HFS1KU21KU2

___________________________________________________________ UANTA COMPUTER INC. ___________________________________________________________ 1KU2 Product Specification Nov. 28 th , 2011 Revision: 2B Issued By: Suya Hou Checked By: Claire Huang ___________________________________________________________________________ The release of this document is under controlled by the company. Any extra copy of this document must be written permission by the project manager. ___________________________________________________________________________ - Quanta Confidential - UANTA COMPUTER INC. CNBU/1KU2 ________________________________________________________________________________________ ____________________________________________________________________________ 1KU Product Specification Rev. 2B Page: 2 - Quanta Confidential - Document History: Vision Release By Date Note 2A Suya Hou 2011.11.25 First release 2B Suya Hou 2011.11.28 Add CE statement UANTA COMPUTER INC. CNBU/1KU2 ________________________________________________________________________________________ ____________________________________________________________________________ 1KU Product Specification Rev. 2B Page: 3 - Quanta Confidential - CONTENT 1. INTRODUCTION ...................................................................................... 4 1.1 RADIO FREQUENCY CONFIGURATIONS ....................................................................................... 4 2. MAIN FEATURES ..................................................................................... 4 3. MECHANICAL SPECIFICATIONS................................................................ 7 4. PERFORMANCE ....................................................................................... 7 4.1 RF SPECIFICATION ................................................................................................................. 7 4.2 ELECTRICAL SPECIFICATION ..................................................................................................... 8 4.2.1 Power Specification............................................................................................................................. 8 4.2.2 Pin Assignment .................................................................................................................................... 8 5. AT COMMAND ....................................................................................... 10 5.1 3GPP STANDARD AT COMMANDS......................................................................................... 10 6. FCC ........................................................................................................ 10 FCC ID: HFS1KU2 .................................................................................................................. 10 7. CE MARKING ......................................................................................... 10 UANTA COMPUTER INC. CNBU/1KU2 ________________________________________________________________________________________ ____________________________________________________________________________ 1KU Product Specification Rev. 2B Page: 4 - Quanta Confidential - 1. Introduction 1KUx is a customized PCI Express Mini Card, which is developed on Qualcomm MDM9600/9200 platform and capable to provide various frequency configurations, support data operation on LTE, EVDO, HSUPA, HSDPA and WCDMA connectivity for portable and hand-held computers. 1.1 Radio Frequency Configurations The required radio frequency has been defined into 3 SKUs based on customer needs, 1KUx is a general definition of this embed module, precise name will be named as 1KU1, 1KU2 and 1KU3 in accordance with bands configuration. Due to limited space reserved for the module and Qualcomm’s chipset configuration, 3 SKUs have to be realized by leveraging 2 PCBs design. This PCI Express Mini Card is able to support UP TO Quad Bands in LTE/UMTS and Quad Bands in EDGE, GPRS, and GSM if required. Hence, the following SKU table will become as whole framework of product specification. Table 1-1 Quanta Model Name 1KU1 1KU2 1KU3 QCI P/N 211KUMB0070 211KUMB0050 211KUMB0060 Description LTE & CDMA HSPA+ Only LTE & HSPA+ HSPA+ X 850/900/1900/2100/AWS 850/1900/2100 LTE 700U X AWS/700D EVDO 800/ 1900 MHz X X PCB Design PCB-1 PCB-2 PCB-2 2. Main Features The following features set can be referred to 1KU1, 1KU2 and 1KU3, bands supported frequency depend on each SKU bands configuration. Features Items Descriptions Remarks Physical Outlook Dimension 35.18 x 30 x 4mm Weight 9 g Temperature Range Operation Temperature -10°C to +55°C Storage Temperature -20°C to +80°C DC Power Supply Supply Voltage 3.4~4.2V Interface Edge connector - 52 pins - 0.8 pitch - 0.5A rating current Host communication Alternative: - USB 2.0 - 8 bit SDIO at 1.8V UANTA COMPUTER INC. CNBU/1KU2 ________________________________________________________________________________________ ____________________________________________________________________________ 1KU Product Specification Rev. 2B Page: 5 - Quanta Confidential - SIM - (U)SIM 1.8V/3V - Class B/Class C Connection 2 Antenna W_FL connectors: - 1 Primary for WCDMA/HSPA/LTE/Cdma2000/EVDO - 1 auxiliary for HSPA/LTE/EVDO Rx diversity Communication ports at USB - 1 Modem port - 1 Diagnostic port - 1 AT command port - 1 NDIS interface CPU Baseband Processor Qualcomm MDM 9600/9200 600MHz - Application μP: ARM926-256MHz - SW/FW Processor: QDSP6 at up to 595 MHz PMIC PMIC 8028 Internal Memory - 64 MB DDR SDRAM internal stacked memory - 166 MHz maximum speed - 32-bit data width support - 1.8 V interface External Memory NAND Flash - 1Gb - 63-Ball FBGA (9 x 11 x 1.0 mm) - Operating voltage: 1.8V - Memory Density: 128M x 8 bit Radio UMTS Frequency - B1: UMTS-2100 (1920-1980MHz; 2110-2170MHz) - B2: UMTS-1900 (1850-1910MHz; 1930-1990MHz) - B4: UMTS-AWS (1710-1755MHz; 2110-2155MHz) - B8: UMTS-900 (880-915MHz; 925-960MHz) - B5: UMTS-850 (824-849MHz; 869-894MHz) Details refer to…

Text truncated - open the document above for the full version.

FCC ID: HFS1KU2 Unless otherwise stated the results shown in this test report refer only to the sample(s) tested and such sample(s) are retained for 90 days only. 除非另有說明，此報告結果僅對測試之樣品負責，同時此樣品僅保留90天。本報告未經本公司書面許可，不可部份複製。 This document is issued by the Company subject to its General Conditions of Service printed overleaf, available on request or accessible at www.sgs.com/terms_and_conditions.htm and, for electronic format documents, subject to Terms and Conditions for Electronic Documents at www.sgs.com/terms_e-document.htm . Attention is drawn to the limitation of liability, indemni- fication and jurisdiction issues defined therein. Any holder of this document is advised that information contained hereon reflects the Company’s findings at the time of its intervention only and within the limits of Client’s instructions, if any. The Company’s sole responsibility is to its Client and this document does not exonerate parties to a transaction from exercising all their rights and obligations under the transaction documents. This document cannot be reproduced except in full, without prior written approval of the Company. Any unauthorized alteration, forgery or falsification of the content or appearance of this document is unlawful and offenders may be prosecuted to the fullest extent of the law. SGS Taiwan Ltd. No.134, Wu Kung Road, Wuku Industrial Zone, Taipei County, Taiwan /台北縣五股工業區五工路134號 台灣檢驗科技股份有限公司 t (886-2) 2299-3279 f (886-2) 2298-0488 www.tw.sgs.com Member of SGS Group Front View of EUT Back View of EUT

D D 1 2 3 4 5 6 7 ABCE 7 6 5 4 3 2 1 ECBA NAME MODEL MATERIAL FINISH DATE SCALE UNIT MM DWG. NO. APPROVED DESIGNED DRAWING REV 3A 3B 3C TOL. + - 1 PLC2 PLCANGLE ITEMDESCRIPTION REVISIONS LTRDESCRIPTION DATE APP THE 3RD PROJECTION PART NO. Quanta Computer Inc. 2 1 FIRST RELEASE LING S/N LING 1/1 3A DEVICE LABEL(1KU2) +-0.2 1KU No.211,Wen Hwa 2nd Ra.,Kuei Shan Tao Yuan 33377,TAIWAN, R.O.C. HC1KU00 100.11.29 100.05.06 3.File No.: 2.Backeround Color: White 1.Matiral:White Polyester White Polyester FCC ID: HFS1KU2 P/N: 211KUMB0050 S/N:A1KU2G2C1BA0065 Model:1KU2 0560 25.0MM 28.0MM

1KU2 Label Location EUT
