech Linear Power Amplifier LPA1900-010-SC01 - 4247602ERev E Driver Board - Part A Bottom BravoTech Linear Power Amplifier LPA1900-010-SC01 - 4247602ERev E Driver Board - Part B Top BravoTech Linear Power Amplifier LPA1900-010-SC01 - 4247602ERev E Driver Board - Part B Bottom BravoTech Linear Power Amplifier LPA1900-010-SC01 - 4247610E Rev A Pilot Board - Part A Top BravoTech Linear Power Amplifier LPA1900-010-SC01 - 4247610E Rev A Pilot Board - Part A Bottom

Digivance LRCS 1900 MHz STM Board Top View Digivance LRCS 1900 MHz STM Board Top View 1 Digivance LRCS 1900 MHz STM Board Top View 2 Digivance LRCS 1900 MHz STM Board Top View 3 Digivance LRCS 1900 MHz STM Board Top View 4 Digivance LRCS 1900 MHz STM Board Top View 5 Digivance LRCS 1900 MHz STM Board Top View 6 Digivance LRCS 1900 MHz STM Board Bottom View Digivance LRCS 1900 MHz STM Board Bottom View 1 Digivance LRCS 1900 MHz STM Board Bottom View 2 Digivance LRCS 1900 MHz STM Board Bottom View 3 Digivance LRCS 1900 MHz STM Board Bottom View 4 Digivance LRCS 1900 MHz STM Board Bottom View 5 Digivance LRCS 1900 MHz STM Board Bottom View 6 Digivance LRCS Power Monitor Board Top View Digivance LRCS Power Monitor Board Bottom View

Digivance Street Coverage Solution (SCS) Host Unit Open Top View Digivance Street Coverage Solution (SCS) Host Board Full Top View Digivance Street Coverage Solution (SCS) Host Board Top View - Lower Left Digivance Street Coverage Solution (SCS) Host Board Top View - Lower Right Digivance Street Coverage Solution (SCS) (labeled as SMR DB in photo) Host Board Top View - Center Right Digivance Street Coverage Solution (SCS) (labeled as SMR DB in photo) Host Board Top View - Center Left Digivance Street Coverage Solution (SCS) (labeled as SMR DB in photo) Host Board Top View - Upper Left Digivance Street Coverage Solution (SCS) (labeled as SMR DB in photo) Host Board Top View - Upper Right Digivance Street Coverage Solution (SCS) Host Board Full Bottom View Digivance Street Coverage Solution (SCS) (labeled as SMR DB in photo) Host Board Bottom View - Lower Left Digivance Street Coverage Solution (SCS) (labeled as SMR DB in photo) Host Board Bottom View - Lower Right Digivance Street Coverage Solution (SCS) (labeled as SMR DB in photo) Host Board Bottom View - Center Right Digivance Street Coverage Solution (SCS) (labeled as SMR DB in photo) Host Board Bottom View - Center Left Digivance Street Coverage Solution (SCS) (labeled as SMR DB in photo) Host Board Bottom View - Upper Left Digivance Street Coverage Solution (SCS) Host Board Bottom View - Upper Right

Digivance Street Coverage Solution (SCS) Power Amplifier Universal II 003 Board Front Digivance Street Coverage Solution (SCS) Power Amplifier Universal II 003 Board Back Digivance Street Coverage Solution (SCS) Power Amplifier 4244601E Rev A Board Front Digivance Street Coverage Solution (SCS) Power Amplifier 4244601E Rev A Board Back Digivance Street Coverage Solution (SCS) Power Amplifier 4244601E Rev A Part B_C Board Front Digivance Street Coverage Solution (SCS) Power Amplifier 4244601E Rev A Part B_C Board Back Digivance Street Coverage Solution (SCS) Power Amplifier 4244602E Rev A Board Front Digivance Street Coverage Solution (SCS) Power Amplifier 4244602E Rev A Board Back Digivance Street Coverage Solution (SCS) Power Amplifier 4244603E Rev P2 Board Front Digivance Street Coverage Solution (SCS) Power Amplifier 4244603E Rev P2 Board Back

Digivance Street Coverage Solution Remote Unit Open Top View Digivance Street Coverage Solution Remote Unit Open Top View Digivance Street Coverage Solution (SCS) STM Board Full Top View Digivance Street Coverage Solution (SCS) (labeled as SMR DB in photo) STM Board Top View - Lower Left Digivance Street Coverage Solution (SCS) (labeled as SMR DB in photo) STM Board Top View - Lower Middle Digivance Street Coverage Solution (SCS) (labeled as SMR DB in photo) STM Board Top View - Lower Right Digivance Street Coverage Solution (SCS) STM Board Top View - Upper Right Digivance Street Coverage Solution (SCS) STM Board Top View - Upper Middle Digivance Street Coverage Solution (SCS) (labeled as SMR DB in photo) STM Board Top View - Upper Left Digivance Street Coverage Solution (SCS) STM Board Full Bottom View Digivance Street Coverage Solution (SCS) (labeled as SMR DB in photo) STM Board Bottom View - Lower Left Digivance Street Coverage Solution (SCS) (labeled as SMR DB in photo) STM Board Bottom View - Lower Middle Digivance Street Coverage Solution (SCS) (labeled as SMR DB in photo) STM Board Bottom View - Lower Right Digivance Street Coverage Solution (SCS) STM Board Bottom View - Upper Right Digivance Street Coverage Solution (SCS) STM Board Bottom View - Upper Middle Digivance Street Coverage Solution (SCS) STM Board Bottom View - Upper Left Digivance Street Coverage Solution (SCS) Quadplexer (a.k.a. Power Monitor / Filter) Open Top View Digivance Street Coverage Solution (SCS) Quadplexer (a.k.a. Power Monitor / Filter) Open Bottom View Digivance SCS Power Monitor Board Top View Digivance SCS Power Monitor Board Bottom View

TÜV America Inc 19333 Wild Mountain Road Taylors Falls MN 55084-1758 Tel: 651 638 0297 Fax: 651 638 0298 112205 EMC Emission - T E S T R E P O R T Test Report File No. : WC505742 Rev B Date of issue: Date:02 November 2006 Model Nos. : DGVC-901X4X1X200SYS Product Name : Digivance® Street Coverage Solution Product Type : Dual band chassis Transports RF between a remote antenna and base station Applicant : ADC Inc. Manufacturer : ADC Inc. License Holder : ADC Inc. Address : P.O. Box 1101 Minneapolis, MN 55440-1101 Test Result : „ Positive † Negative Test Project Number : Reference(s) WC505742 Rev B Total pages including Appendices 258 TÜV America Inc reports apply only to the specific samples tested under stated test conditions. It is the manufacturer’s responsibility to assure that additional production units of this model are manufactured with identical electrical and mechanical components. TÜV America Inc shall have no liability for any deductions, inferences or generalizations drawn by the client or others from TÜV America Inc issued reports. This report is the confidential property of the client. As a mutual protection to our clients, the public and ourselves, extracts from the test report shall not be reproduced except in full without our written approval. This report shall not be used by the client to claim product endorsement by NVLAP, NIST, or any agency of the US government. TÜV America Inc and its professional staff hold government and professional organization certifications and are members of AAMI, ACIL, AEA, ANSI, IEEE, NVLAP, and VCCI Test Report WC505742 Rev B1 of 258 TÜV America Inc 19333 Wild Mountain Road Taylors Falls MN 55084-1758 Tel: 651 638 0297 Fax: 651 638 0298 112205 D I R E C T O R Y Documentation Page(s) Test Regulations 3 Test setup drawings and photos 10 – 16 Test Operation Mode 17 Configuration of the device under test 17 Deviations from standard 18 General Remarks 18 Summary 18 Test Results 90.635 Limitations on power and antenna height 4 90.213 Frequency stability 5 90.669 Emission limits 6 24.232 Power and antenna height limits 7 24.235 Frequency stability 8 24.238 Emission limitations for Broadband PCS equipment 9 Appendix A Test data 19 - 245 Appendix B Constructional data form & Block diagrams 246 - 25 6 Appendix C Measurement Protocol 257 - 258 Sign Explanations: † - not applicable „ - applicable REVISION RECORD REVISION TOTAL NUMBER OF PAGES DATE DESCRIPTION 241 06 March 2006 Initial Release A 240 19 September 2006 Revisions include: ƒ Update all equipment lists ƒ Replace cover page and pages 1-9, 12, 21-23, 30, 35, 48, 65, 78, 87, 131, 160 ƒ Deleted page 11, corrected page numbrs accordingly B 258 02 November 2006 Revisions include: Note: Reference page numbers are from Rev A. ƒ Replace pages 20-34, 47, 62-64, 77-88 and 130. ƒ Added pages after page 47, 57, 61 and 54. Test Report WC505742 Rev B2 of 258 TÜV America Inc 19333 Wild Mountain Road Taylors Falls MN 55084-1758 Tel: 651 638 0297 Fax: 651 638 0298 112205 EMISSIONS TEST REGULATIONS : The emissions tests were performed according to following regulations: † - EN 50081-1 / 1991 † - EN 55011 / 1991 † - Group 1 † - Group 2 † - Class A † - Class B † - EN 55013 / 1990 † …

Text truncated - open the document above for the full version.
