GQK-HK570FPOS COMPUTER

HisenseWindowsall-in-onePOSSystem All-In-OnePOS KeyFeatures  Low-Profile,foldablebase,die-castaluminumhousingforhighreliable；  Withcompactfootprintandsleekdesignelements；  Carriesthefullsuiteofmultipleports:USB2.0&USB3.0,Serial,CashDrawerandNetworkLAN；  MultipleHeightAdjustmentsandVESAmountCapability； ModelNameHK570F ProcessorIntelBayTrailCeleronQuadcoreJ4125,2.0GHzupto2.7GHz ChipsetCPUIntegrated SystemMemory SO-DIMMDDR42400MHz4GB,upto8GB DisplayPanel 15"TFTLCD(LEDbacklight)/4:3/resolution:1024x768（optional） Brightness:400cd/ ㎡ TouchScreenTrueflatCapacitiveTouchscreen Harddisk SATASSD64GB,upto256GB SATAHDD2.5inch500GB PowersupplyAdapter(DC24V2.5A) I/Oports(standard) 4*USB2.0;4*USB3.0(6Rear,2Front) 3*RJ48COMPorts(COM4isoptionalpowerinputforVFD) 1*RJ45100M/1000MGigabitLAN 1*VGA 1*12VDCOutputforsecondscreen 1*Audio,3.5mm 1*24VRJ11forCashdrawer（supportdualcashdrawer） StandardPeripherals2x3W,8ΩSpeaker OptionalPeripherals 3tracksMSR(singleMSR,OPOS) 3tracksMSR+RFID(multi-functioncardreader,OPOS) 15"LEDSecondDisplay(Touch/non-touch) FingerprintReader EMC&SafetyFCC,Class-B/CE,Class-B/RoHS OperatingEnvironment0°C-40°C/20%-80%WIFRHnon-condensing StorageEnvironment-20°C-60°C/10%-90%RHnon-condensing EquipmentTexturesMainUnit:Die-castingaluminum;I/OCover:Plastic ColorBlack TiltAdjustment0°-60°（Vertical） Dimension(WxDxH)400×250×330mm Weight11KG OSSupportedWindows10/Linux Disclaimer:Thisproductspecificationissubjecttochangewithoutpriornotice. FCCRequirement changesormodificationsnotexpresslyapprovedbythepartyresponsibleforcompliancecouldvoidtheuser’ sauthoritytooperatetheequipment. ThisdevicecomplieswithPart15oftheFCCRules.Operationissubjecttothefollowingtwoconditions: (1)thisdevicemaynotcauseharmfulinterference,and (2)thisdevicemustacceptanyinterferencereceived,includinginterferencethatmaycauseundesired operation. Note:ThisequipmenthasbeentestedandfoundtocomplywiththelimitsforaClassBdigitaldevice, pursuanttoPart15oftheFCCRules.Theselimitsaredesignedtoprovidereasonableprotectionagainst harmfulinterferenceinaresidentialinstallation.Thisequipmentgenerates,uses,andcanradiateradio frequencyenergy,andifnotinstalledandusedinaccordancewiththeinstructions,maycauseharmful interferencetoradiocommunications.However,thereisnoguaranteethatinterferencewillnotoccurina particularinstallation.Ifthisequipmentdoescauseharmfulinterferencetoradioortelevisionreception,which canbedeterminedbyturningtheequipmentoffandon,theuserisencouragedtotrytocorrectthe interferencebyoneormoreofthefollowingmeasures: –Reorientorrelocatethereceivingantenna. –Increasetheseparationbetweentheequipmentandreceiver. –Connecttheequipmentintoanoutletonacircuitdifferentfromthattowhichthereceiverisconnected. –Consultthedealeroranexperiencedradio/TVtechnicianforhelp.

FCCID:GQK-HK570F FCCID:GQK-HK570F

Made in China Model:HK570F POS COMPUTER Rated voltage: Rated current: 2.5A S/N:******************* Qingdao Hisense Intelligent Commercial System Co.,Ltd RoHS Model:HK570F POS COMPUTER Rated voltage: Rated current: 2.5A S/N:******************* Qingdao Hisense Intelligent Commercial System Co.,Ltd HK570F HK570F 24V 24V FCC ID:GQK-HK570F Made in China RoHS FCC ID:GQK-HK570F

FCCID:GQK-HK570F FCCID:GQK-HK570F FCCID:GQK-HK570F

ShenzhenHuaxiaTestingTechnologyCo.,Ltd 1F.,BlockAofTongshengTechnologyBuilding,HuahuiRoad,DalangStreet,LonghuaDistrict, Shenzhen,China Telephone:+86-755-26648640 Fax:+86-755-26648637 Website:www.cqa-cert.com ReportTemplateVersion:V03 ReportTemplateRevisionDate:Mar.1st,2017 RFExposureEvaluationReport *Intheconfigurationtested,theEUTcompliedwiththestandardsspecifiedabove. Thetestreportiseffectiveonlywithbothsignatureandspecializedstamp,Theresult(s)showninthisreportreferonlytothesample(s) tested.WithoutwrittenapprovalofCQA,thisreportcan’tbereproducedexceptinfull. ReportNo.: CQASZ20210400481E-02 Applicant: QingdaoHisenseIntelligentCommercialSystemCo.,Ltd. AddressofApplicant:399SonglingRoad,Laoshan,Qingdao,China EquipmentUnderTest(EUT): Product: POSCOMPUTER ModelNo.: HK570F BrandName: N/A FCCID:GQK-HK570F Standards: 47CFRPart1.1307 47CFRPart1.1310 KDB447498D01GeneralRFExposureGuidancev06 DateofTest:2021-4-17to2021-5-28 DateofIssue:2021-5-28 TestResult:PASS* TestedBy： (LewisZhou) ReviewedBy: (JunLi) ApprovedBy: (SheekLuo) ShenzhenHuaxiaTestingTechnologyCo.,Ltd ReportNo.:CQASZ20210400481E-02 Page:2of6 1Version RevisionHistoryOfReport ReportNo.Version Description IssueDate CQASZ20210400481E-02Rev.01 Initialreport 2021-5-28 ShenzhenHuaxiaTestingTechnologyCo.,Ltd ReportNo.:CQASZ20210400481E-02 Page:3of6 2Contents Page 1VERSION.............................................................................................................................................................................2 2CONTENTS.........................................................................................................................................................................3 ..................................................................................................................................................................................................3 3GENERALINFORMATION..............................................................................................................................................4 3.1CLIENTINFORMATION....................................................................................................................................................4 3.2GENERALDESCRIPTIONOFEUT....................................................................................................................................4 3.3GENERALDESCRIPTIONOFNFC....................................................................................................................................4 4RFEXPOSUREEVALUATION.......................................................................................................................................5 4.1RFEXPOSURECOMPLIANCEREQUIREMENT..................................................................................................................5 4.1.1StandardRequirement......................................................................................................................................5 4.1.2Limits....................................................................................................................................................................5 4.2EUTRFEXPOSUREEVALUATION..................................................................................................................................6 ShenzhenHuaxiaTestingTechnologyCo.,Ltd ReportNo.:CQASZ20210400481E-02 Page:4of6 3GeneralInformation 3.1ClientInformation Applicant: QingdaoHisenseIntelligentCommercialSystemCo.,Ltd. AddressofApplicant: 399SonglingRoad,Laoshan,Qingdao,China Manufacturer: QingdaoHisenseIntelligentCommercialSystemCo.,Ltd. AddressofManufacturer: 399SonglingRoad,Laoshan,Qingdao,China Factory: QingdaoHisenseIntelligentCommercialSystemCo.,Ltd. AddressofFactory: 399SonglingRoad,Laoshan,Qingdao,China 3.2GeneralDescriptionofEUT Name: POSCOMPUTER ModelNo.: HK570F TradeMark: N/A HardwareVersion: HS-J4125DS SoftwareVersion: HS-J4125 PowerSupply: Adapter:Input:100-240V~,50-60Hz,1.8A Output:24V⎓,2.5A 3.3GeneralDescriptionofNFC OperationFrequency:13.56MHz ModulationType:ASK ProductType:MobilePortableFixLocation AntennaType:Integralantenna AntennaGain:0dBi ShenzhenHuaxiaTestingTechnologyCo.,Ltd ReportNo.:CQASZ20210400481E-02 Page:5of6 4RFExposureEvaluation 4.1RFExposureComplianceRequirement 4.1.1StandardRequirement AccordingtoKDB447498D01GeneralRFExposureGuidancev06 4.3.1.StandaloneSARtestexclusionconsiderations UnlessspecificallyrequiredbythepublishedRFexposureKDBprocedures,standalone1-g headorbodyand10-gextremitySARevaluationforgeneralpopulationexposureconditions,by measurementornumericalsimulation,isnotrequiredwhenthecorrespondingSARExclusion Thresholdcondition,listedbelow,issatisfied. 4.1.2Limits Forfrequenciesbelow100MHz,thefollowingmaybeconsideredforSARtestexclusion(also illustratedinAppendixC):33 1)Fortestseparationdistances>50mmand<200mm,thepowerthresholdatthecorresponding testseparationdistanceat100MHzinstepb)ismultipliedby[1+log(100/f(MHz))] 2)Fortestseparationdistances≤50mm,thepowerthresholddeterminedbytheequationinc)1) for50mmand100MHzismultipliedby½ 3)SARmeasurementproceduresarenotestablishedbelow100MHz. WhenSARtestexclusioncannotbeapplied,aKDBinquiryisrequiredtodetermineSARevaluation requirementsforanySARtestresultsbelow100MHztobeacceptable.34 ShenzhenHuaxiaTestingTechnologyCo.,Ltd ReportNo.:CQASZ20210400481E-02 Page:6of6 4.2EUTRFExposureEvaluation 1)ForNFC eirp=ptxgt=(Exd) 2 /30 where: pt=transmitteroutputpowerinwatts, gt=numericgainofthetransmittingantenna(unitless), E=electricfieldstrengthinV/m,---10 ((dBμV/m)/20) /10 6 , d=measurementdistanceinmeters(m)---3m, Sopt=(Exd) 2 /30/gt Theworstcase(refertoreportCQASZ20210400481E-01)isbelow: Frequency(MHz)Level(dBuV/m) Polarization 13.5661.2Peak For13.56MHzwireless: Fieldstrength=61.2dBμV/m@3m Ant.gain0dBi;soAntnumericgain=1.0 Sopt={[10 (61.2/20) /10 6 x3] 2 /30/1.0}x1000mW=0.0004mW So(0.0004mW/5mm)x√0.01356GHz=0.000009, 0.000009<3.0for1-gSAR SotheSARreportisnotrequired.

ShenzhenHuaxiaTestingTechnologyCo.,Ltd 1F.,BlockAofTongshengTechnologyBuilding,HuahuiRoad,DalangStreet,LonghuaDistrict, Shenzhen,China Telephone:+86-755-26648640 Fax:+86-755-26648637 Website:www.cqa-cert.com ReportTemplateVersion:V03 ReportTemplateRevisionDate:Mar.1st,2017 TestReport *Intheconfigurationtested,theEUTcompliedwiththestandardsspecifiedabove. Thetestreportiseffectiveonlywithbothsignatureandspecializedstamp,Theresult(s)showninthisreportreferonly tothesample(s)tested.WithoutwrittenapprovalofCQA,thisreportcan’tbereproducedexceptinfull. ReportNo.: CQASZ20210400481E-01 Applicant: QingdaoHisenseIntelligentCommercialSystemCo.,Ltd. AddressofApplicant:399SonglingRoad,Laoshan,Qingdao,China EquipmentUnderTest(EUT): Product: POSCOMPUTER AllModelNo.: HK570F BrandName: N/A FCCID:GQK-HK570F Standards:47CFRPart15,SubpartC DateofTest:2021-4-17to2021-5-28 DateofIssue:2021-5-28 TestResult:PASS* TestedBy： (LewisZhou) ReviewedBy: (JunLi) ApprovedBy: (SheekLuo) ShenzhenHuaxiaTestingTechnologyCo.,Ltd ReportNo.:CQASZ20210400481E-01 Page:2of33 1Version RevisionHistoryOfReport ReportNo.Version Description IssueDate CQASZ20210400481E-01Rev.01 Initialreport 2021-5-28 ShenzhenHuaxiaTestingTechnologyCo.,Ltd ReportNo.:CQASZ20210400481E-01 Page:3of33 2Contents Page 1VERSION...........................................................................................................................................................................2 2CONTENTS.......................................................................................................................................................................3 3TESTSUMMARY.............................................................................................................................................................4 4GENERALINFORMATION............................................................................................................................................5 4.1CLIENTINFORMATION.................................................................................................................................................5 4.2GENERALDESCRIPTIONOFE.U.T...............................................................................................................................5 4.3TESTENVIRONMENT...................................................................................................................................................6 4.4DESCRIPTIONOFSUPPORTUNITS................................................................................................................................6 4.5STATEMENTOFTHEMEASUREMENTUNCERTAINTY....................................................................................................7 4.6TESTLOCATION..........................................................................................................................................................8 4.7TESTFACILITY............................................................................................................................................................8 4.8EQUIPMENTLIST.........................................................................................................................................................9 5TESTRESULTANDMEASUREMENTDATA.........................................................................................................10 5.1ANTENNAREQUIRMENT............................................................................................................................................10 5.2ELECTRICFIELDSTRENGTHOFFUNDAMENTALANDOUTSIDETHEALLOCATEDBANDS........................................11 5.3RADIATEDEMISSIONS...............................................................................................................................................14 5.4FREQUENCYTOLERANCE..........................................................................................................................................19 5.5OCCUPIEDBANDWIDTH.............................................................................................................................................21 5.6CONDUCTEDEMISSION............................................................................................................................................22 6PHOTOGRAPHS-EUTTESTSETUP......................................................................................................................27 6.1RADIATEDEMISSION.................................................................................................................................................27 7PHOTOGRAPHS-EUTCONSTRUCTIONALDETAILS.......................................................................................29 ShenzhenHuaxiaTestingTechnologyCo.,Ltd ReportNo.:CQASZ20210400481E-01 Page:4of33 3TestSummary TestItemTestRequirementTestMethodResult AntennaRequirement 47CFRPart15,SubpartC Section15.203 ANSIC63.102013Pass ConductedEmission (150KHzto30MHz) 47CFRPart15,SubpartC Section15.207 ANSIC63.102013 Section6.2 PASS ElectricFieldStrengthof FundamentalandOutside theAllocatedbands 47CFRPart15,SubpartC Section15.225(a)/(b)/(c) ANSIC63.102013 Section6.9.2 Pass RadiatedEmission 47CFRPart15,SubpartC Section15.225(d)/15.209 ANSIC63.102013 Section6.4 Pass FrequencyTolerance 47CFRPart15,SubpartC Section15.225(e) ANSIC63.102013 Section6.4&6.5 Pass OccupiedBandwidth 47CFRPart15,SubpartC Section15.215 ANSIC63.102013 Section6.8 Pass ShenzhenHuaxiaTestingTechnologyCo.,Ltd ReportNo.:CQASZ20210400481E-01 Page:5of33 4GeneralInformation 4.1ClientInformation Applicant: QingdaoHisenseIntelligentCommercialSystemCo.,Ltd. AddressofApplicant: 399SonglingRoad,Laoshan,Qingdao,China Manufacturer: QingdaoHisenseIntelligentCommercialSystemCo.,Ltd. AddressofManufacturer: 399SonglingRoad,Laoshan,Qingdao,China Factory: QingdaoHisenseIntelligentCommercialSystemCo.,Ltd. AddressofFactory: 399SonglingRoad,Laoshan,Qingdao,China 4.2GeneralDescriptionofE.U.T. Produc…

Text truncated - open the document above for the full version.

FCCID:GQK-HK570F 1 Photographs-EUTTestSetup 1.1RadiatedEmission 9KHz~30MHz: 30MHz~1GHz: FCCID:GQK-HK570F ConductedEmissionsTestSetup
