TomTom Remote Control TomTom Re- mote Control AVolume control Adjust the volume up/down. BSoft buttons Left/center/right keys for use in the navigation screen. The center key is also used to play/ pause tracks while listening to music. CArrow buttons Horizontal: Select menu buttons and keyboard keys and go forward/rewind tracks while listening to music. Vertical: Select menu buttons and keyboard keys and zoom in/out while viewing the navigation screen. DOK button Press a menu button or confirm an action. AControl de volumen Suba/baje el volumen. BBotones táctiles Teclas izquierda/central/derecha para su uso en la pantalla de navegación. La tecla central también se utiliza para reproducir/detener en pausa pistas mientras se escucha música. CBotones de flecha Horizontal: Seleccione botones de menú y teclas de teclado y avance/retroceda en pistas mientras escucha música. Vertical: Seleccione botones de menú y las teclas de teclado y aleje o acerque mientras visualiza la pantalla de navegación. DBotón OK Pulse un botón de menú o confirme una acción. A Réglage du volume Permet d'augmenter/baisser le volume. BBoutons de fonction Touches gauche/centrale/droite à utiliser dans l'écran de navigation. La touche centrale sert également à lire/mettre en pause des titres lorsque vous écoutez de la musique. CBoutons fléchés Horizontaux : Pour sélectionner des boutons de menu et des touches de clavier, mais également avancer/reculer dans le titre que vous écoutez. Verticaux : Pour sélectionner des boutons de menu et des touches de clavier, mais également effectuer un zoom avant/arrière dans l'écran de navigation. DBouton OK Pour appuyer sur un bouton de menu ou confirmer une action. A B C D EN ESFR RemoteControl_OperatingInstructions.fm Page 1 Tuesday, October 2, 2007 5:37 PM FCC Regulations FCC Regula- tions This device complies with part 15 of the FCC Rules. Operation is subject to the following two conditions: (1) This device may not cause harmful interference, and (2) this device must accept any interference received, including interference that may cause undesired operation. This device has been tested and found to comply with the limits for a Class B digital device, pursuant to Part 15 of the FCC Rules. These limits are designed to provide reasonable protection against harmful interference in a residential installation. This equipment generates, uses and can radiated radio frequency energy and, if not installed and used in accordance with the instructions, may cause harmful interference to radio communications. However, there is no guarantee that interference will not occur in a particular installation. If this equipment does cause harmful interference to radio or television reception, which can be determined by turning the equipment off and on, the user is encouraged to try to correct the interference by one or more of the following measures: • Reorient or relocate the receiving antenna. • Increase the separation between the equipment and receiver. • Connect the equipment into an outlet on a circuit different from that to which the receiver is connected. • Consult the dealer or an experienced radio/TV technician for help. Changes or modifications not expressly approved by the party responsible for compliance could void the user‘s authority to operate the equipment. IC Regulations Operation is subject to the following two conditions: 1. This device may not cause harmful interference, and 2. This device must accept any interference received, including interference that may cause undesired operation of the device. FCC ID: HFS-ASTOM2 IC ID: 1787B-ASTOM2 Responsible party in North America TomTom, Inc., 150 Baker Avenue Extension, Concord, MA 01742 Tel: (866 486-6866) option 1 (1-866-4-TomTom) Exposure to Radio Frequency Radiation To comply with RF exposure requirements please maintain a separation distance of at least 20 cm / 7 inches from any part of the product. Emissions information for Canada This Class B digital apparatus complies with Canadian ICES-003. Cet appareil numérique de la classe B est conforme à la norme NMB-003 du Canada. Part number: 6M01.004 LimitedWarranty-Addendum-RemoteControl.fm Page 2 Tuesday, October 2, 2007 5:33 PM

Rev. 1/1/03 Quanta Computer Inc. Federal Communications Commission Authorization and Evaluation Division Confidentiality Request regarding application for certification of FCC ID: HFS-ASTOM2. Pursuant to Sections 0.457 and 0.459 of the Commission’s Rules, we hereby request confidential treatment of information accompanying this application as outlined below: Block Diagram (file: TomTom BlkDia.pdf) Schematics (file: TomTom Schem.pdf) Operation Description (file: TomTom OpDes.pdf) Parts List (file: TomTom PartsLst.pdf) The above materials contain trade secrets and proprietary information not customarily released to the public. The public disclosure of these materials may be harmful to the applicant and provide unjustified benefits to its competitors. The applicant understands that pursuant to Section 0.457 of the Rules, disclosure of this application and all accompanying documentation will not be made before the date of the Grant for this application. Sincerely, 徐生明 Attached: Copy of FCC Confidentiality Policy

FCC / IC Test Report Report NO. : FR763002 SPORTON International Inc. Page Number : A1 OF A4 TEL : 886-2-2696-2468 Report Issued Date : Aug. 25, 2007 FAX : 886-2-2696-2255 Report Version : Rev.01 APPENDIX A. Photographs of EUT 763002 FCC / IC Test Report Report NO. : FR763002 SPORTON International Inc. Page Number : A2 OF A4 TEL : 886-2-2696-2468 Report Issued Date : Aug. 25, 2007 FAX : 886-2-2696-2255 Report Version : Rev.01 763002 FCC / IC Test Report Report NO. : FR763002 SPORTON International Inc. Page Number : A3 OF A4 TEL : 886-2-2696-2468 Report Issued Date : Aug. 25, 2007 FAX : 886-2-2696-2255 Report Version : Rev.01 763002 FCC / IC Test Report Report NO. : FR763002 SPORTON International Inc. Page Number : A4 OF A4 TEL : 886-2-2696-2468 Report Issued Date : Aug. 25, 2007 FAX : 886-2-2696-2255 Report Version : Rev.01 732101 763002

Statement We, SAN JOSE Navigation, Inc, states that our device, FCC ID: HFS-ASTOM2, has no space to put the label except battery compartment as shown in the attached photo. The label will put under the battery compartment, so the label is visible to the users as they purchase the products and install the battery. Signature

Label here

FCC / IC Test Report Report NO. : FR763002 SPORTON International Inc. Page Number : B1 OF B6 TEL : 886-2-2696-2468 Report Issued Date : Aug. 25, 2007 FAX : 886-2-2696-2255 Report Version : Rev. 01 APPENDIX B. Internal Photographs of EUT 763002 FCC / IC Test Report Report NO. : FR763002 SPORTON International Inc. Page Number : B2 OF B6 TEL : 886-2-2696-2468 Report Issued Date : Aug. 25, 2007 FAX : 886-2-2696-2255 Report Version : Rev. 01 763002 Bluetooth Antenna FCC / IC Test Report Report NO. : FR763002 SPORTON International Inc. Page Number : B3 OF B6 TEL : 886-2-2696-2468 Report Issued Date : Aug. 25, 2007 FAX : 886-2-2696-2255 Report Version : Rev. 01 763002 FCC / IC Test Report Report NO. : FR763002 SPORTON International Inc. Page Number : B4 OF B6 TEL : 886-2-2696-2468 Report Issued Date : Aug. 25, 2007 FAX : 886-2-2696-2255 Report Version : Rev. 01 763002 FCC / IC Test Report Report NO. : FR763002 SPORTON International Inc. Page Number : B5 OF B6 TEL : 886-2-2696-2468 Report Issued Date : Aug. 25, 2007 FAX : 886-2-2696-2255 Report Version : Rev. 01 763002 Bluetooth Antenna FCC / IC Test Report Report NO. : FR763002 SPORTON International Inc. Page Number : B6 OF B6 TEL : 886-2-2696-2468 Report Issued Date : Aug. 25, 2007 FAX : 886-2-2696-2255 Report Version : Rev. 01 763002

Document No.: 763002 RF Exposure Test Report Date: October 4, 2007 FCC ID: HFS-ASTOM2 Sporton International Inc. RF Exposure Test Report for Quanta Computer Inc. BT Remote Control Equipment : Bluetooth Go Remote Trade Name : TomTom Model No. : BT Remote Control FCC ID : HFS-ASTOM2 Filing Type : Certification Applicant : Quanta Computer Inc. No. 211, Wen Hwa 2nd Rd., Kuei Shan Hsiang, Tao Yuan Shien, Taiwan, R.O.C. ‚ Without written approval of SPORTON International Inc., the test report shall not be reproduced except in full. SPORTON International Inc. 6F, No.106, Sec. 1, Hsin Tai Wu Rd., Hsi Chih, Taipei Hsien, Taiwan, R.O.C. Document No.: 763002 RF Exposure Test Report Date: October 4, 2007 FCC ID: HFS-ASTOM2 Sporton International Inc. Maximum Permissible Exposure Test Report for BT Remote Control 1.0 Introduction The report has been prepared on behalf of Quanta Computer Inc. Bluetooth Go Remote to show compliance with the RF Exposure. 1.1 Requirements Three different categories of transmitters are defined by the FCC in OET Bulletin 65. These categories are fixed installation, mobile and portable and are defined as follows: ƒ Fixed installation: fixed location means that the device, including its antenna, is physically secured at a permanent location and is not able to be easily moved to another location. Additionally, distance to humans form the antenna is maintained to at least 2 meters. ƒ Mobile Devices: a mobile device is defined as a transmitting device designed to be used in other than fixed locations and to be generally used in such a way that a separation distance of at least 20 centimeters is normally maintained between the transmitter’s radiating structures and the body of the user or nearby persons. Transmitters designed to be used by consumers or workers that can be easily re-located, such as a wireless modem operating in a laptop computer, are considered mobile devices if they meet the 20 centimeter separation requirement. The FCC rules for evaluating mobile devices for RF compliance are found in 47 CFR 2.1091. ƒ Portable Devices: a portable device is defined as a transmitting device designed to be used so that the radiating structure(s) of the device is/are within 20 centimeters of the body of the user. Portable device requirements are found in Section 2.1093 of the FCC’s Rules (47 CFR 2.1093) For this test report the Quanta Computer Inc. BT Remote Control is being done as a mobile device and the MPE is evaluated at the 20cm test distance. The FCC also categorizes the use of the device as based upon the user’s awareness and ability to Document No.: 763002 RF Exposure Test Report Date: October 4, 2007 FCC ID: HFS-ASTOM2 Sporton International Inc. exercise control over his or her exposure. The two categories defined are Occupational/Controlled Exposure and General Population/Uncontrolled Exposure. These two categories are defined as follows: ƒ Occupational/controlled Exposure: In general, occupational/controlled exposure limits are applicable to situation in which persons are exposed as a consequence of their employment, who have been made fully aware of the potential for exposure. Awareness of the potential for RF exposure in a workplcae or similar environment can be provided through specific training as part of a RF safety program. If appropriate, warning signs and labels can also be used to establish such awareness by providing prominent information on the risk of potential exposure and instructions on methods to minimize such exposure risks. ƒ General Population/Uncontrolled Exposure: The general population / uncontrolled exposure limits are applicable to situations in which the general public may be exposed or in which persons who are exposed as a consequence of their employment may not be made fully aware of the potential for exposure or cannot exercise control over their exposure. Members of the general public would come under this category when exposure is not employment-related; for example, in the case of a wireless transmitter that exposes persons in its vicinity. Warning labels placed on low-power consumer devices such as cellular telephones are not considered sufficient to allow the device to be considered under the occupational/controlled category, and the general population/uncontrolled exposure limits apply to these devices. Since there are no warnings or training associated with this unit and it can be used by anyone, Bluetooth Go Remote is evaluated to the General Population / Uncontrolled Exposure limits. 1.2 Radio Frequency Radiation Exposure Evaluation For this device, the calculation is as follows: ¾ No Evaluation Required if power is below this threshold: F (GHz) MW dBm 2.48 24.19 13.84 Maximum measured transmitter power for the EUT: Document No.: 763002 RF Exposure Test Report Date: October 4, 2007 FCC ID: HFS-ASTOM2 Sporton International Inc. Pout (dBm) 0.06 Threshold for no RF Exposure evaluation is 13.84 dBm. Transmitter power of this device is 0.06 dBm Conclustion: No RF Exposure evaluation required since Transmitter Pout is below FCC threshold.

FCC / IC TEST REPORT Report No. : FR763002 SPORTON International Inc. TEL : 886-2-2696-2468 FAX : 886-2-2696-2255 Rev. 01 FCC / IC TEST REPORT for 47 CFR Part 15 Subpart C and RSS-210 Equipment : Bluetooth Go Remote Trade Name : TomTom Model No. : BT Remote Control FCC ID : HFS-ASTOM2 IC ID : 1787B-ASTOM2 Filing Type : Certification Applicant : Quanta Computer Inc. No.211, Wen Hwa 2nd Rd., Kuei Shan Hsiang, Tao Yuan Shien, Taiwan, R.O.C. ‚ The test result refers exclusively to the test presented test model / sample. ‚ Without written approval of SPORTON International Inc., the test report shall not be reproduced except in full. ‚ Certificate or Test Report must not be used by the applicant to claim the product in this test report endorsement by NVLAP or any agency of U.S. government. ‚ The data shown in this test report were carried out on Aug. 14, 2007 at Sporton International Inc. LAB. ‚ Report No.: FR763002, Report Version: Rev. 01. Jones Tsai Manager SPORTON International Inc. 6F, No.106, Sec. 1, Hsin Tai Wu Rd., Hsi Chih, Taipei Hsien, Taiwan, R.O.C. FCC / IC TEST REPORT Report No. : FR763002 SPORTON International Inc. Page Number : i TEL : 886-2-2696-2468 Report Issued Date : Aug. 25, 2007 FAX : 886-2-2696-2255 Report Version : Rev. 01 FCC ID.: HFS-ASTOM2 Table of Contents History of this test report ....................................................................................................................................ii 1. General Description of Equipment under Test .............................................................................................1 1.1. Applicant..................................................................................................................................................1 1.2. Manufacturer ...........................................................................................................................................1 1.3. Basic Description of Equipment under Test ............................................................................................1 1.4. Feature of Equipment under Test............................................................................................................2 2. Test Configuration of Equipment under Test ...............................................................................................3 2.1. Test Manner ............................................................................................................................................3 2.2. Test Mode................................................................................................................................................3 2.3. Ancillary Equipment List ..........................................................................................................................3 2.4. Connection Diagram of Test System.......................................................................................................3 3. RF Utility ...........................................................................................................................................................4 4. General Information of Test............................................................................................................................5 4.1. Test Voltage ............................................................................................................................................5 4.2. Standard for Methods of Measurement...................................................................................................5 4.3. Test Compliance......................................................................................................................................5 4.4. Frequency Range ....................................................................................................................................5 4.5. Test Distance...........................................................................................................................................5 5. Report of Measurements and Examinations.................................................................................................6 5.1. List of Measurements and Examinations ................................................................................................6 5.2. Hopping Channel Separation ..................................................................................................................7 5.3. Number of Hopping Frequency .............................................................................................................11 5.5 Dwell Time of Each Frequency within a 30 Seconds Period ................................................................17 5.6 Output Power.........................................................................................................................................24 5.7 100kHz Bandwidth of Frequency Band Edges......................................................................................28 5.8 Radiated Emission Measurement .........................................................................................................32 5.9 Antenna Requirements..........................................................................................................................46 6. List of Measuring Equipments .....................................................................................................................47 7. Uncertainty Evaluation..................................................................................................................................48 Appendix A. External Product Photograph Appendix B. Internal Photograph Appendix C. Setup Photograph FCC / IC TEST REPORT Report No. : FR763002 SPORTON International Inc. Page Number : ii TEL : 886-2-2696-2468 Report Issued Date : Aug. 25, 2007 FAX : 886-2-2696-2255 Report Version : Rev. 01 FCC ID.: HFS-ASTOM2 History of this test repor…
