ADCP-75-110 Issue 2B July 2001 Digivance ™ 800/1900 MHz Indoor Coverage Solution Installation and Operation Manual DRAFT 1175170 Rev A FCC ID: F8I-DVICS1900-1 ADCP-75-110 • Issue 2B • July 2001 Page ii COPYRIGHT  2001, ADC Telecommunications, Inc. All Rights Reserved Printed in the U.S.A. REVISION HISTORY ISSUE DATE REASON FOR CHANGE Issue 1 04/2001 Original Issue 2 06/2001 Changes in LED operation, new power cable maximum length recommendations, and update to specifications table Issue 2B 07/2001 Updated to cover 1900 MHz version of product TRADEMARK INFORMATION ADC and FiberGuide are registered trademarks of ADC Telecommunications, Inc. Digivance is a trademark of ADC Telecommunications, Inc. LC is a trademark of Lucent Technologies Inc. TORX is a registered trademark of Textron, Inc. DISCLAIMER OF LIABILITY Contents herein are current as of the date of publication. ADC reserves the right to change the contents without prior notice. In no event shall ADC be liable for any damages resulting from loss of data, loss of use, or loss of profits and ADC further disclaims any and all liability for indirect, incidental, special, consequential or other similar damages. This disclaimer of liability applies to all products, publications and services during and after the warranty period. This publication may be verified at any time by contacting ADC’s Technical Assistance Center at 1-800-366-3891, extension 63475 (in U.S.A. or Canada) or 952-946-3475 (outside U.S.A. and Canada), or by e-mail to [email protected]. ADC Telecommunications, Inc. P.O. Box 1101, Minneapolis, Minnesota 55440-1101 In U.S.A. and Canada: 1-800-366-3891 Outside U.S.A. and Canada: (952) 938-8080 Fax: (952) 946-3292 ADCP-75-110 • Issue 2B • July 2001 Page iii  2001, ADC Telecommunications, Inc. TABLE OF CONTENTS Content Page 1 SYSTEM FUNCTIONAL OVERVIEW AND UNIT DESCRIPTIONS........................................1 1.1 System Functional Overview.......................................................1 1.2 Digital Host Unit Description.......................................................3 1.3 Digital Remote Unit Description.....................................................7 1.4 Digital Expansion Unit Description...................................................9 1.5 Terms and Definitions............................................................12 1.6 Specifications.................................................................13 2 INSTALLATION PLANNING AND SYSTEM DESIGN................................................16 2.1 Base Station Interface Requirements..................................................16 2.2 Locating and Mounting Requirements.................................................18 2.3 Powering Requirements..........................................................19 2.4 Optical Options and Requirements...................................................20 2.5 Coaxial Cable Requirements.......................................................20 2.6 System Expansion Planning........................................................20 2.7 DRU Antenna Options............................................................21 2.8 External Alarm System Reporting Requirements..........................................23 2.9 Frequency Band Selection Requirements (1900 Mhz)......................................23 2.10 Maintenance Requirements........................................................24 2.11 System Design Recommendations...................................................24 3 DIGITAL HOST UNIT INSTALLATION PROCEDURE................................................27 3.1 System Plan Review and Pre-Installation Cable Routing.....................................27 3.2 Tools and Materials.............................................................27 3.3 Unpacking and Inspection.........................................................28 3.4 Frequency Band Selection Procedure (1900 Mhz DHU Only).................................28 3.5 Mounting Procecure ............................................................29 3.6 Chassis Ground Procedure.........................................................32 3.7 Coaxial Cable Connections........................................................33 3.8 Ports 1–6 Optical Connections......................................................34 3.9 DC Power Connections...........................................................35 3.10 Exterma; Alarm System Connections..................................................37 3.11 AC Power Connections...........................................................38 3.12 Create As-Built Drawing..........................................................39 4 SYSTEM OPERATION..................................................................40 4.1 Tools and Materials.............................................................40 4.2 Turn-Up System and Verify Operation.................................................40 4.3 Correct Installation Problems.......................................................43 4.4 Test System Performance.........................................................45 5 SYSTEM MAINTENANCE PROCEDURES......................................................46 5.1 Tools and Materials .............................................................46 5.2 Fault Detection and Alarm Reporting..................................................46 (continued) ADCP-75-110 • Issue 2B • July 2001 Page iv  2001, ADC Telecommunications, Inc. TABLE OF CONTENTS Content Page 5.3 Fault Isolation and Troubleshooting..................................................47 5.4 Test Procedures...............................................................50 5.5 DHU or DEU Fan Replacement......................................................54 6 GENERAL INFORMATION...............................................................57 6.1 Warranty/Software.............................................................57 6.2 Software Service Agreement.....................…

Text truncated - open the document above for the full version.

ADCP-75-110 • Issue 2B • July 2001 Page 27 © 2001, ADC Telecommunications, Inc. 3 DIGITAL HOST UNIT INSTALLATION PROCEDURE This section provides the installation procedures for the DHU. Installation of the DEU(s) and DRU(s) may proceed separately from the installation of the DHU. The installation procedures for the DEU are provided in the Digital Expansion Unit Installation Instructions (ADCP -75- 111) which are shipped with the DEU. The installation procedures for the DRU, the DRU antennas, and the ac/dc converter (optional DRU accessory) are provided in the Digital Remote Unit Installation Instructions (ADCP-75-112) which are shipped with the DRU. When all units of the Digivance ICS have been installed, refer to Section 4 of this manual for the system power up and test procedures. 3.1 System Plan Review and Pre-Installation Cable Routing Before beginning the installation, review the system plan with the system engineer. Make sure each equipment installation site is identified and located and all cable runs are mapped out. The coaxial, DC power, and fiber optic cables may be routed between the various equipment locations before the equipment is installed. Whenever possible, route fiber optic cables through conduit or a guideway such as the FiberGuide system. Avoid routing fibers through ladder type cable racks or troughs that do not provide sufficient support to limit bending or prevent accidental damage. Tie-wrapping is not recommended as a means of securing fiber optic cables. Make sure to leave sufficient slack at each equipment location for connectorizing and cable management. The procedures for terminating the cables and for connecting the cables to the DHU are provided in the sections that follow. 3.2 Tools and Materials The following tools are required in order to complete the procedures in this section: • Box cutter • Pencil or scribe • Medium and small size flat-bladed screwdrivers • TORX screwdriver (T20 bit) • Pliers • Wire cutters • Wire stripper • Non-conductive probe (1900 MHz units only) • Tool kit for attaching RJ-45 male connectors to category 3 or 5 cable • Tool kit for attaching N-type male connectors to coaxial cable • Tool kit for attaching LC connectors to multimode fiber optic cable • Drill and assorted drill bits (wall-mount installations only) • Multimeter • Optical power meter • Laser light source FCC ID: F8I-DVICS1900-1 ADCP-75-110 • Issue 2B • July 2001 Page 28 © 2001, ADC Telecommunications, Inc. The following materials are required in order to complete the procedures in this section: • Wall-mount fasteners (wall-mount applications only) • #22 AWG (0.40 mm) category 3 or 5 cable (for power cable and external alarm connections) • RJ-45 male connectors (for power cable) • #18 AWG (1.00 mm) insulated stranded copper wire (for chassis grounding wire) • Ring terminal for #18 wire (for chassis ground wire connection) • 50 or 62.5 micron core multi-mode fiber optic cable • LC-type field installable connectors • High performance, flexible, low loss 50-ohm coaxial cable • N-type male connectors • Wire ties 3.3 Unpacking and Inspection This subsection provides instructions for opening the shipping boxes, verifying that all parts have been received, and verifying that no shipping damage has occurred. Use the following procedure to unpack and inspect the DHU: 1. Open the shipping carton and carefully unpack the DHU from the protective packing material. 2. Check the DHU for broken or missing parts. If there are any damages, contact ADC (see Section 6 at the end of this manual) for an RMA (Return Material Authorization) and to reorder if replacement is required. 3.4 Frequency Band Selection Procedure (1900 MHz DHU only) The 1900 MHz version of the DHU may be configured to operate at any one of four frequency bands. A DIP switch is provided on the underside of the DHU for selecting the required frequency band. Use the following procedure to set the DIP switch to provide the required 1900 MHz frequency band: 1. Determine the required frequency band for the DHU (AD, DBE, BEF, or EFC) as specified in the system design plan. 2. Orient the DHU as shown in Figure 14 and then locate the small hole in the bottom of the DHU that provides access to the band select DIP switch. 3. Use a non-conductive probe to align the DIP switch sliding handles to provide the required frequency band (see Figure 14). 4. Place the copper sticker provided with the DHU over the small opening that provides access to the DIP switch. Note: The copper sticker provides EMI/RFI shielding. Do not use some other type of material to cover the DIP switch access hole. ADCP-75-110 • Issue 2B • July 2001 Page 29 © 2001, ADC Telecommunications, Inc. ALIGN DIP SWITCH HANDLES AS SHOWN ON THE LABEL TO PROVIDE SPECIFIED FREQUENCY BAND Fig 13-A Figure 14. 1900 MHz DHU Frequency Band Selection 3.5 Mounting Procedure The DHU may be either rack-mounted or wall-mounted. Of the procedures that follow, use which ever procedure is appropriate for the installation: Note: To insure that all optical connectors and transceivers remain dust-free during installation, leave all dust caps and dust protectors in place until directed to remove them for connection. 3.5.1 Rack Mount Installation The DHU may be mounted in either a 19-inch or 23-inch EIA or WECO equipment rack. Both US standard and metric machine screws are included for rack mounting the DHU. When loading the DHU in a rack, make sure the mechanical loading of the rack is even to avoid a hazardous condition such as a severely unbalanced rack. The rack should safely support the combined weight of all the equipment it holds. In addition, the maximum recommended ambient temperature for the DHU is 50º C (122º F). Allow sufficient air circulation or space between units when the DHU is installed in a multi-unit rack assembly because the operating ambient temperature of the rack environment might be greater than room ambient. Warning: Wet conditions increase the potential for receivi…

Text truncated - open the document above for the full version.

ADCP-75-112 • •• • Issue 2A • •• • June 2001 TBD Rev APage 1 © 2001, ADC Telecommunications, Inc. Digivance ™ Indoor Coverage Solution 800/1900 MHz Digital Remote Unit Installation Instructions ContentPage INTRODUCTION............................................................................2 1DESCRIPTION........................................................................3 1.1Digital Remote Unit..............................................................3 1.2Antenna Options................................................................5 1.3AC/DC Power Converter............................................................6 2INSTALLATION PROCEDURE..............................................................7 2.1Tools and Materials..............................................................7 2.2Unpacking and Inspection..........................................................8 2.3Frequency Band Selection (1900 DRU Only).............................................8 2.4DRU Mounting Procedure..........................................................9 2.5Antenna Mounting Procedure.......................................................10 2.6Antenna Connection.............................................................16 2.7Optical Connection..............................................................17 2.8DC Power Connection............................................................18 3CUSTOMER INFORMATION AND ASSISTANCE..................................................21 DRAFT 16449-A Digital Remote Unit ADCP-75-112 • Issue 2A • June 2001 Page 2 © 2001, ADC Telecommunications, Inc. INTRODUCTION This publication provides instructions for installing the Digivance Indoor Coverage Solution (ICS) Digital Remote Unit (DRU). A more complete description of the DRU along with the operating and maintenance procedures is provided in the Digivance ICS Installation and Operation Manual (ADCP-75-110). The DRU is installed in conjunction with the Digital Host Unit (DHU) and the Digital Expansion Unit (DEU). Revision History ISSUEDATEREASON FOR CHANGE Issue 104/2001Original release. Issue 206/2001Changes in LED operation and new power cable maximum length recommendations Issue 2A06/2001Updated to cover 1900 MHz version of product Trademark Information ADC is a registered trademark of ADC Telecommunications, Inc. Digivance is a trademark of ADC Telecommunications, Inc. LC is a trademark of Lucent Technologies Inc. Admonishments Important safety admonishments are used throughout this publication to warn of possible hazards to persons or equipment. An admonishment identifies a possible hazard and then explains what may happen if the hazard is not avoided. The admonishments — in the form of Dangers, Warnings, and Cautions — must be followed at all times. These warnings are flagged by use of the triangular alert icon (seen below), and are listed in descending order of severity of injury or damage and likelihood of occurrence. Danger: Danger is used to indicate the presence of a hazard that will cause severe personal injury, death, or substantial property damage if the hazard is not avoided. Warning: Warning is used to indicate the presence of a hazard that can cause severe personal injury, death, or substantial property damage if the hazard is not avoided. Caution: Caution is used to indicate the presence of a hazard that will or can cause minor personal injury or property damage if the hazard is not avoided. Related Publications Listed below are related manuals and their publication numbers. Copies of these publications can be ordered by contacting the ADC Technical Assistance Center at 1-800-366-3891 extension 63475 (in U.S.A. or Canada) or 952-946-3475 (outside U.S.A. and Canada) . TitleADCP Number Digivance ICS Installation and Operation Manual 75-110 Digivance ICS Digital Expansion Unit Installation Instructions75-111 ADCP-75-112 • Issue 2A • June 2001 Page 3 © 2001, ADC Telecommunications, Inc. 1 DESCRIPTION This section describes the DRU, the various DRU antennas, and the AC/DC power converter (optional accessory item). 1.1 Digital Remote Unit The DRU, shown in Figure 1, serves as the cellular user servicing unit for the Digivance ICS. The DRU consists of an electronic circuit board assembly that is mounted within a powder- coated sheet metal enclosure. The electronic circuit board assembly is not user replaceable. The DRU is designed for use within a non-condensing indoor environment such as inside a building. All controls, indicators, and connectors (except the antenna connector) are mounted on the DRU front panel for convenient access. FRONT PANEL MOUNTING FOOT (EACH CORNER) 7.0 INCHES (178 mm) 7.3 INCHES (185 mm) 2.1 INCHES (53 mm) 16420-A Figure 1. Digital Remote Unit The DRU is equipped with four integral mounting feet that allow it to be mounted on any flat horizontal or vertical surface. A typical location for mounting the DRU would be above ceiling tiles where the optical fiber and power cables can be concealed or on a wall. Slots are provided in the mounting feet for securing the DRU to the mounting surface. The RF signal interface between the DRU and the cellular users is provided through an external antenna connected to a female SMA connector. The antenna may be ordered separately from ADC. Several types of antennas with various patterns are available. Non-ADC antennas may also be used with the DRU to meet various application requirements. The DRU is equipped with a small form factor LC type optical transceiver that provides a point for connecting the optical link cables. Depending on the application requirements, the optical transceiver may be connected to either a DHU or a DEU. ADCP-75-112 • Issue 2A • June 2001 Page 4 © 2001, ADC Telecommunications, Inc. The DRU is equipped with a female RJ-45 jack that provides a point for connecting a DC power cable. The DRU is powered by 34–48 Vdc power which is supplied through the RJ-45 connector. Power to the DRU may be supplied by the DH…

Text truncated - open the document above for the full version.

TÜV MANAGEMENT SERVICEPhone: (651) 631 2487 TÜV PRODUCT SERVICE INC.Fax: (651) 638 0285 1775 Old Highway 8 NW, Suite 104email [email protected] New Brighton MN 55112-1891http:://www.tuvglobal.com Divisions of TÜV America Inc., a subsidiary of TÜV Süddeutschland AG TÜV PRODUCT SERVICE INC 19333 WILD MOUNTAIN ROAD TAYLORS FALLS, MINNESOTA 55084-1786 ENGINEERING STATEMENT For Certification of ADC Telecommunications Incorporated P O Box 1101 Minneapolis MN 55440-1101 Digivance 1900 MHz ICS System Model No(s): DGVI-DGVI-312110DHU and DGVI-313110DRU FCC ID: F8I-DVICS1900-1 I am an Electromagnetic Compatibility Engineer for TÜV PRODUCT SERVICE INC, Taylors Falls, Minnesota. My education and experience are a matter of record with the Federal Communications Commission. TÜV PRODUCT SERVICE INC has been authorized by David Conyers, Vice President of Engineering, ADC Telecommunications Incorporated, to make Certification measurements on the DGVI-110000RIU (A Band) and DGVI-120000RIU (B Band) Digivance Remote Interface Unit (Cellular Amplifier). These tests were made by me or under my supervision at our Wild River Laboratory which is on file with the FCC under Paragraph 2.948 of the FCC Rules. Test data required by the TCB is included in this report. It is submitted that the above equipment meets the FCC Part 24, Subpart E Requirements and Certification is hereby requested. Erik J Borgstrom Minnesota EMC Manager Minnesota Wild River Lab TÜV Product Service [email protected] Dated: 18 July 2001 FCC ID: F8I-DVICS1900-1

To Base Station Optical Fiber Block Diagram 1900 MHz Digital Host Unit D To A Converter RF FILTER SAW FILTER 6 WAY DIGITAL COMBINER LASER RX (1 OF 6) 161 MHz Analog Baseband Spectrum Digital Baseband Spectrum Reverse Synthesizer Forward Synthesizer Baseband LO and Reference Compsite Digital Baseband Spectrum 161 MHz IF Spectrum From Base Station SAW FILTER A To D Converter 6 WAY DIGITAL SPLITTER LASER TX (1 OF 6) Optical Fiber Band 1 1930 - 1950 MHz Band 2 1945 - 1970 MHz Band 3 1950 - 1975 MHz Band 41965 - 1990 MHz Band 1 1850 - 1870 MHz Band 2 1865 - 1890 MHz Band 3 1870 - 1895 MHz Band 41885 - 1910 MHz Controller Band Select 142 MHz 142 MHz Forward Synthesizer Reverse Synthesizer BAND 117762019 BAND 217962039 BAND 318012044 BAND 418162059 IF Spectrum Out @ + 13dBm Min, +19dBm Max Duplexer External Antenna Analog Baseband Spectrum Optical Fiber To Digital Host Unit or Digital Expansion Unit Digital Baseband Spectrum Baseband LO and Reference LASER RX D TO A Converter SAW FILTER RF FILTER Reverse Synthesizer Optical Fiber From Digital Host Unit Or Digital Expansion Unit Forward Synthesizer Power AMP Block Diagram 1900 MHz Digital Remote Unit Digital Baseband Spectrum LASER TX A To D Converter SAW FILTER LNA Band 1 1850 - 1870 MHz Band 2 1865 - 1890 MHz Band 3 1870 - 1895 MHz Band 41885 - 1910 MHz Band 1 1930 - 1950 MHz Band 2 1945 - 1970 MHz Band 3 1950 - 1975 MHz Band 41965 - 1990 MHz Controller Band Select Switch Forward Synthesizer Reverse Synthesizer BAND 117762019 BAND 217962039 BAND 318012044 BAND 418162059 IF Spectrum 161 MHz IF Spectrum 161 MHz

FCC ID: F8I-DVICS1900-1

FCC ID: F8I-DVICS1900-1, Page 1 of 6 FCC ID: F8I-DVICS1900-1, Page 2 of 6 FCC ID: F8I-DVICS1900-1, Page 3 of 6 FCC ID: F8I-DVICS1900-1, Page 4 of 6 FCC ID: F8I-DVICS1900-1, Page 5 of 6 FCC ID: F8I-DVICS1900-1, Page 6 of 6

FCC ID: F8I-DVICS1900-1, Page 1 of 38

FCC ID: F8I-DVICS1900-1, Page 1 of 38 FCC ID: F8I-DVICS1900-1, Page 2 of 38 Digivance Digital Host Unit (DHU) Control Board Top FCC ID: F8I-DVICS1900-1, Page 3 of 38 FCC ID: F8I-DVICS1900-1, Page 4 of 38 FCC ID: F8I-DVICS1900-1, Page 5 of 38

FCC ID: F8I-DVICS1900-1, Page 6 of 38 FCC ID: F8I-DVICS1900-1, Page 7 of 38 FCC ID: F8I-DVICS1900-1, Page 8 of 38 FCC ID: F8I-DVICS1900-1, Page 9 of 38 FCC ID: F8I-DVICS1900-1, Page 10 of 38 FCC ID: F8I-DVICS1900-1, Page 11 of 38

FCC ID: F8I-DVICS1900-1, Page 12 of 38 Digivance Digital Host Unit (DHU) Control Board Bottom FCC ID: F8I-DVICS1900-1, Page 13 of 38 FCC ID: F8I-DVICS1900-1, Page 14 of 38 FCC ID: F8I-DVICS1900-1, Page 15 of 38 FCC ID: F8I-DVICS1900-1, Page 16 of 38 FCC ID: F8I-DVICS1900-1, Page 17 of 38 FCC ID: F8I-DVICS1900-1, Page 18 of 38 FCC ID: F8I-DVICS1900-1, Page 19 of 38 FCC ID: F8I-DVICS1900-1, Page 20 of 38 FCC ID: F8I-DVICS1900-1, Page 21 of 38

FCC ID: F8I-DVICS1900-1, Page 27 of 38 Digivance Digital Remote Unit (DRU) Control Board Bottom FCC ID: F8I-DVICS1900-1, Page 28 of 38 FCC ID: F8I-DVICS1900-1, Page 29 of 38 FCC ID: F8I-DVICS1900-1, Page 30 of 38 FCC ID: F8I-DVICS1900-1, Page 31 of 38 FCC ID: F8I-DVICS1900-1, Page 32 of 38 Power Distribution Board FCC ID: F8I-DVICS1900-1, Page 33 of 38 FCC ID: F8I-DVICS1900-1, Page 34 of 38 FCC ID: F8I-DVICS1900-1, Page 35 of 38 FCC ID: F8I-DVICS1900-1, Page 36 of 38 FCC ID: F8I-DVICS1900-1, Page 37 of 38 FCC ID: F8I-DVICS1900-1, Page 38 of 38

Tel: 952.946.3330 Fax: 952.946.3344 Mailing Address: P.O. Box 1101, Minneapolis, Minnesota 55440-1101 World Headquarters: Minneapolis, Minnesota USA +1.952.938.8080 www.adc.com February 27, 2001 DigiVance Theory of Operation System Operation DigiVance is a RF transport system designed to extend the coverage of a base station into buildings and other areas where location and construction prevent direct coverage. The system, consists of two or three modules, Digital Host Unit (DHU), Digital Remote Unit (DRU) and optional Digital Expansion Unit (DEU). To provide coverage, two RF paths must be established, the Forward or Base Station to Remote path and the Reverse of Remote to Base Station path. In the Forward path the DHU down-converts the Base Station RF spectrum to baseband, digitizes the Baseband spectrum, and transports the digitized spectrum over fiber optic cables. At the destination DRU, fiber optic receivers recover the digitized baseband spectrum. The digitized spectrum is converted to analog and upconverted to the original Base Station RF frequencies. The Base Station Forward spectrum is then amplified and supplied to an external coverage antenna. In the Reverse path the process is similar. In the DRU, signals from user handsets are recovered by the external remote antenna, downconverted to baseband, digitized, and transported to the base station over fiber optic cables. At the DHU, fiber optic receivers recover the digitized baseband signals. The digitized spectrum is converted to analog, upconverted to the original Handset RF frequencies, and supplied to the Base Station. Note: The DigiVance system is a solid state design and does not require manual tuning or a tune-up procedure. Digital Host Unit The DHU interfaces directly with the base station, either directly or via an over the air repeater. The DHU provides connections for six individually selectable bi-directional Fiber Optic ports, which provide optical connectivity for up to six remote ports. In the Forward path, after conversion to a digitized spectrum, the forward spectrum is copied, and separately provided to each enabled optical port. In the reverse direction, Fiber optic receivers separately receive the digitized spectrum from all enabled remote ports. The individual digitized spectrums are then digitally added to provide a composite digitized spectrum that is the sum of the individual spectrums. The DHU also contains fault detection circuitry that detects both local and remote faults, shuts down transmission when severe faults exit, and reports faults to the operator. Tel: 952.946.3330 Fax: 952.946.3344 Mailing Address: P.O. Box 1101, Minneapolis, Minnesota 55440-1101 World Headquarters: Minneapolis, Minnesota USA +1.952.938.8080 www.adc.com Digital Remote Unit As previously described, the DRU receives a digitized spectrum from the base station via the DHU, converts the digitized spectrum to the original Base Station RF frequencies, and provides the RF spectrum to an external antenna. In the Reverse direction, the Digital Remote Unit receives RF from any active user handsets, converts the RF spectrum to a digitized spectrum, and transports the digitized spectrum to the DHU on fiber optic cables. The DRU contains fault detection circuits that detect critical faults, disable RF output when critical faults are present, and transports fault information to the Digital Host Unit. Digital Expansion Unit. The DEU is an optional part of the system, and is not required for system operation. The DEU functions as a digital line extender, allowing longer fiber optic cable runs. In addition, the DEU provides up to six additional individually selectable system ports. In the forward path, the extra ports are provided copies of the digitized forward spectrum. In the reverse path, the individual port spectrums are digitally combined to form a composite spectrum.

RPT:ZCOSTBOM ADC PAGE: 1 DATE:06/07/2001 16:13:10 Bill of Materials Comparison date 06/07/2001 Assembly P/N: 1160571 Rev: 11 DGVI-312110DHU: DIGIVANCE HOST UNIT 1900Plant: 0310 BOM Usage: Production Alt BOM: 01 Item #ADC Part Number Material Description Rev Unit Quantity Rel.Stat Eff. Date Reference Designator Manufacturer Manufacturer Part No. 0010 1116896 PS-CHAS AC/DC SW 85-264VIN 48V/3.75AOUT A0 EA 1.000 AREL 09/05/2000 POWER-ONE MPU150-S261 0020 1114354 CBRK-SNAPIN MT 5A 2 POLE THERM OVRLD BLK A0 EA 1.000 AREL 06/28/2000 SCHURTER INC ABDBL050C0 0030 1144961 FAN ASSY-48VDC 32CFM 2 WIRE TERMW/MOLEX B0 EA 2.000 AREL 04/12/2001 KENT ELECTRONICS, INC ADC #1144961 0040 1118407 CABLE ASSY, PWR SUPP, 110 VAC C0 EA 1.000 AREL 05/23/2001 0050 27.0052 CONN-PM IEC 320 MALE QD 15A B0 EA 1.000 AREL 03/01/2001 PANEL COMPONENTS CORPORATION 8301212 0060 1144576 SCR-M3X.5X8MM TORXT10 FLTHD THDFRM W/NIB A0 EA 42.000 AREL 01/30/2001 ADAMS NUT & BOLT INC 101300 0065 4-01480-0520 W11-02 .187,.375 AD EA 1.000 AREL 12/14/1998 ADAMS NUT & BOLT INC 4-01480-0520 0070 4-24174-0350 HDW-100343: S27111-06 6-32X.312SEMS POU F0 EA 5.000 AREL 01/21/1997 ADAMS NUT & BOLT INC 4-24174-0350 CAMCAR DIVISION OF TEXTRON INC 430-004-406100 MONKS AND CRANE GW000306 0075 1155365 SCR-M3x.5x8MM TORX10 PANHD ZINCW/CLRCHRM A0 EA 8.000 AREL 02/21/2001 ADAMS NUT & BOLT INC 1155365 0080 1146072 CORDSET-3X18GA 125V/10A NOAMER W/C13 A0 EA 1.000 AREL 01/05/2001 PANEL COMPONENTS CORPORATION 70401020244 0090 1118637 FRONT PANEL, DIGITAL HOST UNIT L1 EA 1.000 AREL 04/20/2001 0100 1118634 COVER, DIGITAL HOST UNIT G1 EA 1.000 AREL 02/01/2001 0110 1143507 FAN MOUNTING PANEL B1 EA 1.000 AREL 02/01/2001 0120 1135753 PCB ASSY-1900 DHU MAIN BOARD GUPPY 12 EA 1.000 BREL 05/31/2001 Pemstar Inc. 1135753 0130 1125420 PCB ASSY-FRONT PANEL - GUPPY A1 EA 1.000 AREL 05/02/2001 PEMSTAR 0140 1118636 MOUNTING PLATE, DIGITAL HOST UNIT C1 EA 2.000 AREL 02/01/2001 RPT:ZCOSTBOM ADC PAGE: 2 DATE:06/07/2001 16:13:10 Bill of Materials Comparison date 06/07/2001 Assembly P/N: 1160571 Rev: 11 DGVI-312110DHU: DIGIVANCE HOST UNIT 1900Plant: 0310 BOM Usage: Production Alt BOM: 01 Item #ADC Part Number Material Description Rev Unit Quantity Rel.Stat Eff. Date Reference Designator Manufacturer Manufacturer Part No. 0150 1093270 SCREW-PH, M6X1X10mm, THD FORMING W/NIBS A0 EA 4.000 AREL 02/21/2000 ADAMS NUT & BOLT INC 0160 4-27033-9103 HDW-101224: SCREW 12-24X3/8 A0 EA 4.000 AREL 02/25/1993 ADAMS NUT & BOLT INC ADC# 4-27033-9103 CAMCAR DIVISION OF TEXTRON INC 4-27033-9103 MONKS AND CRANE GW000314 0165 1141854 WIRE ASSY-18GA GRN/YEL RINGTERM/FEM DISC D0 EA 1.000 AREL 05/23/2001 VOYAGER ELECTRONICS CORP 1141854 0170 1118410 WIRE ASSY 18 GA BROWN D0 EA 1.000 AREL 05/23/2001 0175 1141192 THERM TRANS MAT 10X15MM X2.0MM THICK A0 EA 1.000 AREL 01/05/2001 FUJIPOLY AMERICA CORPORATION 200G-B 10MM X 15MM 0180 1118412 WIRE ASSY 18 GA BLUE D0 EA 1.000 AREL 05/23/2001 0185 2-25700-0030 CLAMP CABLE .25 INCH A0 EA 1.000 AREL 03/11/1996 HEYCO 3304 0190 1173896 HOUSING, DHE, DEU, PAINTED A1 EA 1.000 AREL 05/19/2001 0200 1125621 LABEL, DHU, DEU, POWER SUPPLY A0 EA 1.000 AREL 01/09/2001 0201 2-42937-2858 LABEL DANGER VOLTAGE A0 EA 1.000 AREL 02/10/1993 DASCO SYSTEMS, INC. 1504432 0202 2-42938-5004 LABEL G…
