H38WL-200RWireless Microphone Receiver

SEIKAKU TECHNICAL GROUPLIMITED APR.16.2012 A3A4A5 3 SHOW -RS WL-200R/H SHOW_V1.3 WL-200R/H 0.035KG/1 105GNH00149(3:8) 6 NF03650 2 V1.3 12/04/16 NO 1 V1.2 11/10/24 User's Manual WL-200R/H/P WIRELESS MICROPHONE SYSTEM NF03650-1.3 SAFETY RELATED SYMBOLS CAUTION RISK OF ELECTRIC SHOCK DO NOT OPEN The symbol is used to indicate thatsome hazardous live terminals areinvolved within this apparatus, evenunder the normal operating conditions. The symbol is used in the service documentation to indicate that specificcomponent shall be only replaced bythe component specified in thatDocumentation for safety reasons. Protective grounding terminal. Alternating current /voltage. ON: Denotes the apparatus turns on. OFF: Denotes the apparatus turns off, bec-ause of using the single pole switch, be sureto unplug the AC power to prevent anyelectric shock before you proceed yourservice.WARNING : Describes precautions that should be observed to prevent the dangerof injury or death to the user.CAUTION : Describes precautions that should be observed to prevent danger of theapparatus. WARNING Power Supply Ensure the source voltage matches thevoltage of the power supply before turningON the apparatus. Unplug this apparatus during lightningstorms or when unused for long periodsof time. External Connection The external wiring connected to the outputhazardous live terminals requires installationby an instructed person, or the use of ready-made leads or cords. Do not Remove any Cover There are maybe some areas with highvoltages inside, to reduce the risk of electricshock, do not remove any cover if the powersupply is connected. The cover should be removed by the qualifiedpersonnel only. No user serviceable parts inside. Fuse To prevent a fire, make sure to use fuseswith specified standard (current, voltage,type). Do not use a different fuse or shortcircuit the fuse holder.Before replacing the fuse, turn OFF theapparatus and disconnected the powersource. Protective Grounding Make sure to connect the protectivegrounding to prevent any electric shockbefore turning ON the apparatus.Never cut off the internal or external pro-tective grounding wire or disconnect thewiring of protective grounding terminal. Operating Conditions Hazardous live terminal . Disposing of this product shouldnot be placed in municipal wasteand should be separate collection. This apparatus shall not be exposed todripping or splashing and that no objectsfilled with liquids, such as vases, shall beplaced on this apparatus. 1 8 Technical Specifications WIRELESS SYSTEM 2 Servicing Refer all servicing to qualified personnel. Toreduce the risk of electric shock, do notperform any servicing other than thatcontained in the operating instructions unlessyouarequalifiedtodoso. Servicing is req uired when the apparatus has been damaged in any way , such as powersupply cord or plug is damaged , liquid hasbeen spilled or objects have fallen into theapparatus, the apparatus has been exposed to rain or moisture , does not operatenormally, or has been dropped. To reduce the risk of fire or electric shock,do not expose this apparatus to rain ormoisture. Do not use this apparatus near water.Install in accordance with the manufacture-r'sinstructions. Do not install near any heat sources such as radiators, heat registers,stoves, or other apparatus (including am-plifiers) that produce heat. Do not blockany ventilation openings. IMPORTANT SAFETY INSTRUCTIONS Read these instructions.Keep these instructions.Heed all warnings. Only use attachments/accessories spec- ified by the manufacturer. Power Cord and Plug Do not defeat the safety purpose of thepolarized or grounding type plug.A polarized plug has two blades withone wider than the other. A groundingtype plug has two blades and a thirdgrounding prong. The wide blade or thethird prong are provided for your safety.If the provided plug does not fit into youroutlet, consult an electrician for replace-ment of the obsolete outlet. Protect the power cord from being walk-ed on or pinched particularly at plugs,convenience receptacles, and the point where they exit from the apparatus. Cleaning When the apparatus needs a cleaning, youcan blow off dust from the apparatus with Follow all instructions. No naked flame sources, such as lightedcandles, should be placed on the apparatus. ablowerorcleanwithragetc. Don't use solvents such as benzol, alcohol,or other fluids with very strong volat ility and flammability for clea ning the apparatus body. Clean only with dry cloth. The mains plug is used as the disconnect device,the disconnect device shall remain readilyoperable.Changes or modifications to this unit notexpressly approved by the party responsiblefor compliance could void the user's authorityto operate the equipment.NOTE: This equipment has been tested andfound to comply with the limits for a class Bdigital device, pursuant to Part 15 of the FCCRules .These limits are designed to providereasonable protection against harmful interference in a residential installation . Thisequipment generates, uses and can radiateradio frequency energy and , if not installed SHOW wireless receivers are certified under FCCRules part 15 and transmitters are certified underFCC Rules part 74.Licensing of SHOW equipmentis the user's responsibility and licensability dependson the user's classification,application and frequencyselected. FCC Rules and Regulations 7 Operating Instruction WL-200 consists of transmitter (microphone) and receiver. Automatically calibrate frequency to match up the frequencies of microphone and receiver 1. Red LED, Orange LED and a push-button equipped at bottom 2. If red LED always lights up, it means that the transmitter (microphone) is muted; if the red LED blinks, it means that the battery is of low level. 3. If the orange LED always illuminates, it means that the battery is of high level. If the orange LED blinks, it means that the IR frequency calibration needs confirming. 4. Press the push-button to power on the unit; pre…

Text truncated - open the document above for the full version.

Page 1 of 2 Type Designation: WL-200R External Photo Report Number: 17024818 001 Page 2 of 2 Type Designation: WL-200R External Photo Report Number: 17024818 001

25# A B C D / E SEIKAKU TECHNICAL GROUP LIMITED : 1:1 5520mm MAY.02.2012 SHOW WL-200R NI00039 (1:43) 0.01KG/100 This deviced complies with Part 15 of the FCC Rules. Operation is subject to the condition that this device dose not cause harmful interference. FCC ID:H38WL-200R 55.0 mm 20.0 mm

Label Location

Page 1 of 5 Type Designation: WL-200R Internal Photo Report Number: 17024818 001 Page 2 of 5 Type Designation: WL-200R Internal Photo Report Number: 17024818 001 Page 3 of 5 Type Designation: WL-200R Internal Photo Report Number: 17024818 001 Page 4 of 5 Type Designation: WL-200R Internal Photo Report Number: 17024818 001 Page 5 of 5 Type Designation: WL-200R Internal Photo Report Number: 17024818 001

Produkte Products Prüfbericht - Nr.: Test Report No. 17024818 001 Seite 2 von 15 Page 2 of 15 TEST SUMMARY 5.1.1 CONDUCTED EMISSION FOR FCC PART15 SUBPART B SECTION 15.107(A) RESULT: Passed 6.1.1 RADIATED EMISSION FOR FCC PART15 SUBPART B SECTION 15.109(A) RESULT: Passed Produkte Products Prüfbericht - Nr.: Test Report No. 17024818 001 Seite 3 von 15 Page 3 of 15 Contents 1. GENERAL REMARKS......................................................................................................... 4 1.1 COMPLEMENTARY MATERIALS.......................................................................................... 4 2. TEST SITES...................................................................................................................... 4 2.1 TEST FACILITIES............................................................................................................... 4 2.2 LIST OF TEST AND MEASUREMENT INSTRUMENTS............................................................... 5 2.3 TRACEABILITY.................................................................................................................. 5 2.4 CALIBRATION................................................................................................................... 5 2.5 MEASUREMENT UNCERTAINTY........................................................................................... 6 2.6 LOCATION OF ORIGINAL DATA........................................................................................... 6 2.7 STATUS OF FACILITY USED FOR TESTING........................................................................... 6 3. GENERAL PRODUCT INFORMATION.................................................................................... 7 3.1 PRODUCT FUNCTION AND INTENDED USE........................................................................... 7 3.2 RATINGS AND SYSTEM DETAILS........................................................................................ 7 3.3 INDEPENDENT OPERATION MODES.................................................................................... 8 3.4 NOISE GENERATING AND NOISE SUPPRESSING PARTS....................................................... 8 3.5 SUBMITTED DOCUMENTS.................................................................................................. 8 4. TEST SET-UP AND OPERATION MODES.............................................................................. 8 4.1 PRINCIPLE OF CONFIGURATION SELECTION........................................................................ 8 4.2 TEST OPERATION AND TEST SOFTWARE............................................................................ 8 4.3 SPECIAL ACCESSORIES AND AUXILIARY EQUIPMENT.......................................................... 8 4.4 COUNTERMEASURES TO ACHIEVE EMC COMPLIANCE......................................................... 9 4.5 TEST SETUP DIAGRAM......................................................................................................9 5 . TEST RESULTS E M I S S I O N ..................................................................................... 11 5.1 EMISSION IN THE FREQUENCY RANGE UP TO 30 MHZ....................................................... 11 5.1.1 Conducted Emission for FCC Part15 Subpart B Section 15.107(a) ..........................................11 6. EMISSION IN THE FREQUENCY RANGE ABOVE 30 MHZ...................................................... 12 6.1.1 Radiated Emission for FCC Part15 Subpart B Section 15.109(a) .............................................12 7. PHOTOGRAPHS OF THE TEST SET-UP.............................................................................. 13 8. LIST OF TABLES............................................................................................................. 15 9. LIST OF PHOTOGRAPHS.................................................................................................. 15 Produkte Products Prüfbericht - Nr.: Test Report No. 17024818 001 Seite 4 von 15 Page 4 of 15 1. General Remarks 1.1 Complementary Materials All attachments are integral parts of this test report. This applies especially to the following appendix: Appendix 1: Test Results 2. Test Sites 2.1 Test Facilities TÜV Rheinland (Guangdong) Ltd. EMC Laboratory Guangzhou Auto Market, Yuan Gang Section, Guangshan Road, Guangzhou, P.R. China FCC Registration No.: 833845 Industry Canada Test site No.: 2932C-1 The tests at the test site have been conducted under the supervision of a TÜV engineer. Produkte Products Prüfbericht - Nr.: Test Report No. 17024818 001 Seite 5 von 15 Page 5 of 15 2.2 List of Test and Measurement Instruments Table 1: List of Test and Measurement Equipment Kind of Equipment Manufacturer Type S/N Calibrated until Conducted emissions EMI Test Receiver Rohde & Schwarz ESCI 100178 2013-03-12 Artificial Mains Network Rohde & Schwarz ESH2-Z5 100114 2013-03-12 Pulse Limiter Rohde & Schwarz ESH3-Z2 100701 2013-03-12 Radiated emissions Spectrum Analyzer Rohde & Schwarz FSP30 100286 2013-03-12 EMI Test Receiver Rohde & Schwarz ESCI 100216 2013-03-12 Pre-Amplifier MITEQ AFS42- 00101800 1101599 2012-07-30 Trilog-Broadband Antenna Schwarzbeck VULB9168 209 2013-03-12 Double-Ridged Waveguide Horn Rohde & Schwarz HF 906 100385 2012-08-23 2.3 Traceability All measurement equipment calibrations are traceable to NIM (National Institute of Metrology) or where calibration is performed in other countries, to equivalent nationally recognized standards organizations. 2.4 Calibration Equipment requiring calibration is calibrated periodically by the manufacturer or according to manufacturer’s specifications. Additionally all equipment is verified for proper performance on a regular basics using in house standards or comparisons. Produkte Products Prüfbericht - Nr.: Test Report No. 17024818 001 Seite 6 von 15 Page 6 of 15 2.5 Measurement Uncertainty For a 95% confidence level, the measurement expanded uncertainties for defined systems, in ac…

Text truncated - open the document above for the full version.

Produkte Products Prüfbericht - Nr.: Test Report No. 17024818 001 Seite 13 von 15 Page 13 of 15 7. Photographs of the Test Set-Up Photograph 1: Set-up for Conducted Emissions Photograph 2: Set-up for Radiated Emissions, below 1GHz Produkte Products Prüfbericht - Nr.: Test Report No. 17024818 001 Seite 14 von 15 Page 14 of 15 Photograph 3: Set-up for Radiated Emissions, above 1GHz
