GMLNSD-1FWPCS Band CDMA Cellular Transceiver

Nokia 5170i User Guide (Phase 1 SW) Keys Menu Power key See p. 8. Navi™ key See p. 8. Scroll keys See p. 9. Emergency 9 key See p. 31. Voice mail key See p. 47. Number keys See p. 13. Retractable antenna See p. 17. Earpiece See p. 18. Screen Current function of Navi™ key C key See p. 9. Case key See p. 13. Para obtener un manual del usuario en español favor de llamar o enviar un fax al teléfono 1-888-NOKIA2U (1-888-665-4228), fax 813-287-6612. Table of Contents 1.Safety At A Glance . . . . . . . . . . . . . . . . . . . . . . .5 2.Getting Connected . . . . . . . . . . . . . . . . . . . . . . .7 Attaching your battery . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .7 Charging your new battery. . . . . . . . . . . . . . . . . . . . . . . . . . .7 Removing the battery . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .9 Important Battery Information. . . . . . . . . . . . . . . . . . . . . . .10 Cool Features. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .11 3.Using Your Phone . . . . . . . . . . . . . . . . . . . . . . .12 What is the ‘start screen’? . . . . . . . . . . . . . . . . . . . . . . . . . .12 Navigating tools . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .12 Scrolling through the main menu . . . . . . . . . . . . . . . . . . . .13 Menu & submenu numbering. . . . . . . . . . . . . . . . . . . . . . . .14 Using Shortcuts. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .14 Help Text . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .14 Summary of Menu Items. . . . . . . . . . . . . . . . . . . . . . . . . . . .15 4.The Basics. . . . . . . . . . . . . . . . . . . . . . . . . . . . .18 Switching the phone on and off. . . . . . . . . . . . . . . . . . . . . .18 Getting a strong signal. . . . . . . . . . . . . . . . . . . . . . . . . . . . .18 Making a call. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .19 Ending a call. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .20 Answering a call . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .20 Keyguard. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .20 5.Your Phone A to Z. . . . . . . . . . . . . . . . . . . . . . .22 ABC/abc mode. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .22 Access codes . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .22 Alarm clock . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .22 All calls timer. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .23 Anykey answer. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .24 Automatic answer. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .24 Automatic redial . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .24 Calculator. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .25 Calendar . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .25 Call forwarding . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .28 Call log . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .29 Call restrictions . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .30 Call settings . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 30 Call timers. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 30 Call waiting . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 31 Caller ID . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 32 Calling card . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 32 Change lock code. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 34 Change security code. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 34 Clear call lists. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 34 Clear timers . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 35 Clock. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 35 Conference call . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 37 Current call timer. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 38 Customize profiles. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 38 Custom Tone. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 38 Data and fax calls . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 39 Dialed calls. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 39 Earpiece volume. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 40 Emergency calls . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 40 Emergency key 9 . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 41 Entering text and numbers . . . . . . . . . . . . . . . . . . . . . . . . . 41 Erase all (text messages). . . . . . . . . . . . . . . . . . . . . . . . . . . 43 Erase options for your phone book. . . . . . . . . . . . . . . . . . . 44 Fax calls . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 44 Games . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 44 Inbox. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 46 In-call menu. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 46 Keyguard. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 46 Keypad tones . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 47 Language. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 47 Last call timer. . . . . . . . . . . . . . . . . . . . . . . . . …

Text truncated - open the document above for the full version.

NOKIA MOBILE PHONES, Inc. 12278 Scripps Summit Drive San Diego, CA 92131 Tel. (858) 831 5000 19 April, 2000 Federal Communications Commission, Authorization & Evaluation Division, 7435 Oakland Mills Road, Columbia, MD 21046 Attention: Equipment Authorization Branch PER:47 CFR 22.919 RE:FCC ID: GMLNSD-1FW The Electronic Serial Number (ESN) for each transceiver is unique. The ESN host component is permanently attached to a main circuit board of the mobile transmitter and the integrity of the unit’s operating software is not alterable. The ESN is isolated from fraudulent contact and tampering. ! The host component does not contain other information, it is not removable and its electrical connections are not accessible. " The host component does contain other information, and the ESN information is encoded using: ! (1) Multiplication or division by a polynomial. " (2) Cyclic coding. " (3) The spreading of ESN bits over various non-sequential memory locations. The ESN is factory set and is not alterable, transferable, removable, or otherwise able to be manipulated. Cellular mobile equipment is designed such that any attempt to remove, tamper with, or change the ESN chip, its logic system, or firmware originally programmed by the manufacturer will render the mobile transmitter inoperative. NOKIA MOBILE PHONES, Inc. Jari Niemelä Product Program Manager, Product Development, San Diego NOKIA MOBILE PHONES, Inc. 12278 Scripps Summit Drive San Diego, CA 92131 Tel. (858) 831 5000 19 April, 2000 Federal Communications Commission, Authorization & Evaluation Division, 7435 Oakland Mills Road, Columbia, MD 21046 Attention: Equipment Authorization Branch We hereby certify that the transceiver FCC ID: GMLNSD-1FW complies with OET Bulletin No. 53 as referenced in Section 22.915 of the Commission’s rules and with ANSI J-STD-008-1996 Personal Station-Base Station Compatibility Requirements for 1.8 to 2.0 GHz Code Division Multiple Access (CDMA) Personal Communications Systems. Compliance was determined by testing appropriate parameters according to standards. Extensive field testing has been performed in several locations in the USA to verify the compatibility against different systems. NOKIA MOBILE PHONES, Inc. Jari Niemelä Product Program Manager, Product Development, San Diego

June 12, 2000 Sincerely yours, Morton Flom, P. Eng.

05JUN 00 FCC ID: GMLNSD-1FW Applicant: Nokia Mobile Phones, Inc.Copyright © 2000 Nokia Mobile Phones, Inc. Type: NSD-1FW MADE IN USA FCC ID: GMLNSD-1FW Model:5170i Code: 0501344 MY ESN DEC: 156/10727654 ESN HEX: FFXXXXXX Type: NSD-1FW MADE IN USA FCC ID: GMLNSD-1FW Model:5170i Code: 0501344 MY ESN DEC: 156/10727654 ESN HEX: FFXXXXXX 05JUN 00 FCC ID: GMLNSD-1FW Applicant: Nokia Mobile Phones, Inc.Copyright © 2000 Nokia Mobile Phones, Inc. Type: NSD-1FW MADE IN USA FCC ID: GMLNSD-1FW Model:5170i Code: 0501344 MY ESN DEC: 156/10727654 ESN HEX: FFXXXXXX NOKIA MOBILE PHONES, Inc. 12278 Scripps Summit Drive San Diego, CA 92131 Tel. (858) 831 5000 19 April, 2000 Federal Communications Commission, Authorization & Evaluation Division, 7435 Oakland Mills Road, Columbia, MD 21046 Attention: Equipment Authorization Branch COMPLIANCE STATEMENT OF NOKIA 5170i, FCC ID: GMLNSD-1FW The compliance statement can be seen in User Guide of NOKIA 5170i because the size of the handportable NOKIA 5170i and its identification label are so small that the compliance statement can not be printed visible enough. NOKIA MOBILE PHONES, Inc. Jari Niemelä Product Program Manager, Product Development, San Diego 6 Accessories and Batteries Use only approved accessories and batteries. Do not connect incompatible products. FCC/Industry Canada Notice Your phone may cause TV or radio interference (e.g. when using a telephone in close proximity to receiving equipment). The FCC/ Industry Canada can require you to stop using your telephone if such interference can not be eliminated. If you require assistance, contact your local service facility. This device complies with part 15 of the FCC rules. Operation is subject to the condition that this device does not cause harmful interference. Using this Guide The wireless phone described in this guide is approved for use in CDMA/AMPS networks. A number of features included in this guide are called Network Services. They are special services provided by wireless service providers. Before you can take advantage of any of these Network Services, you must subscribe to the service(s) from your home service provider and obtain instructions for their use. Disclaimer It’s possible that you may not be able to activate your phone on all wireless systems. Please see your service provider for details.

NOKIA MOBILE PHONES, Inc. 12278 Scripps Summit Drive San Diego, CA 92131 Tel. (858) 831 5000 19 April, 2000 Federal Communications Commission, Authorization & Evaluation Division, 7435 Oakland Mills Road, Columbia, MD 21046 Attention: Equipment Authorization Branch We hereby certify that the transceiver FCC ID:GMLNSD-1FW complies with ANSI/IEEE C95.1-1992 Standard for Safety Levels with Respect to Human Exposure to Radio Frequency Electromagnetic Fields, 3kHz to 300 GHz. Compliance was determined by testing appropriate parameters according to standard. NOKIA MOBILE PHONES, Inc. Jari Niemelä Product Program Manager, Product Development, San Diego

6 FCC/Industry Canada Notice Your phone may cause TV or radio interference (for example, when using a telephone in close proximity to receiving equipment). The FCC or Industry Canada can require you to stop using your telephone if such interference cannot be eliminated. If you require assistance, contact your local service facility. This device complies with part 15 of the FCC rules. Operation is subject to the condition that this device does not cause harmful interference. Using this Guide The wireless phone described in this guide is approved for use in CDMA 1900 networks. Network services A number of features included in this guide are called network services. They are special services provided by wireless service providers. Before you can take advantage of any of these network services, you must subscribe to the service(s) from your home service provider and obtain instructions for their use. Updates The latest version of this Owner’s Manual may be found on Nokia’s World Wide Web site at www.nokia.com.

88 Making an emergency call 1If the phone is not on, switch it on. 2Press and hold for several seconds to ready the phone for calls. 3Key in the emergency number for your present location (e.g. 911 or other official emergency number). Emergency numbers vary by location. 4Press Call If certain features are in use (Keyguard, call restrictions, etc.), you may first need to turn those features off before you can make an emergency call. Consult this document and your local cellular service provider. When making an emergency call, remember to give all the necessary information as accurately as possible. Remember that your wireless phone may be the only means of communication at the scene of an accident - do not cut off the call until given permission to do so. Radio frequency (RF) signals Your wireless handheld portable telephone is a low power radio transmitter and receiver. When it is ON, it receives and also sends out radio frequency (RF) signals. In August, 1996, the Federal Communications Commission (FCC) adopted RF exposure guidelines with safety levels for handheld wireless phones. Those guidelines are consistent with safety standards previously set by both U.S. and international standards bodies: ANSI C95.1 (1992)*, NCRP Report 86 (1986)*, ICNIRP (1996)*. Those standards were based on comprehensive and periodic evaluations of the relevant scientific literature. For example, over 120 scientists, engineers, and physicians from universities, government health agencies and industry reviewed the available body of research to develop the ANSI Standard (C95.1). The design of your phone complies with the FCC guidelines (and those standards). To maintain compliance with FCC RF exposure guidelines, use only Nokia approved accessories. When carrying the phone while it is on, use the specific Nokia belt-clip that has been tested for compliance. *American National Standards Institute, National Council on Radiation Protection and Measurements; International Commission on Non-Ionizing Radiation Protection.

3. Digital mode CDMA (PCS), Right Hand Phantom meas nr: Phone position Frequency MHz / channel Power [dBm] Whip in (1g)[mW/g] 1 90° 1880 / 600 22.5 1.10 FCC ID:GMLNSD-1FW MEASURED: 2000-8- 29 / NMP FCC limit 1.60[mW/g] (ANSI/IEEE) 4. Digital mode CDMA (PCS) meas nr: Phone position Frequency MHz / channel Power [dBm] Whip in (1g)[mW/g] 2 Left side, Cheek/Touching 1880 / 600 22.5 0.87 3 Right side, Cheek/Touching 1880 / 600 22.5 0.78 FCC ID:GMLNSD-1FW MEASURED: 2000-8- 29 / NMP FCC limit 1.60[mW/g] (ANSI/IEEE) 5. Digital mode CDMA (PCS), Left Hand Phantom meas nr: Phone position Frequency MHz / channel Power [dBm] Whip in (1g)[mW/g] 4 90° with battery BLS-4 1880 / 600 22.5 1.29 5 90° with battery BPS-1 1880 / 600 22.5 1.39 6 90° with battery BLS-2N 1880 / 600 22.5 1.44 7 90° with battery BMS-2S 1880 / 600 22.5 1.36 8 90° with battery BMS-2V 1880 / 600 22.5 1.48 FCC ID:GMLNSD-1FW MEASURED: 2000-8- 29 / NMP FCC limit 1.60[mW/g] (ANSI/IEEE) Digital mode CDMA (PCS), Body worn, Whip in meas nr: Phone position Frequency MHz / channel Power [dBm] Whip in (1g)[mW/g] 9 battery BLS-4 1850 / 25 22.5 1.24 10 battery BPS-1 1850 / 25 22.5 1.34 11 battery BLS-2N 1850 / 25 22.5 1.43 12 battery BMS-2S 1850 / 25 22.5 1.33 13 battery BMS-2V 1850 / 25 22.5 1.45 FCC ID:GMLNSD-1FW MEASURED: 2000-8- 29 / NMP FCC limit 1.60[mW/g] (ANSI/IEEE)

Digital mode CDMA (PCS), Body Worn, With Battery BMS-2V meas nr: Phone position Frequency MHz / channel Power [dBm] Whip in (1g)[mW/g] Whip up (1g)[mW/g] 1,2 Against Flat 1850 / 25 22.5 1.43 1.08 3,4 Against Flat 1880 / 600 22.5 1.09 0.88 5,6 Against Flat 1910 / 1175 22.5 0.74 0.87 FCC ID:GMLNSD-1FW MEASURED: 2000-9- 13 / NMP FCC limit 1.60[mW/g] (ANSI/IEEE) 1.60[mW/g] (ANSI/IEEE ) Digital mode CDMA (PCS), Body Worn, With Battery BLS-2N meas nr: Phone position Frequency MHz / channel Power [dBm] Whip in (1g)[mW/g] Whip up (1g)[mW/g] 1,2 Against Flat 1850 / 25 22.5 1.45 1.28 3,4 Against Flat 1880 / 600 22.5 1.00 0.87 5,6 Against Flat 1910 / 1175 22.5 0.81 0.92 FCC ID:GMLNSD-1FW MEASURED: 2000-9- 13 / NMP FCC limit 1.60[mW/g] (ANSI/IEEE) 1.60[mW/g] (ANSI/IEEE )

Digital mode CDMA (PCS), Body Worn, With Battery BMS-2V meas nr: Phone position Frequency MHz / channel Power [dBm] Whip in (1g)[mW/g] Whip up (1g)[mW/g] 1,2 Against Flat 1850 / 25 22.5 1.45 1.08 3,4 Against Flat 1880 / 600 22.5 1.09 0.88 5,6 Against Flat 1910 / 1175 22.5 0.74 0.87 FCC ID:GMLNSD-1FW MEASURED: 2000-9- 13 / NMP FCC limit 1.60[mW/g] (ANSI/IEEE) 1.60[mW/g] (ANSI/IEEE ) Digital mode CDMA (PCS), Body Worn, With Battery BLS-2N meas nr: Phone position Frequency MHz / channel Power [dBm] Whip in (1g)[mW/g] Whip up (1g)[mW/g] 7,8 Against Flat 1850 / 25 22.5 1.43 1.28 9,10 Against Flat 1880 / 600 22.5 1.00 0.87 11,12 Against Flat 1910 / 1175 22.5 0.81 0.92 FCC ID:GMLNSD-1FW MEASURED: 2000-9- 13 / NMP FCC limit 1.60[mW/g] (ANSI/IEEE) 1.60[mW/g] (ANSI/IEEE )

FCC ID: GMLNSD-1FW MFA p0020014, d0060011 Date: June 9, 2000 Federal Communications Commission Via: Electronic Filing Attention: Authorization & Evaluation Division Applicant: Nokia Mobile Phones, Inc. Equipment: 5170i, Type NSD-1FW FCC ID: GMLNSD-1FW FCC Rules: 24, Confidentiality Gentlemen: On behalf of the Applicant, enclosed please find Application Form 731, Engineering Test Report and all pertinent documentation, the whole for approval of the referenced equipment as shown. Filing fees are attached. We trust the same is in order. Should you need any further information, kindly contact the writer who is authorized to act as agent. Sincerely yours, Morton Flom, P. Eng. enclosure(s) cc: Applicant MF/cvr FCC ID: GMLNSD-1FW MFA p0020014, d0060011 LIST OF EXHIBITS (FCCCERTIFICATION(PCS TRANSMITTERS) - REVISED 9/28/98) APPLICANT: Nokia Mobile Phones, Inc. FCC ID: GMLNSD-1FW BY APPLICANT: 1. LETTER OF AUTHORIZATION 2. IDENTIFICATION DRAWINGS, 2.1033(c)(11) ID LABEL LOCATION OF LABEL COMPLIANCE STATEMENT LOCATION OF COMPLIANCE STATEMENT 3. PHOTOGRAPHS, 2.1033(c)(12) 4. CONFIDENTIALITY REQUEST: 0.457 and 0.459 5. DOCUMENTATION: 2.1033(c) (3) USER MANUAL (9) TUNE UP INFO (10) SCHEMATIC DIAGRAM (10) CIRCUIT DESCRIPTION BLOCK DIAGRAM PARTS LIST ACTIVE DEVICES BY M.F.A. INC. A. TESTIMONIAL & STATEMENT OF CERTIFICATION B. STATEMENT OF QUALIFICATIONS FCC ID: GMLNSD-1FW MFA p0020014, d0060011 Sub-part 2.1033(c): EQUIPMENT IDENTIFICATION FCC ID: GMLNSD-1FW NAMEPLATE DRAWING ATTACHED, EXHIBIT 1. LOCATION AS PER LABEL DRAWING(S) DATE OF REPORT June 9, 2000 SUPERVISED BY: Morton Flom, P. Eng. FCC ID: GMLNSD-1FW MFA p0020014, d0060011 THE APPLICANT HAS BEEN CAUTIONED AS TO THE FOLLOWING: 15.21 INFORMATION TO USER. The users manual or instruction manual for an intentional radiator shall caution the user that changes or modifications not expressly approved by the party responsible for compliance could void the user's authority to operate the equipment. 15.27(a) SPECIAL ACCESSORIES. Equipment marketed to a consumer must be capable of complying with the necessary regulations in the configuration in which the equipment is marketed. Where special accessories, such as shielded cables and/or special connectors are required to enable an unintentional or intentional radiator to comply with the emission limits in this part, the equipment must be marketed with, i.e. shipped and sold with, those special accessories. However, in lieu of shipping or packaging the special accessories with the unintentional or intentional radiator, the responsible party may employ other methods of ensuring that the special accessories are provided to the consumer, without additional charge. Information detailing any alternative method used to supply the special accessories for a grant of equipment authorization or retained in the verification records, as appropriate. The party responsible for the equipment, as detailed in § 2.909 of this chapter, shall ensure that these special accessories are provided with the equipment. The instruction manual for such devices shall include appropriate instructions on the first page of text concerned with the installation of the device that these special accessories must be used with the device. It is the responsibility of the user to use the needed special accessories supplied with the equipment. FCC ID: GMLNSD-1FW MFA p0020014, d0060011 TABLE OF CONTENTS RULEDESCRIPTIONPAGE . Test Report 1 2.1033(c) General Information Required 2 2.1033(c)(14) Rule Summary 5 . Standard Test Conditions and Engineering Practices 6 2.1046(a), 24.232(b) . Carrier Output Power (Radiated) 7 2.1049(c), 24, 24.238(b). . Transmitter Conducted Measurements 9 2.1053(a). Transmitter Radiated Measurements 15 2.202(g) Necessary Bandwidth and Emission Bandwidth 18 FCC ID: GMLNSD-1FW MFA p0020014, d0060011 PAGE NO.1of18. Required information per ISO/IEC Guide 25-1990, paragraph 13.2: a) TEST REPORT b) Laboratory: (FCC: 31040/SIT) (Canada: IC 2044) M. Flom Associates, Inc. 3356 N. San Marcos Place, Suite 107 Chandler, AZ 85224 c) Report Number: d0060011 d) Client: Nokia Mobile Phones 12278 Scripps Summit Dr. San Diego, CA 92131 e) Identification: 5170i, Type NSD-1FW FCC ID: GMLNSD-1FW Description: PCS Band CDMA Cellular Transceiver f) EUT Condition: Not required unless specified in individual tests. g) Report Date: June 9, 2000 EUT Received May 17, 2000 h, j, k): As indicated in individual tests. i) Sampling method: No sampling procedure used. l) Uncertainty: In accordance with MFA internal quality manual. m) Supervised by: Morton Flom, P. Eng. n) Results: The results presented in this report relate only to the item tested. o) Reproduction: This report must not be reproduced, except in full, without written permission from this laboratory. FCC ID: GMLNSD-1FW MFA p0020014, d0060011 PAGE NO.2of18. LIST OF GENERAL INFORMATION REQUIRED FOR CERTIFICATION IN ACCORDANCE WITH FCC RULES AND REGULATIONS, VOLUME II, PART 2 AND TO 24, Confidentiality Sub-part 2.1033 (c)(1): NAME AND ADDRESS OF APPLICANT: Nokia Mobile Phones, Inc. 6200 Courtney Campbell Causeway, Suite 900 P.O. Box 30730 Tampa, Florida 33630-3730 MANUFACTURER: Nokia Mobile Phones Manufacturing (USA), Inc. 5650 Alliance Gateway Fort Worth, TX 76178 (c)(2): FCC ID: GMLNSD-1FW MODEL NO: 5170i, Type NSD-1FW (c)(3): INSTRUCTION MANUAL(S): PLEASE SEE ATTACHED EXHIBITS (c)(4): TYPE OF EMISSION: 1M25F9W (c)(5): FREQUENCY RANGE, MHz : 1851.25 to 1908.75 (c)(6): POWER RATING, Watts: 0.006 to 0.16 EIRP Switchable x Variable N/A (c)(7): MAXIMUM POWER RATING, Watts:2 FCC ID: GMLNSD-1FW MFA p0020014, d0060011 PAGE NO.3of18. Subpart 2.1033(continued) (c)(8): VOLTAGES & CURRENTS IN ALL ELEMENTS IN FINAL R. F. STAGE, INCLUDING FINAL TRANSISTOR OR SOLID STATE DEVICE: COLLECTOR CURRENT, A = per manual COLLECTOR VOLTAGE, Vdc = per manual SUPPLY VOLTAGE, Vdc = 3.8 (c)(9): TUNE-UP PROCEDURE: PLEASE SEE ATTACHED EXHIBITS (c)(10): CIRCUIT DIAGRAM/CIRCUIT DESCRIPTION: Including description of circuitry & d…

Text truncated - open the document above for the full version.

FCC ID: GMLNSD-1FW MFA p0020014, d0060011 PAGE NO.7 of 18. AMENDED August 18, 2000 NAME OF TEST: Carrier Output Power (Radiated) SPECIFICATION: 47 CFR 2.1046(a), 24.232(b) GUIDE: As indicated on page 6 TEST EQUIPMENT: As per attached page MEASUREMENT PROCEDURE (RADIATED) 1. The EUT was placed on an open-field site and its radiated field strength at a known distance was measured by means of a spectrum analyzer. Equivalent loading was calculated from the equation P t =((E x R) 2 /30) watts, whereR=3m. 2. Measurement accuracy is ±1.5 dB. MEASUREMENT RESULTS FREQUENCY TUNED, MHz FREQUENCY EMISSION, MHz EIRP, dBm EIRP, Watts 1851.250 1851.380000 23.6 0.229 1880.000 1880.250000 23.6 0.229 1908.750 1908.630000 24.0 0.251 SUPERVISED BY: Morton Flom, P. Eng.

FCC ID: GMLNSD-1FW MFA p0020014, d0060011 PAGE NO.7 of 18. AMENDED September 15, 2000 NAME OF TEST: Carrier Output Power (Radiated) SPECIFICATION: 47 CFR 2.1046(a), 24.232(b) GUIDE: As indicated on page 6 TEST EQUIPMENT: As per attached page MEASUREMENT PROCEDURE (RADIATED) 1. The EUT was placed on an open-field site and its radiated field strength at a known distance was measured by means of a spectrum analyzer. Equivalent loading was calculated from the equation P t =((E x R) 2 /30) watts, whereR=3m. 2. Measurement accuracy is ±1.5 dB. MEASUREMENT RESULTS FREQUENCY EMISSION, MHz dbuv/m C.F. EIRP, dBm EIRP, Watts 1851.38 78.147 40.7 23.6 0.229 1880.25 77.847 41.0 23.6 0.229 1908.63 77.925 41.3 24.0 0.251 SUPERVISED BY: Morton Flom, P. Eng.
