Part Number 1282804 Rev A Issue 1 Element Management System EMS User Manual ADCP-75-166 Page ii Element Management System (EMS) 4.0 User Manual Element Management System (EMS) 4.0 User ManualPage iii About This Manual This manual tells how to install and use the Digivance™ Element Management System (EMS), version 4.0 for Software-Defined Radio (SDR) applications. EMS is a software application that may be used on a PC or laptop computer. EMS can also be accessed remotely using a direct data link to the computer on which EMS is running. Revision History Trademark Information The following trademarks are referenced in this guide: ADC is a registered trademark of ADC Telecommunications, Inc. Digivance is a trademark of ADC Telecommunications, Inc. Pentium is a registered trademark of Intel Corporation. Java is a trademark of Sun Microsystems. Windows is a registered trademark of MicroSoft Corporation. Related ADC Publications The following ADC publications contain information related to the Element Management System. Copies of these documents can be ordered by calling ADC Technical Assistance Center (1-800-366-3891 extension 73475, in U.S.A. and Canada; 1-952-917-3475 outside U.S.A. and Canada). •Digivance Long Range Coverage Solution 1900 MHz System With Version 3.01 Element Management System Installation and Operation Manual (ADCP-75-153) •Digivance Long Range Coverage Solution 800 MHz System With Version 3.01 Element Management System Installation and Operation Manual (ADCP-75-156) IssueDateReason for Change Issue 14/2004Original. Page iv Element Management System (EMS) 4.0 User Manual STANDARDS CERTIFICATION FCC: This equipment complies with the applicable sections of Title 47 CFR Section 22. IC: This equipment complies with the applicable sections of RSS-131. ABLE OF CONTENTS Element Management System (EMS) 4.0 User Manual Page v SECTION 1. INTRODUCTION TO EMS . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 3 1.1General Description . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 3 1.2Data Flow . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 5 1.3Wider View of SDR-Based Network . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 6 1.4Common Use Scenarios . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 7 1.4.1Laptop Use for Installation or Routine Maintenance. . . . . . . . . . . . . . . 7 1.4.2Local Office With Multiple Hosts . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 8 1.4.3 SNMP Manager and Proxy Agents. . . . . . . . . . . . . . . . . . . . . . . . . . . . 9 1.5Overview of User Interfaces . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 10 1.5.1Maintenance Interface . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 10 1.5.2NOC-NEM Interface . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 11 1.6 Overview of EMS Tasks . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 13 1.7Use of Ports . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 14 SECTION 2. INSTALLATION AND SYSTEM CHECK . . . . . . . . . . . . . . . . . . . . . 19 2.1System Requirements . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 19 2.2Installation CD Contents . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 20 2.3Installation Procedure . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 20 2.3.1Installing the Java Runtime System. . . . . . . . . . . . . . . . . . . . . . . . . . . 20 2.3.2Installing the EMS Software . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 21 2.3.3Completing the Installation . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 21 2.4Connecting to the Host/Remote Pair . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 22 2.5Checking the System . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 23 SECTION 3. USING EMS FOR NETWORK TASKS . . . . . . . . . . . . . . . . . . . . . . . . 27 3.1Master List of Tasks . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 27 3.2Starting EMS . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 28 3.3Defining EMS Ports . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 29 3.4Selecting EMS Program File Directory . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 31 3.5Defining Log File Name and Trim Time . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 32 3.6Setting EMS Link Timeout, Cataloging Time, Demo Mode . . . . . . . . . . . . . . 34 3.7Entering Host/Remote Site Numbers and Site Names . . . . . . . . . . . . . . . . . . . 36 3.8Using Alarm Overview to View and Acknowledge Alarms . . . . . . . . . . . . . . 38 3.9Viewing Alarm Detail . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 42 3.10 Determining RF Signal Levels . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 43 3.11 Setting RF Forward Attenuation . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 44 3.12 Defining RF Logical Channels . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 46 3.13 Setting Operating Mode . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 48 Table of Contents Page vi Element Management System (EMS) 4.0 User Manual 3.14 Downloading Program Files . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 50 3.15 Viewing the EMS Log File . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 53 SECTION 4. SCREEN-BASED REFERENCE . . . .…

Text truncated - open the document above for the full version.

Overview of User InterfacesSection 1 Element Management System (EMS) 4.0 User Manual 10 1.5Overview of User Interfaces EMS provides two user interfaces: •A windows-based graphical user interface, called the “Maintenance Interface,” which is intended for use in most situations; and •A character interface, called the NOC-NEM interface, which can be accessed remotely using a terminal or a computer with a terminal emulator program. NOTE: For convenience, the character interface is also available within the Main- tenance Interface using a user-selectable character window. 1.5.1 Maintenance Interface The Maintenance Interface is a graphical user interface (GUI) with a menu toolbar and “dashboard” displays containing indicators. Figure 8 shows an example, a display with alarm details for a host/remote pair connected to EMS. Figure 8. Maintenance Interface Example Introduction to EMSOverview of User Interfaces Element Management System (EMS) 4.0 User Manual 11 The dashboard displays, refreshed about once every three seconds, allow you to quickly assess the status of host/remote pairs by checking the indicator colors. The color green indicates “okay.” Red and yellow, respectively, indicate major and minor alarms. The Maintenance Interface also has dialogs used to set values such as remote forward attenuation as shown in Figure 9. Figure 9. Dialog Example 1.5.2 NOC-NEM Interface The NOC-NEM interface is a “character interface” that can be accessed using a direct data link connection between a terminal, or a computer with a terminal emulator program, and a remote computer on which EMS is running. The NOC- NEM interface is also available as a window within the Maintenance Interface, in which case it provides a character, command line interface for the same host/ remote pairs as are being reported in the graphical displays. When used side by side with EMS graphical displays, the NOC-NEM interface augments system function through such features as automatic status updates, immediate alarm notification, easy retrieval of alarm and status history stored in the EMS log file, and ability to send ALL commands affecting multiple network elements at the same time. Overview of User InterfacesSection 1 Element Management System (EMS) 4.0 User Manual 12 Figure 10 shows an example of a NOC-NEM interface display. Appearance will vary depending on the terminal or terminal emulator program being used. Figure 10. NOC-NEM Interface Example Using NOC-NEM, you can perform most of the tasks done using the Maintenance Interface. Below is an example of a command and response message. Apr 7, 2003 12:17:21 PM: DEMS (39 Host.13)Askov GET Alarm 3p8Volt \ 3p8Volt Ok \ END Introduction to EMSOverview of EMS Tasks Element Management System (EMS) 4.0 User Manual 13 1.6 Overview of EMS Tasks Table 1 summarizes the tasks done using EMS. Table 1: Summary of EMS Tasks TASKDESCRIPTION Determine which network elements are currently con- nected You can do this inside the Maintenance Interface by using a menu item to refresh the “catalog” of host/ remote pairs. If using the NOC-NEM interface, you can enter a command to do this. Enter site name and site number When turning up a host/remote pair and “introducing” the units to EMS, you can give them a site name and (host only) site number. If using the NOC-NEM inter- face, you can enter a command to do this. Check for alarmsYou can check an alarm overview window to determine if any network element has an alarm. If so, you can view an alarm detail window to check individual alarm indicators in the alarmed network element. Any new alarm also causes the NOC–NEM window, if open, to scroll down with new text as the alarm is reported. Acknowledge alarmsUsing the alarm overview window, you can also deter- mine which alarms, if any, remain to be investigated. Every alarm, when it first occurs, is flagged with an alarm history indicator (red or yellow). The indicator remains in the window until someone clicks on it to acknowledge that the alarm has been noticed. Determine current statusYou can check the current status of any network ele- ment using seven function-related windows (for exam- ple, there are separate windows for optics functions and DC power). In addition, the NOC–NEM window dis- plays periodic messages summarizing the current status of all connected pairs. Obtain status history and alarm history text Using the NOC–NEM window, you can retrieve status and alarm messages written to the EMS log file. You can also scroll back in the NOC-NEM window to see which events preceded an error condition. Use of PortsSection 1 Element Management System (EMS) 4.0 User Manual 14 1.7Use of Ports EMS uses a DB-9 port with an RS-232 DCE interface, identified in the software as the “EMS/Host/Remote Comm Port,” to communicate with LRCS network elements. This port is used by the Maintenance Interface. It also provides the information available in the NOC-NEM window within the Maintenance Interface. A second serial port, identified in the software as the “NOC Comm Port,” can optionally be used to provide NOC-NEM access to a remote terminal or to a remote computer running a terminal emulator program. Figure 11 provides a schematic of the ports from the perspective of the EMS software. Physically the ports have the following requirements: •EMS/Host/Remote Comm Port—This port connects to the PC- compatible receptor on one end of the straight-through RS-232 cable provided with the Digivance system. The DB-9 plug on the other end of the cable, in a working system, connects to a DB-9 receptor either on a Host Network Card (in a BTS server) or on an ADC remote unit. When connected directly to a remote unit, the EMS system is used for a single, collocated host/remote pair. Define RF logical channelsFor each logical RF channel, you can select modulation type and FCC channel number. Check RF signal levelsYou can check signal levels of RF forward and reverse path signals as measured on the PCIx card. Alarm indi- cators p…

Text truncated - open the document above for the full version.

3 U SING EMS FOR NETWORK TASKS Element Management System (EMS) 4.0 User Manual 27 USING EMS FOR N ETWORK TASKS This section contains instructions for all tasks performed using the Maintenance Interface. Some of these tasks can also be done using the NOC-NEM interface. If so, there is a cross-reference to the NOC-NEM instructions in Section 5. This section also includes instructions for viewing the EMS log file. 3.1Master List of Tasks Ta b l e 2 lists all EMS tasks and tells where to look for instructions. Table 2: Master List of EMS Tasks YOU CANSEE TOPIC Start EMS. 3.2 on page 28 Define EMS ports. 3.3 on page 29 Set directory (folder) for EMS program file. 3.4 on page 31 Set name, directory, and trim time for EMS log file. 3.5 on page 32 Set link timeout, cataloging time, and demo mode. 3.6 on page 34 Enter site names and site number for a host/remote pair. 3.7 on page 36 Use the alarm overview to view and acknowledge alarms. 3.8 on page 38 View alarm detail for a particular host/remote pair. 3.9 on page 42 Determine RF signal levels. 3.10 on page 43 Enter RF attenuation settings for remote unit antenna. 3.11 on page 44 Define RF logical channels and signal gain. 3.12 on page 46 Set the host/remote operating mode. 3.13 on page 48 Load software from EMS computer to host/remote pair. 3.14 on page 50 View the EMS log file. 3.15 on page 53 Starting EMSSection 3 Element Management System (EMS) 4.0 User Manual 28 3.2Starting EMS After being installed, EMS has an icon on the desktop. The icon can be used to start EMS. To start EMS 1. Double-click on the ADC icon, shown in Figure 13. Figure 13. ADC Icon 2. Watch for the DEMS.BAT program to start at the DOS prompt as shown in Figure 14. Figure 14. DEMS.BAT Starting at DOS Command Line 3. Watch for the EMS initial screen shown in Figure 15. Task-Based ReferenceDefining EMS Ports Element Management System (EMS) 4.0 User Manual 29 Figure 15. EMS Initial Screen 3.3Defining EMS Ports Using the Preferences window in EMS, shown in Figure 16, you can define the communication ports to be used by EMS. For a description of the EMS ports, refer to Topic 1.7, Use of Ports, on page 14. To display the Preferences window Select Edit
Preferences. To define EMS ports NOTE: EMS default port values may not need to be changed. 1. Check the current setting for two ports in the top left area of the Preferences window (shown in Figure 16): Defining EMS PortsSection 3 Element Management System (EMS) 4.0 User Manual 30 •EMS/Host/Remote Comm Port—This is the port connected via the ADC-provided RS-232 interface cable to the DB-9 SERVICE port on the host unit front panel. This port provides all components of the Maintenance Interface including the NOC–NEM interface window. •NOC Comm Port—This is an optional second port that can be connected via an RS-232 cable to a direct data link with a remote terminal or with a computer running a terminal emulator program. Figure 16. Preferences Window 2. If either of these ports is incorrectly identified: a. Click in the port pull-down menu (port names listed are PC-specific). b. Select the port name causing it to be highlighted as shown in Figure 17. Figure 17. Set Comm Ports Dialog When done with all entries in the Preferences window, click on OK. For changes to be effective, you have to quit and restart EMS Task-Based ReferenceSelecting EMS Program File Directory Element Management System (EMS) 4.0 User Manual 31 3.4Selecting EMS Program File Directory Using the Preferences window in EMS (shown in ". Preferences Window" on page 30), you can select the directory (folder) to be used for host and remote control programs and Field Programmable Gate Arrays (FPGSs). To display the Preferences window Select Edit
Preferences. To select the EMS program file directory 1. Click in the data entry box for Program File Directory. 2. In the window that displays, browse to select the desired folder (causing the folder name to display in the File name field), and click on OK. Figure 18 shows an example. Figure 18. Selecting a Program File Directory When done with all entries in the Preferences window, click on OK. For changes to be effective, you have to quit and restart EMS NOTE: You cannot use NOC-NEM to select the EMS program file directory. Defining Log File Name and Trim TimeSection 3 Element Management System (EMS) 4.0 User Manual 32 3.5Defining Log File Name and Trim Time Using the Preferences window (shown in Figure 16 on page 30), you can perform the following tasks related to the EMS log file: •Select the directory (folder) where the EMS log file is stored. •Change the EMS log file name ( EMSlog by default). •Define the trim time. EMS Log File—is a system-created file into which EMS periodically places network status information. This status information includes all parameter values and all alarm states for all NEs currently connected to the system. By default, EMS places new entries into the log file at time intervals of 30 minutes. This time interval can be changed for EMS as a whole, or for any particular NE, using a SET RECORD command in the NOC-NEM window. EMS also writes a status entry into the log file whenever any alarm changes in state (for example, from “no alarm” to “major alarm”). The log file can be viewed using a browser such as Internet Explorer (for more information, refer to Topic 3.15, Viewing the EMS Log File, on page 53). Trim Time—is the number of days that a log file entry remains in the file before it is automatically deleted by the system. When any entry reaches an age in days exceeding the trim time, the entry is deleted. EMS trims the log file once every 24 hours. Maximum trim time allowed is 60 days. NOTE: To avoid losing the entries trimmed from the EMS log file, you should periodically copy and paste the log file into another log folder. To do this, use Windows Explorer copy and paste functions. Save the file with a unique name such as the log file name plus the date on which the file was copied. To display the…

Text truncated - open the document above for the full version.

Task-Based ReferenceUsing Alarm Overview to View and Element Management System (EMS) 4.0 User Manual 39 •ALARM HISTORY Indicator—present only until it is clicked away, indicates, in effect, whether someone has noticed the alarm and looked into its significance. The color of this indicator will be that of the worst alarm existing for the identified network element (if any major alarm exists, the color will be red). NOTE: These two types of indicators operate independently from one another. If the condition causing the alarm is cleared, resulting in a “green” status indicator, the history indicator will still remain until it is clicked away. By the same token, acknowledging the alarm has no effect on the alarm status indicator since that has no effect on the underlying physical condition causing the alarm. To view and acknowledge alarms 1. Select View
AlarmOverview to display the AlarmOverview window. 2. Look for ALARM STATUS indicators with colors yellow or red, as shown in Figure 27. Figure 27. Units With Alarms 3. Interpret the ALARM STATUS indicators as follows: •Red = one or more major alarms exist. A major alarm places the identified unit in standby operating mode (stopping RF functions). •Ye l l o w = one or more minor alarms exist at the network element. A minor alarm allows the unit to continue functioning in normal mode. •Green = no alarms exist at the network element. 4. Check if any unit has an ALARM HIST indicator, such as shown in Figure 28. If any does, click on the ALARM HIST button (labeled Hist Ack) to start the process to acknowledge the alarm. Using Alarm Overview to View and Acknowledge AlarmsSection 3 Element Management System (EMS) 4.0 User Manual 40 Figure 28. ALARM HIST Indicator 5. When the dialog window shown below in Figure 29 appears, click on the OK button to indicate that you are aware of the alarm and aware that alarm history text is available for viewing. Figure 29. Alarm Overview Example NOTE: After you click on the OK button, the ALARM HIST indicator will dis- appear from the display, as shown in Figure 30. 6. Check the EMS log file, as shown in Figure 31, for alarm history text to deter- mine the events associated with the alarm. For information on how to view the file, refer to Topic 3.15, Viewing the EMS Log File, on page 53. Task-Based ReferenceUsing Alarm Overview to View and Element Management System (EMS) 4.0 User Manual 41 Figure 30. HOST ALARM HIST Cleared Figure 31. Example of Alarm History Text 7. If desired, also check the alarm detail windows for the host and remote unit. To interpret the host display, see Topic 4.4.2 on page 71. To interpret the remote display, see Topic 4.5.2 on page 82. To view alarm history using the NOC-NEM interface Use the GET ALARM command (see Topic 5.5.6 on page 101). Viewing Alarm DetailSection 3 Element Management System (EMS) 4.0 User Manual 42 3.9Viewing Alarm Detail Alarm Detail lists and tells the status for all alarm indicators received from the host/remote pair. There are separate windows for the host and remote units. To view alarm detail for a host/remote pair 1. From the View menu, select the names of the host/remote pair. 2. The Alarms windows display as shown in Figure 32. 3. To interpret the host display, see Topic 4.4.1 on page 69. To interpret the remote display, see Topic 4.5.1 on page 80. Figure 32. Alarm Detail Example To view alarm detail using the NOC-NEM interface Use the GET ALARM command (see Topic 5.5.6 on page 101).

Task-Based ReferenceDetermining RF Signal Levels Element Management System (EMS) 4.0 User Manual 43 3.10 Determining RF Signal Levels An operational host/remote pair has forward and reverse path RF signals passing through it between the SDR BTS application and the cell phone user. The RF signals are transported in digital format as RF spectrum data by way of fiber or fiber-to-free-space optics links between the host unit (Host PCIx Card) and remote unit (in both directions). To view RF signal levels for a host/remote pair 1. From the View menu, select the site names of a host/remote pair. 2. Click on the host RF tab for the host or remote unit to view RF signal levels and associated information for the selected unit (see Figure 33). 3. To interpret host display, see Topic 4.4.2, Host RF Window, on page 71. To interpret remote display, see Topic 4.5.2, Remote RF Window, on page 82. Figure 33. RF Display Example Setting RF Forward AttenuationSection 3 Element Management System (EMS) 4.0 User Manual 44 To view RF signal levels using the NOC-NEM interface Use the GET DATA command (see Topic 5.5.7 on page 105). 3.11 Setting RF Forward Attenuation Using the remote unit RF window, you can adjust the current attenuation setting for the RF forward path. This setting affects the strength of the forward path RF analog signal transmitted from the remote unit antenna. Adjustments made in EMS are passed to the remote unit control software, which operates a digital attenuator. The attenuator provides an attenuation adjustment range of 0 to 31 dB, and can be set in 1 dB increments. Any input signal with a level of –9 dBm to –40 dBm (composite) can be adjusted to the required level using the forward path atttenuator. NOTE: Default settings for the attenuator are the maximum, 31 dB. NOTE: An external attenuator is required if more than 30 dB of attenuation is required to adjust the input RF signal to the required level. To adjust the attenuator, use the procedure below. To enter attenuation settings for a host RF signal 1. From the View menu, select the names of a host/remote pair. 2. Click on remote RF tab to view the remote RF window (for an example, see Figure 33 on page 43). 3. Click on the Edit button in the Remote Fwd Att area in the window to dis- play the Remote Fwd Att dialog shown in Figure 34. (The Edit button to be clicked on is in the lower right in the figure.) Task-Based ReferenceSetting RF Forward Attenuation Element Management System (EMS) 4.0 User Manual 45 Figure 34. Attenuation Area in RF Window 4. In the Remote Fwd Att dialog, key in the desired setting as shown in the example in Figure 35. Figure 35. Entering Remote Forward Attenuation 5. When done, click on the OK button. To enter forward path attenuation values using NOC-NEM interface Use the SET THRESHOLD command (see Topic 5.5.18 on page 115). Defining RF Logical ChannelsSection 3 Element Management System (EMS) 4.0 User Manual 46 3.12 Defining RF Logical Channels Using the host SDR Config window, shown in Figure 36, you can define a logical RF channel and enter gain settings for each path within the channel. A logical RF channel is a multiplex of up to eight RF voice channels. A logical RF channel consists of a forward path, a primary reverse path, and a secondary reverse path, if supported by the remote unit. The gain setting is simply a number that affects the amount of gain to applied to the signal within the specified path. A negative value results in attenuation. Each gain setting increment corresponds approximately to 1 dBm of adjustment. To define an RF logical channel 1. From the View menu, select the names of a host/remote pair. 2. Click on the host SDR Cfg tab to display the window shown in Figure 36. (This example shows typical a data display for logical RF channels that are already defined.) Figure 36. Host SDR Cfg Window 3. Determine which logical RF channel you want to enter data for. To enter val- ues for that channel, move across in the same row in the window. The system supports up to eight logical channels. 4. Click on the Modulation Type field to display a pulldown list such as shown in Figure 37. From the list, select the modulation type of the channel being configured. Task-Based ReferenceDefining RF Logical Channels Element Management System (EMS) 4.0 User Manual 47 Figure 37. Modulation Type 5. Click in the FCC RF Chnl Number field and from the pulldown list select an FCC channel number as shown in the example in Figure 38. Based on modu- lation type, band, and sub-band, EMS will list only available FCC channel numbers. Figure 38. FCC RF Chnl Number (Example) 6. Click in the Fwd RF Chnl Gain field to display a pulldown list such shown in Figure 39. Select the item for the desired gain setting for the forward path. The range of possible values is from 10 to −20 dBm. The standard value for this field is 10. Figure 39. Fwd RF Chnl Gain Setting Operating ModeSection 3 Element Management System (EMS) 4.0 User Manual 48 7. Click in the Rev RF Chnl Gain field to display a pulldown list. Select the item for the desired amount of signal gain. The range of possible values is from 10 to −20 dBm. The standard value for this field is 0. 8. If the remote unit supports the diversity option (second reverse path), click on the Div RF Chnl Gain field to display the pulldown list. Select the item for the desired amount of signal gain. The range of possible values is from 10 to −20 dBm. The standard value for this field is 0. 9. Use the last field on the right, RF Chnl Enable, to enable the channel if it will go into immediate use. To enable the channel, click on the field to set the dis- played value to “true.” If the channel should not be enabled at this time, let it stay at the value “false.” When a value is changed in this field, a box appears temporarily as shown in Figure 40. Figure 40. Setting Channel Enable 10. When done, exit the window to proceed with other tasks if desired. To do this same task using the NOC-NEM in…

Text truncated - open the document above for the full version.

Downloading Program FilesSection 3 Element Management System (EMS) 4.0 User Manual 52 6. Click on the Load button to start downloading the program. This causes the operating mode to change automatically to PrgLd or FPGALd (Figure 43), followed by a progressive fill-in of the progress bar (Figure 44). Figure 43. Changing Mode Figure 44. Program Load Progress 7. When the program download has been completed, the message shown in Figure 45 appears. Figure 45. Done Message Task-Based ReferenceViewing the EMS Log File Element Management System (EMS) 4.0 User Manual 53 3.15 Viewing the EMS Log File The EMS log file (by default, dems.xml) serves as a repository for status and alarm records written by the EMS software. Within the file, the records are stored in an “extended markup language” ( xml) format that can be displayed by most internet browsers. Each separate record is preceded and ended by the tag <logrec> which can be seen in the example shown in Figure 46. NOTE: The instructions below show functions and displays from MicroSoft Inter- net Explorer. Most other internet browsers have similar functions and displays. To view the log file using an internet browser 1. Start the internet browser. 2. In the internet browser, select File
Open (or comparable function) to select and open the EMS log file. 3. The log file displays in the browser window as shown in Figure 46. Figure 46. Log File Displayed in Internet Browser Viewing the EMS Log FileSection 3 Element Management System (EMS) 4.0 User Manual 54 To use the log file 1. Scroll down through the records. Note that the records are displayed in chro- nological order from most recent to oldest. 2. Use the search function of the browser (Edit
Find (on This Page) or com- parable function) to find particular types of records or a particular item such as PSBattVolt in Figure 47. 3. To open or close a record, click on the minus or plus sign on the left of the entry (“-”closes the entry, “+” opens it). Figure 47. Searching the Log File 4 S 4 S4 S 4 SC CC CR RR RE EE EE EE EN NN N-B -B-B -BA AA AS SS SE EE ED DD D R R R RE EE EF FF FE EE ER RR RE EE EN NN NC CC CE EE E Element Management System (EMS) 4.0 User Manual 57 This section contains examples and descriptions of the EMS Maintenance Interface “screens.” The descriptions cover all menu items, all “dashboard” indicators, all mouse-selectable controls, and all data entry fields. 4.1EMS Pull-Down Menus The EMS toolbar, shown in Figure 48, is a standard Windows application toolbar with pull…
