WTD 13.4.9 FCC Compliance Opinion TECO0004 Information about the Applicant Grantee (Company Name) ADC Telcommunications Inc. FCC Contact Person Joshua Wittman Address 1187 Park Place City, State, Zip Shakopee, MN 55379 Job Number TECO0004 Model Prism HDM 20W AWS MIMO RF Module FCC ID F8I-PSMAWS2D Agent Approval Type Original Equipment Class TNB Licensed Non-Broadcast Base Station Transmitter Rule Part 47 Cfr Part 27 Overview The FlexWave PRISM, FCC ID: F8I-PSMAWS2D, serves as a transport between an approved base station and a remote antenna to enhance signals in a wireless network. The system consists of an indoor host device and a remote unit, designed for an outdoor environment. FCC has granted a limited waiver of the prohibition in paragraph 133 of the Signal Booster Report and Order. See FCC response “Labeling waiver.pdf” Confidentiality requested for allowed files. Request is properly addressed and referenced. Recommendation All items have been resolved and completed to my satisfaction; therefore I recommend this application for approval. Signature Dave Tolman, TCB Committee 8/19/2013

Mailing Address: 1187 Park Place, Shakopee, Minnesota 55379 www.te.com August 19, 2013 Attention: Reviewing Engineering Type of Certification: Original - FCC Part 27 Applicant: ADC Telecommunications Inc. Equipment: FlexWave™ Prism – HDM 20 Watt AWS MIMO Model #: FWP-A4MT000MOD FCC ID: F8I-PSMAWS2D Dear Sir/Madam: Enclosed please find a signed FR410 TCB Application for certification of the above mentioned RF module. Further details and supporting documents have been uploaded to the Northwest EMC CTS system. Should you have any questions, please feel free to contact the undersigned. Sincerely, Joshua J. Wittman Compliance Engineer Tele: 952 403-8322 Fax: 952 403-8858 Email: [email protected]

1(1) Attention: Application Examiner Re: Request for Confidentiality Applicant: ADC Telecommunications, Inc. FCC ID: F8I-PSMAWS2D To whom it may concern, Permanent Confidentiality Request is hereby submitted by ADC Telecommunications, Inc. to withhold permanently from public review certain portions of the application for equipment certification for the referenced FCC identifiers. This request for confidentiality is made pursuant to 47 CFR 0.457(d) and 0.459 of the FCC Rules. In particular, the following sections of the application are to be kept permanently confidential: • Schematics • Detailed Block diagrams • Detailed Operational/Functional Description Rationale for request for confidentiality: ADC Telecommunications, Inc. has invested considerable time and materials in research and development to produce the referenced product. Disclosure of the permanently confidential portions of this application to competitors would not only give them significant competitive advantages in developing similar products, but would also disclose successful implementation of unpublished, leading edge technology developed by us. The fee for confidentiality has been submitted along with the fee for certification. If you have questions or need further information, please contact the undersigned. Sincerely, Joshua J. Wittman Compliance Engineer ADC Telecommunications, Inc.

RF Module Assembly #1 RF Module Assembly #2 RF Module Assembly #3 RF Module Assembly #4 RF Module Assembly #5 RF Module Assembly #6 RF Module Assembly #7 RF Module Assembly #8

INFORMATION ON THIS DOCUMENT IS PROPRIETARY TO ADC AND SHALL NOT BE USED, COPIED, REPRODUCED OR DISCLOSED IN WHOLE OR IN PART WITHOUT WRITTEN CONSENT OF ADC TITLE FlexWave™ Prism – HDM 20W AWS MIMO FCC Identification Label TOLERANCE UNLESS .XX NA OTHERWISE SPECIFIED .XX NA DRAWING NUMBER None A REV DO NOT SCALE DRAWING ENGR. Joshua J. Wittman SIZE A SHEET 1 OF 1 REV ECO DWN DATE A JJW 7-22-2013 XXXX-XXXXXXXX FCC ID: F8I-PSMAWS2D 2 1.500 REF R.075 (4) DIE CUT LABEL .750 REF 1,4 - See Note 4 for Model Number NOTES: 1 PRINTING TYPE: TRANSFER METHOD. COLOR: BLACK TEXT 8 PT ARIAL NON-BOLD LOCATED APPROXIMATELY AS SHOWN. 2 PRINTING TYPE: TRANSFER METHOD. COLOR: BLACK TEXT 6 PT ARIAL NON-BOLD LOCATED APPROXIMATELY AS SHOWN. MATERIAL: ADC PART NUMBER 1215140 3 4 FWP-A4MT000MOD

Motherboard – Front #1 Motherboard – Front #2 Motherboard – Front #3 Motherboard – Back #1 Motherboard – Back #2 Motherboard – Back #3 Tx Board – Front Tx Radio Tx Board – Back Rx Board – Front Rx Board – Back Duplexer #1 Duplexer #2 Antenna port Duplexer #3 LPA #1 LPA #2 LPA #3

Mailing Address: 1187 Park Place, Shakopee, Minnesota 55379 www.te.com August 19, 2013 Antenna Information Attention: Reviewing Engineering Type of Certification: Original - FCC Part 27 Applicant: ADC Telecommunications, Inc. Equipment: FlexWave™ Prism – HDM 20 Watt AWS MIMO Model #: FWP-A4MT000MOD FCC ID: F8I-PSMAWS2D Dear Sir/Madam: We, ADC Telecommunications, Inc. do not manufacture or distribute any antennas to our customers for their deployments. The customer provides their own . Dipole and omni antennas with a typical gain of 6dBi will be used with this product. Further details and supporting documents have been uploaded to the Northwest EMC CTS system. Should you have any questions, please feel free to contact the undersigned. Sincerely, Joshua J. Wittman Compliance Engineer Tele: 952 403-8322 Fax: 952 403-8858 Email: [email protected]

Mailing Address: 1187 Park Place, Shakopee, Minnesota 55379 www.TE.com July 24, 2013 Attn: Application Examiner, Reviewing Engineer Re: Tune-up Procedure The FlexWave™ Prism – HDM 20 Watt AWS MIMO model number FWP-A4MT000MOD employs a solid-state design that does not require a tune-up procedure. Sincerely, Joshua J. Wittman Compliance Engineer Tele: 952 403-8322 Fax: 952 403-8858 Email: [email protected]

Mailing Address: P.O. Box 1101, Minneapolis, Minnesota 55440-1101 World Headquarters: Minneapolis, Minnesota USA +1.952.938.8080 www.adc.com August 8, 2013 Attn: Application Examiner, Reviewing Engineer Re: RF Exposure Statement The antenna(s) used for this transmitter must be fixed-mounted on (outdoor/indoor) structures. RF exposure compliance is addressed at the time of licensing, as required by the responsible FCC Bureau(s), including antenna co-location requirements of 47 CFR 1.1307 (b)(3) Sincerely, Joshua J. Wittman Compliance Engineer Tele: 952 403-8322 Fax: 952 403-8858 Email: [email protected]

TE Connectivity /ADC Telecommunications Prism HDM 20W AWS MIMO RF Module Model: FWP-A4MT000MOD FCC 27:2013 Report #: TECO0004 Rev 2 Report Prepared By Northwest EMC Inc. NORTHWEST EMC – (888) 364-2378 – www.nwemc.com California – Minnesota – Oregon – New York – Washington WTD 12.5.23 CERTIFICATE OF TEST Last Date of Test: July 25, 2013 TE Connectivity /ADC Telecommunications Prism HDM 20W AWS MIMO RF Module Model: FWP-A4MT000MOD Emissions Test Description Specification Test Method Pass/Fail Conducted Output Power FCC 27:2013, FCC 2.1046:2013 ANSI/TIA/EIA-603-C-2004 Pass Occupied Bandwidth FCC 27:2013, FCC 2.1049:2013 ANSI/TIA/EIA-603-C-2004 Pass Out of Band Emissions - Conducted FCC 27:2013, FCC 2.1051:2013 ANSI/TIA/EIA-603-C-2004 Pass Band Edge FCC 27:2013, FCC 2.1051:2013 ANSI/TIA/EIA-603-C-2004 Pass Intermodulation FCC 27:2013, FCC 2.1051:2013 ANSI/TIA/EIA-603-C-2004 Pass Frequency Stability FCC 27:2013, FCC 2.1055:2013 ANSI/TIA/EIA-603-C-2004 Pass Field Strength of Spurious Emissions FCC 27:2013, FCC 2.1053:2013 ANSI/TIA/EIA-603-C-2004 Pass Deviations From Test Standards None Approved By: Tim O'Shea, Operations Manager NVLAP Lab Code: 200881-0 Test Facility The measurement facility used to collect the data is located at: Northwest EMC, Inc. 9349 W Broadway Ave. Brooklyn Park, MN 55445 Phone: (763) 425-2281 Fax: (763) 424-3469 This site has been fully described in a report filed with and accepted by the FCC (Federal Communications Commission) and Industry Canada (Site filing #2834E-1). This report must not be used to claim product certification, approval, or endorsement by NVLAP, NIST, or any agency of the federal government of the United States of America. Product compliance is the responsibility of the client, therefore the tests and equipment modes of operation represented in this report were agreed upon by the client, prior to testing. This Report may only be duplicated in its entirety. The results of this test pertain only to the sample(s) tested. The specific description is noted in each of the individual sections of the test report supporting this certificate of test. REV 2012.08.02 REVISION HISTORY Revision Number Description Date Page Number 00 None 01 Updated Intermodulation Test Description 8-12-2013 71 02 Revised CoT to add applicable references to FCC 2.1046-2.1055 8-27-13 2 Barometric Pressure The recorded barometric pressure has been normalized to sea level. REV 2012.05.24 ACCREDITATIONS AND AUTHORIZATIONS United States FCC - Designated by the FCC as a Telecommunications Certification Body (TCB). Certification chambers, Open Area Test Sites, and conducted measurement facilities are listed with the FCC. A2LA - Accredited by A2LA to ISO / IEC Guide 65 as a product certifier. This allows Northwest EMC to certify transmitters to FCC and IC specifications. NVLAP - Each laboratory is accredited by NVLAP to ISO 17025 Canada IC - Recognized by Industry Canada as a Certification Body (CB). Certification chambers and Open Area Test Sites are filed with IC. European Union European Commission – Validated by the European Commission as a Conformity Assessment Body (CAB) under the EMC directive and as a Notified Body under the R&TTE Directive. Australia/New Zealand ACMA - Recognized by ACMA as a CAB for the acceptance of test data. Korea KCC / RRA - Recognized by KCC’s RRA as a CAB for the acceptance of test data. Japan VCCI - Associate Member of the VCCI. Conducted and radiated measurement facilities are registered. Taiwan BSMI – Recognized by BSMI as a CAB for the acceptance of test data. NCC - Recognized by NCC as a CAB for the acceptance of test data. Singapore IDA – Recognized by IDA as a CAB for the acceptance of test data. Hong Kong OFTA – Recognized by OFTA as a CAB for the acceptance of test data. Vietnam MIC – Recognized by MIC as a CAB for the acceptance of test data. Russia GOST – Accredited by Certinform VNIINMASH, CERTINFO, SAMTES, and Federal CHEC to perform EMC and Hygienic testing for Information Technology products to GOST standards. SCOPE For details on the Scopes of our Accreditations, please visit: http://www.nwemc.com/accreditations/ REV 2012.08.02 MEASUREMENT UNCERTAINTY Measurement Uncertainty When a measurement is made, the result will be different from the true or theoretically correct value. The difference is the result of tolerances in the measurement system that cannot be completely eliminated. To the extent that technology allows us, it has been our aim to minimize this error. Measurement uncertainty is a statistical expression of measurement error qualified by a probability distribution. A measurement uncertainty estimation has been performed for each test per our internal quality document WP 342. The estimation is used to compare the measured result with its "true" or theoretically correct value. The expanded measurement uncertainty (K=2) for each test is on each data sheet. Our measurement data meets or exceeds the measurement uncertainty requirements of the applicable specification; therefore, the test data can be compared directly to the specification limit to determine compliance. The calculations for estimating measurement uncertainty are based upon ETSI TR 100 028 (or CISPR 16-4-1 as applicable), and are available upon request. The following table represents the Measurement Uncertainty (MU) budgets for each of the tests that may be contained in this report. Test + MU - MU Frequency Accuracy (Hz) 0.12 -0.01 Amplitude Accuracy (dB) 0.49 -0.49 Conducted Power (dB) 0.41 -0.41 Radiated Power via Substitution (dB) 0.69 -0.68 Temperature (degrees C) 0.81 -0.81 Humidity (% RH) 2.89 -2.89 Field Strength (dB) 4.00 -4.00 AC Powerline Conducted Emissions (dB) 2.70 -2.70 REV 2013.06.28 FACILITIES Oregon Labs EV01-12 22975 NW Evergreen Pkwy Hillsboro, OR 97124 (503) 844-4066 California Labs OC01-13 41 Tesla Irvine, CA 92618 (949) 861-8918 New York Labs NY01-04 4939 Jordan Rd. Elbridge, NY 13060 (315) 685-0796 Minnesota Labs MN01-08 9349 W Broadway Ave. Brooklyn…
