HDCTRC4108L12.4 GHz bi-directional transceiver

612804208L1-1B August 2003 TRACER 4108/4208 System Manual 12804108L1ATRACER 4108 System (Plan A) 12804108L1BTRACER 4108 System (Plan B) 12804208L1ATRACER 4208 System (Plan A) 12804208L1BTRACER 4208 System (Plan B) TrademarksTRACER 4108/4208 System Manual 2© 2003 ADTRAN, Inc.612804208L1-1B Trademarks Any brand names and product names included in this manual are trademarks, registered trademarks, or trade names of their respective holders. To the Holder of the Manual The contents of this manual are current as of the date of publication. ADTRAN reserves the right to change the contents without prior notice. In no event will ADTRAN be liable for any special, incidental, or consequential damages or for commercial losses even if ADTRAN has been advised thereof as a result of issue of this publication. About this Manual This manual provides a complete description of the TRACER 4108/4208 system and system software. The purpose of this manual is to provide the technician, system administrator, and manager with general and specific information related to the planning, installation, operation, and maintenance of the TRACER 4108/4208. This manual is arranged so that needed information can be quickly and easily found. 901 Explorer Boulevard P.O. Box 140000 Huntsville, AL 35814-4000 Phone: (256) 963-8000 © 2003 ADTRAN, Inc. All Rights Reserved. Printed in U.S.A. TRACER 4108/4208 System Manual Revision History 612804208L1-1B© 2003 ADTRAN, Inc.3 Revision History Document Revision DateDescription of Changes AMarch 2003Initial release of manual. BAugust 2003Introduced 2.4 GHz radio (TRACER 4108) information. Notes provide additional useful information. Cautions signify information that could prevent service interruption. Warnings provide information that could prevent damage to the equipment or endangerment to human life. Safety InstructionsTRACER 4108/4208 System Manual 4© 2003 ADTRAN, Inc.612804208L1-1B Safety Instructions When using your telephone equipment, please follow these basic safety precautions to reduce the risk of fire, electrical shock, or personal injury: 1. Do not use this product near water, such as a bathtub, wash bowl, kitchen sink, laundry tub, in a wet basement, or near a swimming pool. 2. Avoid using a telephone (other than a cordless-type) during an electrical storm. There is a remote risk of shock from lightning. 3. Do not use the telephone to report a gas leak in the vicinity of the leak. 4. Use only the power cord, power supply, and/or batteries indicated in the manual. Do not dispose of batteries in a fire. They may explode. Check with local codes for special disposal instructions. Save These Important Safety Instructions TRACER 4108/4208 System Manual FCC-Required Information 612804208L1-1B© 2003 ADTRAN, Inc.5 FCC-Required Information Federal Communications Commission Radio Frequency Interference Statement This equipment has been tested and found to comply with the limits for a Class A digital device, pursuant to Part 15 of the FCC Rules. These limits are designed to provide reasonable protection against harmful interference when the equipment is operated in a commercial environment. This equipment generates, uses, and can radiate radio frequency energy and, if not installed and used in accordance with the instruction manual, may cause harmful interference to radio frequencies. Operation of this equipment in a residential area is likely to cause harmful interference in which case the user will be required to correct the interference at his own expense. Radio Frequency Interface Statement This equipment has been tested and found to comply with the limits for an intentional radiator, pursuant to Part 15, Subpart C of the FCC Rules. This equipment generates, uses, and can radiate radio frequency energy. If not installed and used in accordance with the instructions, it may cause interference to radio communications. The limits are designed to provide reasonable protection against such interference in a residential situation. However, there is no guarantee that interference will not occur in a particular installation. If this equipment does cause interference to radio or television reception, which can be determined by turning the equipment on and off, the user is encouraged to try to correct the interference by one or more of the following measures: •Reorient or relocate the receiving antenna of the affected radio or television. •Increase the separation between the equipment and the affected receiver. •Connect the equipment and the affected receiver to power outlets on separate circuits. •Consult the dealer or an experienced radio/TV technician for help. Shielded cables must be used with this unit to ensure compliance with Class A FCC limits. Changes or modifications to this unit not expressly approved by the party responsible for compliance could void the user’s authority to operate the equipment. Changes or modifications not expressly approved by ADTRAN could void the user’s authority to operate the equipment. FCC-Required InformationTRACER 4108/4208 System Manual 6© 2003 ADTRAN, Inc.612804208L1-1B FCC Output Power Restrictions The FCC does not require licensing to implement this device. License-free operation in the industrial, scientific, and medical band is documented in FCC Rules Part 15.247. It is the responsibility of the individuals designing and implementing the radio system to assure compliance with any pertinent FCC Rules and Regulations. This device must be professionally installed. Exposure to Radio Frequency Fields The TRACER 4108 is designed to operate at 2.4 GHz with 100 mW maximum transmit power. The TRACER 4208 is designed to operate at 5.8 GHz with 100 mW maximum transmit power. This level of RF energy is below the Maximum Permissible Exposure (MPE) levels specified in FCC OET 65:97-01. The installation of high gain antenna equipment in the system configuration may create the opportunity for exposure to levels higher than recommended for the general population a…

Text truncated - open the document above for the full version.

RF PRE-AMP 3 dB PAD RF PRE-AMP IMAGE FILTER MIXER 3db PAD 450MHz LPF 2282-2322 MHz LO I IF AMP SAW FILTER DIRECTIONAL PIN DIODE IF AMP IF AMP COUPLER ATTENUATOR Q DEMODULATOR RSSI LOG AMP RSSI AMP RF INPUT From DIPLEXER I & Q OUTPUTS BASEBAND PROCESSOR, RSSi OUTPUT RECEIVER BLOCK DIAGRAM For the 4108 2.4 GHz RADIO

DIPLEXER PWR SENSOR POWER AMP DRIVER AMP ADJ ATTN IMAGE FILTER BUFFER AMP M IXER 2142-2182 MHz LO I 3 dB PAD Q 560MHz LPF MODULATOR 280 Mhz LO TRANSMITTER BLOCK DIAGRAM For the 4108 2.4 GHz RADIO I,Q Baseband outputs from Baseband processor

FCC ID: HDCTRC4108L1 External Photos - Top/Front view FCC ID: HDCTRC4108L1 External Photos - Bottom/Rear view



 !"  #$   %  & ' (  &) *      + & ',(  &)   *   )&+ &%    *  && ! ,! ,- ./0! , - ! - ./0! , - ! - 1! 12 23 2"4 "5526 7/, / 816/1 " 961 23 : ";  1<6=>269622 1:: "32=> 1!1 5165!9166 2 ?12<9!6"!  12  +,! 9@ A B, C ,7 1=2+
 ! -  C 2D:" 2 =3! :!"!="D ;6?32+1B 0 6"2? !: 6:2 1 <" E?;::2! ,!512 1! ,<25>1 ?;=? 12 =1E22 69+! 21 5>1 "32 1>15612+
2D"60B " ;1:: "322F;1: 2??; 2 ?26?3212?32=1E?2! B!
"62321="+6"
"6 ?;=?;"6?:2 52! !
525;?"6?2;:!

FCC ID: HDCTRC4108L1 Note: This photo displays the position of the label. The actual label including correct FCC ID number is shown in the FCC Label exhibit.

FCC ID: HDCTRC4108L1 Internal Photo - Assembled, Top Cover Removed FCC ID: HDCTRC4108L1 Internal Photo - Inside Top Cover FCC ID: HDCTRC4108L1 Internal Photos - Diplexer FCC ID: HDCTRC4108L1 Internal Photos - Main Board (Component Side) FCC ID: HDCTRC4108L1 Internal Photos - Main Board (Solder Side) FCC ID: HDCTRC4108L1 Internal Photos - RF Board (Component Side) (Note: Shields removed for photo) FCC ID: HDCTRC4108L1 Internal Photos - RF Board (Solder Side)

Project: 04CA18700 File: MC1002 Report: 040087 Date: May 27, 2004 Model: Tracer 4108 (2.4 GHz bi-directional transceiver) FCC ID: HDCTRC4108L1 Test Report On Electromagnetic Compatibility Testing Adtran Huntsville, AL USA Copyright  2004 Underwriters Laboratories Inc. Underwriters Laboratories Inc. authorizes the above-named company to reproduce this Report provided it is reproduced in its entirety. Project: 04CA18700 Underwriters Laboratories, Inc. Issued: 05/27/04 File: MC1002 Test Report on Electromagnetic Compatibility Page 2 of 48 FCC ID: HDCTRC4108L1 Test Report: 040087 Test Report Details: Tests Performed By: Underwriters Laboratories Inc. 12 Laboratory Drive Research Triangle Park, NC 27709 Tests Performed For: Adtran 901 Explorer Blvd. Huntsville, AL USA Applicant Contact: Mr. Derek Foster Compliance Engineer 256-963-8000 [email protected] Test Report Number: 040087 Test Report Date: May 27, 2004 Product Type: Point-to-Point RF link Model Number: Tracer 2.4 GHz Sample Serial Number: Unserialized sample Sample Tag Number: 0575627-001 EUT Category: Transmitter - Low Powered EUT Type: Table Top Sample Receive Date: April 28, 2004 Testing Start Date: May 12, 2004 Date Testing Complete: May 26, 2004 Underwriters Laboratories Inc. reports apply only to the specific samples tested under stated test conditions. All samples tested were in good operating condition throughout the entire test program. It is the manufacturer's responsibility to assure that additional production units of this model are manufactured with identical electrical and mechanical components. Underwriters Laboratories Inc. shall have no liability for any deductions, inferences or generalizations drawn by the client or others from Underwriters Laboratories Inc. issued reports. This report shall not be used to claim, constitute or imply product certification, approval, or endorsement by NVLAP, A2LA, or any agency of the US government. This report may contain test results that are not covered by the NVLAP or A2LA accreditation. The scope of accreditation is limited to the specific tests that are listed on the NVLAP and/or A2LA certificates provided at the end of this report. Complaints or inquiries regarding the contents of this report shall be brought to the attention of the report’s author. Project: 04CA18700 Underwriters Laboratories, Inc. Issued: 05/27/04 File: MC1002 Test Report on Electromagnetic Compatibility Page 3 of 48 FCC ID: HDCTRC4108L1 Test Report: 040087 Summary of Testing: Test Test Name Comply Does Not See # Test Requirement/Specification Comply Remark 1 Conducted Emissions - Conducted Power and Spurious Emissions X - 47 CFR Part 15, Subpart C / 47 CFR Part 15, Subpart C - Section 15.247 2 Occupied Bandwidth X - 47 CFR Part 15.247 / ANSI C63.4:2001 3 Spectral Density - Digitally Modulated Spread Spectrum X - 47 CFR Part 15.247 / ANSI C63.4:2001 4 Bandedge X - 47 CFR Part 15 Subpart C / 47 CFR Part 15.247 5 Radiated Spurious Emissions X - 47 CFR Part 15.247 / ANSI C63.42:2001 6 Radiated Disturbance Emissions - 30 to 1000 MHz Electric Field X - 47 CFR Part 15, Subpart B / CISPR 22:1997 Class A 7 Restricted Bands X - 47 CFR Part 15 Subpart C / 47 CFR Part 15.205 8 Maximum Permissible Exposure - - 3 47 CFR Part 1 Subpart I / 47 CFR Part 1.1307 Remarks: 1) Device contains a detachable antenna with a standard N-female connector. This device must be professionally installed, because the antenna does not contain a unique connector. 2) Device maximum conducted power is 109 mW. Output power must be set at end of attaching cable and reduced as necessary to remain compliant to limits in 15.247 when the intended antenna is taken into consideration. 3) Device antenna is must be installed with adequate precautions regarding RF exposure. Worst-case spacing to comply with uncontrolled/general exposure limit is 1.3 m. 4) Only high and low channel measurements are present (no middle channel), because this device only operates at two channels. 5) All testing was performed in an environmentally controlled facility with the following bounds: Temp 20 - 25°C, Relative Humidity 30 - 60%, Absolute Barometric Pressure 98 - 102 kPa. Conclusion: The tests listed in the Summary of Testing section of this report have been performed and the results recorded by Underwriters Laboratories Inc. in accordance with the procedures stated in each test requirement and specification. The test list was determined by the Applicant as being applicable to the Equipment Under Test. As a result, the subject product has been verified to comply or not comply as noted in the Summary of Testing with each test specification. The test results relate only to the items tested. Prepared By: Reviewed By: Jim Marley Mark Nolting NARTE Certified EMC Engineer NARTE Certified EMC Test Lab Engineer EMC-002278-NE ATL-0340-E (919) 549-1408 (919) 549-1584 Project: 04CA18700 Underwriters Laboratories, Inc. Issued: 05/27/04 File: MC1002 Test Report on Electromagnetic Compatibility Page 4 of 48 FCC ID: HDCTRC4108L1 Test Report: 040087 Test Facilities: Test Location A) 10-Meter Anechoic Chamber (Industry Canada - IC 2953, NVLAP - 200246-0, VCCI - R-722) Constructed by Lindgren RF Enclosures, this room consists of a 17.9 by 12 by 8.3 m (inside clearance) shielded room lined with TDK absorber material. The walls, floor (conducting ground plane) and ceiling are constructed of double sided galvanized sheet steel supported by 19 mm thick particle board. The interior walls and ceiling are covered with 10 by 10 cm, 4.6 mm thick ferrite tiles and partially covered with polystyrene absorber cones. Removable floor tiles and cones covering the floor between the EUT and antenna are provided when RF immunity testing is performed. Room is provided with a 4.0 m diameter embedded turntable and a 1.2 by 2.1 m and 2.4 by 2.4 m double knife edge doors for access. Also, the room is fed electrical EUT power via permanently installed filters and is provided with a permanently mounted vid…
