Re: Certification for Code Systems, Inc Transceiver Model/PN(s): 19131628, 19131602 FCC ID: GOH-GMRFAB01 IC: 3954A-RFA1 The device under test is manufactured by the grantee (Code Systems, Inc) and sold as an OEM product. Per 47 CFR 2.909, 2.927, 2.931, 2.1033, 15.15(b) etc..., the grantee must ensure the end-user has all applicable / appropriate operating instructions. When end-user instructions are required, as in the case of this product, the grantee must notify the OEM to notify the end-user. Code Systems, Inc will supply the following information to the reseller/distributor dictating what must be included in the end user’s manual for the commercial product. INFORMATION TO BE INCLUDED IN THE END USER'S MANUAL The following information must be included in the end product user’s manual to ensure continued FCC and Industry Canada regulatory compliance. The ID numbers must be included in the manual if the device label is not readily accessible to the end user. The compliance paragraphs below must be included in the user's manual. ************************************************************************ FCC ID:GOH-GMRFAB01 IC: 3954A-RFA1 This device complies with Part 15 of the FCC Rules and with RSS-210 of Industry Canada. Operation is subject to the following two conditions: (1) This device may not cause harmful interference, and (2) This device must accept any interference received, including interference that may cause undesired operation. WARNING: Changes or modifications not expressively approved by the party responsible for compliance could void the user's authority to operate the equipment. In addition, this device has been designed to operate with the antenna listed below having a maximum gain of 1.5 dB and a minimum cable loss of 1.2 dB. Antennas and cable not included in this list or having a gain greater than 0.3 dB are strictly prohibited for use with this device. The required antenna impedance is 50 ohms. Xuzhou Huaxia Harness Co, PN: GM19131608, Dipole antenna with 8 ft RG174/U coax. To reduce potential radio interference to other users, the antenna type and its gain should be so chosen that the equivalent isotropically radiated power (e.i.r.p.) is not more than that needed for successful communication. ************************************************************************

October 16, 2007 Certification and Engineering Bureau Industry Canada 3701 Carling Avenue, Bldg. 94 Ottawa, Ontario K2H 8S2 Re: Certification for Code Systems, Inc Transceiver Model/PN(s): GM19131628, GM19131602 FCC ID: GOH-GMRFAB01 IC: 3954A-RFA1 Please find enclosed application materials for certification of Code Systems, Inc Transceiver. We tested the device and found it to comply with RSS-GEN/102/210. The product is identified by: IC: 3954A-RFA1 If there are any questions, suggestions, etc., regarding the application or testing performed, please contact me at the above address or call 734-483-4211, fax 734-647- 2106; e-mail: [email protected]. Sincerely, Valdis V. Liepa Research Scientist October 16, 2007 Federal Communications Commission Equipment Approval Services P.O. Box 358315 Pittsburgh, PA 15251-5315 Re: Certification for Code Systems, Inc Transceiver Model/PN(s): GM19131628, GM19131602 FCC ID: GOH-GMRFAB01 IC: 3954A-RFA1 Please find enclosed application materials for certification of Code Systems, Inc Transceiver. We tested it and found it to comply with FCC Part 15. If there are any questions regarding the application or testing performed, please contact me at the above address or call 734-483-4211, fax 734-647-2106, or e-mail [email protected]. Sincerely, Valdis V. Liepa Research Scientist

Re: Certification for Code Systems, Inc Transceiver FCC ID: GOH-GMRFAB01 IC: 3954A-RFA1 REQUEST FOR CONFIDENTIALITY Pursuant to FCC 47 CRF 0.457(d) and 0.459 and IC RSP-100, Section 10, Code Systems, Inc requests that a part of the subject FCC application be held confidential. Type of Confidentiality Requested Exhibit Short Term Permanent (1) ID Label & Location Short Term Permanent (3) External Photos Short Term Permanent (4) Block Diagram Short Term Permanent (5) Schematics Short Term Permanent (7) Test Setup Photos Short Term Permanent (8) User’s Manual Short Term Permanent (DUT is potted) (9) Internal Photos Short Term Permanent (10) Parts List & Placement Short Term Permanent (11) RF Exposure Short Term Permanent (12) Description of Operation Code Systems, Inc has spent substantial effort in developing this product and it is one of the first of its kind in industry. Having the subject information easily available to "competition" would negate the advantage they have achieved by developing this product. Not protecting the details of the design will result in financial hardship. Permanent Confidentiality: Code Systems, Inc requests the exhibits listed above as permanently confidential be permanently withheld from public review. Short-Term Confidentiality: Code Systems, Inc requests the exhibits selected above as short term confidential be withheld from public view for a period of 45 days from the date of the Grant of Equipment Authorization and prior to marketing. If there are any questions regarding this request, please contact me at the above address or call 734-483-4211, fax 734-647-2106 or e-mail [email protected]. Sincerely, Valdis V. Liepa, Research Scientist University of Michigan

October 25, 2007 RE: ATCB005539 FCC ID: GOH‐GMRFAB01 & IC: 3954A‐RFA1 for Code Systems, Inc. The following is in response to the comments made on the above referenced application. 1. Please provide a legible schematic diagram in accordance with Section 2.1033(b)(5) of the FCC Rules. When I enlarge the schematic diagram to read the components and their values, the schematic becomes unreadable. An updated schematic drawing has been uploaded. 2. Please provide IC labels with the two model numbers shown on them. The IC label provided had model number GM19131602 on it not model number 19131602. There was no IC lable with model number 19131628 on it. Labels have now been provided for both models. All associated paperwork has been modified to include “GM” in the part number. 3. Please upload a confidentiality letter for the IC portion of this filing. On September 10, 2007, IC started requiring all exhibits in any filing to be uploaded to their Website. As a result, the applicant or his authorized agent must request confidentiality of exhibits that are considered trade secret. Please see the ATCB IC application form on our Website. It has been updated to include a sample confidentiality letter for IC that you may use. Updated request has been uploaded. 4. For Your Information – The frequency band 225 ‐ 399.9 MHz is allocated for Government of Canada usage. There are different types of operations in different parts of this band of frequencies, including communications with aircraft and operations using high power transmitters. Besides avoiding the frequency bands of Table 1 of RSS‐210 Issue 7 dated June 2007, designers of low power devices are strongly recommended to so avoid wherever possible the entire 225‐399.9 MHz band.

University of Michigan Radiation Laboratory FCC Part 15, IC RSS-210/Gen - Test Report No. 415031-385 Page 1 of 10 The University of Michigan Radiation Laboratory 3228 EECS Building Ann Arbor, MI 48109-2122 Tel: (734) 764-0500 Measured Radio Frequency Emissions From Code Systems, Inc Transceiver Transmitter Report FCC ID: GOH-GMRFAB01 Model/PN(s): GM19131628, GM19131602 Report No. 415031-385 October 16, 2007 Copyright © 2007 For: Code Systems, Inc 525 Minnesota Ave., Troy, Michigan 48083 Contact: Vincent Mrak [email protected] Tel: 248-307-3851 Fax: 248-585-4799 PO: verbal Tests supervised by: Measurements made by: Valdis V. Liepa Report approved by: _____________________ Valdis V. Liepa Test Report Prepared by: Joseph D. Brunett Research Scientist Summary Tests for compliance with FCC Regulations Part 15, Subpart C, and Industry Canada RSS-210/GEN, were performed on Code Systems, Inc model/PN(s) GM19131628, GM19131602. This device is subject to the Rules and Regulations as a Transceiver. In testing completed on September 18, 2007, the device tested in the worst case met the allowed FCC specifications for radiated emissions by 0.6 dB (see p. 6). Besides harmonics, there were no other significant spurious emissions found; emissions from digital circuitry were negligible. The conducted emission tests do not apply, since the device is powered from a 12 VDC battery. University of Michigan Radiation Laboratory FCC Part 15, IC RSS-210/Gen - Test Report No. 415031-385 Page 2 of 10 1. Introduction Code Systems, Inc model/PN(s) GM19131628, GM19131602 were tested for compliance with FCC, Part 15, adopted under Docket 87-389, April 18, 1989 as subsequently amended, and with Industry Canada RSS-210/Gen, Issue 7, June 2007. The tests were performed at the University of Michigan Radiation Laboratory Willow Run Test Range following the procedures described in ANSI C63.4-2003 "Methods of Measurement of Radio-Noise Emissions from Low-Voltage Electrical and Electronic Equipment in the Range of 9 kHz to 40 GHz". The Site description and attenuation characteristics of the Open Area Test Site are on file with FCC Laboratory, Columbia, Maryland (FCC Reg. No: 91050) and with Industry Canada, Ottawa, ON (File Ref. No: IC 2057A-1). 2. Test Procedure and Equipment Used The pertinent test equipment commonly used in our facility for measurements is listed in Table 2.1 below. The middle column identifies the specific equipment used in these tests. Table 2.1 Test Equipment. Test Instrument Eqpt. Used Manufacturer/Model Spectrum Analyzer (0.1-1500 MHz) Hewlett-Packard, 182T/8558B Spectrum Analyzer (9kHz-22GHz) X Hewlett-Packard 8593A SN: 3107A01358 Spectrum Analyzer (9kHz-26GHz) X Hewlett-Packard 8593E, SN: 3412A01131 Spectrum Analyzer (9kHz-26GHz) Hewlett-Packard 8563E, SN: 3310A01174 Spectrum Analyzer (9kHz-40GHz) Hewlett-Packard 8564E, SN: 3745A01031 Power Meter Hewlett-Packard, 432A Power Meter Anritsu, ML4803A/MP Harmonic Mixer (26-40 GHz) Hewlett-Packard 11970A, SN: 3003A08327 Harmonic Mixer (40-60 GHz) Hewlett-Packard 11970U, SN: 2332A00500 Harmonic Mixer (75-110 GHz) Hewlett-Packard 11970W, SN: 2521A00179 Harmonic Mixer (140-220 GHz) Pacific Millimeter Prod., GMA, SN: 26 S-Band Std. Gain Horn S/A, Model SGH-2.6 C-Band Std. Gain Horn University of Michigan, NRL design XN-Band Std. Gain Horn University of Michigan, NRL design X-Band Std. Gain Horn S/A, Model 12-8.2 X-band horn (8.2- 12.4 GHz) Narda 640 X-band horn (8.2- 12.4 GHz) Scientific Atlanta , 12-8.2, SN: 730 K-band horn (18-26.5 GHz) FXR, Inc., K638KF Ka-band horn (26.5-40 GHz) FXR, Inc., U638A U-band horn (40-60 GHz) Custom Microwave, HO19 W-band horn(75-110 GHz) Custom Microwave, HO10 G-band horn (140-220 GHz) Custom Microwave, HO5R Bicone Antenna (30-250 MHz) X University of Michigan, RLBC-1 Bicone Antenna (200-1000 MHz) X University of Michigan, RLBC-2 Dipole Antenna Set (30-1000 MHz) X University of Michigan, RLDP-1,-2,-3 Dipole Antenna Set (30-1000 MHz) EMCO 2131C, SN: 992 Active Rod Antenna (30 Hz-50 MHz) EMCO 3301B, SN: 3223 Active Loop Antenna (30 Hz-50 MHz) EMCO 6502, SN:2855 Ridge-horn Antenna (300-5000 MHz) X University of Michigan Amplifier (5-1000 MHz) X Avantak, A11-1, A25-1S Amplifier (5-4500 MHz) X Avantak Amplifier (4.5-13 GHz) Avantek, AFT-12665 Amplifier (6-16 GHz) Trek Amplifier (16-26 GHz) Avantek LISN Box University of Michigan Signal Generator Hewlett-Packard 8657B University of Michigan Radiation Laboratory FCC Part 15, IC RSS-210/Gen - Test Report No. 415031-385 Page 3 of 10 3. Device Under Test 3.1 Identification The DUT is a 315 MHz transceiver, 3 x 2 x 1 inches in size. The device is the in-vehicle unit used in a two way remote vehicle start/keyless entry system. The DUT contains both a 315 MHz transmitter and a 315 MHz receiver. Emissions relating only to the transmitter portion of the device are reported herein. The DUT transmits Manchester encoded data at 2.1 kbs. The antenna external to the DUT. The DUT was designed and manufactured by Code Systems, Inc, 525 Minnesota Ave., Troy, Michigan 48083. It is identified as: Code Systems, IncTransceiver Model/PN(s): GM19131628, GM19131602 FCC ID: GOH-GMRFAB01 IC: 3954A-RFA1 3.2 Variants There are two models of the DUT (19131628 and 19131602). Both units contain identical RF circuitry, but in the digital section the input power connector and the CAN bus message structure are different. The device with the green connector (19131628) utilizes 29 bit CAN messages while the device with the black connector (19131602) utilizes 11 bit CAN messages. 3.3 Modes of Operation The DUT utilizes only a single mode of operation. The device is remotely activated after interrogation from an associated hand-held unit via an encoded protocol. After interrogation, the DUT ceases to transmit within 5 seconds (see Figure 6.1). 3.4 EMI/EMC Relevant Modifications There were no modifications made to the DUT by this laboratory. 4. Emission Limits The DUT tested falls under the category of an Intentional R…
