1.17.13 06431B © Inovonics, 2013 - www.inovonics.com EN1252 Extended Range Universal TransmitterInstallation Instructions1 OverviewThe EN1252 extended range universal transmitter provides five times the power of standard Inov onics universal transmitters. To support the increased power, the EN1252 can operate using an external power source or the internal battery. The unit is designed for use with any standard contact or sensor that provides a contact closure – normally open or closed – and includes connections for two alarm inputs as well as tamper and reset.Note: The EN1252 requires use of a serial receiver or network coordinator, as well as an a pplication designed to support advanced functionality.1.1 Inovonics Contact InformationIf you have any problems with this procedure, contact Inovonics technical services: • E-mail: [email protected]• Phone: (800) 782-2709; (303) 939-9336 1.2 EN1252 Internal Components Figure 1 EN1252 internal components 1.3 What’s In the Carton • One 3.0V lithium battery, Inovonics part number BAT604• Three drywall anchors• Three mounting screws• Two selection jumpers 2 Installation and Startup2.1 Installation Notes • These products are designed to be maintained by professional security technicians • Products are tested for indoor use• All products should be manually tested weekly 2.2 Install the Battery 1. Pry the top lip of the mounting bracket up, and lift the bracket off of the transmitter. 2. Use your thumb to depress the housing release tab on the bottom of the transmitter; separate the housing. 3. Install the battery. 2.3 Connect Input WiringThe transmitter has a three-term inal contact block that can connect inputs from one or two external contact loops. The middle terminal is a ground, wh ich is shared by both contact loops. Input one can be configured for either a normally open or a normally closed contact loop using the NO/NC selection pins; input two is always normally closed. 4. Connect cabling to input one and/or input two, as desired. 2.4 Select Input TypeThe N/O-N/C selection pins allow the choice of a normally open or normally closed state for the c ontact circuit wired to the input one terminal. The terminal is shipped set for normally closed, with no selection jumper on the N/O selections pins. If you need the input one terminal set for normally closed, no action is needed; skip to 2.5, “Enable/Disable Housing Tamper”.5. Place a selection jumper on the selection pins to select normally open. 2.5 Enable/Disable Housing Tamper The tamper disable selection pins allow the housing tamper to be disabled. If you do not wish to disable the tamper, no action is needed; skip to 2.6, “Register the EN1252”. If you wish to disable the housing tamper:6. Place a selection jumper on the tamper disable selection pins to disable the housing tamper. 7. Press the reset button to complete configuration. Caution: When pressing the reset button, make sure you don’t also touch any selection pins. Touching selection pins while pressing the reset button can inadvertently set the EN1252 to an undesired configuration. 2.6 Register the EN1252Transmitters must be registered with the system in order to be monitored and supervised. When su pervised, the transmitter will send a check-in message to the re ceiver. Transmitters will send a check-in message every three mi nutes. Each transmitter has a unique factory-programmed identification number.Note: Refer to the receiver installation instructions for details about registering a transmitter.8. When prompted by the receiver to reset transmitter, press the reset button. 9. Replace the cover. Caution: The EN1252 should be tested after registration to ensure operation. To test the EN1252, activate each of the conditions and ensure an appropriate response.2.7 Mount the EN125210. Mount the bracket on the wall with the screws provided so that the catch is on the bottom. 11. Clip the transmitter onto the bracket. Hook the bottom catch first, then press the top into place. 3 SpecificationsDimensions: 3.5x1.7x0.9”Weight: 1.9 ozTypical battery life: 1 – 2 years (This does not include current drawn by external devices)Internal battery type: 3.0V lith ium battery, Inovonics part number BAT604RF output power: 24 dBm (250 milliwatts) equivalent isotropically radiated powerOperating environment: Temperature: -4°F to 140°F using internal battery (-40°F to 185°F using appropriate external power source)Humidity: Up to 90% (non-condensing)Market: North AmericaEchoStream® frequency: 902-928 MHz, Frequency hopping spread spectrumRegulatory compliance: FCC, Industry Canada, RoHSNote: Specifications and data are subject to change without notice. A Reset button B Tamper disable selection pins C Input two terminal D Ground terminal E Input one terminal F NO/NC selection pins G Housing tamper button A D C E F G B 1.17.13 06431B © Inovonics, 2013 - www.inovonics.com 4 Television and Radio InterferenceThis equipment has been tested and found to comply with the limits for a Class B digital device, pursuant to Part 15 of the FCC Rules. These limits are des igned to provide reasonable protection against harmful inte rference in a residential installation. This equipment generates, uses and can radiate radio frequency energy and, if not installed and used in accordance with the instructions, may cause harmful interference to radio communications. However, there is no guarantee that interference will not occur in a particular installation. If this equipment does cause harmful interference to radio or television reception, wh ich can be determined by turning the equipment off and on, the user is encouraged to try to correct the interference by one or more of the following measures: • Reorient or relocate the receiving antenna.• Increase the separation between the equipment and receiver. • Connect the equipment into an outlet on a circuit different from that to which the receiver is connected. • Consult the dealer or an exper ienced radio/TV technician fo…

Text truncated - open the document above for the full version.

PROPRIETARY & CONFIDENTIAL DOCUMENTATION © 2013 The information contained in this document is proprietary in nature and is confidential to and the sole property of Inovonics Corporation. This document may not to be reproduced or redistributed without prior written permission from Inovonics Corporation. Page 1 of 2 Request for Confidentiality Date: January 3, 2012 Subject: Confidentiality Request for: _____FCC ID: HCQ3B6OT9HPT______ Pursuant to FCC 47 CRF 0.457(d) and 0.459 and IC RSP-100, Section 10, the applicant requests that a part of the subject FCC application be held confidential. Type of Confidentiality Requested Exhibit Short Term Permanent Block Diagrams Short Term External Photos Short Term Permanent* 1 Internal Photos Short Term Permanent Operation Description/Theory of Operation Short Term Permanent Parts List & Placement/BOM Short Term Permanent Tune-Up Procedure Short Term Permanent Schematics Short Term Test Setup Photos Short Term Permanent* User’s Manual *Note: ______(Insert Explanation as Necessary)______ ___Inovonics Wireless Corporation____ has spent substantial effort in developing this product and it is one of the first of its kind in industry. Having the subject information easily available to "competition" would negate the advantage they have achieved by developing this product. Not protecting the details of the design will result in financial hardship. 1 - The asterisked items (*) require further justification before permanent confidentiality will be allowed. These also currently require review by the FCC under their Permit-But-Ask policy before the grant is issued and can delay completion of an application. Further justification should be added to the note above. One such example for a potted device would be: “The EUT is FULLY potted using a non-removable epoxy based material. Removal of potting material causes irreparable damage to internal circuitry. See photographs exhibits that outline the device before and after potting.” PROPRIETARY & CONFIDENTIAL DOCUMENTATION © 2013 The information contained in this document is proprietary in nature and is confidential to and the sole property of Inovonics Corporation. This document may not to be reproduced or redistributed without prior written permission from Inovonics Corporation. Page 2 of 2 Permanent Confidentiality: The applicant requests the exhibits listed above as permanently confidential be permanently withheld from public review due to materials that contain trade secrets and proprietary information not customarily released to the public. Short-Term Confidentiality: The applicant requests the exhibits selected above as short term confidential be withheld from public view for a period of ___180 2 ___ days from the date of the Grant of Equipment Authorization and prior to marketing. This is to avoid premature release of sensitive information prior to marketing or release of the product to the public. Applicant is also aware that they are responsible to notify ACB in the event information regarding the product or the product is made available to the public. ACB will then release the documents listed above for public disclosure pursuant to FCC Public Notice DA 04-1705. NOTE for Industry Canada Applications: The applicant understands that until such time that IC distinguishes between Short Term and Permanent Confidentiality, either type of marked exhibit above will simply be marked Confidential when submitted to IC. Sincerely, By: __Mark Hassebrock, Compliance Engineer___ (Signature/Title 2 ) (Print name) C1212003-001 X2 2 - Must be signed by applicant contact given for applicant on the FCC site, or by the authorized agent if an appropriate authorized agent letter has been provided. Letters should be placed on appropriate letterhead.

PROPRIETARY & CONFIDENTIAL DOCUMENTATION © 2013 The information contained in this document is proprietary in nature and is confidential to and the sole property of Inovonics Corporation. This document may not to be reproduced or redistributed without prior written permission from Inovonics Corporation. Page 1 of 2 Inovonics – EN1252 Date: December 28, 2012 Re: Inovonics, Model: EN1252 FCC Modular Transmitter Approval FCC ID: HCQ3B6OT9HPT To Whom It May Concern; The following information is being provided per the requirements of FCC CFR 47, Part 15.212 regarding Singular Modular Transmitters. Inovonics, Model: EN1252, is a complete, independent RF module which complies with the applicable rules and policies defined FCC Part 15.212 and 15.247 for a Singular Modular Transmitter. The following numbered items correspond to similarly numbered paragraphs in 15.212 (a). Each item is a response to the criteria specified in 15.212 (a). Inovonics has provided supporting documentation where applicable. See references below. 1. Tx Shielding  The EN1252 has an integral RF Shield which provides isolation between the radio elements and surrounding equipment.  Photographs with the shield installed and removed have been included in the submittal package. Refer to Inovonics document number: C1212006-001. 2. Modulation/Data Input Buffering  The EN1252 processes all input data via on-board circuitry. The end-user has no direct control of transmitter characteristics or modulation. 3. Onboard Power Regulation  The EN1252 has been designed with a separate RF Tx power regulation circuit.  Refer to Inovonics Block Diagram doc no: C1212004-001, Schematic doc no: C1212011-001 and Photographs doc no: C1212006-001. 4. Antenna Connection Requirement  The EN1252 has been designed with a permanently attached RF Tx antenna which has no end- user controls.  Refer to Inovonics Block Diagram doc no: C1212004-001, Schematic doc no: C1212011-001 and Photographs doc no: C1212006-001. PROPRIETARY & CONFIDENTIAL DOCUMENTATION © 2013 The information contained in this document is proprietary in nature and is confidential to and the sole property of Inovonics Corporation. This document may not to be reproduced or redistributed without prior written permission from Inovonics Corporation. Page 2 of 2 5. Stand-Alone Compliance  The EN1252 module has been tested and found to meet the applicable FCC Pt 15 compliance criteria in a stand-alone configuration. Compliance testing was performed at a third party, NVLAP certified facility – Intertek.  Refer to Inovonics EMC Test Report, Inovonics doc no: C1212012-001. 6. Labeling  A FCC ID label is permanently affixed to each unit at the time of manufacture. Information is also clearly presented in the Inovonics Installation/User Manual, doc no: C1212014-001.  Refer to Inovonics FCC Label drawing, doc no: C1212007-001. 7. Compliance to Applicable Regulations & Compliance Instructions  The EN1252 module complies with all specific rules applicable to RF Transmitters as specified in FCC Pt 15.212 and 15.247. Inovonics, as the FCC Grantee, shall provide comprehensive instructions explaining compliance requirements.  Information is presented in the Inovonics Installation/User Manual, doc no: C1212014-001. 8. RF Exposure Requirements  The EN1252 module complies with RF exposure requirements specified in FCC Pt 15.247 and 2.1091. Additionally, the EN1252 is intended to be permanently installed well away from human contact and is not meant to be a portable device.  Installation instructions are presented in Inovonics Installation Manual, doc no: C1212014-001. Also refer to Inovonics RF Exposure Information letter, doc no: C1212010-001. Best Regards, Mark Hassebrock Compliance Engineer Inovonics C1212018-001 X1

PROPRIETARY & CONFIDENTIAL DOCUMENTATION © 2013 The information contained in this document is proprietary in nature and is confidential to and the sole property of Inovonics Corporation. This document may not to be reproduced or redistributed without prior written permission from Inovonics Corporation. Page 1 of 1 Inovonics – EN1252 Product Pictures CONFIDENTIAL C1212006-001 X3 Picture 3 - EN1252 Rear View Picture 1 - EN1252 Top View w/Shield Can Installed Picture 2 - EN1252 Top View Shield Can Removed

PROPRIETARY & CONFIDENTIAL DOCUMENTATION © 2013 The information contained in this document is proprietary in nature and is confidential to and the sole property of Inovonics Corporation. This document may not to be reproduced or redistributed without prior written permission from Inovonics Corporation. Page 1 of 1 Inovonics – EN1252 FCC / IC ID Label Location C1212019-001 X1 Picture 1 - EN1252 Module w/Label Bottom View EN1252 FCC ID: HCQ3B6OT9HPT IC ID: 2309A-0T9HPT

PROPRIETARY & CONFIDENTIAL DOCUMENTATION © 2013 The information contained in this document is proprietary in nature and is confidential to and the sole property of Inovonics Corporation. This document may not to be reproduced or redistributed without prior written permission from Inovonics Corporation. Page 1 of 1 Inovonics – EN1252 Product Pictures CONFIDENTIAL C1212006-001 X3 Picture 3 - EN1252 Rear View Picture 1 - EN1252 Top View w/Shield Can Installed Picture 2 - EN1252 Top View Shield Can Removed

PROPRIETARY & CONFIDENTIAL DOCUMENTATION © 2013 The information contained in this document is proprietary in nature and is confidential to and the sole property of Inovonics Corporation. This document may not to be reproduced or redistributed without prior written permission from Inovonics Corporation. Page 1 of 1 Inovonics – EN1252 RF Exposure Information 9. RF Exposure Information: Calculation for compliance with MPE requirements (47CFR2.1091) is done using a worst-case transmitter power of 250mW, assumption of a unity gain antenna, and an exposure limit of 0.6mW/cm 2 (f/1500mW/cm 2 at 20cm per 47CFR1.1310) for general applications. This device is not carried or worn by the end user. It has an extremely low duty cycle and a low rate of transmission that dramatically reduces the average power level that could pose an exposure hazard. The transmitter is typically activated by the opening or closing of a door or window. In addition to these change-of-state transmissions, the transmitter is configured to transmit a supervisory message once every 3 minutes. The averaging interval specified in Table 1(B) of 47CFR1.1310 is 30 minutes. For the purposes of this calculation, it is assumed that ten supervisory and five change-of- state messages will be sent in the 30 minute interval. Each supervisory message consists of 3 redundant packets, and each change of state message contains 21 packets, for a total of 135 packets in the 30 minute interval. A packet is typically 20ms in length. The worst-case power density at a distance of 20cm is then, This is well below the 0.6mW/cm 2 limit. C1212010-001 X1
