TravelMate 660 series User’s guide Changes may be made periodically to the information in this publication without obligation to notify any person of such revision or changes. Such changes will be incorporated in new editions of this manual or supplementary documents and publications. This company makes no representations or warranties, either expressed or implied, with respect to the contents hereof and specifically disclaims the implied warranties of merchantability or fitness for a particular purpose. Record the model number, serial number, purchase date, and place of purchase information in the space provided below. The serial number and model number are recorded on the label affixed to your computer. All correspondence concerning your unit should include the serial number, model number, and purchase information. No part of this publication may be reproduced, stored in a retrieval system, or transmitted, in any form or by any means, electronic, mechanical, photocopy, recording, or otherwise, without the prior written permission of Acer Incorporated. Model number : _________________________________ Serial number: ___________________________________ Purchase date: ___________________________________ Place of purchase: ________________________________ Copyright © 2003 Acer Incorporated. All Rights Reserved. TravelMate 660 series User’s guide Original Issue: June 2003 TravelMate 660 series Notebook computer Acer and the Acer logo are registered trademarks of Acer Incorporated. Other company's product names or trademarks are used herein for identification purposes only and belong to their respective companies. iii English First things first We would like to thank you for making the TravelMate series of notebook computers your choice for your mobile computing needs. We hope you will be happy with your TravelMate as much as we enjoyed making it for you. Yo u r g u i d e s To help you use your TravelMate, we have designed a set of guides: For more information about our products, services, and support information, please visit our Web site (www.acer.com). First off, the Just for Starters... poster helps you get started with setting up your computer. This User’s guide introduces you to the many ways your computer can help you be more productive. This guide provides clear and concise information about the computer, so read it thoroughly. If you ever need to print out a copy, this User’s guide is also available in PDF (Portable Document Format). Follow these steps: 1 Click on Start, Programs, TravelMate. 2 Click on TravelMate User’s guide. Note: Viewing the file requires Adobe Acrobat Reader installed. For instructions on how to use Adobe Acrobat Reader, access the Help menu. iv English Basic care and tips for using your computer Turning your computer on and off To turn on the computer, simply press the power button on the left of the launch keys found above your TravelMate’s standard keyboard. See “Front view” on page 4 for the location of the power switch. To turn the power off, do any of the following: •Use the Windows shutdown command For Windows 2000: Click on Start, Shut Down..., and select Shut down; then click on OK. - or - For Windows XP: Click on Start, Turn off Computer; then click Tur n Off. •Use the power switch Note: You can also use the power switch to perform power management functions. See Windows help for more information. •Use the customized functions for power management You can also shut down the computer by closing the display cover, or by pressing the sleep hot key (Fn-F4). See the online guide for details. Note: If you cannot power off the computer normally, press and hold the power switch for more than four seconds to shut down the computer. If you turn off the computer and want to turn it on again, wait at least two seconds before powering up. Taking care of your computer Your computer will serve you well if you take care of it. •Do not expose the computer to direct sunlight. Do not place it near sources of heat, such as a radiator. •Do not expose the computer to temperatures below 0ºC (32ºF) or above 50ºC (122ºF). •Do not subject the computer to magnetic fields. v English •Do not expose the computer to rain or moisture. •Do not spill water or any liquid on the computer. •Do not subject the computer to heavy shock and vibration. •Do not expose the computer to dust and dirt. •Never place objects on top of the computer to avoid damaging the computer. •Do not slam the computer display when you close it. •Never place the computer on uneven surfaces. Taking care of your AC adapter Here are some ways to take care of your AC adapter: •Do not connect the adapter to any other device. •Do not step on the power cord or place heavy objects on top of it. Carefully route the power cord and any cables away from personal traffic. •When unplugging the power cord, do not pull on the cord itself but pull on the plug. •The total ampere ratings of the equipment plugged in should not exceed the ampere rating of the cord if you are using an extension cord. Also, the total current rating of all equipment plugged into a single wall outlet should not exceed the fuse rating. Taking care of your battery pack Here are some ways to take care of your battery pack: •Use only batteries of the same kind as replacements. Turn the power off before removing or replacing batteries. •Do not tamper with batteries. Keep them away from children. •Dispose of used batteries according to local regulations. Recycle if at all possible. Cleaning and servicing When cleaning the computer, follow these steps: 1Power off the computer and remove the battery pack. 2Disconnect the AC adapter. vi English 3Use a soft cloth moistened with water. Do not use liquid or aerosol cleaners. 4To clean the display screen, use an LCD cleaning kit. If any of the following occurs: •The computer has been dropped or the body has been damaged. •Liquid has been spilled into the product. •The computer does not operate normally. Please refer to…

Text truncated - open the document above for the full version.

23 English Tapping on the touchpad produces similar results. •Use the 4-way scroll (2) button (top/bottom/left and right) to scroll a page up, down, left or right. This button mimics your cursor pressing on the vertical and horizontal scroll bars of Windows applications. Note: Keep your fingers dry and clean when using the touchpad. Also keep the touchpad dry and clean. The touchpad is sensitive to finger movements. Hence, the lighter the touch, the better the response. Tapping harder will not increase the touchpad’s responsiveness. FunctionLeft button Right button Center buttons Ta p ExecuteClick twice quickly Tap twice (at the same speed as double-clicking a mouse button) SelectClick onceTap once DragClick and hold, then use finger to drag the cursor on the touchpad Tap twice (at the same speed as double-clicking a mouse button) then hold finger to the touchpad on the second tap and drag the cursor Access context menu Click once ScrollClick and hold the button in the desired direction (up/down/ left/right) 1 Getting to know your TravelMate24 English Storage This computer supplies you with the following media storage: •High-capacity Enhanced-IDE hard disk •AcerMedia drive Hard disk The high-capacity hard disk is the answer to your storage needs. This is where your programs and data are stored. AcerMedia bay The AcerMedia bay accepts a wide variety of optional media drive modules for use with your computer. These optional items include: •CD-ROM drive •DVD-ROM drive •DVD/CD-RW drive •Second hard disk drive •Second battery Note: To swap AcerMedia drive modules, see “Swapping AcerMedia drive modules” on page 52 25 English Ejecting the optical (CD or DVD) drive tray To eject the optical drive tray when the computer is turned on, press the drive eject button. When the power is off, you can eject the drive tray using the emergency eject hole. See page 58. Using software Playing DVD movies When the DVD-ROM drive module is installed in the AcerMedia bay, you can play DVD movies on your computer. 1Eject the DVD tray and insert a DVD movie disc; then close the DVD tray. Important! When you launch the DVD player for the first time, the program asks you to input the region code. DVD discs are divided into 6 regions. Once your DVD drive is set to a region code, it will play DVD discs of that region only. You can set the region code a maximum of five times (including the first time), after which the last region code set will remain permanent. Recovering your hard disk does not reset the number of times the region code has been set. Refer to the table below for DVD movie region code information. 1 Getting to know your TravelMate26 English 2The DVD movie will automatically play after a few seconds. Note: To change the region code, insert a DVD movie of a different region into the DVD-ROM drive. Please refer to the online help for more information. Region codeCountry or region 1U.S.A., Canada 2Europe, Middle East, South Africa, Japan 3Southeast Asia, Taiwan, Korea (South) 4Latin America, Australia, New Zealand 5Former U.S.S.R., parts of Africa, India 6People's Republic of China 27 English Audio The computer comes with 16-bit high-fidelity AC’97 stereo audio, and includes a built-in sensitive microphone and dual stereo speakers. There are audio ports on the rear of the computer. See “Rear view” on page 8 for more information on connecting external audio devices. Adjusting the volume Adjusting the volume on the computer is as easy as pressing some buttons. See “Hot keys” on page 16 for more informations on adjusting the speaker volume. 1 Getting to know your TravelMate28 English Power management This computer has a built-in power management unit that monitors system activity. System activity refers to any activity involving one or more of the following devices: keyboard, mouse, floppy drive, hard disk, peripherals connected to the serial and parallel ports, and video memory. If no activity is detected for a period of time (called an inactivity timeout), the computer stops some or all of these devices in order to conserve energy. This computer employs a power management scheme that supports ACPI (Advanced Configuration and Power Interface), which allows for maximum power conservation and maximum performance at the same time. Windows handles all power-saving chores for your computer. 29 English Moving around with your TravelMate This section gives you tips and hints to consider when moving around or traveling with your computer. Disconnecting from the desktop Follow these steps to disconnect your computer from external accessories: 1Save your work in progress. 2Remove any media, diskette or compact disc, from the drive(s). 3Shut down the computer. 4Close the display cover. 5Disconnect the cord from the AC adapter. 6Disconnect the keyboard, pointing device, printer, external monitor, and other external devices. 7Disconnect the Kensington lock if you are using one to secure the computer. Moving around “when you are just moving within short distances, for example, from your office desk to a meeting room” Preparing the computer Before moving the computer, close and latch the display cover to place it in Sleep mode. You can now safely take the computer anywhere you go within the building. To bring the computer out of Sleep mode, open the display; then slide and release the power switch. If you are taking the computer to a client's office or a different building, you may choose to shut down the computer: 1Click on Start, Shut Down... or Turn off Computer (Windows XP). 2Select Shut down and click on OK, or select Tur n Off (Windows XP). 1 Getting to know your TravelMate30 English - or - you can put the computer in Sleep mode by pressing Fn-F4. Then close and latch the display. When you are ready to use the computer again, unlatch and open the display; then slide and release the power switch. Note: If the sleep indicator is off, the computer has entered Hibernation mode and turned off. If the power indicator is off …

Text truncated - open the document above for the full version.

C&C Laboratory Co. Ltd. REPORT NO: 030049-RID FCC ID: HFSZI2WM3B2100BT DATE: Apr 24, 2003 Page 1 Rev. 00 APPENDIX 2 EXTERNAL PHOTOGRPHS OF EUT C&C Laboratory Co. Ltd. REPORT NO: 030049-RID FCC ID: HFSZI2WM3B2100BT DATE: Apr 24, 2003 Page 2 Rev. 00 Open of EUT Front of EUT C&C Laboratory Co. Ltd. REPORT NO: 030049-RID FCC ID: HFSZI2WM3B2100BT DATE: Apr 24, 2003 Page 3 Rev. 00 Back of EUT Left of EUT C&C Laboratory Co. Ltd. REPORT NO: 030049-RID FCC ID: HFSZI2WM3B2100BT DATE: Apr 24, 2003 Page 4 Rev. 00 Right of EUT Front of Adaptor C&C Laboratory Co. Ltd. REPORT NO: 030049-RID FCC ID: HFSZI2WM3B2100BT DATE: Apr 24, 2003 Page 5 Rev. 00 Back of adaptor

C&C Laboratory Co. Ltd. REPORT NO: 030049-RID FCC ID: HFSZI2WM3B2100BT DATE: Apr 24, 2003 Page 1 Rev. 00 APPENDIX 3 INTERNAL PHOTOGRPHS OF EUT C&C Laboratory Co. Ltd. REPORT NO: 030049-RID FCC ID: HFSZI2WM3B2100BT DATE: Apr 24, 2003 Page 2 Rev. 00 Internal of EUT-1 Internal of EUT-2 WLAN Antenna Position WLAN Antenna Position C&C Laboratory Co. Ltd. REPORT NO: 030049-RID FCC ID: HFSZI2WM3B2100BT DATE: Apr 24, 2003 Page 3 Rev. 00 Internal of EUT-3 Internal of EUT-4 C&C Laboratory Co. Ltd. REPORT NO: 030049-RID FCC ID: HFSZI2WM3B2100BT DATE: Apr 24, 2003 Page 4 Rev. 00 Internal of EUT-5 Internal of EUT-6 WLAN Module Bluetooth Module BT Antenna C&C Laboratory Co. Ltd. REPORT NO: 030049-RID FCC ID: HFSZI2WM3B2100BT DATE: Apr 24, 2003 Page 5 Rev. 00 Front of motherboard Back of motherboard Bluetooth Antenna Position C&C Laboratory Co. Ltd. REPORT NO: 030049-RID FCC ID: HFSZI2WM3B2100BT DATE: Apr 24, 2003 Page 6 Rev. 00 Front of Bluetooth Module Back of Bluetooth Module C&C Laboratory Co. Ltd. REPORT NO: 030049-RID FCC ID: HFSZI2WM3B2100BT DATE: Apr 24, 2003 Page 7 Rev. 00 Front of Bluetooth Module with Antenna Back of Bluetooth Module with Antenna C&C Laboratory Co. Ltd. REPORT NO: 030049-RID FCC ID: HFSZI2WM3B2100BT DATE: Apr 24, 2003 Page 8 Rev. 00 Front of Wireless LAN Module-1 Front of Wireless LAN Module-2 C&C Laboratory Co. Ltd. REPORT NO: 030049-RID FCC ID: HFSZI2WM3B2100BT DATE: Apr 24, 2003 Page 9 Rev. 00 Back of Wireless LAN Module Front of WLAN Antenna C&C Laboratory Co. Ltd. REPORT NO: 030049-RID FCC ID: HFSZI2WM3B2100BT DATE: Apr 24, 2003 Page 10 Rev. 00 Back of WLAN Antenna

in accordance with the requirements of FCC Report and Order: ET Docket 93-62, and OET Bulletin 65 Supplement C for Notebook Computer With 802.11b Wireless LAN and Bluetooth Modem MODEL: ZI2 FCC ID: HFSZI2WM3B2100BT May 2, 2003 REPORT NO: 03T1947-1 Prepared for Quanta Computer Inc. No. 188, Wen Hwa 2 nd Road Kuei Shan Hsiang, Tao Yuan Shien Taiwan, R. O. C. Prepared by COMPLIANCE CERTIFICATION SERVICES 561F MONTEREY ROAD MORGAN HILL, CA 95037 USA TEL: (408) 463-0885 REPORT NO: 03T1947-1 DATE: May 2, 2003 FCC ID: HFSZI2WM3B2100BT COMPLIANCE CERTIFICATION SERVICES Page: 2 of 24 This report shall not be reproduced except in full, without the written approval of CCS. This document may be altered or revised by Compliance Certification Services personnel only, and shall be noted in the revision section of the document. CERTIFICATE OF COMPLIANCE (SAR EVALUATION) Date of Tests: May 1 & 2, 2003 Report No: 03T1947-1 APPLICANT: Quanta Computer Inc. No. 188, Wen Hwa 2nd Road Kuei Shan Hsiang, Tao Yuan Shien Taiwan, R. O. C. MODEL: ZI2 FCC ID: HFSZI2WM3B2100BT DEVICE CATEGORY: PORTABLE DEVICES EXPOSURE CATEGORY: GENERAL POPULATION/UNCONTROLLED EXPOSURE Test Sample is a: Production unit Modulation type: DSSS - 802.11b Wireless LAN DSSS - Bluetooth Tx Frequency: Wireless LAN - 2412 ~ 2462 MHz Bluetooth - 2402 ~ 2480 MHz Max. O/P Power: Wireless LAN – 14.43 dBm (Conducted) Max. SAR (1g): Wireless LAN – 0.0243 mW/g Co-Location – 0.0247 mW/g Application Type: Certification FCC Rule Part(s): §15.247 This wireless portable device has been shown to be capable of compliance for localized specific absorption rate (SAR) for uncontrolled environment/general population exposure limits specified in ANSI/IEEE Std. C95.1-1992 and had been tested in accordance with the measurement procedures specified in FCC OET 65 Supplement C (released on 6/29/2001 see Test Report). I attest to the accuracy of data. All measurements reported herein were performed by me or were made under my supervision and are correct to the best of my knowledge and belief. I assume full responsibility for the completeness of these measurements and vouch for the qualifications of all persons taking them. Steve Cheng EMC Engineering Manager REPORT NO: 03T1947-1 DATE: May 2, 2003 FCC ID: HFSZI2WM3B2100BT COMPLIANCE CERTIFICATION SERVICES Page: 3 of 24 This report shall not be reproduced except in full, without the written approval of CCS. This document may be altered or revised by Compliance Certification Services personnel only, and shall be noted in the revision section of the document. TABLE OF CONTENT 1. EUT DESCRIPTION ............................................................................................. 4 2. REQUIREMENTS FOR COMPLIANCE TESTING DEFINED BY THE FCC ............... 5 3. DOSIMETRIC ASSESSMENT SYSTEM ................................................................ 5 3.1. MEASUREMENT SYSTEM DIAGRAM.............................................................................................6 3.2. SYSTEM COMPONENTS.................................................................................................................7 4. EVALUATION PROCEDURES .............................................................................. 9 5. MEASUREMENT UNCERTAINTY ....................................................................... 12 6. EXPOSURE LIMIT ............................................................................................. 13 7. MEASUREMENT RESULTS ............................................................................... 14 7.1. SYSTEM VALIDATION ...................................................................................................................14 7.2. TEST LIQUID CONFIRMATION .....................................................................................................15 7.3. EUT TUNE-UP PROCEDURES......................................................................................................16 7.4. EUT SETUP PHOTOS....................................................................................................................17 7.5. SAR MEASUREMENT RESULTS ..................................................................................................19 8. EUT PHOTOS .................................................................................................... 20 9. EQUIPMENTS LIST & CALIBRATION STATUS .................................................. 22 10. REFERENCES .................................................................................................. 23 11. ATTACHMENTS ................................................................................................ 24 REPORT NO: 03T1947-1 DATE: May 2, 2003 FCC ID: HFSZI2WM3B2100BT COMPLIANCE CERTIFICATION SERVICES Page: 4 of 24 This report shall not be reproduced except in full, without the written approval of CCS. This document may be altered or revised by Compliance Certification Services personnel only, and shall be noted in the revision section of the document. 1. EUT DESCRIPTION APPLICANT: Quanta Computer Inc. No. 188, Wen Hwa 2nd Road Kuei Shan Hsiang, Tao Yuan Shien Taiwan, R. O. C. MODEL: ZI2 FCC ID: HFSZI2WM3B2100BT DEVICE CATEGORY: PORTABLE DEVICES EXPOSURE CATEGORY: GENERAL POPULATION/UNCONTROLLED EXPOSURE Test Sample is a: Production unit Modulation type: DSSS - 802.11b Wireless LAN DSSS - Bluetooth Tx Frequency: Wireless LAN - 2412 ~ 2462 MHz Bluetooth - 2402 ~ 2480 MHz Max. O/P Power: Wireless LAN – 14.43 dBm (Conducted) Max. SAR (1g): Wireless LAN – 0.0243 mW/g Co-Location – 0.0247 mW/g Application Type: Certification FCC Rule Part(s): §15.247 Wireless Module: 1. Wireless LAN - Manufactured “Intel”, model “WM3B2100” 2. Bluetooth - Manufactured “Ambit”, model “T60M665” Antenna (s): 1. Main / Aux - Manufactured by Foxconn, Part no WDAN-Q1ZI1002 2. Bluetooth - Manufactured by Foxconn, Part no WDAN-Q1ZI1003 See attachments for details. 1 Specific Absorption Rate (SAR) is a measure of the ra…

Text truncated - open the document above for the full version.

Date/Time: 05/01/03 09:47:22 Test Laboratory: Compliance Certification Services File Name: D2450V2 SN 706_12.8 mW.da4 DUT: Dipole Type & Serial Number: D2450V2 SN 706 Program: System Validation (ET3DV6 SN 1577); I/P Power 250 mW, Air temp. 26 deg C, liquid temp. 24 deg C Communication System: CW - 2450 MHz; Frequency: 2450 MHz; Duty Cycle: 1:1 Medium: Head 2450 MHz ( σ = 1.8496 mho/m, ε = 39.94, ρ = 1000 kg/m3) Phantom section: FlatSection DASY4 Configuration: - Probe: ET3DV6 - SN1577; ConvF(5.1, 5.1, 5.1); Calibrated: 2/7/2003 - Sensor-Surface: 4mm (Mechanical Surface Detection) - Electronics: DAE3 Sn427; Calibrated: 2/4/2003 - Phantom: SAM 1 - TP:1185 - Software: DASY4, V4.0 Build 51 Zoom Scan (5x5x7)/Cube 0: Measurement grid: dx=7.5mm, dy=7.5mm Reference Value = 93.9 V/m Peak SAR = 26.7 mW/g SAR(1 g) = 12.8 mW/g; SAR(10 g) = 5.79 mW/g Power Drift = -0.02 dB Area Scan (9x9x1): Measurement grid: dx=10mm, dy=10mm SAR in dB -21.8 -19.6 -17.4 -15.3 -13.1 -10.9 -8.72 -6.54 -4.36 -2.18 0 Date/Time: 05/02/03 09:53:02 Test Laboratory: Compliance Certification Services File Name: D2450V2 SN 706_12.9 mW.da4 DUT: Dipole Type & Serial Number: D2450V2 SN 706 Program: System Validation (ET3DV6 SN 1577); I/P Power 250 mW, Air temp. 26 deg C, liquid temp. 24 deg C Communication System: CW - 2450 MHz; Frequency: 2450 MHz; Duty Cycle: 1:1 Medium: Head 2450 MHz ( σ = 1.8536 mho/m, ε = 39.55, ρ = 1000 kg/m3) Phantom section: FlatSection DASY4 Configuration: - Probe: ET3DV6 - SN1577; ConvF(5.1, 5.1, 5.1); Calibrated: 2/7/2003 - Sensor-Surface: 4mm (Mechanical Surface Detection) - Electronics: DAE3 Sn427; Calibrated: 2/4/2003 - Phantom: SAM 1 - TP:1185 - Software: DASY4, V4.0 Build 51 Zoom Scan (5x5x7)/Cube 0: Measurement grid: dx=7.5mm, dy=7.5mm Reference Value = 93.8 V/m Peak SAR = 26.7 mW/g SAR(1 g) = 12.9 mW/g; SAR(10 g) = 5.88 mW/g Power Drift = -0.04 dB Area Scan (9x9x1): Measurement grid: dx=10mm, dy=10mm SAR in dB -22 -19.8 -17.6 -15.4 -13.2 -11 -8.78 -6.59 -4.39 -2.2 0

Date/Time: 05/01/03 14:27:12 Test Laboratory: Compliance Certification Services File Name: 1L-CH_0.0233 mW.da4 EUT Seup Configuration 1 (Main Antenna) SAR in dB -2.85 -2.53 -2.21 -1.9 -1.58 -1.26 -0.949 -0.632 -0.316 0 Date/Time: 05/01/03 14:27:12 Test Laboratory: Compliance Certification Services File Name: 1L-CH_0.0233 mW.da4 DUT: Quanta Type & Serial Number: Z12 Program: EUT Seup Configuration 1; Air temp 26 deg C & Liquid temp 24 deg C Communication System: DSSS; Frequency: 2412 MHz; Duty Cycle: 1:1 Medium: Muscle 2450 MHz ( σ = 1.8632 mho/m, ε = 54.89, ρ = 1000 kg/m3) Phantom section: FlatSection DASY4 Configuration: - Probe: ET3DV6 - SN1577; ConvF(4.7, 4.7, 4.7); Calibrated: 2/7/2003 - Sensor-Surface: 4mm (Mechanical Surface Detection) - Electronics: DAE3 Sn427; Calibrated: 2/4/2003 - Phantom: SAM 2 - TP:1050 - Software: DASY4, V4.0 Build 51 Zoom Scan (5x5x7)/Cube 0: Measurement grid: dx=7.5mm, dy=7.5mm Reference Value = 3.59 V/m Peak SAR = 0.0421 mW/g SAR(1 g) = 0.0233 mW/g; SAR(10 g) = 0.0182 mW/g Power Drift = -0.12 dB Area Scan (10x29x1): Measurement grid: dx=10mm, dy=10mm SAR in dB -2.85 -2.53 -2.21 -1.9 -1.58 -1.26 -0.949 -0.632 -0.316 0 Date/Time: 05/01/03 14:27:12 Test Laboratory: Compliance Certification Services File Name: 1L-CH_0.0229 mW.da4 DUT: Quanta Type & Serial Number: Z12 Program: EUT Seup Configuration 1; Air temp 26 deg C & Liquid temp 24 deg C Communication System: DSSS; Frequency: 2412 MHz; Duty Cycle: 1:1 Medium: Muscle 2450 MHz ( σ = 1.8632 mho/m, ε = 54.89, ρ = 1000 kg/m3) Phantom section: FlatSection DASY4 Configuration: - Probe: ET3DV6 - SN1577; ConvF(4.7, 4.7, 4.7); Calibrated: 2/7/2003 - Sensor-Surface: 4mm (Mechanical Surface Detection) - Electronics: DAE3 Sn427; Calibrated: 2/4/2003 - Phantom: SAM 2 - TP:1050 - Software: DASY4, V4.0 Build 51 Zoom Scan (5x5x7)/Cube 1: Measurement grid: dx=7.5mm, dy=7.5mm Reference Value = 3.59 V/m Peak SAR = 0.0464 mW/g SAR(1 g) = 0.0229 mW/g; SAR(10 g) = 0.0181 mW/g Power Drift = -0.12 dB Area Scan (10x29x1): Measurement grid: dx=10mm, dy=10mm SAR in dB -2.53 -2.27 -2.02 -1.77 -1.52 -1.26 -1.01 -0.758 -0.505 -0.253 0 Date/Time: 05/01/03 14:35:46 Test Laboratory: Compliance Certification Services File Name: 2M-CH_0.0223 mW.da4 DUT: Quanta Type & Serial Number: Z12 Program: EUT Seup Configuration 1; Air temp 26 deg C & Liquid temp 24 deg C Communication System: DSSS; Frequency: 2437 MHz; Duty Cycle: 1:1 Medium: Muscle 2450 MHz ( σ = 1.8632 mho/m, ε = 54.89, ρ = 1000 kg/m3) Phantom section: FlatSection DASY4 Configuration: - Probe: ET3DV6 - SN1577; ConvF(4.7, 4.7, 4.7); Calibrated: 2/7/2003 - Sensor-Surface: 4mm (Mechanical Surface Detection) - Electronics: DAE3 Sn427; Calibrated: 2/4/2003 - Phantom: SAM 2 - TP:1050 - Software: DASY4, V4.0 Build 51 Zoom Scan (5x5x7)/Cube 0: Measurement grid: dx=7.5mm, dy=7.5mm Reference Value = 3.25 V/m Peak SAR = 0.041 mW/g SAR(1 g) = 0.0223 mW/g; SAR(10 g) = 0.0171 mW/g Power Drift = 0.09 dB Area Scan (10x29x1): Measurement grid: dx=10mm, dy=10mm SAR in dB -3.26 -2.93 -2.6 -2.28 -1.95 -1.63 -1.3 -0.977 -0.651 -0.326 0 Date/Time: 05/01/03 14:35:46 Test Laboratory: Compliance Certification Services File Name: 2M-CH_0.0209 mW.da4 DUT: Quanta Type & Serial Number: Z12 Program: EUT Seup Configuration 1; Air temp 26 deg C & Liquid temp 24 deg C Communication System: DSSS; Frequency: 2437 MHz; Duty Cycle: 1:1 Medium: Muscle 2450 MHz ( σ = 1.8632 mho/m, ε = 54.89, ρ = 1000 kg/m3) Phantom section: FlatSection DASY4 Configuration: - Probe: ET3DV6 - SN1577; ConvF(4.7, 4.7, 4.7); Calibrated: 2/7/2003 - Sensor-Surface: 4mm (Mechanical Surface Detection) - Electronics: DAE3 Sn427; Calibrated: 2/4/2003 - Phantom: SAM 2 - TP:1050 - Software: DASY4, V4.0 Build 51 Zoom Scan (5x5x7)/Cube 1: Measurement grid: dx=7.5mm, dy=7.5mm Reference Value = 3.25 V/m Peak SAR = 0.0467 mW/g SAR(1 g) = 0.0209 mW/g; SAR(10 g) = 0.0167 mW/g Power Drift = 0.09 dB Area Scan (10x29x1): Measurement grid: dx=10mm, dy=10mm SAR in dB -2.4 -2.16 -1.92 -1.68 -1.44 -1.2 -0.962 -0.721 -0.481 -0.24 0 Date/Time: 05/01/03 14:43:46 Test Laboratory: Compliance Certification Services File Name: 3H-CH_0.0243 mW.da4 DUT: Quanta Type & Serial Number: Z12 Program: EUT Seup Configuration 1; Air temp 26 deg C & Liquid temp 24 deg C Communication System: DSSS; Frequency: 2462 MHz; Duty Cycle: 1:1 Medium: Muscle 2450 MHz ( σ = 1.8632 mho/m, ε = 54.89, ρ = 1000 kg/m3) Phantom section: FlatSection DASY4 Configuration: - Probe: ET3DV6 - SN1577; ConvF(4.7, 4.7, 4.7); Calibrated: 2/7/2003 - Sensor-Surface: 4mm (Mechanical Surface Detection) - Electronics: DAE3 Sn427; Calibrated: 2/4/2003 - Phantom: SAM 2 - TP:1050 - Software: DASY4, V4.0 Build 51 Zoom Scan (5x5x7)/Cube 0: Measurement grid: dx=7.5mm, dy=7.5mm Reference Value = 3.27 V/m Peak SAR = 0.0445 mW/g SAR(1 g) = 0.0243 mW/g; SAR(10 g) = 0.0186 mW/g Power Drift = 0.08 dB Area Scan (10x29x1): Measurement grid: dx=10mm, dy=10mm SAR in dB -3.15 -2.84 -2.52 -2.21 -1.89 -1.58 -1.26 -0.946 -0.631 -0.315 0 Date/Time: 05/01/03 17:08:08 Test Laboratory: Compliance Certification Services File Name: 2M-CH_0.0154 mW .da4 EUT SeupConfiguration 1 (Aux Antenna) SAR in dB -6.55 -5.89 -5.24 -4.58 -3.93 -3.27 -2.62 -1.96 -1.31 -0.655 0 Date/Time: 05/01/03 17:05:22 Test Laboratory: Compliance Certification Services File Name: 2M-CH_0.0154 mW.da4 DUT: Quanta Type & Serial Number: Z12 Program: EUT Seup Configuration 1; Air temp 26 deg C & Liquid temp 24 deg C Communication System: DSSS; Frequency: 2437 MHz; Duty Cycle: 1:1 Medium: Muscle 2450 MHz ( σ = 1.8632 mho/m, ε = 54.89, ρ = 1000 kg/m3) Phantom section: FlatSection DASY4 Configuration: - Probe: ET3DV6 - SN1577; ConvF(4.7, 4.7, 4.7); Calibrated: 2/7/2003 - Sensor-Surface: 4mm (Mechanical Surface Detection) - Electronics: DAE3 Sn427; Calibrated: 2/4/2003 - Phantom: SAM 2 - TP:1050 - Software: DASY4, V4.0 Build 51 Zoom Scan (5x5x7)/Cube 0: Measurement grid: dx=7.5mm, dy=7.5mm Reference Value = 1.67 V/m Peak SAR = 0.044 mW/g SAR(1 g) = 0.0154 mW/g; SAR(10 g) = 0.00…

Text truncated - open the document above for the full version.

C&C Laboratory Co. Ltd. REPORT NO: 030049-RID FCC ID: HFSZI2WM3B2100BT DATE: Apr 24, 2003 Page 1 of 55 Rev. 00 ELECTROMAGNETIC EMISSIONS COMPLIANCE REPORT INTENTIONAL RADIATOR CERTIFICATION TO FCC PART 15 SUBPART C (DSS) REQUIREMENT OF Notebook with WLAN + Bluetooth module MODEL No.: ZI2 FCC ID: HFSZI2WM3B2100BT REPORT NO: 030049-RID ISSUE DATE: April 24, 2003 Prepared for Quanta Computer Inc. No. 188, Wen Hwa 2 nd Rd., Kuei Shan Hsiang, Tao Yuan Hsien, Taiwan, R.O.C. Prepared by C&C LABORATORY, CO., LTD. No. 81-1, 210 Lane, Pa-de 2 nd Road, Lu-Chu Hsiang, Taoyuan, Taiwan, R.O.C. TEL: (03) 324-0332 FAX: (03) 324-5235 This report shall not be reproduced, except in full, without the written approval of C&C LABORATORY, CO., LTD. C&C Laboratory Co. Ltd. REPORT NO: 030049-RID FCC ID: HFSZI2WM3B2100BT DATE: Apr 24, 2003 Page 2 Rev. 00 VERIFICATION OF COMPLIANCE Applicant: Quanta Computer Inc. No. 188, Wen Hwa 2 nd Rd., Kuei Shan Hsiang, Tao Yuan Hsien, Taiwan, R.O.C. Equipment Under Test: Notebook with WLAN + Bluetooth module BRAND NAME: acer MODEL No.: ZI2 Serial Number: N/A File Number: 030049-RID Date of Test: Apr. 10 2003 ~Apr. 15, 2003 We hereby certify that: The above equipment was tested by C&C Laboratory Co., Ltd. The test data, data evaluation, test procedures, and equipment configurations shown in this report were made in accordance with the procedures given in ANSI C63.4 ( 2001 ) and the energy emitted by the sample EUT tested as described in this report is in compliance with conducted and radiated emission lim- its of FCC Rules Part 15. The test results of this report relate only to the tested sample identified in this report. Approved by: Reviewed by: Jonson Lee / EMC Director Susan Su / Section Manager C&…
