GCD-2628SATXRemote Control

Rosslare Enterprises Ltd. Copyright Rosslare Enterprises Ltd 1999-2002 Product Documentation Compatibility: The SA-26,27,28 F and FP Wireless 1,2 & 4-Button Remote Controls are compatible with a variety of Rosslare's RF receivers and panels, available in 418.00 MHz. For a list of these products and other information please contact your nearest Rosslare representative. Page 1 of 1 5501-0010054-00 MAIN FEATURES: A) Fully compatible with a selection of panels, universal receivers, and RF accessories such as repeaters. B) Excellent RF performance. C) The SA-28 is designed to be attached to the belt using the belt clip attachment, or mounted on a hook with the wall mount attachment. D) Small and smooth enough to fit into your pocket or purse comfortably. E) Microprocessor and SMT Designed electronics for higher quality, and superior performance. F) LED indicator visually confirms a good transmission signal. G) Two cells AAA sized replaceable batteries (Model AAA Standard Alkaline Battery) with a long life. H) Over 16 million random RF ID Codes. Multiple SA-26,27 28 units can be programmed to work with a single panel. GENERAL SPECIFICATIONS Battery:Two 1.5 Volt Alkaline Standard Battery Model AAA. Rosslare recommends to use the following brands: Energizer, Duracell, Panasonic, Varta SA-26 F&FP: 1 Button (1 Channel) PANIC or ID SA-27 F&FP: 2 Button (2 Channel) ARM / DISARM or ID SA-28 F&FP: 4 Button (4 Channel) ARM / DISARM / PARTIAL ARM / PANIC or ID Operating Temp: -10 o C to +50 o C (14 o F to + 122 o F) Operating Humidity: Up to 95% Non- Condensing (max.) RF Frequency:418.00 MHz Installation:Indoor Use Only (Not Water Proof) Supervisor: The SA-26,27 & 28 F and FP Remote control transmitters are not supervised. Tamper:There is no case tamper on the SA-26,27,and 28. Current:Standby: 0 A Transmit: 16 mA Size:104mm x 40mm x 15mm (4.09" x 1.57 " x 0.59 ") Weight: 28 grams Including battery. GENERAL DESCRIPTION: Rosslare has designed the SA-26,27,28 F and FP series to be compliant with the USA standards UL and FCC. The SA-26,27 and 28 are wireless remote controls that have 1,2 and 4 buttons respectively, the F series are designed to function in 418.00 MHz with Rosslare’s Popular receivers and controls. (For a full list of available controls please contact your nearest distributor). The FP series are designed to function with the AY-L24 D Wireless to Weigand Receiver. The SA-26,27,28 F and FP are slim, portable, and except for the number of buttons, all three models have the same smooth surface mechanical enclosure which comes with a belt-clip and a wall mounting attachment. SA-26,27,28 use state of the art microprocessor design, internal antenna design, and integrated RF with ASK RF technology, designed and manufactured under ISO9001 standards. Each model is factory encoded with Individual ID codes, ensuring that multiple units can be used to provide a reliable remote control solution in a single installation. Model : SA-26 Model : SA-27 Model : SA-28 www.rosslare.com.hk FCC NOTE:Transmitter FCC ID : GCD-2628SATX This equipment has been tested and found to comply with the limits for a Class B digital device, pursuant to part 15 of the FCC Rules. These limits are designed to provide reasonable protection against harmful interference in a residential installation. This equipment generates, uses and can radiate radio frequency energy and, if not installed and used in accordance with the instructions, may cause harmful interference to radio communications. However, there is no guarantee that interference will not occur in a particular installation. If this equipment does cause harmful interference to radio or television reception, which can be determined by turning the equipment off and on, the user is encouraged to try to correct the interference by one or more of the following measures: -Reorient or relocate the receiving antenna. -Increase the separation between the equipment and receiver. -Connect the equipment into an outlet on a circuit different from that to which the receiver is connected. -Consult the dealer or an experienced radio/TV technician for help. ! Warning ! Changes or modifications to this equipment not expressly approved by the party responsible for compliance (Rosslare Enterprises Ltd.) could void the user's authority to operate the equipment. OPERATING AND INSTALLING: Installing/Replacing the Batteries: >> On the back of the unit, there is a battery door, which can be opened via the latch. >> For a new unit, simply remove the Plastic Tab Insulator to activate the unit. >> To replace the batteries, when the unit is no longer functioning, replace the two primary cells with the recommended AAA batteries. Enrolling the Remote to the Host Control >> Using the control unit’s interface go to the enrolling menu, select the options for the new remote, and transmit to the control unit to enroll. (See Host Instructions) Operation >> Simply pressing one of the buttons will generate the RF transmission to the control unit. >> Local LED indicator visually confirms a good transmission signal. FCC Notice: Transmitter FCC ID : GCD-2628SATX This device complies with Part 15 of the FCC Rules. Operation is subject to the following two conditions: (1) This device may not cause harmful interference (2) This device must accept any interference received including any interference that may cause undersired operation

S7 R R BAT - MICRO CONTROLLER R R X-TAL (4MHz) MELEXIS TH71071 TX-EN S3 MOD ANT R R Oleg Perlin / Last change by Alex Chaplik00 SA26/27/28 G (433.92 MHz) V1 A3 11 Monday, December 09, 2002 7 Buttons Remote Controle Project Name SizeDesign by:Rev Date: Sheet of Rosslare Israel Ltd. 418MHz 7 SWITCHES USED OPTIONALLY S4 SI X-TAL 13.56MHz S5 BOOSTER SWITCH VCC = 3.0 v S6 BAT + S2 BLOCK DIAGRAM SA26/27/28

Rosslare Enterprises Ltd. Page 1 of 1 Rosslare Enterprises Ltd. 905-912 Wing Fat Industrial Bldg., 12 Wang Tai Road, Kowloon Bay, Hong Kong. Tel: (852) 27955630, Fax: (852) 27951508 Tel: 852 2795 5630 Ext. 303 Email address: [email protected] February 24, 2003 American TCB 6731 Whittier Ave Suite C110 McLean, VA 22101 USA Subject: Request for confidentiality for a wireless remote controls, model numbers SA26F, SA26FP, SA27F, SA27FP, SA28F, SA28FP, FCC ID:GCD-2628SATX Dear Gentlemen, We apply to you with request to withhold Rosslare Enterprises Ltd. trade secrets in Application for Certification for FCC ID:GCD-2628SATX. These trade secrets can be found in the transmitter schematic diagram, Schematic_diagram_15316 (1 page of this Application) and operational description, Description_15316 (4 pages of this Application). Many thanks in advance. Sincerely yours, / Mrs. Zipora Ozer, Director

American Telecommunications Certification Body Inc. 6731 Whittier Ave, McLean, VA 22101 February 27, 2003 RE: Rosslare Enterprises Ltd. FCC ID: GCD-2628SATX I have a few comments on the above referenced Application. 1) Two different Confidentiality request letters appear to be provided. One asks for the test report to be held confidential. Please note that only technical proprietary information may be held confidential. Test reports may not be held confidential. The second one references schematics and operational description only. Please explain. 2) The spurious emission for 1672 MHz falls in a restricted band. Therefore the limit for this emissions must follow 15.205. Also, it appears that the limits of 15.205 were applied to 2090 MHz. Please note that this emissions does not fall in a restricted band and the limit of 15.231 may apply. Please correct this information given on page 9 and 21 of the test report. Timothy R. Johnson Examining Engineer mailto: [email protected] The items indicated above must be submitted before processing can continue on the above referenced application. Failure to provide the requested information may result in application termination. Correspondence should be considered part of the permanent submission and may be viewed from the Internet after a Grant of Equipment Authorization is issued. Please do not respond to this correspondence using the email reply button. In order for your response to be processed expeditiously, you must submit your documents through the AmericanTCB.com website. Also, please note that partial responses increase processing time and should not be submitted. Any questions about the content of this correspondence should be directed to the sender.

HERMON LABORATORIES March 5, 2003 American TCB 6731 Whittier Ave Suite C110 McLean, VA 22101 Attn: Mr. T. Johnson, Examining Engineer RE: your e-mail dated February 27, 2003; Rosslare Enterprises Ltd. FCC ID: GCD-2628SATX Dear Mr. Johnson, Please find below the answers to your questions. 1. Please cancel Letter_confidentiality.doc, dated December 24, 2002, which contains a request for the test report to be held confidential. We apologize for any inconvenience caused by this matter. We confirm that only request for confidentiality of schematics and operational description is in force. 2. Sorry for my mistake. The revised test report with corrected pages 9 and 21, ROSRAD_FCC.15316_ATCB_rev1, was uploaded on March 5, 2003. Many thanks for your assistance. Sincerely, Marina Cherniavsky, Certification engineer Hermon Laboratories

FCC ID:GCD-2628SATX Date: February 2003 Page 1 of 3 EXTERNAL PHOTOGRAPHS This document contains 2 photographs FCC ID:GCD-2628SATX Date: February 2003 Page 2 of 3 Photograph No.1 Remote control transmitter general view, model SA27F/FP FCC ID:GCD-2628SATX Date: February 2003 Page 3 of 3 Photograph No.2 Remote control transmitter rear view

FCC ID:GCD-2628SATX Date: February, 2003 Page 1 of 2 LABEL The FCC identifier FCC ID:GCD-2628SATX is affixed to the unit rear side, as shown in external view photograph. The FCC statement according to section 15.19 (a)(3) is placed in the instruction manual, supplied to the user. FCC ID:GCD-2628SATX Date: February, 2003 Page 2 of 2 Exhibit – Label location Remote control transmitter with the label view

FCC ID:GCD-2628SATX Date: February 2003 Page 1 of 4 INTERNAL PHOTOGRAPHS This document contains 3 photographs FCC ID:GCD-2628SATX Date: February 2003 Page 2 of 4 Photograph No.1 Remote control transmitter internal view without batteries FCC ID:GCD-2628SATX Date: February 2003 Page 3 of 4 Photograph No.2 Remote control transmitter PCB view FCC ID:GCD-2628SATX Date: February 2003 Page 4 of 4 Photograph No.3 Remote control transmitter internal view with antenna PCB second side

This report is in conformity with ISO/IEC 17025. The A2LA logo endorsement applies only to the test methods and the standards that are listed in the scope of Hermon Laboratories accreditation. The test results relate only to the items tested. This test report must not be reproduced in any form except in full with the approval of Hermon Laboratories Ltd. Page 1 of 28 Document ID: ROSRAD_FCC.15316_ATCB_rev1.doc Date of issue: November 02 HERMON LABORATORIES Electrical Hermon Laboratories Ltd. P.O.Box 23 Binyamina 30550, Israel Tel.+972 4628 8001 Fax.+972 4628 8277 e-mail: [email protected] RADIO TEST REPORT According to 47 CFR Part 15 subpart C §15.231 and subpart B for Rosslare Israel Ltd. EQUIPMENT UNDER TEST: Remote control transmitter Models SA26F/FP, SA27F/FP, SA28F/FP Page 2 of 28 Document ID: ROSRAD_FCC.15316_ATCB_rev1.doc Date of Issue: November 02 HERMON LABORATORIES Contents Contents.....................................................................................................................................................2 1 Project information..............................................................................................................................3 2 Summary of tests and requirements....................................................................................................4 3 EUT description...................................................................................................................................6 3.1 GENERAL........................................................................................................................................6 3.2 TRANSMITTER DESCRIPTION...............................................................................................................6 4 Test results..........................................................................................................................................7 4.1 BANDWIDTH OF EMISSION ACCORDING TO § 15.231 (C)...........................................................................7 4.2 FIELD STRENGTH OF FUNDAMENTAL, § 15.231(B)(2)..............................................................................8 4.3 FIELD STRENGTH OF SPURIOUS RADIATION, § 15.231(B)(3).....................................................................9 4.4 UNINTENTIONAL RADIATED EMISSIONS TEST ACCORDING TO §15.109......................................................10 Appendix A - Plots...................................................................................................................................11 Appendix B - Test equipment used for tests............................................................................................24 Appendix C – Antenna factors and cable loss..........................................................................................25 Appendix C - General information............................................................................................................28 TEST FACILITY DESCRIPTION.......................................................................................................................28 ABBREVIATIONS AND ACRONYMS.................................................................................................................28 SPECIFICATION REFERENCES......................................................................................................................28 Page 3 of 28 Document ID: ROSRAD_FCC.15316_ATCB_rev1.doc Date of Issue: November 02 HERMON LABORATORIES 1 Project information Description of equipment under test Test items : Remote control transmitter Manufacturer : Rosslare Israel Ltd. Types (Models) : SA26F/FP, SA27F/FP, SA28F/FP Equipment FCC code : DSR Applicant information Applicant’s responsible person : Mr. Israel Schneiderman, R&D, RF Design Manager Company : Rosslare Israel Ltd. Address : 22, Hamelacha street P.O.Box : 11407 City : Rosh Ha’ayin Postal code : 48091 Country : Israel Telephone number : +972 3 9386989 Telefax number : +972 3 9386830 Test performance Project Number: : 15316 Location : Hermon Laboratories Receipt date : October 15, 2002 Test completed : October 15, 2002 Purpose of test Apparatus compliance verification in accordance with emission requirements Test specification(s) 47CFR Part 15, subpart C, §15.231, §15.209, §15.205 and subpart B §15.109 Page 4 of 28 Document ID: ROSRAD_FCC.15316_ATCB_rev1.doc Date of Issue: November 02 HERMON LABORATORIES Hermon Laboratories Ltd. P.O.Box 23 Binyamina 30550, Israel Tel.+972 66288001 Fax.+972 66288277 e-mail: [email protected] 2 Summary of tests and requirements Parameter Subclause C NC NT NA Tested by Date tested Remarks Transmitter characteristics, §15.231 Periodic operation 15.231(a) X Bandwidth of emission 15.231(c) X Mr. M. Feldman, test engineer October 15, 2002 Field strength of fundamental 15.231(b), (2) X Mr. M. Feldman, test engineer October 15, 2002 Field strength of spurious radiation 15.231(b)(3) X Mr. M. Feldman, test engineer October 15, 2002 Unintentional radiation, §15.107, §15.109 Conducted emissions 15.107 X Radiated emissions 15.109 X Mr. M. Feldman, test engineer October 15, 2002 General conditions under §15.231, Periodic operation in the band 40.66 - 40.70 MHz and above 70 MHz The intentional radiator does not operate in the restricted bands of operation. 15.205 X The intentional radiator has permanently attached antenna or antenna that uses a unique coupling to the intentional radiator. 15.203 X Integral antenna No antenna other than that furnished by the responsible party can be used with the device. 15.203 X The intentional radiator has no standard antenna jack or electrical connector. 15.203 X The intentional radiator must be professionally installed. 15.203 X The intentional radiator operates at 418.00 MHz. 15.231 (a) X Intentional radiator is restricted to the transmission of a control signal such as those used with alarm systems, door openers, remote switches, etc.…

Text truncated - open the document above for the full version.

This report is in conformity with ISO/IEC 17025. The A2LA logo endorsement applies only to the test methods and the standards that are listed in the scope of Hermon Laboratories accreditation. The test results relate only to the items tested. This test report must not be reproduced in any form except in full with the approval of Hermon Laboratories Ltd. Page 1 of 47 Document ID: ROSRAD_FCC.15316_ATCB_rev2.doc Date of issue: December 03 HERMON LABORATORIES Electrical Hermon Laboratories Ltd. P.O.Box 23 Binyamina 30550, Israel Tel.+972 4628 8001 Fax.+972 4628 8277 e-mail: [email protected] RADIO TEST REPORT According to 47 CFR Part 15 subpart C §15.231 and subpart B for Rosslare Israel Ltd. EQUIPMENT UNDER TEST: Remote control transmitter Models SA26F/FP, SA27F/FP, SA28F/FP Page 2 of 47 Document ID: ROSRAD_FCC.15316_ATCB_rev2.doc Date of Issue: December 03 HERMON LABORATORIES Contents Contents.............................................................................................................................................................................................................................................................2 1 Project information............................................................................................................................................................................................................................3 2 Summary of tests and requirements.........................................................................................................................................................................................4 3 EUT description...................................................................................................................................................................................................................................6 3.1 GENERAL............................................................................................................................................................................6 3.2 TRANSMITTER DESCRIPTION.................................................................................................................................................6 4 Test results............................................................................................................................................................................................................................................7 4.1 BANDWIDTH OF EMISSION ACCORDING TO § 15.231 (C)........................................................................................................7 4.2 FIELD STRENGTH OF FUNDAMENTAL, § 15.231(B)(2)............................................................................................................8 4.3 FIELD STRENGTH OF SPURIOUS RADIATION, § 15.231(B)(3)..................................................................................................9 4.4 UNINTENTIONAL RADIATED EMISSIONS TEST ACCORDING TO §15.109..................................................................................11 Appendix A - Plots.......................................................................................................................................................................................................................................12 Appendix B - Test equipment used for tests..................................................................................................................................................................................35 Appendix C – Antenna factors and cable loss..............................................................................................................................................................................36 Appendix D - General information.......................................................................................................................................................................................................47 TEST FACILITY DESCRIPTION...........................................................................................................................................................47 ABBREVIATIONS AND ACRONYMS.....................................................................................................................................................47 SPECIFICATION REFERENCES..........................................................................................................................................................47 Page 3 of 47 Document ID: ROSRAD_FCC.15316_ATCB_rev2.doc Date of Issue: December 03 HERMON LABORATORIES 1 Project information Description of equipment under test Test items : Remote control transmitter Manufacturer : Rosslare Israel Ltd. Types (Models) : SA26F/FP, SA27F/FP, SA28F/FP Equipment FCC code : DSR Applicant information Applicant’s responsible person : Mr. Israel Schneiderman, R&D, RF Design Manager Company : Rosslare Israel Ltd. Address : 22, Hamelacha street P.O.Box : 11407 City : Rosh Ha’ayin Postal code : 48091 Country : Israel Telephone number : +972 3 9386989 Telefax number : +972 3 9386830 Test performance Project Number: : 15316 Location : Hermon Laboratories Test performed : October 15, 2002; December 23, 24, 2003 Purpose of test Apparatus compliance verification in accordance with emission requirements Test specification(s) 47CFR Part 15, subpart C, §15.231, §15.209, §15.205 and subpart B §15.109 Page 4 of 47 Document ID: ROSRAD_FCC.15316_ATCB_rev2.doc Date of Issue: December 03 HERMON LABORATORIES Hermon Laboratories Ltd. P.O.Box 23 Binyamina 30550, Israel Tel.+972 66288001 Fax.+972 66288277 e-mail: [email protected] 2 Summary of tests and requirements Parameter Subclause C NC NT NA Tested by Date tested Remarks Transmitter characteristics, §15.231 Periodic operation 15.231(a) X Bandwidth of emission 15.231(c) X Mr. M. Feldman, test engineer October 15, 2002 Field strength of fundam…

Text truncated - open the document above for the full version.

FCC ID:GCD-2628SATX Date: February 2003 Page 1 of 6 SETUP PHOTOGRAPHS This document contains 5 photographs FCC ID:GCD-2628SATX Date: February 2003 Page 2 of 6 Photograph No.1 Radiated emissions measurement setup FCC ID:GCD-2628SATX Date: February 2003 Page 3 of 6 Photograph No.2 Radiated emissions measurement setup FCC ID:GCD-2628SATX Date: February 2003 Page 4 of 6 Photograph No.3 Radiated emissions measurement setup FCC ID:GCD-2628SATX Date: February 2003 Page 5 of 6 Photograph No.4 Radiated emissions measurement setup FCC ID:GCD-2628SATX Date: February 2003 Page 6 of 6 Photograph No.5 Radiated emissions measurement setup

FCC ID:GCD-2628SATX Date: December 2003 Setup_photos_15316_retest.doc Page 1 of 5 SETUP PHOTOGRAPHS This document contains 4 photographs FCC ID:GCD-2628SATX Date: December 2003 Setup_photos_15316_retest.doc Page 2 of 5 Photograph No.1 Radiated emissions measurement setup in the anechoic chamber with loop antenna FCC ID:GCD-2628SATX Date: December 2003 Setup_photos_15316_retest.doc Page 3 of 5 Photograph No.2 Radiated emissions measurement setup in the anechoic chamber with biconilog antenna FCC ID:GCD-2628SATX Date: December 2003 Setup_photos_15316_retest.doc Page 4 of 5 Photograph No.3 Radiated emissions measurement setup in the anechoic chamber with double ridged guide antenna FCC ID:GCD-2628SATX Date: December 2003 Setup_photos_15316_retest.doc Page 5 of 5 Photograph No.4 EUT configuration
