ADCP-75-348 • Issue 1 • 04/2008 Page 18 © 2008, ADC Telecommunications, Inc. 6.8.1Optical Connections Without WDM System Use the following procedure to connect the optical fibers when there is no WDM installed with the HU: 1. Obtain two patch cords that are of sufficient length to reach from the HU to the fiber distribution panel. 2. Designate one of the patch cords as the forward path link and the other as the reverse path link and attach an identification label or tag next to the connector. 3. Remove the dust caps from the HU SeRF SFP optical ports and from the patch cord connectors that will be connected to the SeRF SFP optical ports. 4. Clean each patch cord connector following the patch cord supplier’s recommendations. 5. Insert each patch cord connector into the appropriate optical port as shown in Figure 13 and as specified by the following: PORT 1 FWD - Forward path patch cord PORT 1 REV - Reverse path patch cord 6. Route the patch cords from the HU to the fiber distribution panel. 7. At the fiber distribution panel, identify the OSP cable optical fiber terminations that correspond to the forward and reverse paths. 8. Remove the dust caps from the OSP cable optical fiber adapters and from the patch cord connectors. 9. Clean each patch cord connector (follow patch cord supplier’s recommendations) and then mate the connector with the appropriate OSP cable adapter. Danger: This equipment uses a Class 1 Laser according to FDA/CDRH rules. Laser radiation can seriously damage the retina of the eye. Do not look into the ends of any optical fiber. Do not look directly into the optical transmitter of any unit or exposure to laser radiation may result. An optical power meter should be used to verify active fibers. A protective cap or hood MUST be immediately placed over any radiating transmitter or optical fiber connector to avoid the potential of dangerous amounts of radiation exposure. This practice also prevents dirt particles from entering the connector. Note: To protect the optical receivers, insert a 15 dB attenuator in each optical path. When the system is turned-up and tested, the attenuator may be resized or removed. Caution: Improper handling can damage fiber optic cables. Do not bend fiber optic cable more sharply than the minimum recommended bend radius specified by the cable manufacturer. Do not apply more pulling force to the cable than specified. Note: The HU optical adapters are angled to the left. Therefore, always route patch cords to the HU from the left side of the rack. Routing patch cords to the HU from the right may exceed the bend radius limitations for the optical fiber. ADCP-75-348 • Issue 1 • 04/2008 Page 19 © 2008, ADC Telecommunications, Inc. Figure 13. Fiber Optic Cable Connections To Host Unit 10. Repeat this procedure for the remaining SeRF SFPs in the HU. 11. Store any excess patch cord slack at the fiber distribution panel or storage panel. 6.8.2Optical Connections For Systems With a WDM Use the following procedure to connect the optical fibers when a WDM module is installed with the HU: 1. Obtain a patch cord that is of sufficient length to reach from the WDM module to the fiber distribution panel. 2. Remove the dust cap from WDM Port or Port 4 on the WDM module and from the patch cord connector that will be connected to the WDM module. Note: WDM module ports are labeled FWD, REV, TEST, and WDM. 22410 -A PORT 8 FWD (FORWARD PATH) PORT 8 REV (REVERSE PATH) ADCP-75-348 • Issue 1 • 04/2008 Page 20 © 2008, ADC Telecommunications, Inc. Figure 14. Fiber Optic Connections To WDM Module 3. Clean the patch cord connector (follow patch cord supplier’s recommendations). 4. Insert the connector into the WDM module optical WDM port (port 4). 5. Route the patch cord from the WDM to the fiber distribution panel or storage panel. 6. Identify the OSP cable optical fiber termination that corresponds to the RU. 7. Remove the dust cap from the OSP cable optical adapter and from the patch cord connector. 8. Clean the patch cord connector (follow patch cord supplier’s recommendations) and then mate the connector with the appropriate OSP cable adapter. 9. Store any excess patch cord slack at the fiber distribution panel. 10. Obtain two patch cords that are of sufficient length to reach from the WDM module to the HU. 11. Designate one of the patch cords as the forward path link and the other as the reverse path link and attach an identification label or tag next to the connector. 12. Remove the dust caps from the HU SeRF SFP optical ports and from the patch cord connectors that will be connected to the SeRF SFP optical ports. 13. Clean each pigtail connector (follow the procedures provided with the WDM module) and then insert the connector into the appropriate optical port on the HU as shown in Figure 13 and as diagramed in Figure 14. Note: To protect the optical receivers, insert a 15 dB attenuator in each optical path. When the system is turned-up and tested, the attenuator may be resized or removed. FIBER DISTRIBUTION PANEL (FDP) X X HOST UNIT 1 PORT 8 FWD PORT 8 REV REVERSE PAT H FORWARD PAT H WAVELENGTH DIVISION MULTIPLEXERS 1234 PORT 1 FWD PORT 1 REV HOST UNIT 2 REVERSE PAT H FORWARD PAT H 22416-A TO/FROM REMOTE UNIT 1 TO/FROM REMOTE UNIT 1 HOST UNIT 1 (BI-DIRECTIONAL FIBER LINK WITH REMOTE UNIT) HOST UNIT 1 (BI-DIRECTIONAL FIBER LINK WITH REMOTE UNIT) PORT 1 FWD PORT 1 REV REVERSE PAT H FORWARD PAT H 1234 TESTTEST 1234 TEST FIBER DISTRIBUTION PANEL (FDP) X TO/FROM REMOTE UNIT 2 HOST UNIT 2 (BI-DIRECTIONAL FIBER LINK WITH REMOTE UNIT) ADCP-75-348 • Issue 1 • 04/2008 Page 21 © 2008, ADC Telecommunications, Inc. 6.9EXT REF Connections EXT REF connections between multiple HU’s is supported through two QMA type female connectors mounted on the System card. One of the jacks is designated as the IN port and the other jack is designated as the OUT port. The EXT REF interface allows HU’s to be connected together (in daisy-chain fashion) and clocked through a single source. Use the…
