BF-01C User Manual Introduction Installing the BF-01C Wireless Connection to the BF-01C Internet Connection Settings Use Overseas Troubleshooting 1 2 3 4 5 6 Thank you for purchasing the BF-01C. This manual describes product installation and its default settings. It also provides troubleshooting information. Please always read this manual before using the product. Appendix 7 1 1 Introduction 1 Main Features This section describes the main product features. • Supports NTT Docomo ”Xi”. (When receiving: Max. 37.5 Mbps; When sending: Max. 12.5 Mbps) ※ The communication speeds are the maximum values in sending and receiving standards. However, these do not indicate actual communication speeds. Data transmission is provided over a best-effort network. For that reason, actual communication speeds may vary according to the communication environ- ment and the traffic load on the network. ※ When outside of the Xi area, this can also be used in a FOMA high-speed area (when receiving: Max. 7.2 Mbps; when sending: Max. 5.7 Mbps). • The Internet connection automatically switches in public wireless LAN areas, such as Mzone, from the Xi line or FOMA line to the public wireless LAN. • The included cradle provides a wired port connection, and recharges the product. • Connects up to 10 wireless LAN devices, such as personal computers and game consoles. • Connects to wireless LAN devices with one touch using AOSS or WPS. Operating Environment This section describes the product operating environment. Supported Devices iPad, iPod touch, game console (Nintendo 3DS ™ , Nintendo DS ® , PSP ® ”PlayStation Portable”), and devices that support wireless LAN. 2 Supported OS (Personal Computers) Windows 7 (32 bit/64 bit), Vista (32 bit/64 bit), XP (32 bit), Mac OS X (10.4/10.5/10.6) ※ Supports Windows 7 Starter/Home Premium/Professional/Ultimate. ※ Supports Windows Vista Home Basic/Home Premium/Business/Ultimate. ※ Windows XP must have Service Pack 3 or later installed. Supported Browsers Internet Explorer 6/7/8/9 Firefox 3.5/3.6/4 Nintendo DS Browser, Nintendo DSi Browser PSP ® Internet Browser Internet Explorer Mobile (Windows Mobile 6.x) Opera Mobile 9/10 Safari 3/4/5 (Mac OS/iPod touch) ※ To change the product's settings, or to check the setting contents, use Internet Explorer 6/7/8/9, or Firefox 3.5/3.6/4 (Windows 7/Vista/XP). Browsers provided in game console or cell phones cannot implement all product settings. 3 Mobile Wi-Fi Router (BF-01C) Unit (Rear Cover BF01C, Includes Warrantee) Desktop Cradle BF01C (Includes Warrantee) AC Adapter BF01 (Includes Warrantee)Battery Pack BF01 Main Unit Accessories Before using this product, check that all of the accessories are included. 4 Note If separate, additional information is included, refer to that. USB Cable BF01LAN Cable (Free Sample) User Manual (This Manual)Mobile Device Connection Guide 5 Part Names and Functions Front Panel 1. WIRELESS LED Glowing (light blue) : When in Xi area Glowing (purple) : When in FOMA international roaming area Glowing (blue) : When in FOMA area Glowing (green) : When in wireless LAN area Glowing (red) : When outside of Xi area, FOMA line and wireless LAN area, and when not connected to wired Internet Glowing (yellow) : When in power saving mode Flashing (light blue) : When communicating on Xi line Flashing (purple) : When communicating on FOMA international roaming line Flashing (blue) : When communicating on FOMA line Flashing (green) : When communicating on wireless LAN Off : When connected to wired Internet 2. BATTERY LED Glowing (blue) : Battery capacity is 50% or higher Recharging is completed and the power is turned on Glowing (green) : Battery capacity is 50 - 25% Glowing (red) : Battery capacity is 25 - 10% Flashing (red) : Battery capacity is 10% or lower Glowing (yellow) : Recharging Off : Recharging is completed and the power is turned off ※ Battery capacity is a general indicator. 1 2 3 6 3. AOSS/DIAG LED Glowing (yellow) : Security key exchange succeeds (AOSS/ WPS succeeds)/Wireless LAN security setting completed Flashing Two Times (blue) : This product can exchange security keys. (LAN Side: AOSS/WPS Idling) (Internet Side: AOSS Idling) *1 Continuous Flashing (blue) : Failed to exchange security keys (AOSS/WPS failed) Flashing (red) : The number of flashes indicates the status of the product. Off : Wireless LAN security is not set. Flashing (red) status ContentStatus Continuous Flashing *2 • Booting up system • Updating the firmware • Saving settings • Initializing • Accessing internal storage region Flashing Three Times *3 Wired LAN Error Wired LAN controller is malfunctioning. Flashing Four Times *3 Wireless LAN errorWireless LAN controller is malfunctioning. Flashing Five Times IP Address Setting ErrorCommunication is not possible because the network addresses are the s ame on the Internet side and the L AN side. Change the product's LAN-side IP address setting. Flashing Six Times Temperature ErrorThe internal product temperature is high. Turn the power to the product off and allow it to cool for a while before using it. 7 *1 Devices idling with AOSS switch to flashing two times (yellow) when detected by the Internet side of the product. *2 Do not turn off the power when the device is continuously flashing. Doing so can damage it. *3 When the AC adapter is disconnected from the device, turn off the power to it, and remove the battery pack. Return the battery pack to its original position after waiting for a while. Side Panel 4. Power Button When the power is off, hold down the power button for approximately three seconds to turn the power on. When operating this device, hold down the power button for approximately three seconds to turn the power off. 5. AOSS Button When the power is on, hold down the button (for approximately three seconds) until the AOSS/DIAG LED flashes in blue to enter a status (AOSS operating status) where security keys can be exchanged. 6. Strap Hole Attaches commercially available straps. 7. Cradl…
