GSS-VS15197Smart Display

Model No. VS15197 VSD241 Smart Display User Guide Guide de l’utilisateur Guía del usuario Bedienungsanleitung Pyководство пользователя iPB Compliance Information Please read before proceeding • Use only the batteries and power adapter provided by the manufacturer. The use of unauthorized accessories may void your warranty. • Do not store your device in temperatures higher than 50°C (122°F). • The operating temperature for this device is from 0°C (32°F) to 35°C (95°F). FCC Notice The following statement applies to all products that have received FCC approval. Applicable products bear the FCC logo, and/or an FCC ID in the format FCC ID: GSS- VS15197 on the product label.This device complies with part 15 of the FCC Rules. Operation is subject to the following two conditions: (1) This device may not cause harmful interference, and (2) This device must accept any interference received, including interference that may cause undesired operation. This mobiledevice has been tested and found to comply with the limits for a Class B digital device, pursuant to Part 15 of the FCC Rules. These limits are designed to provide reasonable protection against harmful interference in a residential installation. This equipment generates, uses and can radiate radio frequencyenergy and, if not installed and used in accordance with the instructions, may cause harmful interferenceto radio communications. However, there is no guarantee that interference will not occur in a particular installation. If this equipment does cause harmful interference to radio or television reception, which can be determined by turning the equipment off and on, the user is encouraged to try to correct the interference by one or more of the following measures • Reorient or relocate the receiving antenna. • Increase the separation between the equipment and receiver . • Connect the equipment into an outlet on a circuit dif ferent from that to which the receiver is connected. • Consult the dealer or an experienced radio/TV technician for help. Changes or modifications not expressly approved by the party responsible for compliance could void theuser ’s authority to operate the equipment.The antenna(s) used for this transmitter must not be colocated or operating in conjunction with any otherantenna or transmitter. The device was tested and complies to measurement standards and procedures specified in FCC OET Bulletin 65, Supplement C FCC SAR Information This equipment complies with FCC radiation exposure limits set forth for an uncontrolled environment. End users must follow the specific operating instructions for satisfying RF exposure compliance. This transmitter must not be co-located or operating in conjunction with any other antenna or transmitter. This equipment should be installed and operated with a minimum distance of 20 centimeters between the radiator and your body. The users manual or instruction manual for an intentional or unintentional radiator shall caution the user that changes or modifications not expressly approved by the party responsible for compliance could void the user's authority to operate the equipment. iiiii Canada Statement This device complies with Industry Canada licence-exempt RSS standard(s). Operation is subject to the following two conditions: (1) this device may not cause interference, and (2) this device must accept any interference, including interference that may cause undesired operation of the device. Caution: Exposure to Radio Frequency Radiation To comply with RSS 102 RF exposure compliance requirements, a separation distance of at least 20 cm must be maintained between the antenna of this device and all persons. Pour se conformer aux exigences de conformité CNR 102 RF exposition, une distance de séparation d'au moins 20 cm doit être maintenue entre l'antenne de cet appareil et toutes les personnes. CE Conformity for European Countries The device complies with the EMC Directive 2004/108/EC and Low Voltage Directive 2006/95/EC, R&TTE Directive 1999/5/EC. Following information is only for EU-member states: The mark shown to the right is in compliance with the Waste Electrical and Electronic Equipment Directive 2002/96/EC (WEEE). The mark indicates the requirement NOT to dispose the equipment as unsorted municipal waste, but use the return and collection systems according to local law. If the batteries, accumulators and button cells included with this equipment, display the chemical symbol Hg, Cd, or Pb, then it means that the battery has a heavy metal content of more than 0.0005% Mercury, or more than 0.002% Cadmium, or more than 0.004% Lead. European Union Regulatory Conformance The equipment complies with the RF Exposure Requirement 1999/519/EC, Council Recommendation of 12 July 1999 on the limitation of exposure of the general public to electromagnetic fields (0-300 GHz). This equipment meets the following conformance standards: EN301489-1, EN301489-17, EN55022/24, EN60950-1, EN300328. We, hereby, declare that this Wi-Fi & Bluetooth radio is in compliance with the essential requirements and other relevant provisions of Directive 1999/5/EC. iiiii ENERGY STAR This ENERGY STAR qualified product saves your money by reducing energy cost and protecting the environment without sacrificing features or performance. We are proud to offer our customers products with the ENERGY STAR mark. What is ENERGY STAR? Products that are ENERGY STAR qualified use less energy and prevent greenhouse gas emissions by meeting strict energy efficiency guidelines set by the U.S. Environmental Protection Agency. We commit to offering products and services worldwide that help customers save money, conserve energy and improve the quality of our environment. The more energy we can save through higher energy efficiency, the more we reduce greenhouse gases and the risks of climate change. More information refers to www. energystar.gov or ww.energystar.gov/powermanagement. Note: Information in this section may not apply to your compu…

Text truncated - open the document above for the full version.

UI1 XZ-plane Frequency PEAK 2G 2400MHz -3.16 48.30% -1.76 dB2450MHz -2.94 50.77% -1.55 dB2500MHz -2.70 53.66% -1.37 dB +X +Y +Z

Date: 2013/05/14 To who may concerns, I, the undersigned, responsible for the designated person in FCC grant communicator / IC company code contactor, hereby authorized Delia Lee to sign the FCC / IC application form for certification process. Thank you, Sincerely Yours, Sophia Wu Product Regulation Assistance Manager ViewSonic Corporation

Report No.: EF/2013/40033 FCC ID: GSS-VS15197 Issue Date: May 28, 2013 IC: 4280A-VS15197 Unless otherwise stated the results shown in this test report refer only to the sample(s) tested and such sample(s) are retained for 90 days only. 除非另有說明，此報告結果僅對測試之樣品負責，同時此樣品僅保留90天。本報告未經本公司書面許可，不可部份複製。 This document is issued by the Company subject to its General Conditions of Service printed overleaf, available on request or accessible at www.sgs.com/terms_and_conditions.htm and, for elec- tronic format documents, subject to Terms and Conditions for Electronic Documents at www.sgs.com/terms_e-document.htm. Attention is drawn to the limitation of liability, indemnification and jurisdiction issues defined therein. Any holder of this document is advised that information contained hereon reflects the Company’s findings at the time of its intervention only and within the limits of Client’s instructions, if any. The Company’s sole responsibility is to its Client and this document does not exonerate parties to a transaction from exercising all their rights and obligations under the transaction documents. This document cannot be reproduced except in full, without prior written approval of the Company. Any unauthorized alteration, forgery or falsification of the content or ap- pearance of this document is unlawful and offenders may be prosecuted to the fullest extent of the law. SGS Taiwan Ltd. No.134,WuKungRoad,NewTaipeiIndustrialPark,WukuDistrict,NewTaipeiCity,Taiwan24803/新北市五股區新北產業園區五工路134號 台灣檢驗科技股份有限公司 t (886-2) 2299-3279 f (886-2) 2298-0488 www.tw.sgs.com Member of SGS Group APPENDIX 2 EXTERNAL PHOTOGRAPHS OF EUT Report No.: EF/2013/40033 FCC ID: GSS-VS15197 Issue Date: May 28, 2013 IC: 4280A-VS15197 Unless otherwise stated the results shown in this test report refer only to the sample(s) tested and such sample(s) are retained for 90 days only. 除非另有說明，此報告結果僅對測試之樣品負責，同時此樣品僅保留90天。本報告未經本公司書面許可，不可部份複製。 This document is issued by the Company subject to its General Conditions of Service printed overleaf, available on request or accessible at www.sgs.com/terms_and_conditions.htm and, for elec- tronic format documents, subject to Terms and Conditions for Electronic Documents at www.sgs.com/terms_e-document.htm. Attention is drawn to the limitation of liability, indemnification and jurisdiction issues defined therein. Any holder of this document is advised that information contained hereon reflects the Company’s findings at the time of its intervention only and within the limits of Client’s instructions, if any. The Company’s sole responsibility is to its Client and this document does not exonerate parties to a transaction from exercising all their rights and obligations under the transaction documents. This document cannot be reproduced except in full, without prior written approval of the Company. Any unauthorized alteration, forgery or falsification of the content or ap- pearance of this document is unlawful and offenders may be prosecuted to the fullest extent of the law. SGS Taiwan Ltd. No.134,WuKungRoad,NewTaipeiIndustrialPark,WukuDistrict,NewTaipeiCity,Taiwan24803/新北市五股區新北產業園區五工路134號 台灣檢驗科技股份有限公司 t (886-2) 2299-3279 f (886-2) 2298-0488 www.tw.sgs.com Member of SGS Group All View of EUT Front View of EUT Report No.: EF/2013/40033 FCC ID: GSS-VS15197 Issue Date: May 28, 2013 IC: 4280A-VS15197 Unless otherwise stated the results shown in this test report refer only to the sample(s) tested and such sample(s) are retained for 90 days only. 除非另有說明，此報告結果僅對測試之樣品負責，同時此樣品僅保留90天。本報告未經本公司書面許可，不可部份複製。 This document is issued by the Company subject to its General Conditions of Service printed overleaf, available on request or accessible at www.sgs.com/terms_and_conditions.htm and, for elec- tronic format documents, subject to Terms and Conditions for Electronic Documents at www.sgs.com/terms_e-document.htm. Attention is drawn to the limitation of liability, indemnification and jurisdiction issues defined therein. Any holder of this document is advised that information contained hereon reflects the Company’s findings at the time of its intervention only and within the limits of Client’s instructions, if any. The Company’s sole responsibility is to its Client and this document does not exonerate parties to a transaction from exercising all their rights and obligations under the transaction documents. This document cannot be reproduced except in full, without prior written approval of the Company. Any unauthorized alteration, forgery or falsification of the content or ap- pearance of this document is unlawful and offenders may be prosecuted to the fullest extent of the law. SGS Taiwan Ltd. No.134,WuKungRoad,NewTaipeiIndustrialPark,WukuDistrict,NewTaipeiCity,Taiwan24803/新北市五股區新北產業園區五工路134號 台灣檢驗科技股份有限公司 t (886-2) 2299-3279 f (886-2) 2298-0488 www.tw.sgs.com Member of SGS Group Back View of EUT Side View of EUT – 1 Report No.: EF/2013/40033 FCC ID: GSS-VS15197 Issue Date: May 28, 2013 IC: 4280A-VS15197 Unless otherwise stated the results shown in this test report refer only to the sample(s) tested and such sample(s) are retained for 90 days only. 除非另有說明，此報告結果僅對測試之樣品負責，同時此樣品僅保留90天。本報告未經本公司書面許可，不可部份複製。 This document is issued by the Company subject to its General Conditions of Service printed overleaf, available on request or accessible at www.sgs.com/terms_and_conditions.htm and, for elec- tronic format documents, subject to Terms and Conditions for Electronic Documents at www.sgs.com/terms_e-document.htm. Attention is drawn to the limitation of liability, indemnification and jurisdiction issues defined therein. Any holder of this document is advised that information contained hereon reflects the Company’s findings at the time of its intervention only and within the limits of Client’s instructions, if any. The Company’s sole responsibility is to its Client and this document does not exonerate parties to a transaction from exercising all their rights and obligations under the transaction documents. This document cannot be repr…

Text truncated - open the document above for the full version.

3A 3B 3C LTR REVISIONS DESCRIPTI ON DATEAPP UI1A 3A HCUI1001010 RATING LABEL PL UI1A(HCUI1001,R3A) RATING LABEL PL UI1A HCUI1001 2013-05-02 50-100 0-10 RANGE 100- THIRD ANGLE PROJECTION FINISH MATERIAL TOLERANCE A4 DRAWN REV. DATE SCALE DWG NO. ITEM NAME TOL.± 2 PLC 1 PLC MODEL APPROVED MMUNIT ANGLE DESIGNED 10-50 1:1 1/1 ±0.15 ±0.20 ±0.25 ±0.10 PART NO. DESCRIPTION KENT KENT 1 Quanta Computer Inc. 50#+25# 40mm 90mm 10mm Note: 1.MATERIAL: 50#+25#P 2.ADHESIVE BASE:ACRYLIC 3.BACKGROUND COLOR:ORIGINAL 4.TEXT COLOR:BLACK 5.CCC:, :5.3mm :4mm 6. 7.FILE NO.: HCUI1001010 Label vender’s trademark CT1 ViewSonic VSD241 制造商: ViewSonic Corporation 381 Brea Canyon Road, Walnut, CA 91789, USA 中国总经销: 优派科技(中国)有限公司 上海市外高桥保税区芬菊路308号10号厂房西侧 Smart Display / Smart Display / 桌上型平板電腦 / 桌上型平板电脑 Model No. (Numéro de Modèle / 產品型號 / 产品型号) : VS15197 Power Input (Alimentation / 輸入 / 输入) : 19Vdc , 3.42A Made in China / Fabrique én Chine / 製造地 中國 / 制造地 中国 This device complies with Part 15 of the FCC Rules. Operation is subject to the following two conditions: (1) This device may not cause harmful interference, (2) This device must accept any interference received, including interference that may cause undesired operation. CAN ICES-3 (B) / NMB-3 (B) S/N: PPPYYWWXXXXX Code 128(PPPYYWWXXXXX) FCC ID: GSS-VS15197 IC: 4280A-VS15197 SCT: RCPINxxxx-xxxx xxxxxxxxxxxxxx HCUI1001010-3A CONSUMO DE ENERGIA EN OPERACION: xx.xWh EN MODE DE ESPERA: x.xxWh E142692 CS70 LISTED I.T.E R31374 N768 Complies with IDA Standards DB101482

Report No.: EF/2013/40033 FCC ID: GSS-VS15197 Issue Date: May 28, 2013 IC: 4280A-VS15197 Unless otherwise stated the results shown in this test report refer only to the sample(s) tested and such sample(s) are retained for 90 days only. 除非另有說明，此報告結果僅對測試之樣品負責，同時此樣品僅保留90天。本報告未經本公司書面許可，不可部份複製。 This document is issued by the Company subject to its General Conditions of Service printed overleaf, available on request or accessible at www.sgs.com/terms_and_conditions.htm and, for elec- tronic format documents, subject to Terms and Conditions for Electronic Documents at www.sgs.com/terms_e-document.htm. Attention is drawn to the limitation of liability, indemnification and jurisdiction issues defined therein. Any holder of this document is advised that information contained hereon reflects the Company’s findings at the time of its intervention only and within the limits of Client’s instructions, if any. The Company’s sole responsibility is to its Client and this document does not exonerate parties to a transaction from exercising all their rights and obligations under the transaction documents. This document cannot be reproduced except in full, without prior written approval of the Company. Any unauthorized alteration, forgery or falsification of the content or ap- pearance of this document is unlawful and offenders may be prosecuted to the fullest extent of the law. SGS Taiwan Ltd. No.134,WuKungRoad,NewTaipeiIndustrialPark,WukuDistrict,NewTaipeiCity,Taiwan24803/新北市五股區新北產業園區五工路134號 台灣檢驗科技股份有限公司 t (886-2) 2299-3279 f (886-2) 2298-0488 www.tw.sgs.com Member of SGS Group APPENDIX 3 INTERNAL PHOTOGRAPHS OF EUT Report No.: EF/2013/40033 FCC ID: GSS-VS15197 Issue Date: May 28, 2013 IC: 4280A-VS15197 Unless otherwise stated the results shown in this test report refer only to the sample(s) tested and such sample(s) are retained for 90 days only. 除非另有說明，此報告結果僅對測試之樣品負責，同時此樣品僅保留90天。本報告未經本公司書面許可，不可部份複製。 This document is issued by the Company subject to its General Conditions of Service printed overleaf, available on request or accessible at www.sgs.com/terms_and_conditions.htm and, for elec- tronic format documents, subject to Terms and Conditions for Electronic Documents at www.sgs.com/terms_e-document.htm. Attention is drawn to the limitation of liability, indemnification and jurisdiction issues defined therein. Any holder of this document is advised that information contained hereon reflects the Company’s findings at the time of its intervention only and within the limits of Client’s instructions, if any. The Company’s sole responsibility is to its Client and this document does not exonerate parties to a transaction from exercising all their rights and obligations under the transaction documents. This document cannot be reproduced except in full, without prior written approval of the Company. Any unauthorized alteration, forgery or falsification of the content or ap- pearance of this document is unlawful and offenders may be prosecuted to the fullest extent of the law. SGS Taiwan Ltd. No.134,WuKungRoad,NewTaipeiIndustrialPark,WukuDistrict,NewTaipeiCity,Taiwan24803/新北市五股區新北產業園區五工路134號 台灣檢驗科技股份有限公司 t (886-2) 2299-3279 f (886-2) 2298-0488 www.tw.sgs.com Member of SGS Group Open View of EUT – 1 Open View of EUT – 2 Report No.: EF/2013/40033 FCC ID: GSS-VS15197 Issue Date: May 28, 2013 IC: 4280A-VS15197 Unless otherwise stated the results shown in this test report refer only to the sample(s) tested and such sample(s) are retained for 90 days only. 除非另有說明，此報告結果僅對測試之樣品負責，同時此樣品僅保留90天。本報告未經本公司書面許可，不可部份複製。 This document is issued by the Company subject to its General Conditions of Service printed overleaf, available on request or accessible at www.sgs.com/terms_and_conditions.htm and, for elec- tronic format documents, subject to Terms and Conditions for Electronic Documents at www.sgs.com/terms_e-document.htm. Attention is drawn to the limitation of liability, indemnification and jurisdiction issues defined therein. Any holder of this document is advised that information contained hereon reflects the Company’s findings at the time of its intervention only and within the limits of Client’s instructions, if any. The Company’s sole responsibility is to its Client and this document does not exonerate parties to a transaction from exercising all their rights and obligations under the transaction documents. This document cannot be reproduced except in full, without prior written approval of the Company. Any unauthorized alteration, forgery or falsification of the content or ap- pearance of this document is unlawful and offenders may be prosecuted to the fullest extent of the law. SGS Taiwan Ltd. No.134,WuKungRoad,NewTaipeiIndustrialPark,WukuDistrict,NewTaipeiCity,Taiwan24803/新北市五股區新北產業園區五工路134號 台灣檢驗科技股份有限公司 t (886-2) 2299-3279 f (886-2) 2298-0488 www.tw.sgs.com Member of SGS Group Open View of EUT –3 Open View of EUT –4 Report No.: EF/2013/40033 FCC ID: GSS-VS15197 Issue Date: May 28, 2013 IC: 4280A-VS15197 Unless otherwise stated the results shown in this test report refer only to the sample(s) tested and such sample(s) are retained for 90 days only. 除非另有說明，此報告結果僅對測試之樣品負責，同時此樣品僅保留90天。本報告未經本公司書面許可，不可部份複製。 This document is issued by the Company subject to its General Conditions of Service printed overleaf, available on request or accessible at www.sgs.com/terms_and_conditions.htm and, for elec- tronic format documents, subject to Terms and Conditions for Electronic Documents at www.sgs.com/terms_e-document.htm. Attention is drawn to the limitation of liability, indemnification and jurisdiction issues defined therein. Any holder of this document is advised that information contained hereon reflects the Company’s findings at the time of its intervention only and within the limits of Client’s instructions, if any. The Company’s sole responsibility is to its Client and this document does not exonerate parties to a transaction from exercising all their rights and obligations under the transaction documents. This document cann…

Text truncated - open the document above for the full version.

1 MAXIMUM PERMISSIBLE EXPOSURE (MPE) 1.1 STANDARD APPLICABLE According to §1.1307(b)(1), systems operating under the provisions of this section shall be operated in a manner that ensure that the public is not exposed to radio frequency energy level in excess of the Commission’s guideline. This is a Mobile device, the MPE is required. According to §1.1310 and §2.1093 RF exposure is calculated. Limits for Maximum Permissive Exposure (MPE) Frequency Range (MHz) Electric Field Strength (V/m) Magnetic Field Strength (A/m) Power Density (mW/cm 2 ) Averaging Time (minute) Limits for General Population/Uncontrolled Exposure 0.3-1.34 614 1.63 *(100) 30 1.34-30 824/f 2.19/f *(180/f 2 ) 30 30-300 27.5 0.073 0.2 30 300-1500 / / F/1500 30 1500-15000 / / 1.0 30 F = frequency in MHz * = Plane-wave equipment power density 1.2 MAXIMUM PERMISSIBLE EXPOSURE (MPE) EVALUATION 802.11b Cable loss = 0 Peak Power Output CH Frequency (MHz) Data Rate Required Limit 1 2 5.5 11 1 2412 18.49 18.36 18.19 18.07 1 Watt = 30 dBm 6 2437 18.72 18.57 18.44 18.30 1 Watt = 30 dBm 11 2462 18.87 18.74 18.59 18.45 1 Watt = 30 dBm Cable loss = 0 Average Power Output CH Frequency (MHz) Data Rate Required Limit 1 2 5.5 11 1 2412 15.39 15.24 15.08 14.92 1 Watt = 30 dBm 6 2437 15.62 15.47 15.33 15.17 1 Watt = 30 dBm 11 2462 15.79 15.65 15.52 15.40 1 Watt = 30 dBm *Note: Measured by power meter, cable loss as 11.952dB that offsets on the power meter. MPE Prediction (802.11b) Prediction of MPE limit at a given distance Equation from page 18 of OET Bulletin 65, Edition 97-01 S=PG/4πR 2 Where: S = Power density P = Power input to antenna G = Power gain of the antenna in the direction of interest relative to an isotropic radiator R = Distance to the center of radiation of the antenna Maximum peak output power at antenna input terminal: 18.87 (dBm) Maximum peak output power at antenna input terminal: 77.09034691 (mW) Duty cycle: 100 (%) Maximum Pav : 77.09034691 (mW) Antenna gain (typical): -1.37 (dBi) Maximum antenna gain: 0.72945751 (numeric) Prediction distance: 20 (cm) Prediction frequency: 2462 (MHz) MPE limit for uncontrolled exposure at prediction 1 (mW/cm2) Power density at predication frequency at 20 (cm) 0.011193 (mW/cm^2) Measurement Result The predicted power density level at 20 cm is 0.011193mW/cm 2 . This is below the uncontrolled exposure limit of 1mW/cm 2 at 2462MHz. 802.11g Cable loss = 0 Peak Power Output CH Frequency (MHz) Data Rate Required Limit 6 9 12 18 24 36 48 54 1 2412 20.87 20.74 20.61 20.49 20.35 20.23 20.09 19.95 1 Watt = 30 dBm 6 2437 21.51 21.38 21.26 21.12 21.00 20.87 20.72 20.55 1 Watt = 30 dBm 11 2462 21.29 21.14 21.00 20.87 20.73 20.59 20.46 20.33 1 Watt = 30 dBm Cable loss = 0 Average Power Output CH Frequenc y (MHz) Data Rate Required Limit 6 9 12 18 24 36 48 54 1 2412 13.47 13.33 13.19 13.05 12.91 12.77 12.65 12.52 1 Watt = 30 dBm 6 2437 14.57 14.42 14.28 14.14 14.01 13.88 13.74 13.59 1 Watt = 30 dBm 11 2462 13.65 13.51 13.37 13.23 13.10 12.97 12.83 12.69 1 Watt = 30 dBm *Note: Measured by power meter, cable loss as 12.109dB that offsets on the power meter. MPE Prediction (802.11g) Prediction of MPE limit at a given distance Equation from page 18 of OET Bulletin 65, Edition 97-01 S=PG/4πR 2 Where: S = Power density P = Power input to antenna G = Power gain of the antenna in the direction of interest relative to an isotropic radiator R = Distance to the center of radiation of the antenna Maximum peak output power at antenna input terminal: 21.51 (dBm) Maximum peak output power at antenna input terminal: 141.579378 (mW) Duty cycle: 100 (%) Maximum Pav : 141.579378 (mW) Antenna gain (typical): -1.37 (dBi) Maximum antenna gain: 0.72945751 (numeric) Prediction distance: 20 (cm) Prediction frequency: 2437 (MHz) MPE limit for uncontrolled exposure at prediction 1 (mW/cm2) Power density at predication frequency at 20 (cm) 0.020557 (mW/cm^2) Measurement Result The predicted power density level at 20 cm is 0.020557mW/cm2. This is below the uncontrolled exposure limit of 1mW/cm2 at 2437MHz. 802.11n_20M Cable loss = 0 Peak Power Output CH Frequency (MHz) Data Rate Required Limit 6.5 13 19.526 39 52 58.5 65 1 2412 20.29 20.17 20.05 19.91 19.76 19.62 19.51 19.38 1 Watt = 30 dBm 6 2437 20.57 20.45 20.29 20.14 20.02 19.88 19.75 19.64 1 Watt = 30 dBm 11 2462 20.74 20.62 20.48 20.34 20.17 20.04 19.86 19.72 1 Watt = 30 dBm Cable loss = 0 Average Power Output CH Frequency (MHz) Data Rate Required Limit 6.5 13 19.526 39 52 58.5 65 1 2412 12.00 11.86 11.73 11.59 11.45 11.33 11.19 11.05 1 Watt = 30 dBm 6 2437 12.14 12.00 11.86 11.73 11.59 11.44 11.30 11.15 1 Watt = 30 dBm 11 2462 12.29 12.15 12.01 11.87 11.75 11.64 11.50 12.36 1 Watt = 30 dBm *Note: Measured by power meter, cable loss as 12.146dB that offsets on the power meter. MPE Prediction (802.11 n_20M) Prediction of MPE limit at a given distance Equation from page 18 of OET Bulletin 65, Edition 97-01 S=PG/4πR 2 Where: S = Power density P = Power input to antenna G = Power gain of the antenna in the direction of interest relative to an isotropic radiator R = Distance to the center of radiation of the antenna Maximum peak output power at antenna input terminal: 20.74 (dBm) Maximum peak output power at antenna input terminal: 118.5768748 (mW) Duty cycle: 100 (%) Maximum Pav : 118.5768748 (mW) Antenna gain (typical): -1.37 (dBi) Maximum antenna gain: 0.72945751 (numeric) Prediction distance: 20 (cm) Prediction frequency: 2462 (MHz) MPE limit for uncontrolled exposure at prediction 1 (mW/cm2) Power density at predication frequency at 20 (cm) 0.017217 (mW/cm^2) Measurement Result The predicted power density level at 20 cm is 0.17217mW/cm2. This is below the uncontrolled exposure limit of 1mW/cm2 at 2462MHz.
