GSS-VS14905Tablet PC

TABLET PC Security Alert For safety and effective using the tablet PC, you should read the basic safety precautions carefully. · · · · · · Keep the computer away from heat, cold, moisture and dust. Don't spill any liquid onto the tablet PC to damage it or cause a fire. Don't use liquid orto wipe the tablet PC. Don't insert any object into the computer's air vents or other slots. Don't place heavy objects on the tablet PC. Don't disassemble the tablet PC, let the qualified professional for the service to keep safe. chemically cleaner Quick Start Guide [Note]: The appearance, color, features, and pictures in the manual are for reference only; if any difference, please see the actual products. The company reserves the right to update the products and the manual without prior notice. Part Names and Functions: Camera DC-In Jack USB Port Mini-HDMI Port Built-in speaker Volume button Volume button Back key Micro- Micro-SD Taking pictures or recording video Audio output,connect to headphone Connect to the DC power supply Connect USB device Sound output If the light being amber means the battery is charging, if the light being blue means it's been fully charged. Decrease the volume Micro- External Micro-SD card to extend storage Increase the volume Back to the previous interface from the current interface External mini high-definition Multimedia monitor Battery status indicator Cut power Forced off with needle insert the reset hole, you can't turn off the tablet PC by press power button 4S, when the system stuck Built-in microphone Audio output Interface 1 2 3 5 6 7 8 9 12 13 14 4 10 Home Screen Use Instructions ·Press Power for 3 seconds, after booting picture enters the home screen as below: Press for more than 4 seconds to turn on/off; press once for screensaver, press again to wake it up Power button 11 Application:touch and goes to Application interface where all the applications shown Back: touch and return menu Home: touch and return home screen muti-task switch;click here to open the procedure list applied recently 11121314 10 9 876543 2 9 1 Used for video Conference,dubbing and simple recording 105.00 mm 105.00 mm 290.00 mm FCC Statement This device complies with part 15 of the FCC Rules. Operation is subject to the following two conditions: (1) This device may not cause harmful interference, and (2) this device must accept any interference received, including interference that may cause undesired operation Changes or modifications not expressly approved by the party responsible for compliance could void the user's authority to operate the equipment. NOTE: This equipment has been tested and found to comply with the limits for a Class B digital device, pursuant to Part 15 of the FCC Rules. These limits are designed to provide reasonable protection against harmful interference in a residential installation. This equipment generates, uses and can radiate radio frequency energy and, if not installed and used in accordance with the instructions, may cause harmful interference to radio communications. However, there is no guarantee that interference will not occur in a particular installation. If this equipment does cause harmful interference to radio or television reception, which can be determined by turning the equipment off and on, the user is encouraged to try to correct the interference by one or more of the following measures: -- Reorient or relocate the receiving antenna. -- Increase the separation between the equipment and receiver. -- Connect the equipment into an outlet on a circuit different from that to which the receiver is connected. -- Consult the dealer or an experienced radio/TV technician for help. IC STATEMENT This device complies with Industry Canada licence-exempt RSS standard(s). Operation is subject to the following two conditions: (1) this device may not cause interference, and (2) this device must accept any interference, including interference that may cause undesired operation of the device. Le présent appareil est conforme aux CNR d'Industrie Canada applicables aux appareils radio exempts de licence. L'exploitation est autorisée aux deux conditions suivantes : (1) l'appareil ne doit pas produire de brouillage, et (2) l'utilisateur de l'appareil doit accepter tout brouillage radioélectrique subi, même si le brouillage est susceptible d'en compromettre le fonctionnement. RF warning statement: The device has been evaluated to meet general RF exposure requirement set forth for an uncontrolled enviroment. End users must maintain 0.5 cm distance away from the Tablet PC and its antenna. This tran smitter must not be co-located or operating in conjunction with any other antenna or transmitter.

ViewSonic Corporation 381 Brea Canyon Road, Walnut, CA 91789, USA DATE :2012-07-05 Nemko Canada Inc 303 River Road Ottawa, Ontario, Canada K1V 1H2 Attn: Director of Certification Authority to Act as Agent On our behalf, I appoint Hans.Hu of Global United Technology Services Co., Ltd. 2nd Floor, Block No.2, Laodong Industrial Zone, Xixiang Road Baoan District Shenzhen Guangdong to act as our agent in the preparation of this application for equipment certification. I certify that submitted documents properly describe the device or system for which equipment certification is sought. I also certify that each unit manufactured, imported or marketed, as defined in the Federal Communications Commission’s regulations will have affixed to it a label identical to that submitted for approval with this application. For instances where our authorized agent signs the application for certification on our behalf, I acknowledge that all responsibility for complying with the terms and conditions for certification, as specified by Nemko Canada Inc, still resides with ViewSonic Corporation and 381 Brea Canyon Road, Walnut, CA 91789, USA Dated this / Day of 07/05/2012 / Agency agreement expiration date: 07/05/2013 By: Sophia Wu Signature Printed Title: Compliance Assistance Manager On behalf of : ViewSonic Corporation Telephone: 886-02-2246-3456

Date: 07/05/2012 To: Federal Communications Commission 7435 Oakland Mills Road Columbia, MD FCC ID: GSS-VS14905 To Whom It May Concern: We, ViewSonic Corporation, are applying FCC DOC for product Tablet PC which model no. is VS14905. the FCC DOC is doing at proper FCC authorized and recognized lab, and FCC DOC will be issued soon. If you have any question or concerns, pls. contact us. Sincerely, Client’s signature Client’s name / title Sophia Wu / Compliance Assistance Manager Contact information / address Tel: 886-02-2246-3456 Address: 381 Brea Canyon Road, Walnut, CA 91789, USA

ViewSonic Corporation 381 Brea Canyon Road, Walnut, CA 91789, USA 2012-07-05 Equipment Autorisation Division Federal Communications Commission 7435 Oakland Mills Road Columbia, MD 21046 FCC ID: GSS-VS14905 Product Name: Tablet PC Request for Confidentiality Pursuant to Sections 0.457 and 0.459 of the commissions rules, we hereby request that the following documents be held confidential:  Schematics  Block diagram  Operational Description These materials contain trade secrets and proprietary information and are not customarily released to the public. The public disclosure of this information might be harmful to the company and provide unjustified benefits to our competitors. Dated this 07/05/2012 By: Sophia Wu Signature Printed Title: Compliance Assistance Manager On behalf of : ViewSonic Corporation Telephone: 886-02-2246-3456

Label Location

Report No.: 126S066R-HP-US-P03V01 Page: 1 of 63 SAR Test Report Product Name : Tablet PC Model No. : VS14905 FCC ID : GSS-VS14905 IC : 4280A-VS14905 Applicant : ViewSonic Corporation Address : 381 Brea Canyon Road, Walnut, CA 91789, USA Date of Receipt : 25/06/2012 Date of Test : 26/06/2012 Issued Date : 27/06/2012 Report No. : 126S066R-HP-US-P03V01 Report Version : V1.1 The test results relate only to the samples tested. The test report shall not be reproduced except in full without the written approval of QuieTek Corporation. Report No.: 126S066R-HP-US-P03V01 Page: 2 of 63 Test Report Certification Issued Date: 27/06/2012 Report No.: 126S066R-HP-US-P03V01 Product Name : Tablet PC Applicant : ViewSonic Corporation Address : 381 Brea Canyon Road, Walnut, CA 91789, USA Manufacturer : ViewSonic Corporation Address : 381 Brea Canyon Road, Walnut, CA 91789, USA Model No. : VS14905 FCC ID : GSS-VS14905 IC : 4280A-VS14905 Brand Name : ViewSonic EUT Voltage : DC 5V Applicable Standard : FCC Oet65 Supplement C June 2001 RSS-102 Issue 4 (March 2010), updated December 2010. IEEE Std. 1528-2003,47CFR § 2.1093 Test Result : Max. SAR Measurement (1g) 0.539W/kg Performed Location : Suzhou EMC Laboratory No.99 Hongye Rd., Suzhou Industrial Park Loufeng Hi-Tech Development Zone., Suzhou, China TEL: +86-512-6251-5088 / FAX: +86-512-6251-5098 FCC Registration Number: 800392, IC Lab Code: 4075B Documented By : (Engineering ADM: Alice Ni) Reviewed By : (Engineering Supervisor: Robin Wu) Approved By : (Manager: Marlin Chen) Report No.: 126S066R-HP-US-P03V01 Page: 3 of 63 Laboratory Information We, QuieTek Corporation, are an independent EMC and safety consultancy that was established the whole facility in our laboratories. The test facility has been accredited/accepted(audited or listed) by the following related bodies in compliance with ISO 17025, EN 45001 and specified testing scope: The related certificate for our laboratories about the test site and management system can be downloaded from QuieTek Corporation’s Web Site :http://www.quietek.com/tw/ctg/cts/accreditations.htm The address and introduction of QuieTek Corporation’s laboratories can be founded in our Web site : http://www.quietek.com/ If you have any comments, Please don’t hesitate to contact us. Our contact information is as below: HsinChu Testing Laboratory : No.75-2, 3rd Lin, Wangye Keng, Yonghxing Tsuen, Qionglin Shiang, Hsinchu County 307, Taiwan, R.O.C. TEL:+886-3-592-8858 / FAX:+886-3-592-8859 E-Mail : [email protected] LinKou Testing Laboratory : No.5-22, Ruishukeng, Linkou Dist., New Taipei City 24451, Taiwan, R.O.C. TEL : 886-2-8601-3788 / FAX : 886-2-8601-3789 E-Mail : [email protected] Suzhou Testing Laboratory : No.99 Hongye Rd., Suzhou Industrial Park Loufeng Hi-Tech Development Zone., SuZhou, China TEL : +86-512-6251-5088 / FAX : 86-512-6251-5098 E-Mail : [email protected] Taiwan R.O.C. :BSMI, NCC, TAF Germany :TUV Rheinland Norway :Nemko, DNV USA :FCC, NVLAP Japan :VCCI China :CNAS Report No.: 126S066R-HP-US-P03V01 Page: 4 of 63 TABLE OF CONTENTS Description Page 1. General Information .................................................................................................6 1.1. EUT DESCRIPTION.................................................................................................6 1.2. TEST ENVIRONMENT..............................................................................................7 2. SAR Measurement System ......................................................................................8 2.1. DASY5 SYSTEM DESCRIPTION...............................................................................8 2.1.1. Applications .....................................................................................................9 2.1.2. Area Scans ......................................................................................................9 2.1.3. Zoom Scan (Cube Scan Averaging) ................................................................9 2.1.4. Uncertainty of Inter-/Extrapolation and Averaging ...........................................9 2.2. DASY5 E-FIELD PROBE.......................................................................................10 2.2.1. Isotropic E-Field Probe Specification .............................................................10 2.3. BOUNDARY DETECTION UNIT AND PROBE MOUNTING DEVICE.................................. 11 2.4. DATA ACQUISITION ELECTRONICS (DAE) AND MEASUREMENT SERVER.................. 11 2.5. ROBOT................................................................................................................12 2.6. LIGHT BEAM UNIT................................................................................................12 2.7. DEVICE HOLDER..................................................................................................13 2.8. SAM TWIN PHANTOM...........................................................................................13 3. Tissue Simulating Liquid .......................................................................................14 3.1. THE COMPOSITION OF THE TISSUE SIMULATING LIQUID.............................................14 3.2. TISSUE CALIBRATION RESULT...............................................................................15 3.3. TISSUE DIELECTRIC PARAMETERS FOR HEAD AND BODY PHANTOMS........................16 4. SAR Measurement Procedure ...............................................................................17 4.1. SAR SYSTEM VALIDATION....................................................................................17 4.1.1. Validation Dipoles..........................................................................................17 4.1.2. Validation Result............................................................................................18 4.2. SAR MEASUREMENT PROCEDURE........................................................................19 5. SAR Exposure Limits…
