HFS-HA1SANI Wireless Card

American Telecommunications Certification Body Inc. 6731 Whittier Ave, McLean, VA 22101 July 30, 2004 RE: Quanta Computer, Inc. FCC ID: HFS-HA1 After a review of the submitted information, I have a few comments on the above referenced Application. 1) The block diagram provided appears to be for a system. The block diagram should show the frequencies of all oscillators in the TX portion of the device (CFR 2.1033(a)(5)). Please provide the block diagram for the TX portion. 2) The schematic appears to be for a system. The schematic should be for the TX portion of the device (CFR 2.1033(a)(5)). Please provide the schematic for the TX portion. 3) Please justify the use of the DoC labeling information (FCC Logo). This labeling is reserved for particular approvals that do not appear to apply to this application (PC Peripheral, Stand alone RX, etc.). Please justify or remove from the labeling. 4) FYI.....This application does not appear to be applicable for a DoC, therefore the DoC exhibit is not necessary and is not being reviewed or forwarded to the FCC. 5) A system manual was provided. Is a manual available just for the EUT? 6) This device is tested to 15.249. The limits > 1 GHz do allow for average emissions. However for readings < 1 GHz, including the fundamental, no average emissions are allowed. The limits are strictly 94 dBuV/m for PEAK emissions, or alternatively QP emissions as long as the repetition rate is > 20 Hz during the measurements. Please correct the report. 7) The average calculation shown and used for average measurements > 1 GHz does not appear correct. From the data, it appears that 33.386774/100 should have been used. Please correct all calculations and data as necessary. Timothy R. Johnson Examining Engineer mailto: [email protected] The items indicated above must be submitted before processing can continue on the above referenced application. Failure to provide the requested information may result in application termination. Correspondence should be considered part of the permanent submission and may be viewed from the Internet after a Grant of Equipment Authorization is issued. Please do not respond to this correspondence using the email reply button. In order for your response to be processed expeditiously, you must submit your documents through the AmericanTCB.com website. Also, please note that partial responses increase processing time and should not be submitted. Any questions about the content of this correspondence should be directed to the sender.

American Telecommunications Certification Body Inc. 6731 Whittier Ave, McLean, VA 22101 October 5, 2004 RE: Quanta Computer, Inc. FCC ID: HFS-HA1 After a review of the submitted information, I have a few comments on the above referenced Application. 1) The new users manual provided does not appears to be for the device being approved. The new manual discusses PCMCIA, WLAN characteristics, channels and output power that do not apply to this device. This device appears to be a frequency hopping on specific channels in the 900 MHz ISM band only. Please provide a correct manual for the TX card. Timothy R. Johnson Examining Engineer mailto: [email protected] The items indicated above must be submitted before processing can continue on the above referenced application. Failure to provide the requested information may result in application termination. Correspondence should be considered part of the permanent submission and may be viewed from the Internet after a Grant of Equipment Authorization is issued. Please do not respond to this correspondence using the email reply button. In order for your response to be processed expeditiously, you must submit your documents through the AmericanTCB.com website. Also, please note that partial responses increase processing time and should not be submitted. Any questions about the content of this correspondence should be directed to the sender.

Dear Tim The user's manual has been revised and re-upload to website today. Please check and would you please send the grant today if no other comment? Thanks for your assistance! Best Regards Wendy Liao Page 1 of 1In 10/8/2004Printed for "Timothy R. Johnson" <[email protected]>

Dear Tim The comments has been solved today. Please check and would you please send the grant today? Thanks for your assistance! Best Regards Wendy Liao Page 1 of 1Quanta HFS-HA1 10/8/2004Printed for "Timothy R. Johnson" <[email protected]>

Federal Communications Commission Authorization and Evaluation Division Confidentiality Request Pursuant to Sections 0.457 and 0.459 of the Commission’s Rules, the Applicant hereby requests confidential treatment of information accompanying this Application as outlined below: Schematics Block Diagram The above materials contain trade secrets and proprietary information not customarily released to the public. The public disclosure of these matters might be harmful to the Applicant and provide unjustified benefits to its competitors. The Applicant understands that pursuant to Rule 0.457, disclosure of this Application and all accompanying documentation will not be made before the date of the Grant for this application. Sincerely, Quanta Computer Inc. 7F, 116 Hou Kang St., Shih Lin, Taipei, Taiwan, R.O.C. Tel: +886 3 327 2345 Fax: +886 3 328 5048 e-mail: [email protected] Quanta Computer Inc. 7F, 116 Hou Kang St., Shih Lin, Taipei, Taiwan, R.O.C. Tel: +886 3 327 2345 Fax: +886 3 328 5048 FCC ID: HFS-HA1

Page 1 CONSTRUCTION PHOTOS OF EUT

Label Location

Quanta Computer Inc. FCC ID: HFS-HA1 IC ID: 1787B-HA1 Model name: IBF-003, Brand: Quanta This device complies with Part 15 of the FCC Rules. Operation is subject to the following two conditions: (1) This device may not cause harmful interference, and (2) this device must accept any interference received, including interference that may cause undesired operation.

Page 2 Page 3 Page 4 Page 5

FCC ID: HFS-HA1 Report No.: 930701L11 Operational Description This device is a Flipscreen with 28 hopping frequencies. The antenna type is Dipole antenna and there is no antenna connector used. The other instruction, please have a look at the users manual.

FCC ID: HFS-HA1 Report No: SA930701L11 1 RF EXPOSURE REPORT REPORT NO.: SA930701L11 MODEL NO.: IBF-003, IBF-005 ACCORDING: FCC Guidelines for Human Exposure IEEE C95.1 APPLICANT: QUANTA COMPUTER INC. ADDRESS: 7F, 116, Hou Kang St., Shih Lin, Taipei, Taiwan, R.O.C. ISSUED BY: Advance Data Technology Corporation LAB LOCATION: No. 19, Hwa Ya 2 nd Rd., Wen Hwa Tsuen, Kwei Shan Hsiang, Taoyuan Hsien 333, Taiwan, R.O.C. FCC ID: HFS-HA1 Report No: SA930701L11 2 RF Exposure Measurement (Mobile Device) 1. Introduction In this document, we try to prove the safety of radiation harmfulness to the human body for our product. The limit for Maximum Permissible Exposure (MPE) specified in FCC 1.1310 is followed. The Gain of the antenna used in this product is measured in a Fully Anechoic Chamber (FAC) calibrated for antenna measurement in ADT, and also the maximum total power input to the antenna is measured. Through the Friis transmission formula and the maximum gain of the antenna, we can calculate the distance, away from the product, where the limit of MPE is reached. Although the Friis transmission formula is a far field assumption, the calculated result of that is an over-prediction for near field power density. We will take that as the worst case to specify the safety range. 2. RF Exposure Limit According to FCC 1.1310: The criteria listed in the following table shall be used to evaluate the environmental impact of human exposure to radio-frequency (RF) radiation as specified in 1.1307(b) LIMITS FOR MAXIMUM PERMISSIBLE EXPOSURE (MPE) Frequency Range (MHz) Electric Field Strength (V/m) Magnetic Field Strength (A/m) Power Density (mW/cm 2 ) Average Time (minutes) (A)Limits For Occupational / Control Exposures 300-1500......F/3006 1500-100,000......56 (B)Limits For General Population / Uncontrolled Exposure 300-1500......F/15006 1500-100,000......1.030 F = Frequency in MHz FCC ID: HFS-HA1 Report No: SA930701L11 3 3. Friis Formula Friis transmission formula: Pd = (Pout*G) / (4*pi*r 2 ) where Pd = power density in mW/cm 2 Pout = output power to antenna in mW G = gain of antenna in linear scale Pi = 3.1416 R = distance between observation point and center of the radiator in cm If we know the maximum Gain of the antenna and the total power input to the antenna, through the calculation, we will know the MPE value at distance 20cm. Ref.: David K. Cheng, Field and Wave Electromagnetics, Second Edition, Page 640, Eq. (11-133). 4 EUT Operating condition The software provided by Manufacturer enabled the EUT to transmit and receive data at lowest, middle and highest channel individually. 5. Classification This device is not fixed inside the host equipment; it is connected with host through wire. So it is easy to be re-located in the place where at least 20cm far away from the body of the user. Warning statement to the user for keeping at least 20cm or more separation distance with the antenna should be included in users manual. So, this device is classified as Mobile Device. FCC ID: HFS-HA1 Report No: SA930701L11 4 6 Test Results 6.1 Antenna Gain The maximum Gain measured in Fully Anechoic Chamber is -2dBi. 6.2 Output Power Into Antenna & RF Exposure Distance: CHANNEL CHANNEL FREQUENCY (MHz) FIELD STRENGTH AT 3m (dBuV/m) E.I.R.P (mW) POWER DENSITY (mW/cm 2 ) LIMIT OF POWER DENSITY (mW/cm 2 ) 0905.60975683.020.0600.0000121.0 14915.60975681.420.0420.0000841.0 27924.39024480.580.0340.0000071.0

FCC ID: HFS-HA1 Report No.: RF930701L111Issued: July 20, 2004. FCC TEST REPORT REPORT NO.: RF930701L11 MODEL NO.: IBF-005 (for other model names please refer to page 5) RECEIVED: July 01, 2004 TESTED: July 01, 2004 ~ July 15, 2004 APPLICANT: QUANTA COMPUTER INC. ADDRESS: 7F, 116, Hou Kang St., Shih Lin, Taipei, Taiwan, R.O.C. ISSUED BY: Advance Data Technology Corporation LAB LOCATION: No. 19, Hwa Ya 2 nd Rd., Wen Hwa Tsuen, Kwei Shan Hsiang, Taoyuan Hsien 333, Taiwan, R.O.C. This test report consists of 33 pages in total. It may be duplicated completely for legal use with the approval of the applicant. It should not be reproduced except in full, without the written approval of our laboratory. The client should not use it to claim product endorsement by CNLA or any government agencies. The test results in the report only apply to the tested sample. 0528 ILAC MRA FCC ID: HFS-HA1 Report No.: RF930701L112Issued: July 20, 2004. Table of Contents 1CERTIFICATION ..................................................................................... 3 2SUMMARY OF TEST RESULTS ............................................................. 4 2.1 MEASUREMENT UNCERTAINTY ........................................................... 4 3.GENERAL INFORMATION...................................................................... 5 3.1GENERAL DESCRIPTION OF EUT ........................................................ 5 3.2DESCRIPTION OF TEST MODES .......................................................... 6 3.3GENERAL DESCRIPTION OF APPLIED STANDARDS ......................... 6 3.4DESCRIPTION OF SUPPORT UNITS .................................................... 7 3.5CONFIGURATION OF SYSTEM UNDER TEST..................................... 8 4.TEST TYPES AND RESULTS ................................................................. 9 4.1CONDUCTED EMISSION MEASUREMENT .......................................... 9 4.1.1LIMITS OF CONDUCTED EMISSION MEASUREMENT ........................ 9 4.1.2TEST INSTRUMENTS............................................................................. 9 4.1.3TEST PROCEDURES ........................................................................... 10 4.1.4DEVIATION FROM TEST STANDARD ................................................. 10 4.1.5TEST SETUP ........................................................................................ 11 4.1.6 EUT OPERATING CONDITIONS ......................................................... 11 4.1.7 TEST RESULTS ..................................................................................... 12 4.2RADIATED EMISSION MEASUREMENT ............................................. 18 4.2.1LIMITS OF RADIATED EMISSION MEASUREMENT ........................... 18 4.2.2TEST INSTRUMENTS........................................................................... 19 4.2.3TEST PROCEDURES ........................................................................... 20 4.2.4DEVIATION FROM TEST STANDARD ................................................. 20 4.2.5TEST SETUP ........................................................................................ 21 4.2.6EUT OPERATING CONDITIONS .......................................................... 21 4.2.7TEST RESULTS .................................................................................... 22 4.3BAND EDGES MEASUREMENT .......................................................... 27 4.3.1LIMITS OF BAND EDGES MEASUREMENT........................................ 27 4.3.2TEST INSTRUMENTS........................................................................... 27 4.3.3TEST PROCEDURE ............................................................................. 27 4.3.4EUT OPERATING CONDITION ............................................................ 27 4.3.5TEST RESULTS .................................................................................... 28 5.PHOTOGRAPHS OF THE TEST CONFIGURATION ............................ 31 6 APPENDIX - INFORMATION ON THE TESTING LABORATORIES ....... 33 FCC ID: HFS-HA1 Report No.: RF930701L113Issued: July 20, 2004. 1 CERTIFICATION PRODUCT : Flipscreen MODEL NO.: IBF-005 (for other model names please refer to page 5) BRAND: Quanta APPLICANT : QUANTA COMPUTER INC. TEST ITEM: ENGINEERING SAMPLE TESTED: July 01 ~ July 19, 2004 STANDARDS : FCC Part 15, Subpart C (Section 15.249), ANSI C63.4-2001 The above equipment has been tested by Advance Data Technology Corporation, and found compliance with the requirement of the above standards. The test record, data evaluation & Equipment Under Test (EUT) configurations represented herein are true and accurate accounts of the measurements of the sample’s EMC characteristics under the conditions specified in this report. PREPARED BY:, DATE: July 20, 2004 APPROVED BY: Stacy Hsueh , DATE:July 20, 2004 Cody Chang / Supervisor FCC ID: HFS-HA1 Report No.: RF930701L114Issued: July 20, 2004. 2 SUMMARY OF TEST RESULTS The EUT has been tested according to the following specifications: APPLIED STANDARD: FCC Part 15, Subpart C STANDARD PARAGRAPH TEST TYPERESULTREMARK 15.207Conducted Emission TestPASS Minimum passing margin is –22.19dB at 0.213MHz 15.209 15.249 Radiated Emission TestPASS Minimum passing margin is –6.75dB at 1810.71MHz 15.249 (d)Band Edge MeasurementPASS Meet the requirement of limit Note: The information of measurement uncertainty is available upon the customer’s request. 2.1 MEASUREMENT UNCERTAINTY Where relevant, the following measurement uncertainty levels have been estimated for tests performed on the EUT as specified in CISPR 16-4: MEASUREMENTFREQUENCYUNCERTAINTY Conducted emissions 9k~30MHz 2.44 dB Radiated emissions 30MHz ~ 200MHz 3.63 dB 200MHz ~1000MHz3.65 dB 1GHz ~ 18GHz2.20 dB 18GHz ~ 40GHz1.88 dB FCC ID: HFS-HA1 Report No.: RF930701L115Issued: July 20, 2004. 3. GENERAL INFORMATION 3.1 GENERAL DESCRIPTION OF EUT PRODUCT Flipscreen MODEL NO. IBF-005 (for other model names please refer to following table) BRAND Quanta POWER…
