MatrixBus™ XR-16A Installation Instructions AuraSys™ L-4/6 Wireless Zone Expansion 1 0706-0960344+01 1. Introduction This wireless expansion transforms the AuraSys Lite system from a limited hardwired system into a wireless system. The expansion is a two way RF communicator which allows connection to wireless sensors, sirens, keypads, repeaters and remote controls. With up to 4/6 zones depending on the hosting panel having the same characteristics as the on board zones. The stand alone expansion option is housed in a plastic casing installed outside of the system's case considering RF environment and wireless devices deployment. 2. Technical Specifications 2.1. Electrical Characteristics Auxiliary Voltage: 13.4 – 13.8 VDC from hosting panel Maximum Input Current: 55-75 mA Indication: 2.2. Environmental Characteristics Red LED Operating Environment: indoor use Operating Temperature: -10°C to 50°C (14°F to 122°F) Operating Humidity: 0 to 95% (Non-Condensing) RFI Protection: 2.3. Physical Characteristics (with case) >20 V/m up to 1000 MHz. Dimensions (HxWxD): 101 x 99 x 35 mm (4 x 3.9 x1.4 in) Weight: 2.4. Available models: 143 g (0.316 lbs) XR-16AH – 868.35 MHz XR-16AG – 433.92 MHz 3. Installation 3.1. General The XR-16A is designed for easy installation. Only a few steps are required to install the keypad. Changes or modifications to this equipment not expressly approved by Rosslare security as the party responsible for compliance could void the user’s authority to operate the equipment. 3.2. Mounting the XR-16A expansion Perform the following steps to mount the expansion: 1) Remove the four screws holding the front cover. Set the screws aside. 2) Disassemble the PCB assembly from the back plate, remove the four screws holding the PCB, set them aside. 3) Locate the back plate at the desired installation location. The wireless expansion should be installed at a secured location considering RF environment and wireless devices deployment. 4) Use the back cover itself as a template for the wall screws. 5) Drill holes in the wall and insert anchors. Hardware is provided. 6) Route a four-wire cable from the panel to the wireless expansion location. 7) Pass the 4-wire cable via one of the channels designed in the back plate. Use pliers to remove the section covering the channel. 8) Mount and fasten the back plate using the screws provided. Make sure to level the plate. 9) Make wiring connections, to the PCB assembly and mount on the back plate. 10) Secure with the screws, set aside previously. 3.3. Wiring Refer to the wiring diagram below. NOTE: Wiring must be done when the AuraSys™ L-4/6 panel power is turned off. 4. Configuration 4.1. LEDs The module LED flashes red until the panel finishes initialization of Wireless module. After initialization, the wireless module turns the LED on continuously. During normal operation, when the module is in programming mode, or any time the module is LOCKED, the LED flashes red. 4.2. Tamper The stand alone expansion option cover and back tamper switches prevent vandalism and unauthorized PCB access. The module continuously checks the Tampers status when JP5 is disconnected. The JP5 jumper is the Tamper jumper. When using the expansion on the board inside the metal casing the tampers must be shorted in order to prevent false alarms. When operating as a stand alone module, jumper JP5 must be open (no jumper). MatrixBUS XR-16A 2 0706-0960344+01 5. Limited Warranty ROSSLARE ENTERPRISES LIMITED S (Rosslare) TWO YEAR LIMITED WARRANTY is applicable worldwide. This warranty supersedes any other warranty. Rosslare's TWO YEAR LIMITED WARRANTY is subject to the following conditions: Warranty of Rosslare's products extends to the original purchaser (Customer) of the Rosslare product and is not transferable. Warranty ROSSLARE ENTERPRISES LTD. AND / ORSUBSIDIARIES (ROSSLARE) warrants that the MatrixBus XR-16A wireless zone expansion, to be free from defects in materials and assembly in the course of normal use and service. The warranty period commences with the date of shipment to the original purchaser and extends for a period of 2 years (24 Months). Products Covered By This Warranty and Duration In the event of a breach of warranty, ROSSLARE will credit Customer with the price of the Product paid by Customer, provided that the warranty claim is delivered to ROSSLARE by the Customer during the warranty period in accordance with the terms of this warranty. Unless otherwise requested by ROSSLARE ENTERPRISES LTD. AND / OR SUBSIDIARIES representative, return of the failed product(s) is not immediately required. Warranty Remedy Coverage If ROSSLARE has not contacted the Customer within a sixty (60) day holding period following the delivery of the warranty claim, Customer will not be required to return the failed product(s). All returned Product(s), as may be requested at ROSSLARE ENTERPRISES LTD. AND /OR SUBSIDIARY’S sole discretion, shall become the property of ROSSLARE ENTERPRISES LTD. AND /OR SUBSIDIARIES. To exercise the warranty, the user must contact Rosslare Enterprises Ltd. to obtain an RMA number after which, the product must be returned to the Manufacturer freight prepaid and insured In the event ROSSLARE chooses to perform a product evaluation within the sixty (60) day holding period and no defect is found, a minimum US$ 50.00 or equivalent charge will be applied to each Product for labor required in the evaluation. Rosslare will repair or replace, at its discretion, any product that under normal conditions of use and service proves to be defective in material or workmanship. No charge will be applied for labor or parts with respect to defects covered by this warranty, provided that the work is done by Rosslare or a Rosslare authorized service center. ROSSLARE shall not be responsible or liable for any damage or loss resulting from the operation or performance of any Product or any systems in which a Product is incorporated. This warranty shall not extend to any a…

Text truncated - open the document above for the full version.

RF_160, Issue 02 Declaration of Authorization We Name: Rosslare Enterprises Ltd. Address: Flat 12, 9 Floor, Wing Fat Ind. Bldg., 12 Wang Tai Road City: Kowloon Bay, Kowloon Country: Hong Kong ............................................................................ Declare that: Name Representative of agent: ............. (1) Agent Company name: Hermon Laboratories Ltd. Address: Harakevet Industrial Zone City: Binyamina 30500 Country Israel is authorized to apply for Certification of the following product(s): Product description: ... Wireless expantion ....... Type designation: ...XR-16AG ................... Trademark: ...Rosslare........................................ on our behalf. Date: April 28, 2011 Name: Joe LeKostaj .......................... (2) Function: Engineering Manager Signature: ............................... Notes: (1): Required for FCC application (2): For FCC it must be the Grantee Code “owner” or the authorized agent.

FCC, Request for non-disclosure Date: 16-Jul-10 RF_501, Issue 6 Page 1 of 1 Company Name: Rosslare Enterprises Ltd. Address: Flat 12, 9 Floor, Wing Fat Ind. Bldg., 12 Wang Tai Road City: Kowloon Bay, Kowloon Country: Hong Kong To: Telefication B.V., Dept. FCC TCB Edisonstraat 12A 6902 PK ZEVENAAR The Netherlands Subject: Request for confidentiality FCC ID: GCD-XR-16AG Reference number: ###### Dear FCC TCB, 1. Long-Term Confidentiality Pursuant to 47 CFR Section 0.459(a) & (b), we hereby requests non-disclosure and confidential treatment of the following materials submitted in support of FCC certification application: Bill(s) of Material Block Diagrams Operational Description Schematic Diagrams Tune-up Procedure Above materials contain secrets, proprietary and technical information, which would customarily be guarded from competitors under 47 CFR, section 0.457(d)(2). Disclosure or publication or any portion of this company confidential material to other parties could cause substantial competitive harm and provide unjustified benefits for competitors. 2. Short-Term Confidentiality (STC) Pursuant to Public Notice DA 04-1705 of the Commission’s policy, in order to comply with the marketing regulations in 47 CFR §2.803 and the importation rules in 47 CFR §2.1204, applicant hereby requests Short-Term Confidential treatment of the following materials (note 1): Internal Photos User’s Manual Test Set-up Photos External Photos Justification: Planned Release Date STC: (notes 2, 3, 4, 5) Date: April 28, 2011 Name and signature of applicant: Mr. Joe LeKostaj Notes: 1) A document or type of document can only have ONE type of confidentiality! 2) Short-Term confidentiality is in principle for 45 days from date of grant; it can be extended max 3 times (total time 180 days max.)! 3) FCC must be informed when marketing begins earlier. 4) Release takes place automatically thus extension must be requested in time. Telefication does not remind you of this! 5) Request for extension or for release must be received by Telefication at least 7 days before date of actual marketing or before expiration of the STC period

Rosslare Enterprises Ltd. FCC ID:GCD-XR-16AG Page 1 of 3 EXTERNAL PHOTOGRAPHS This document contains 2 photographs Rosslare Enterprises Ltd. FCC ID:GCD-XR-16AG Page 2 of 3 Photograph No.1 XR-16AG wireless expansion front view Rosslare Enterprises Ltd. FCC ID:GCD-XR-16AG Page 3 of 3 Photograph No.2 XR-16AG wireless expansion rear side view
