HDCTRC5045L1Tracer 5045 Point-to-Point Spread Spectrum System

612805045L1-1A March 2003 TRACER 5045 System Manual 12805045L1ATRACER 5045 System (Plan A) 12805045L1BTRACER 5045 System (Plan B) TrademarksTRACER 5045 System Manual 2© 2003 ADTRAN, Inc.612805045L1-1A Trademarks Any brand names and product names included in this manual are trademarks, registered trademarks, or trade names of their respective holders. TRACER ® is a registered trademark of ADTRAN, Inc. To the Holder of the Manual The contents of this manual are current as of the date of publication. ADTRAN reserves the right to change the contents without prior notice. In no event will ADTRAN be liable for any special, incidental, or consequential damages or for commercial losses even if ADTRAN has been advised thereof as a result of issue of this publication. About this Manual This manual provides a complete description of the TRACER 5045 system and system software. The purpose of this manual is to provide the technician, system administrator, and manager with general and specific information related to the planning, installation, operation, and maintenance of the TRACER 5045. This manual is arranged so that needed information can be quickly and easily found. 901 Explorer Boulevard P.O. Box 140000 Huntsville, AL 35814-4000 Phone: (256) 963-8000 © 2003 ADTRAN, Inc. All Rights Reserved. Printed in U.S.A. TRACER 5045 System Manual Revision History 612805045L1-1A© 2003 ADTRAN, Inc.3 Revision History Document Revision DateDescription of Changes AMarch 2003Initial release of manual. Notes provide additional useful information. Cautions signify information that could prevent service interruption. Warnings provide information that could prevent damage to the equipment or endangerment to human life. Safety InstructionsTRACER 5045 System Manual 4© 2003 ADTRAN, Inc.612805045L1-1A Safety Instructions When using your telephone equipment, please follow these basic safety precautions to reduce the risk of fire, electrical shock, or personal injury: 1. Do not use this product near water, such as a bathtub, wash bowl, kitchen sink, laundry tub, in a wet basement, or near a swimming pool. 2. Avoid using a telephone (other than a cordless-type) during an electrical storm. There is a remote risk of shock from lightning. 3. Do not use the telephone to report a gas leak in the vicinity of the leak. 4. Use only the power cord, power supply, and/or batteries indicated in the manual. Do not dispose of batteries in a fire. They may explode. Check with local codes for special disposal instructions. Save These Important Safety Instructions TRACER 5045 System Manual FCC-Required Information 612805045L1-1A© 2003 ADTRAN, Inc.5 FCC-Required Information Federal Communications Commission Radio Frequency Interference Statement This equipment has been tested and found to comply with the limits for a Class A digital device, pursuant to Part 15 of the FCC Rules. These limits are designed to provide reasonable protection against harmful interference when the equipment is operated in a commercial environment. This equipment generates, uses, and can radiate radio frequency energy and, if not installed and used in accordance with the instruction manual, may cause harmful interference to radio frequencies. Operation of this equipment in a residential area is likely to cause harmful interference in which case the user will be required to correct the interference at his own expense. Radio Frequency Interface Statement This equipment has been tested and found to comply with the limits for an intentional radiator, pursuant to Part 15, Subpart C of the FCC Rules. This equipment generates, uses, and can radiate radio frequency energy. If not installed and used in accordance with the instructions, it may cause interference to radio communications. The limits are designed to provide reasonable protection against such interference in a residential situation. However, there is no guarantee that interference will not occur in a particular installation. If this equipment does cause interference to radio or television reception, which can be determined by turning the equipment on and off, the user is encouraged to try to correct the interference by one or more of the following measures: •Reorient or relocate the receiving antenna of the affected radio or television. •Increase the separation between the equipment and the affected receiver. •Connect the equipment and the affected receiver to power outlets on separate circuits. •Consult the dealer or an experienced radio/TV technician for help. Shielded cables must be used with this unit to ensure compliance with Class A FCC limits. Changes or modifications to this unit not expressly approved by the party responsible for compliance could void the user’s authority to operate the equipment. Changes or modifications not expressly approved by ADTRAN could void the user’s authority to operate the equipment. FCC-Required InformationTRACER 5045 System Manual 6© 2003 ADTRAN, Inc.612805045L1-1A FCC Output Power Restrictions The FCC does not require licensing to implement this device. License-free operation in the industrial, scientific, and medical band is documented in FCC Rules Part 15.247. It is the responsibility of the individuals designing and implementing the radio system to assure compliance with any pertinent FCC Rules and Regulations. This device must be professionally installed. Exposure to Radio Frequency Fields The TRACER 5045 is designed to operate at 5.8 GHz with 100 mW maximum transmit power. This level of RF energy is below the Maximum Permissible Exposure (MPE) levels specified in FCC OET 65:97-01. The installation of high gain antenna equipment in the system configuration may create the opportunity for exposure to levels higher than recommended for the general population at a distance less than 15 feet (4.6 meter) from the center of the antenna. The following precautions must be taken during installation of this equipment: •The installed antenna must not be located in a manner that allo…

Text truncated - open the document above for the full version.

RF PRE-AMP IMAGE FILTER RF PRE-AMP IMAGE FILTER MIXER 3db PA D 2 GHz LPF &7GHz LPF 5607-5687 MHz LO I IF AMP SAW FILTER DIRECTIONAL PIN DIODE IF AMP IF AMP COUPLER ATTENUATOR Q DEMODULATOR RSSI LOG AMP RSSI AMP RF INPUT From DIPLEXER I & Q OUTPUTS BASEBAND PROCESSOR, RSSi OUTPUT RECEIVER BLOCK DIAGRAM For the 4208 5.8 GHz RADIO

Front Panel Rear Panel Top View Bottom View Side View

FCC Label Location - Rear Panel FCC Label

Overview Cover Removed RFC Board Baseband Board Signal Filter Baseband Board Top, Detail A Baseband Board Top, Detail B Baseband Board Top, Detail C Baseband Board Bottom, Detail A Baseband Board Bottom, Detail B Baseband Board Bottom, Detail C

Document 8031-MPE, Rev. 1 FCC ID: HDCTRC5045L1 RF Exposure Test Report Washington Laboratories, Ltd July 2004 Maximum Permissible Exposure Test Report for Adtran TRACER 5045L1 FCC ID: HDCTRC5045L1 July 2004 WLL PROJECT #: 8031X This report may not be reproduced, except in full, without the prior written consent of Washington Laboratories, Ltd. RF Exposure Test Report Document 8031-MPE, Rev. 1 FCC ID: HDCTRC5045L1 RF Exposure Test Report Washington Laboratories, Ltd July 2004 1 Maximum Permissible Exposure Test Report for FCC ID: HDCTRC5045L1 1.0 Introduction This report has been prepared on behalf of Adtran Model: TRACER 5045L1 Transmitter to show compliance with the RF exposure requirements as defined in FCC §1.1307. 1.1 Requirements Three different categories of transmitters are defined by the FCC in OET Bulletin 65. These categories are fixed installation, mobile, and portable and are defined as follows: ƒ Fixed Installations: fixed location means that the device, including its antenna, is physically secured at a permanent location and is not able to be easily moved to another location. Additionally, distance to humans from the antenna is maintained to at least 2 meters. ƒ Mobile Devices: a mobile device is defined as a transmitting device designed to be used in other than fixed locations and to be generally used in such a way that a separation distance of at least 20 centimeters is normally maintained between the transmitter's radiating structures and the body of the user or nearby persons. Transmitters designed to be used by consumers or workers that can be easily re-located, such as a wireless modem operating in a laptop computer, are considered mobile devices if they meet the 20 centimeter separation requirement. The FCC rules for evaluating mobile devices for RF compliance are found in 47 CFR §2.1091. ƒ Portable Devices: a portable device is defined as a transmitting device designed to be used so that the radiating structure(s) of the device is/are within 20 centimeters of the body of the user. Portable device requirements are found in Section 2.1093 of the FCC's Rules (47 CFR§2.1093). For this test report the Adtran TRACER 5045L1 is classified as a “Fixed Installation Device” and therefore must meet the limits as specified in §1.307. The FCC also categorizes the use of the device as based upon the user’s awareness and ability to exercise control over his or her exposure. The two categories defined are Occupational/Controlled Exposure and General Population/Uncontrolled Exposure. These two categories are defined as follows: Document 8031-MPE, Rev. 1 FCC ID: HDCTRC5045L1 RF Exposure Test Report Washington Laboratories, Ltd July 2004 2 ƒ Occupational/Controlled Exposure: In general, occupational/controlled exposure limits are applicable to situations in which persons are exposed as a consequence of their employment, who have been made fully aware of the potential for exposure and can exercise control over their exposure. This exposure category is also applicable when the exposure is of a transient nature due to incidental passage through a location where the exposure levels may be higher than the general population/uncontrolled limits, but the exposed person is fully aware of the potential for exposure and can exercise control over his or her exposure by leaving the area or by some other appropriate means. Awareness of the potential for RF exposure in a workplace or similar environment can be provided through specific training as part of a RF safety program. If appropriate, warning signs and labels can also be used to establish such awareness by providing prominent information on the risk of potential exposure and instructions on methods to minimize such exposure risks. ƒ General Population/Uncontrolled Exposure: The general population / uncontrolled exposure limits are applicable to situations in which the general public may be exposed or in which persons who are exposed as a consequence of their employment may not be made fully aware of the potential for exposure or cannot exercise control over their exposure. Members of the general public would come under this category when exposure is not employment-related; for example, in the case of a wireless transmitter that exposes persons in its vicinity. Warning labels placed on low-power consumer devices such as cellular telephones are not considered sufficient to allow the device to be considered under the occupational/controlled category, and the general population/uncontrolled exposure limits apply to these devices. Since there are no warnings or training associated with this unit and it can be used by anyone, the Adtran TRACER 4208L1 is evaluated to the General Population/Uncontrolled Exposure limits. 1.2 Radio Frequency Radiation Exposure Evaluation The highest RF output power of the unit was measured at 19.9dBm at 5747 MHz. According to §1.1310 of the FCC rules, the power density limit for General Population/Uncontrolled Exposure is 1mW/cm 2 . To comply with the exposure limits for this section, individuals must maintain a safe distance from the transmit antenna. The following formula was used to calculate the minimum safe distance: 2 4R PG S π = Where: S = Power Density P = Output Power at the Antenna Terminals G = Gain of Transmit Antenna (linear gain) R = Distance from Transmitting Antenna Document 8031-MPE, Rev. 1 FCC ID: HDCTRC5045L1 RF Exposure Test Report Washington Laboratories, Ltd July 2004 3 For this device, the calculation is as follows: S = FCC Limit = 1mW/cm 2 P = Output Power = 97.7 mW G = Worst Case Gain = 44.2 dBi = INVLOG(44.2/10) = 26302.7 R = Based on 4.6 meters (15 feet) specified in User’s Manual S = {(97.7mW)(26302.7}/{(12.56)(460cm 2 )} = 0.9664mW/cm 2 This power density is the worst case for maximum beam exposure. This level is below the limit of 1mW/cm 2 MPE for general population/uncontrolled access. This unit is only installed by professionals and is limited in practice to installations on rooftops or …

Text truncated - open the document above for the full version.

Document 8031-01, Rev. 1 FCC Certification Test Report Washington Laboratories, Ltd July 2004 FCC Certification Test Report for ADTRAN, Inc. HDCTRC5045L1 Revision 1 - July 26, 2004 Prepared for: ADTRAN, Inc. 901 Explorer Blvd Huntsville, AL 35806 Prepared By: Washington Laboratories, Ltd. 7560 Lindbergh Drive Gaithersburg, Maryland 20879 FCC Certification Test Report Document 8031-01, Rev. 1 FCC Certification Test Report Washington Laboratories, Ltd July 2004 FCC Certification Test Report for the ADTRAN, Inc. TRACER Transceiver 5045 FCC ID: HDCTRC5045L1 WLL JOB# 8031 Prepared by: Gregory M. Snyder Chief EMC Engineer Reviewed by: Michael Violette President Document 8031-01, Rev. 1 FCC ID: HDCTRC5045L1 FCC Certification Test Report Washington Laboratories, Ltd July 2004 ii Abstract This report has been prepared on behalf of ADTRAN, Inc. to support the attached Application for Equipment Authorization. The test report and application are submitted for a Digitally Modulated Transmitter under Part 15.247 of the FCC Rules and Regulations. This Federal Communication Commission (FCC) Certification Test Report documents the test configuration and test results for an ADTRAN, Inc. TRACER 5045. Testing was performed on an Open Area Test Site (OATS) of Washington Laboratories, Ltd, 7560 Lindbergh Drive, Gaithersburg, MD 20879. Site description and site attenuation data have been placed on file with the FCC's Sampling and Measurements Branch at the FCC laboratory in Columbia, MD. Washington Laboratories, Ltd. has been accepted by the FCC and approved by NIST NVLAP (NVLAP Lab Code: 200066-0) as an independent FCC test laboratory. The ADTRAN, Inc. TRACER 5045 complies with the limits for a Digitally Modulated Transmitter device under Part 15.247 of the FCC Rules and Regulations. Document 8031-01, Rev. 1 FCC ID: HDCTRC5045L1 FCC Certification Test Report Washington Laboratories, Ltd July 2004 iii Table of Contents Abstract ............................................................................................................................... ii 1 Introduction..............................................................................................................1 1.1 Compliance Statement ........................................................................................ 1 1.2 Test Scope ........................................................................................................... 1 1.3 Contract Information........................................................................................... 1 1.4 Test Dates ........................................................................................................... 1 1.5 Test and Support Personnel ................................................................................ 1 1.6 Abbreviations ...................................................................................................... 2 2 Equipment Under Test .............................................................................................3 2.1 EUT Identification & Description ...................................................................... 3 2.2 Test Configuration .............................................................................................. 4 2.3 Testing Algorithm............................................................................................... 4 2.4 Test Location ...................................................................................................... 4 2.5 Measurements ..................................................................................................... 5 2.5.1 References................................................................................................... 5 2.6 Measurement Uncertainty................................................................................... 5 3 Test Equipment ........................................................................................................6 4 Test Results ..............................................................................................................7 4.1 RF Power Output ................................................................................................ 7 4.2 RF Peak Power Spectral Density ........................................................................ 8 4.3 Occupied Bandwidth......................................................................................... 11 4.4 Spurious Emissions at Antenna Terminals (FCC Part §15.247(b)).................. 13 4.5 Radiated Spurious Emissions: (FCC Part §15.247(c)) ..................................... 22 4.5.1 Test Procedure .......................................................................................... 23 4.6 AC Powerline Conducted Emissions: (FCC Part §15.207) .............................. 26 Document 8031-01, Rev. 1 FCC ID: HDCTRC5045L1 FCC Certification Test Report Washington Laboratories, Ltd July 2004 iv List of Tables Table 1. Device Summary................................................................................................... 4 Table 2: Test Equipment List.............................................................................................. 6 Table 3. RF Power Output .................................................................................................. 7 Table 4. Power Spectral Density......................................................................................... 9 Table 4. Occupied Bandwidth Results.............................................................................. 12 Table 6: Radiated Emission Test Data - Plan A ............................................................... 24 Table 7: Radiated Emission Test Data - Plan B................................................................ 25 Table 8: Conducted Emissions Test Data; 15.207 ............................................................ 27 List of Figures Figure 4-1: RF Power Measurement Test Setup Diagram.....…

Text truncated - open the document above for the full version.

Document 8031, Rev. 0 FCC ID: HDCTRC5045L1 IC: 2250A-TRC5045L1 FCC & IC Certification Test Report Washington Laboratories, Ltd April 2005 FCC & IC Certification Test Report Addendum for ADTRAN, Inc. FCC ID: HDCTRC5045L1 IC: 2250A-TRC5045L1 April 26, 2005 Prepared for: ADTRAN, Inc. 901 Explorer Blvd Huntsville, AL 35806 Prepared By: Washington Laboratories, Ltd. 7560 Lindbergh Drive Gaithersburg, Maryland 20879 FCC Certification Test Report Document 8031, Rev. 0 FCC ID: HDCTRC5045L1 IC: 2250A-TRC5045L1 FCC & IC Certification Test Report Washington Laboratories, Ltd April 2005 FCC & IC Certification Test Report Addendum for the ADTRAN, Inc. TRACER Transceiver 5045L1 FCC ID: HDCTRC5045L1 WLL JOB# 8031 Prepared by: Gregory M. Snyder Chief EMC Engineer Reviewed by: Steve Koster EMC Operation Manager Document 8031, Rev. 0 FCC ID: HDCTRC5045L1 IC: 2250A-TRC5045L1 FCC & IC Certification Test Report Washington Laboratories, Ltd April 2005 ii Abstract This report has been prepared on behalf of ADTRAN, Inc. to supply emissions test data in support of large high gain antenna systems. The ADTRAN TRACER Model 5045 was originally tested with a 2’ diameter dish antenna (28.5dBi). As this device is being sought for certification under §15.247 and operates as a fixed installation point-to-point system at 5.8GHz, the antenna gain can exceed 6dBi without any reduction in output power. The user manual specifies antennas up to 12’ in diameter with gains up to 44.2dBi. This test report presents emissions data for the 10’ dish antenna (42.5dBi). It can be seen from the spurious emission data collected at the antenna terminal and the comparison of the radiated emissions data from the 2’ to 10’ dish antenna that the spurious emissions are not increased by the use of the high gain antenna. Testing was performed at Washington Laboratories, Ltd, 7560 Lindbergh Drive, Gaithersburg, MD 20879. Document 8031, Rev. 0 FCC ID: HDCTRC5045L1 IC: 2250A-TRC5045L1 FCC & IC Certification Test Report Washington Laboratories, Ltd April 2005 iii Table of Contents Abstract ............................................................................................................................... ii 1 Introduction..............................................................................................................1 1.1 Compliance Statement ........................................................................................ 1 1.2 Test Scope ........................................................................................................... 1 1.3 Contract Information........................................................................................... 1 1.4 Test Dates ........................................................................................................... 1 1.5 Test and Support Personnel ................................................................................ 1 2 Equipment Under Test .............................................................................................2 2.1 EUT Identification & Description ...................................................................... 2 2.2 Test Configuration .............................................................................................. 2 3 Test Equipment ........................................................................................................2 4 Test Results ..............................................................................................................4 4.1 Radiated Spurious Emissions: (FCC Part §15.247(c)) ....................................... 4 4.1.1 Test Procedure ................................................................................................ 4 4.1.2 Test results ...................................................................................................... 5 4.2 E-Mail From FCC Referencing Testing of Large Dish ...................................... 9 List of Tables Table 1: Test Equipment List.............................................................................................. 3 Table 2: Radiated Emission Test Data - Plan A, Band 1 .................................................... 5 List of Figures Figure 1. Test Setup Photograph......................................................................................... 7 Figure 2. Test Setup Photograph......................................................................................... 8 Document 8031, Rev. 0 FCC ID: HDCTRC5045L1 IC: 2250A-TRC5045L1 FCC & IC Certification Test Report Washington Laboratories, Ltd April 2005 Page 1 of 9 1 Introduction 1.1 Compliance Statement The ADTRAN, Inc. TRACER 5045L1 Spread Spectrum System with dish antennas up to 44.2dBi gain complies with the limits for a Digitally Modulated intentional radiator device under FCC Part 15.247 and Industry Canada RSS-210. 1.2 Test Scope Tests for radiated emissions of the TRACER 5045L1 with a 10’ dish antenna were performed in accordance with guidance provided by the FCC Laboratory. Reference the e-mail included in 4.2. The face of the antenna was scanned to determine the location of maximum field intensity. Both horizontal and vertical polarities were evaluated. 1.3 Contract Information Customer: ADTRAN, Inc. 901 Explorer Blvd Huntsville, AL 35806 Quotation Number: 62208 1.4 Test Dates Testing was performed on March 7, 2005. 1.5 Test and Support Personnel Washington Laboratories, LTD Greg Snyder, Mike Violette Document 8031, Rev. 0 FCC ID: HDCTRC5045L1 IC: 2250A-TRC5045L1 FCC & IC Certification Test Report Washington Laboratories, Ltd April 2005 Page 2 of 9 2 Equipment Under Test 2.1 EUT Identification & Description ADTRAN Part # Product Name/Description 12805045L1A Tracer 5045 Plan A 12805045L1B Tracer 5045 Plan B Top Assembly #: 12805045L1A/B Sub Assembly #(s): 2280030-6, 2280018-11 Circuit Board #(s): 5280030-6, 5280018-11 Antenna Description: Manufacturer Model Description Gain Andrew PL10F-23-N7A 10’ Dish Antenna with …
