HCQ-IDTOUCH1Inovonics Wired Touchscreen Keypad

3.2.26 357-XXXXX-XX Rev A © Inovonics, 2025 - www.inovonics.com Inovonics Wired Touchscreen Keypad Installation Instructions 1 Overview The Inovonics Intrusion System IDTOUCH1 touchpad connects to the Gateway Mark II hybrid panel for reliable performance and intuitive control. Featuring a sleek, high-resolution seven-inch full-color display, it allows users to easily arm, disarm, and bypass the system while providing real- time system status and alerts. 1.1 Inovonics Contact Information If you have any problems with this procedure, contact Inovonics technical support: • E-mail: [email protected]. • Phone: (800) 782-2709. 1.2 IDTOUCH1 Touchpad Components Figure 1 IDTOUCH1 touchpad components 1.3 Operation LEDs The following LEDs are used to monitor touchpad operation: POWER: Lit when the touchpad is powered. COMMS: Lit when communicating with the Gateway Mark II. 1.4 Operation Buttons The following buttons are used for the touchpad operation: RESET: Used for a hard reset during troubleshooting. 1.5 Installation Notes • These products are designed to be installed and maintained by professional security technicians. • Products are tested for indoor use. • All products should be manually tested weekly. • The Gateway Mark II can only power and backup a single touchpad and meet the UL 24-hour battery backup requirement. 2 Mounting and Wiring 2.1 Mark and Drill Holes 1.Use the included touchscreen back plate onto the wall and mark two screw holes and the wire cutout. • Use a level to ensure the mount is • When mounting to plasterboard, drill two 7/64 inch (2.5mm) holes. • When mounting to masonry, drill two 1/4 inch (6mm) holes for the included wall anchors. 2.If the wire is being fed through the wall, drill an appropriately-sized hole in the wall for the wire to feed through 2.2 Mount the Touchpad Back Plate 1.Mount the included wall mount back plate to the wall using the included screws and anchors. Figure 2 Touchpad back plate mounting holes 2.3 Connect Primary Touchpad to the Gateway Mark II The Gateway Mark II connection terminal accepts one 16, 18, or 22-gauge wire, or up to two 18-gauge wires per terminal. Wiring between the graphic touchpad and the Gateway Mark II must comply with the maximum wiring length as follows. This cable length is based on a maximum allowed voltage drop of 3 Vdc at startup. If a longer run is required, install an additional power supply listed for Fire Protective Signaling, power limited and regulated (12 VDC nominal), with a For product and installation videos visit us at www.inovonics.com/videos or use the QR code below. ATouchscreenBGateway Mark II connection terminal CReset buttonDLEDs A B C E Maximum Cable Run Wire Length Between Panel and Touchpad Gauge (AWG) Less than 150 ft22 150 - 350 ft18 350 - 600 ft16 HVIN:IDTOUCH1 3.2.26 357-XXXXX-XX Rev A © Inovonics, 2025 - www.inovonics.com 2 battery backup at the end of the run at the touchpad. The maximum wire run length cannot exceed 2500 feet. To connect the primary touchpad to the Gateway Mark II: 1.Use the included female connector to wire the touchpad to the Gateway Mark II as shown in Figure 3, “Connect the primary touchpad to the Gateway Mark II.”. Figure 3 Connect the primary touchpad to the Gateway Mark II. 2.Feed cabling through one of the wiring knockouts in the Gateway Mark II. 3.Connect to one of the Gateway Mark II’s RS485 buses per the Gateway Mark II Installation and Operation Manual. 3 Connect Additional Touchpads to the Gateway Mark II The panel can only power the single primary touchpad. Use appropriately listed AC to DC power supplies for additional touchpads that meet the following specifications: • Input: 100-240V 50/60Hz. • Output: DC 12V, 1.5A, 18W. The external power supply ground and panel ground must be connected, and the last touchpad on a cable run longer than 500 feet must be terminated. To connect additional touchpads to the Gateway Mark II: 1.Use the included female connector to wire the touchpad’s data terminals to the Gateway Mark II as shown in Figure 4, “Connect additional touchpads to the Gateway Mark II.” 2.Wire the female connector to the power supply as shown in Figure 4, “Connect additional touchpads to the Gateway Mark II.”. Figure 4 Connect additional touchpads to the Gateway Mark II. 3.Feed cabling through one of the wiring knockouts in the Gateway Mark II. 4.Connect the data terminal to one of the Gateway Mark II’s RS485 buses per the Gateway Mark II Installation and Operation Manual. 5.Connect the power supply terminals to the power supply. 4 Mount the Touchpad to the Back Plate 1.Slide the touchpad onto the back plate in the opposite direction of the camera until you feel a click. Figure 5 Install the touchpad onto the back plate 5 Secure the Gateway Mark II Housing 1.Close and lock the housing door. 2.As desired, secure the door shut on one or both sides with a #8 sheet metal screw. 3.Secure the housing (left side shown) 6 Startup The IDTOUCH1 Touchpad will start up as soon as power is applied. For further instructions, see the Inovonics Intrusion System User Guide. 7 Specifications Dimensions: 7.75" x 4.5" x 0.5". Weight: 1 lb. Power requirement: 18W. WiFi: Wi-Fi 6, WPA-2, 2.5 gHz and 5 gHz. Operating environment: 32°F (0°C) to 120°F (49°C); 0% to 85% relative humidity, non condensing. Storage environment: -40°F (-40°C) to 158°F (70°C); 0% to 85% relative humidity, non condensing. Note: Inovonics supports recycling and reuse whenever possible. Please recycle these parts using a certified electronics recycler. To panel To panel To panel To panel To power supply To panel To panel To power supply FCC Warnning: This equipment has been tested and found to comply with the limits for a Class B digital device, pursuant to part 15 of the FCC Rules. These limits are designed to provide reasonable protection againstharmful interference in a residential installation. This equipment generates, uses and can radiateradio frequency energy and, if not installed and used in ac…

Text truncated - open the document above for the full version.

Shenzhen CTA Testing Technology Co., Ltd. Room 106, Building 1, Yibaolai Industrial Park, Qiaotou Community, Fuhai Street, Bao’an District, Shenzhen, China Shenzhen CTA Testing Technology Co., Ltd. Room 106, Building 1, Yibaolai Industrial Park, Qiaotou Community, Fuhai Street, Bao’an District, Shenzhen, China Tel:+86-755 2322 5875 E-mail:[email protected] Web:http://www.cta-test.cn RF Exposure MPE Report Reference No. ..................... : FCC ID. ........................................... : CTA26020600504 HCQ-IDTOUCH1 Compiled by ( position+printed name+signature) .. : File administrators Zoey Cao Supervised by ( position+printed name+signature) .. : Project Engineer Ace Chai Approved by ( position+printed name+signature) .. : RF Manager Eric Wang Date of issue ..................................... : Feb. 24, 2026 Testing Laboratory Name ............. : Shenzhen CTA Testing Technology Co., Ltd. Address ............................................ : Room 106, Building 1, Yibaolai Industrial Park, Qiaotou Community, Fuhai Street, Bao’an District, Shenzhen, China Applicant’s name ........................... : Inovonics Wireless Corporation Address ............................................ : 11000 Westmoor Circle Building 10 Westminster, CO 80021 United States Standard ........................................... : 47CFR §1.1310 47CFR §2.1091 KDB447498 D01 General RF Exposure Guidance v06 Shenzhen CTA Testing Technology Co., Ltd. All rights reserved. This publication may be reproduced in whole or in part for non-commercial purpses as long as the Shenzhen CTA Testing Technology Co., Ltd. is acknowledged as copyright owner and source of the material. Shenzhen CTA Testing Technology Co., Ltd. takes no responsibility for and will not assume liability for damages resulting from the reader's interpretation of the reproduced material due to its placement and context. Test item description .................... : Inovonics Wired Touchscreen Keypad Trade Mark ....................................... : N/A Manufacturer .................................... : Shenzhen Maxevis Technology Ltd. Model/Type reference ....................... : IDTOUCH1 Listed Models ................................... : N/A Rating ............................................... : DC 24V From external circuit Result ................................................ : PASS Report No.: CTA26020600504 Page 2 of 10 Shenzhen CTA Testing Technology Co., Ltd. Room 106, Building 1, Yibaolai Industrial Park, Qiaotou Community, Fuhai Street, Bao’an District, Shenzhen, China Tel:+86-755 2322 5875 E-mail:[email protected] Web:http://www.cta-test.cn T E S T R E P O R T Equipment under Test : Inovonics Wired Touchscreen Keypad Model /Type : IDTOUCH1 Listed Models : N/A Applicant : Inovonics Wireless Corporation Address : 11000 Westmoor Circle Building 10 Westminster, CO 80021 United States Manufacturer : Shenzhen Maxevis Technology Ltd. Address : Room 401/406, Building 4, Huajia Industrial Park, No. 5 Beiba Road, Hangcheng Street, Bao'an District, Shenzhen City, China. Test Result: PASS The test report merely corresponds to the test sample. It is not permitted to copy extracts of these test result without the written permission of the test laboratory. Report No.: CTA26020600504 Page 3 of 10 Shenzhen CTA Testing Technology Co., Ltd. Room 106, Building 1, Yibaolai Industrial Park, Qiaotou Community, Fuhai Street, Bao’an District, Shenzhen, China Tel:+86-755 2322 5875 E-mail:[email protected] Web:http://www.cta-test.cn Contents 1 TEST STANDARDS ............................................................................................................ 4 2 SUMMARY .......................................................................................................................... 5 2.1 General Remarks .................................................................................................... 5 2.2 Product Description ................................................................................................. 5 2.3 Special Accessories ................................................................................................ 6 2.4 Modifications ........................................................................................................... 6 3 TEST ENVIRONMENT ....................................................................................................... 7 3.1 Address of the test laboratory ................................................................................. 7 3.2 Test Facility ............................................................................................................. 7 3.3 Statement of the measurement uncertainty ............................................................ 7 4 Test limit .............................................................................................................................. 8 4.1 Requirement ........................................................................................................... 8 4.2 MPE Calculation Method ........................................................................................ 8 4.3 Conducted Power Results ...................................................................................... 8 4.4 Manufacturing tolerance ......................................................................................... 9 4.5 Standalone MPE Result .......................................................................................... 9 4.6 Simultaneous Transmission for MPE Result ........................................................ 10 5 Conclusion ......................................................................................................................... 10 Report No.: CTA26020600504 Page 4 of 10 Shenzhen CTA Testing Technology Co., Ltd. Room 106, Building 1, Yibaolai Industrial Park, Qiaotou Community, Fuhai Street, Bao’an District, Shenzhen, China Tel:+86-755 2322 5875 E-mail:cta@cta-test…

Text truncated - open the document above for the full version.

FCC ID:HCQ-IDTOUCH1 Test Setup Photos of the EUT FCC ID:HCQ-IDTOUCH1

1. Antenna Description: Antenna type PIFA antenna Model IDTOUCH1 Frequency range 2400-2500MHz Manufacturer 8 Limited Address Unit AA, 16-18 Taylors Road Morningside Auckland, 1025 New Zealand ANT Peak Gain 2.0 dBi 2. Antenna Photo: Length: 16.93mm Width: 26.19mm 3. Test Equipment & Conditions 3.1 Test instrument VSWR is tested using Agilent E5071B connected to a hand mechanism, and the status is free space. 3.2 Test environment and methods 4．Antenna Radiation Pattern 2400MHz 2450MHz 2500MHz

Shenzhen CTA Testing Technology Co., Ltd. Room 106, Building 1, Yibaolai Industrial Park, Qiaotou Community, Fuhai Street, Bao’an District, Shenzhen, China Shenzhen CTA Testing Technology Co., Ltd. Room 106, Building 1, Yibaolai Industrial Park, Qiaotou Community, Fuhai Street, Bao’an District, Shenzhen, China Tel:+86-755 2322 5875 E-mail:[email protected] Web:http://www.cta-test.cn FCC PART 15 SUBPART C TEST REPORT FCC PART 15.247 Report Reference No. ...................: FCC ID. ......................................... : CTA26020600501 HCQ-IDTOUCH1 Compiled by ( position+printed name+signature) : File administrators Zoey Cao Supervised by ( position+printed name+signature) : Project Engineer Ace Chai Approved by ( position+printed name+signature) : RF Manager Eric Wang Date of issue ...................................: Feb. 24, 2026 Testing Laboratory Name .............: Shenzhen CTA Testing Technology Co., Ltd. Address ..........................................: Room 106, Building 1, Yibaolai Industrial Park, Qiaotou Community, Fuhai Street, Bao’an District, Shenzhen, China Applicant’s name...........................: Inovonics Wireless Corporation Address ...........................................: 11000 Westmoor Circle Building 10 Westminster, CO 80021 United States Test specification ......................... : Standard ..........................................: FCC Part 15.247 Shenzhen CTA Testing Technology Co., Ltd. All rights reserved. This publication may be reproduced in whole or in part for non-commercial purposes as long as the Shenzhen CTA Testing Technology Co., Ltd. is acknowledged as copyright owner and source of the material. Shenzhen CTA Testing Technology Co., Ltd. takes no responsibility for and will not assume liability for damages resulting from the reader's interpretation of the reproduced material due to its placement and context. Equipment description ................ : Inovonics Wired Touchscreen Keypad Trade Mark ......................................: N/A Manufacturer ...................................: Shenzhen Maxevis Technology Ltd. Model/Type reference .....................: IDTOUCH1 Listed Models ..................................: N/A Modulation ......................................: GFSK Frequency .......................................: From 2402MHz to 2480MHz Ratings ............................................: DC 24V From external circuit Result ..............................................: PASS Report No.: CTA26020600501 Page 2 of 39 Shenzhen CTA Testing Technology Co., Ltd. Room 106, Building 1, Yibaolai Industrial Park, Qiaotou Community, Fuhai Street, Bao’an District, Shenzhen, China Tel:+86-755 2322 5875 E-mail:[email protected] Web:http://www.cta-test.cn T E S T R E P O R T Equipment under Test : Inovonics Wired Touchscreen Keypad Model /Type : IDTOUCH1 Listed Models : N/A Applicant : Inovonics Wireless Corporation Address : 11000 Westmoor Circle Building 10 Westminster, CO 80021 United States Manufacturer : Shenzhen Maxevis Technology Ltd. Address : Room 401/406, Building 4, Huajia Industrial Park, No. 5 Beiba Road, Hangcheng Street, Bao'an District, Shenzhen City, China. Test Result: PASS The test report merely corresponds to the test sample. It is not permitted to copy extracts of these test result without the written permission of the test laboratory. Report No.: CTA26020600501 Page 3 of 39 Shenzhen CTA Testing Technology Co., Ltd. Room 106, Building 1, Yibaolai Industrial Park, Qiaotou Community, Fuhai Street, Bao’an District, Shenzhen, China Tel:+86-755 2322 5875 E-mail:[email protected] Web:http://www.cta-test.cn Contents 1 TEST STANDARDS ...................................................................................................................................... 4 2 SUMMARY .................................................................................................................................................... 5 2.1 General Remarks .............................................................................................................................. 5 2.2 Product Description* ......................................................................................................................... 5 2.3 Equipment Under Test ...................................................................................................................... 5 2.4 Short description of the Equipment under Test (EUT) ..................................................................... 5 2.5 EUT configuration ............................................................................................................................. 5 2.6 EUT operation mode......................................................................................................................... 5 2.7 Block Diagram of Test Setup ............................................................................................................ 6 2.8 Related Submittal(s) / Grant (s) ........................................................................................................ 6 2.9 Modifications ..................................................................................................................................... 6 3 TEST ENVIRONMENT ................................................................................................................................. 7 3.1 Address of the test laboratory ........................................................................................................... 7 3.2 Test Facility ....................................................................................................................................... 7 3.3 Environmental conditions ................................................................................................................. 7 3.4 Summary of measurement results .................................................................................................... …

Text truncated - open the document above for the full version.

1 FCC Appendix RF Test Data for BLE FCC ID : HCQ-IDTOUCH1 Company : Inovonics Wireless Corporation EUT : Inovonics Wired Touchscreen Keypad Model Number : IDTOUCH1 Report No. : CTA26020600501 Reviewed By : Eric Wang 2 Appendix A: DTS Bandwidth Test Result TestMode Antenna Freq(MHz) DTS BW [MHz] FL[MHz] FH[MHz] Limit[MHz] Verdict BLE_1M Ant1 2402 0.648 2401.696 2402.344 0.5 PASS 2440 0.648 2439.688 2440.336 0.5 PASS 2480 0.660 2479.684 2480.344 0.5 PASS 3 Test Graphs BLE_1M_Ant1_2402 BLE_1M_Ant1_2440 BLE_1M_Ant1_2480 4 5 Appendix B: Occupied Channel Bandwidth Test Result TestMode Antenna Freq(MHz) OCB [MHz] FL[MHz] FH[MHz] Limit[MHz] Verdict BLE_1M Ant1 2402 1.0042 2401.5158 2402.5200 --- --- 2440 1.0126 2439.5162 2440.5288 --- --- 2480 1.0128 2479.5151 2480.5279 --- --- 6 Test Graphs BLE_1M_Ant1_2402 BLE_1M_Ant1_2440 BLE_1M_Ant1_2480 7 8 Appendix C: Maximum conducted output power Test Result Peak TestMode Antenna Freq(MHz) Conducted Peak Powert[dBm] Conducted Limit[dBm] Verdict BLE_1M Ant1 2402 0.23 ≤30 PASS 2440 -0.39 ≤30 PASS 2480 -0.63 ≤30 PASS 9 Appendix D: Maximum power spectral density Test Result TestMode Antenna Freq(MHz) Result[dBm/3kHz] Limit[dBm/3kHz] Verdict BLE_1M Ant1 2402 -15.55 ≤8.00 PASS 2440 -16.74 ≤8.00 PASS 2480 -16.14 ≤8.00 PASS 10 Test Graphs BLE_1M_Ant1_2402 BLE_1M_Ant1_2440 BLE_1M_Ant1_2480 11 12 Appendix E: Band edge measurements Test Result TestMode Antenna ChName Freq(MHz) RefLevel[dBm] Result[dBm] Limit[dBm] Verdict BLE_1M Ant1 Low 2402 0.17 -50.14 ≤-19.83 PASS High 2480 -1.16 -51.07 ≤-21.16 PASS 13 Test Graphs BLE_1M_Ant1_Low_2402 BLE_1M_Ant1_High_2480 14 Appendix F: Conducted Spurious Emission Test Result TestMode Antenna Freq(MHz) FreqRange [MHz] RefLevel [dBm] Result[dBm] Limit[dBm] Verdict BLE_1M Ant1 2402 Reference -0.28 -0.28 --- PASS 30~1000 -0.28 -67.2 ≤-20.28 PASS 1000~26500 -0.28 -41.2 ≤-20.28 PASS 2440 Reference -1.84 -1.84 --- PASS 30~1000 -1.84 -67.36 ≤-21.84 PASS 1000~26500 -1.84 -41.12 ≤-21.84 PASS 2480 Reference -2.21 -2.21 --- PASS 30~1000 -2.21 -68.21 ≤-22.21 PASS 1000~26500 -2.21 -43.53 ≤-22.21 PASS 15 Test Graphs BLE_1M_Ant1_2402_0~Reference BLE_1M_Ant1_2402_30~1000 BLE_1M_Ant1_2402_1000~26500 16 BLE_1M_Ant1_2440_0~Reference BLE_1M_Ant1_2440_30~1000 17 BLE_1M_Ant1_2440_1000~26500 BLE_1M_Ant1_2480_0~Reference BLE_1M_Ant1_2480_30~1000 18 BLE_1M_Ant1_2480_1000~26500 19 Appendix G: Duty Cycle Test Result TestMode Antenna Freq(MHz) ON Time [ms] Period [ms] X DC [%] xFactor Limit Verdict BLE_1M Ant1 2402 0.42 0.63 0.6667 66.67 1.76 --- --- 2440 0.41 0.62 0.6613 66.13 1.80 --- --- 2480 0.41 0.62 0.6613 66.13 1.80 --- --- 20 Test Graphs BLE_1M_Ant1_2402 BLE_1M_Ant1_2440 BLE_1M_Ant1_2480 21 22 Appendix H: Emissions in Restricted Bands Test Result TestMode Antenna ChName Freq(MHz) Detector Freq [MHz] Result [dBm] Gain [dB] DC Factor [dB] Result [dBuV/m] Limit [dBuV/m] Verdict BLE_1M Ant1 Low 2402 AV 2310.000 -59.59 2.00 1.76 39.37 ≤54 PASS AV 2378.855 -58.44 2.00 1.76 40.52 ≤54 PASS AV 2390.000 -58.88 2.00 1.76 40.08 ≤54 PASS Peak 2310.000 -51.94 2.00 0.00 45.26 ≤74 PASS Peak 2368.040 -48.03 2.00 0.00 49.17 ≤74 PASS Peak 2390.000 -51.47 2.00 0.00 45.73 ≤74 PASS High 2480 AV 2483.500 -57.3 2.00 1.80 41.70 ≤54 PASS AV 2484.160 -57.16 2.00 1.80 41.84 ≤54 PASS AV 2500.000 -59.18 2.00 1.80 39.82 ≤54 PASS Peak 2483.500 -50.88 2.00 0.00 46.32 ≤74 PASS Peak 2484.560 -43.47 2.00 0.00 53.73 ≤74 PASS Peak 2500.000 -50.12 2.00 0.00 47.08 ≤74 PASS Note： 1. The limit in dBm for average detector is conversion from 54dBuV/m, according to 15.209(a). The limit in dBm for peak detector is 20dB above the limit of average detector in dBm. 23 Test Graphs BLE_1M_Ant1_Low_2402_AV BLE_1M_Ant1_Low_2402_Peak BLE_1M_Ant1_High_2480_AV 24 BLE_1M_Ant1_High_2480_Peak

Shenzhen CTA Testing Technology Co., Ltd. Room 106, Building 1, Yibaolai Industrial Park, Qiaotou Community, Fuhai Street, Bao’an District, Shenzhen, China Shenzhen CTA Testing Technology Co., Ltd. Room 106, Building 1, Yibaolai Industrial Park, Qiaotou Community, Fuhai Street, Bao’an District, Shenzhen, China Tel:+86-755 2322 5875 E-mail:[email protected] Web:http://www.cta-test.cn FCC PART 15 SUBPART C TEST REPORT FCC PART 15.247 Report Reference No. .................... : FCC ID. .......................................... : CTA26020600503 HCQ-IDTOUCH1 Compiled by ( position+printed name+signature) . : File administrators Zoey Cao Supervised by ( position+printed name+signature) . : Project Engineer Ace Chai Approved by ( position+printed name+signature) . : RF Manager Eric Wang Date of issue .................................... : Feb. 24, 2026 Testing Laboratory Name ............. : Shenzhen CTA Testing Technology Co., Ltd. Address ............................................ : Room 106, Building 1, Yibaolai Industrial Park, Qiaotou Community, Fuhai Street, Bao’an District, Shenzhen, China Applicant’s name ........................... : Inovonics Wireless Corporation Address ............................................ : 11000 Westmoor Circle Building 10 Westminster, CO 80021 United States Test specification.......................... : Standard .......................................... : FCC Part 15.247 TRF Originator ................................. : Shenzhen CTA Testing Technology Co., Ltd. Shenzhen CTA Testing Technology Co., Ltd. All rights reserved. This publication may be reproduced in whole or in part for non-commercial purposes as long as the Shenzhen CTA Testing Technology Co., Ltd. is acknowledged as copyright owner and source of the material. Shenzhen CTA Testing Technology Co., Ltd. takes no responsibility for and will not assume liability for damages resulting from the reader's interpretation of the reproduced material due to its placement and context. Test item description .................... : Inovonics Wired Touchscreen Keypad Trade Mark ....................................... : N/A Manufacturer .................................... : Shenzhen Maxevis Technology Ltd. Model/Type reference ...................... : IDTOUCH1 Listed Models ................................... : N/A Modulation Type .............................. : CCK/DSSS/OFDM Operation Frequency ....................... : From 2412 - 2462MHz Rating ............................................... : DC 24V From external circuit Result ............................................... : PASS Report No.: CTA26020600503 Page 2 of 34 Shenzhen CTA Testing Technology Co., Ltd. Room 106, Building 1, Yibaolai Industrial Park, Qiaotou Community, Fuhai Street, Bao’an District, Shenzhen, China Tel:+86-755 2322 5875 E-mail:[email protected] Web:http://www.cta-test.cn T E S T R E P O R T Equipment under Test : Inovonics Wired Touchscreen Keypad Model /Type : IDTOUCH1 Listed Models : N/A Applicant : Inovonics Wireless Corporation Address : 11000 Westmoor Circle Building 10 Westminster, CO 80021 United States Manufacturer : Shenzhen Maxevis Technology Ltd. Address : Room 401/406, Building 4, Huajia Industrial Park, No. 5 Beiba Road, Hangcheng Street, Bao'an District, Shenzhen City, China. Test Result: PASS The test report merely corresponds to the test sample. It is not permitted to copy extracts of these test result without the written permission of the test laboratory. Report No.: CTA26020600503 Page 3 of 34 Shenzhen CTA Testing Technology Co., Ltd. Room 106, Building 1, Yibaolai Industrial Park, Qiaotou Community, Fuhai Street, Bao’an District, Shenzhen, China Tel:+86-755 2322 5875 E-mail:[email protected] Web:http://www.cta-test.cn Contents 1 TEST STANDARDS ...................................................................................................................................... 4 2 SUMMARY .................................................................................................................................................... 5 2.1 General Remarks .............................................................................................................................. 5 2.2 Product Description .......................................................................................................................... 5 2.3 Equipment Under Test ...................................................................................................................... 5 2.4 Short description of the Equipment under Test (EUT) ..................................................................... 5 2.5 EUT configuration ............................................................................................................................. 6 2.6 EUT operation mode......................................................................................................................... 6 2.7 Block Diagram of Test Setup ............................................................................................................ 6 2.8 Related Submittal(s) / Grant (s) ........................................................................................................ 6 2.9 Modifications ..................................................................................................................................... 6 3 TEST ENVIRONMENT ................................................................................................................................. 7 3.1 Address of the test laboratory ........................................................................................................... 7 3.2 Test Facility ....................................................................................................................................... 7 3.3 Environmental conditions ................................................................................................................. 7 3.4 Test…

Text truncated - open the document above for the full version.

31 11N20SISO_Ant1_2412_1000~26500 11N20SISO_Ant1_2437_0~Reference 11N20SISO_Ant1_2437_30~1000 32 11N20SISO_Ant1_2437_1000~26500 11N20SISO_Ant1_2462_0~Reference 33 11N20SISO_Ant1_2462_30~1000 11N20SISO_Ant1_2462_1000~26500 34 Appendix G: Duty Cycle Test Result TestMode Antenna Frequency[MHz] Transmission Duration [ms] Transmission Period [ms] Duty Cycle [%] DC Factor [dB] T Factor [dB] 11B Ant1 2412 8.35 8.39 99.52 0.02 0.12 2437 8.35 8.40 99.40 0.03 0.12 2462 8.35 8.40 99.40 0.03 0.12 11G Ant1 2412 0.15 0.20 75.00 1.25 6.67 2437 0.15 0.20 75.00 1.25 6.67 2462 0.15 0.20 75.00 1.25 6.67 11N20SISO Ant1 2412 0.18 0.22 81.82 0.87 5.56 2437 0.17 0.22 77.27 1.12 5.88 2462 0.18 0.23 78.26 1.06 5.56 35 Test Graphs 11B_Ant1_2412 11B_Ant1_2437 11B_Ant1_2462 36 11G_Ant1_2412 11G_Ant1_2437 37 11G_Ant1_2462 11N20SISO_Ant1_2412 11N20SISO_Ant1_2437 38 11N20SISO_Ant1_2462 39 Appendix H: Emissions in Restricted Bands Test Result TestMode Antenna ChName Frequency[MHz] Detector Freq [MHz] Result [dBm] Gain [dB] DC Factor [dB] Result [dBuV/m] Limit [dBuV/m] Verdict 11B Ant1 Low 2412 AV 2310.000 -59.91 2.00 0.02 37.31 ≤54 PASS AV 2385.800 -55.86 2.00 0.02 41.36 ≤54 PASS AV 2390.000 -56.93 2.00 0.02 40.29 ≤54 PASS Peak 2310.000 -50.89 2.00 0.00 46.31 ≤74 PASS Peak 2385.410 -47.14 2.00 0.00 50.06 ≤74 PASS Peak 2390.000 -47.16 2.00 0.00 50.04 ≤74 PASS High 2462 AV 2483.500 -57.25 2.00 0.03 39.98 ≤54 PASS AV 2488.070 -55.98 2.00 0.03 41.25 ≤54 PASS AV 2500.000 -57.66 2.00 0.03 39.57 ≤54 PASS Peak 2483.500 -49.85 2.00 0.00 47.35 ≤74 PASS Peak 2488.950 -47.34 2.00 0.00 49.86 ≤74 PASS Peak 2500.000 -50.09 2.00 0.00 47.11 ≤74 PASS 11G Ant1 Low 2412 AV 2310.000 -59.65 2.00 1.25 38.80 ≤54 PASS AV 2…
