K4866 4/00 -1- OmniProx™ Reader Model Series OP-10/20/30/40 Installation Instructions WHAT IS THE ADEMCO OmniProx™ READER? The OmniProx Reader is an RFID proximity card reader to be installed for use with access control systems. These Installation Instructions contain the following information: • Mounting Instructions • Connecting the Reader to the Host • Testing and Operation of the Reader Visit www.omniprox.com for the latest information and technical support. HOW TO MOUNT THE READER To mount the Reader, perform the following: 1. Determine an appropriate mounting position for the Reader. 2. Peel off the back of the self-stick mounting label template included with the unit and place at the desired mounting position. (Additional templates can be downloaded from www.omniprox.com.) 3. Using the template as a guide, drill two holes (hole size is indicated on mounting template) for mounting the Reader to the surface. 4. Drill a 7/16” (10mm) hole for the cable. If mounting on metal, place a grommet or electrical tape around the edge of the hole. 5. Route the interface cable from the Reader and/or power supply to the host. A linear type power supply is recommended. NOTE: The OmniProx Reader can also be mounted using strong epoxy glue. After application, the Reader should be firmly held in place until the glue dries. Check all electrical codes for proper installation. Mount the Reader with the appropriate screws (not supplied) as indicated on the template. HOW TO CONNECT THE READER TO THE HOST The OmniProx Reader is supplied with an 18-inch pigtail, having a 6-conductor cable. To connect the Reader to the Host, perform the following steps: 1. Prepare the Reader cable by cutting the cable jacket back 1¼ inches and strip the wires ½ inch. 2. Prepare the Host cable by cutting the cable jacket back 1¼ inches and strip the wires ½ inch. 3. Splice the Reader pigtail wires to the corresponding Host wires and cover each connection (see Figure 1). 4. If the tamper output is being utilized, connect the purple wire to the correct input on the host. 5. Trim and cover all conductors that are not used. Figure 1 below shows how you should wire the Reader to the Host. Cable Notes: 1. The individual wires coming out of the reader are color coded according to the recommended Wiegand standard. 2. When using a separate power supply for the Reader, this supply and the Host’s power supply must have a common ground. 3. The recommended cable is Alpha 1295C which has five conductors. If the Host is monitoring the Reader’s tamper output, use six conductor Alpha 1296C. Larger wire gauges are acceptable. The wire must be stranded with an overall shield, either foil or braided. 4. The cable shield wire on the Reader should be Figure 1 -2- attached to an Earth ground (best) or signal ground connection at the panel or power supply end of the cable. This configuration is best for shielding the Reader cable from external interference. HOW TO TEST AND OPERATE THE READER The Reader should be tested after wiring it to a power supply and the Host. Do this by performing the following steps: 1. Power up the Reader. The LED and Beeper will activate three times. This indicates that the Reader is working properly. 2. Present the appropriate type of ID card to the Reader. (See Table 1 for the correct card type based on the reader model.) The LED should momentarily flash green and a short beep will be emitted. This indicates that the card was read properly by OmniProx and this LED flash and beep is generated by the Reader. 3. After the card data is processed by the Host, the Host can then turn the LED green or yellow. Refer to the Host description of the LED operation if the Reader LED is controlled by the Host. Table 1: Part Number vs. Feature Matrix Model Number ♦♦ Card Type Output Format Read Range (Max.) * OP10-FWcHIDWiegand3” OP11-AWcADEMCOWiegand3” OP20-FWcHIDWiegand4” OP21-AWcADEMCOWiegand4” OP30-FWcHIDWiegand5” OP31-AWcADEMCOWiegand5” OP40-FWcHIDWiegand4” OP41-AWcADEMCOWiegand4” ♦ Last character of Omniprox P/N indicates color; B = Black, G = Gray, W = White, etc. * Measured using HID Corp. Prox Card II (P/N 1326LSSMV) or equivilent. Range also depends on electrical environment and/or proximity to metal. OmniProx models with HID compatibility are capable of reading genuine HID cards under the terms of a license agreement between HID Corp. and the ADEMCO Group. -3- SPECIFICATIONS Electrical Characteristics: Power Supply Type: Linear type Recommended Operating Voltage Range: 4.75 – 16 VDC Absolute Maximum (non-operating): 18 VDC Current @ 12V: Standby: 25 mA Read: 40 mA Tamper Output Open collector, active low, max.sink current is 30 mA Maximum Cable Distance to Host: 500 ft. (150 meters) Card Read Distance: See Table 1 Regulatory Approvals: USA: UL 294 & FCC Part15 B Europe: CE Listed Operating Temperature Range: -25° F to 145° F (-31°C to 63°C) Operating Humidity: 0 to 95% (non condensing) Dimensions: OP-10/11: 3.15” (80mm) L x 1.58” (40mm) W x 0.50” (12.8mm) D OP-20/21 4.73” (120mm) L x 1.65” (42mm) W x 0.55” (14mm) D OP-30/31 5.71” (145mm) L x 1.69” (43mm) W x 0.79” (20mm) D OP-40/41 4.33” (110mm) L x 2.96” (75mm) W x 0.59” (15mm) D -4- ADEMCO Limited Warranty Alarm Device Manufacturing Company, a Division of Pittway Corporation, and its divisions, subsidiaries and affiliates ("Seller"), 165 Eileen Way, Syosset, New York 11791, warrants OmniProx products to be in conformance with its own plans and specifications and to be free from defects in materials and workmanship under normal use and service for the life of the product. Seller's obligation shall be limited to repairing or replacing, at its option, free of charge for materials or labor, any product which is proved not in compliance with Seller's specifications or proves defective in materials or workmanship under normal use and service. Seller shall have no obligation under this Limited Warranty or otherwise if the product is altered or improperly repaired or serviced by an…
