HFS-QMV7B7 inch Tablet PC

1 Get to Know Your Tablet 2 My Verizon You’re now connected to Verizon 4G LTE. Lightning fast, Lightning strong. For more information, visit verizonwireless.com/4GLTE. REGISTER at verizonwireless.com/myverizon to learn how to use your tablet. q
Go to My Verizon q
Click Support q
Click Device q
Click Select Another Device My Verizon allows you to manage your account, pay your bill, purchase accessories & more. Assistance is at your fingertips anytime at verizonwireless.com. Customer Service is at your disposal at 1-800-922-0204 or Prepaid Customer Service at 1-800-786-8419 or at any Verizon Wireless Store. A User Guide is available on demand—simply download at support.vzw.com/phones. NOTE: Not all features, apps or services may be available with your plan, tablet operating system and software version. Please contact your wireless service provider for more information. 3 Tablet Features Notifications Panel Google™ Search Front Camera Status Panel & Quick Settings Apps Home Recent AppsBack TIP: From the Home screen, tap Apps then tap Help to see the user guide, an icon glossary and more, right from your tablet. NOTE: Devices and software are constantly evolving—the screen images and icons you see here are for reference only. 4 Headset Connector USB/Charger Port Rear Camera CAUTION! Use only an approved charger to charge your tablet. Improper handling of the charging port, as well as the use of an incompatible charger, may cause damage to your device and void the warranty. To p V i e w Bottom View Back View 5 CAUTION! Your tablet is equipped with an internal rechargeable battery that is non-removable. You should never attempt to open or disassemble this tablet. Doing so may cause damage that voids your warranty. Ta b l e t S i d e V i e w Microphone Power/Lock Key Volume Keys SIM Card Slot MicroSD™ Card Slot 6 Setting Up Your Tablet Insert the SIM Card NOTE: If not already installed, follow the instructions below to insert your 4G LTE SIM card. 1.Open the cover to the SIM card slot and carefully insert the 4G LTE SIM card with the Verizon logo facing up. 2.Push the SIM card into the slot until it clicks into place. 3.Replace the SIM card slot cover. 7 Charge the Tablet Before turning on your tablet, charge it fully. Be sure to use the charger that came with your tablet. USB Cable Charger 8 Insert/Remove the Optional MicroSD Card* To Insert the MicroSD card: 1.Open the cover to the MicroSD card slot. 2.With the gold contacts facing down, carefully push the MicroSD card into the slot (as shown) until it clicks into place. 3.Replace the MicroSD card cover. To remove the MicroSD card: 1.Open the cover to the MicroSD card slot. 2.Push the memory card inward to release and carefully slide the card out of the MicroSD card slot. 3.Replace the MicroSD card cover. *MicroSD card sold separately. 9 Turning Your Tablet On/Off q
To turn your tablet on, press and hold the Power/Lock key for a couple of seconds until the screen lights up. q
To turn your tablet off, press and hold the Power/Lock key until the tablet options are displayed. Tap Power off > OK. 10 Unlocking the Screen 1.Press the Power/Lock key to turn on your screen. Your Lock Screen will appear. 2.From the center of the screen, swipe in any direction to unlock it. 11 Setting Up Your Google Account Your Gmail™, Google™ contacts, and Google calendar events can all be loaded to your tablet automatically. Follow the onscreen instructions to quickly set up your Gmail account. Record your Google account information here. Please keep this document in a safe place. Username:@gmail.com Password: Setting Up Other Email Accounts To add additional email accounts, tap Apps ́ Settings ́ + Add account. Tap one of the options and enter your email address, password, and any other necessary information. q
Corporate is for Exchange server work email accounts. q
Email is for most personal email accounts. For account details, contact the account provider. q
Google is for adding other Gmail accounts. 12 Wi-Fi® Enhanced Connectivity When you launch an Internet-capable app, like the browser, your tablet scans for available Wi-Fi networks even when Wi-Fi is turned off, and gives you the option of connecting to an available Wi-Fi network. You can save on your monthly data allowance by using a Wi-Fi connection instead of the Verizon network. Connecting Your Bluetooth® Devices 1.From the Home screen, tap Apps ́ Settings ́Bluetooth. 2.Slide the Bluetooth switch from OFF to ON. 3.The tablet will automatically scan for nearby Bluetooth devices. 4.Tap the name of the device you want to pair with your tablet. NOTE: Depending on the type of device you are pairing with, you will be asked to enter a passkey, confirm matching passkeys, or the device will automatically pair. 13 Prepaid Tablet Service Verizon Wireless offers month to month, pay as you go 4G LTE Mobile Broadband service that puts you in charge of your Internet access on your tablet. Surf the web at blazing speeds and enjoy thousands of apps with the freedom of no long-term contract, no activation fees, and no termination fees. Easily manage your account directly from the Settings menu of your tablet. All of our data plans require a credit card or select debit cards and will automatically renew every month unless canceled. Activating Your Prepaid Device 1.Make sure your SIM card is inserted. 2.With the device powered on, from the Pay as you go screen in the Setup wizard, select Sign up. 3.You will automatically be directed to My Verizon. 4.Select a data plan and follow the instructions to create and activate your account. 5.You will receive a confirmation email when registration is complete and your data plan is active. NOTE: Subject to specific terms of use. For coverage details, verizonwireless.com/coveragelocator. 14 Apps & More Play it up with music, videos, wallpapers, apps and games. Keep up with Twitter™ and Facebook. Installing Apps Hundreds of thousands of apps are available to download from Google Play. Fr…
