Unitech Electronics Co., Ltd. Code: MS860 Product Design Specification Version 1.0 (Internal Used Only) Prepared by Eric Date: June 11, 2003 _____________________ VP Yuan / SBU Release to UTA, UTC, UTI, UTT, and APAC _____________________ General Manager Chen / ADC Group FEDERAL COMMUNICATIONS COMMISSION This device complies with Part 15 of the FCC Rules. Operation is subject to the following two conditions: (1) this device may not cause harmful interference, and (2) this device must accept any interference received, including interference that may cause undesired operation. Note This equipment has been tested and found to comply with the limits for a Class B digital device, pursuant to Part 15 of the FCC Rules. These limits are designed to provide reasonable protection. This equipment generates, uses and can radiated radio frequency energy and, if not installed and used in accordance with the instructions, may cause harmful interference to radio communications. However, there is no guarantee that interference will not occur in a particular installation If this equipment does cause harmful interference to radio or television reception, which can be determined by turning the equipment off and on, the user is encouraged to try to correct the interference by one or more of the following measures: -Reorient or relocate the receiving antenna. -Increase the separation between the equipment and receiver. -Connect the equipment into an outlet on a circuit different from that to which the receiver is connected. -Consult the dealer or an experienced radio/TV technician for help. Changes or modifications not expressly approved by the party responsible for compliance could void the user‘s authority to operate the equipment. The antenna(s) used for this transmitter must not be co-located or operating in conjunction with any other antenna or transmitter. - 1 - 1. Product Goal and Applications 1.1. The Product Goal This product MS860 is ready to give a brand new image of handheld gun type Laser scanner with extremely robust design and solid feel holding that incorporates bluetooth design. Unitech has moved one step forward to the wireless scanner that addresses the need of many applications, giving an additional value to the product when mobility is a must nowadays. 1.2. Applications 2.2.1. Cash & Retail Application 2.2.3. Back Office Inventory 2.2.4. Oversized items checkout 2.2.5. Document Tracking and Utilities 1 3. Features and Benefits 3.1 Comfortable and solid feel holding for easy use 3.2 Wireless design eliminates cables for safer and more reliable scanning 3.3 Enables users to format data before it is sent to the host computer eliminating costly modifications to the host software 3.4 Fast reading and decoding of all major linear bar codes 3.5 High tone beeper and strong illuminating LED 3.6 Rechargeable Lithium-ion battery: 10 hours of wireless scanning performance. 3.7 Unlicensed radio frequency transmission for maximum application flexibility 3.8 Flexible setup using PC utility (Windows based) download, or by scanning a sequence of bar codes 3.9 Interface to all major PCs, Apple computer and terminals. 2 4. Specifications 4.1 Performance/Optics 4.1.1 Optical System: Symbol SE 1200WA Wide Angle Scan Engine 4.1.2 Light Source: Visible Laser Diode 650 nm 4.1.3 Ambient light: Immune to light exposure in stores and offices, and direct exposure to sunlight 4.1.4 Scan Rate: 35 (± 5) scans/sec (bi-directional) 4.1.5 Maximum Resolution: 0.13mm (5mil) 4.1.6 Reading Distance: 0cm – 63.5cm (25”) 4.1.7 Reading Width: Up to 52.4cm (20.6”) on 55mil resolution code and Up to 22cm on the code on local/national tax receipt in Taiwan 4.1.8 PCS: Minimum 20% 4.1.9 Scan Angle: 53º ± 2º 4.1.10 Symbologies: CODE 39 Full ASCII CODABAR Label Code CODE 39 Standard CODE 128 Plessy Code EAN-13 CODE 93 CODE 11 UPC-A Standard 2 of 5 China Postal Code (Toshiba Code) EAN-8 MSI Code UPC-E EAN-128 Interleaved 2 of 5 CODE 32 (Italian pharmacy) 3 4.2 Mechanical design 4.2.1 Color for main body: Dark Color. 4.2.2 Drop Test: Scanner – 1.8m drop onto concrete over entire temperature range, Cradle – 1m drop onto concrete over entire temperature range. 4.2.3 Housing (scanner and cradle): Rubber and ABS plastic with solid feel holding for demanding work environment 4.2.4 Switch (with 1 million time micro switch life) 4.2.5 Handle is smoothly contoured to fit all sized hands. 4.2.6 A battery compartment located inside of gun grip is required. 4.2.7 Battery pack can be replacement 4.3 Electrical 4.3.1 Decoder in Scanner: Unitech Hamster decoder chip for MS860 4.3.2 Decoder in Cradle: Unitech Hamster decoder chip 4.3.3 Indications for Scanner (using one dual color LED and one buzzer): Read (LED Red), Good Read and Transmit to Host OK (LED Green with one beep), Battery Low (LED Red flash), Programming and Configuration Status (Green LED flashing), Cable Connection Detection (10 beeps when cable fall off cradle), Out of Range and Cradle power off (3 beeps) 4.3.4 Indications for Cradle (using three LED): Power On (LED 1 Green), Scanner Charging (LED 2 Red), Charge Complete (LED 2 Green), Receive data from Scanner (LED 3 Red), Transmit data to Host OK (LED 3 Green) 4.3.5 Battery Recharge Time: below 4.5 hours 4.3.6 Operating Time: more than 10 hours under per 5 sec scan 4.3.7 Blue Tooth Module: Built in the Rainsun BT-20 of Scanner and Cradle 4.3.8 Battery type: 1900mAH / 3.6V SANYO Lithium-ion 4 4.3.9 Buzzer (in Scanner and Cradle): 90dB from 10cm distance measured 4.4 Communications Cradle / Host: Keyboard Wedge / RS232 / USB for IBM PC or compatible, MAC, and common terminals. (replace the interface cable on cradle without changing H/W or F/W) 4.4.1 4.4.2 4.4.3 4.4.4 4.4.5 4.4.6 Radio: unlicensed 2.4GHz point to point Transmit Power (dBm): 0 dbm Radio Range: under 30M, line of sight Out of Range detection: error tone indication and scanner doesn’t transmit the code decoding Cable fall off detection 4.5 Programming Method 4.5.1 User’s Man…

Text truncated - open the document above for the full version.

FCC ID: HLEMS860 Label Location

MODEL NO.: MS860 10mm 40mm

FCC TEST REPORT REPORT NO. : F390307 SPORTON International Inc. PAGE NUMBER : A1 OF A9 TEL : 886-2-2696-2468 ISSUED DATE : Oct. 17, 2003 FAX : 886-2-2696-2255 FCC TEST REPORT REPORT NO. : F390307 SPORTON International Inc. PAGE NUMBER : A2 OF A9 TEL : 886-2-2696-2468 ISSUED DATE : Oct. 17, 2003 FAX : 886-2-2696-2255 FCC TEST REPORT REPORT NO. : F390307 SPORTON International Inc. PAGE NUMBER : A3 OF A9 TEL : 886-2-2696-2468 ISSUED DATE : Oct. 17, 2003 FAX : 886-2-2696-2255 FCC TEST REPORT REPORT NO. : F390307 SPORTON International Inc. PAGE NUMBER : A4 OF A9 TEL : 886-2-2696-2468 ISSUED DATE : Oct. 17, 2003 FAX : 886-2-2696-2255 FCC TEST REPORT REPORT NO. : F390307 SPORTON International Inc. PAGE NUMBER : A5 OF A9 TEL : 886-2-2696-2468 ISSUED DATE : Oct. 17, 2003 FAX : 886-2-2696-2255 FCC TEST REPORT REPORT NO. : F390307 SPORTON International Inc. PAGE NUMBER : A6 OF A9 TEL : 886-2-2696-2468 ISSUED DATE : Oct. 17, 2003 FAX : 886-2-2696-2255 FCC TEST REPORT REPORT NO. : F390307 SPORTON International Inc. PAGE NUMBER : A7 OF A9 TEL : 886-2-2696-2468 ISSUED DATE : Oct. 17, 2003 FAX : 886-2-2696-2255 FCC TEST REPORT REPORT NO. : F390307 SPORTON International Inc. PAGE NUMBER : A8 OF A9 TEL : 886-2-2696-2468 ISSUED DATE : Oct. 17, 2003 FAX : 886-2-2696-2255 FCC TEST REPORT REPORT NO. : F390307 SPORTON International Inc. PAGE NUMBER : A9 OF A9 TEL : 886-2-2696-2468 ISSUED DATE : Oct. 17, 2003 FAX : 886-2-2696-2255

FCC ID:HLE-MS860 Description of Operation EUT is a Bluetooth UART Adapter with 79 channels. This device provided of transmitting speed 1.5Mbps . The device of RF carrier is GFSK. The device adapts Frequency Hopping Spread Spectrum modulation ( FHSS ). An embedded system can become Bluetooth enabled by inserting the Bluetooth RF module that interfaces to the embedded processor via UART interface . The antenna is Dipole Antenna, With embedded system becoming Bluetooth-enable by the Bluetooth Modules, many wireless applications will become possible, such as: Communicate with each other wirelessly (between embedded systems, laptops, PCs, and others), including sharing or exchanges of data (i.e. wireless file transfers between bluetooth-enabled devices).

FCC ID: HLEMS860 Issued on Feb. 16, 2004 Report No.: F390307 SPORTON International Inc. TEL : 886-2-2696-2468 FCC TEST REPORT CATEGORY: Outdoor Mobile End Product PRODUCT NAME: Laser Scanner FCC ID.: HLEMS860 FILING TYPE: Certification BRAND NAME: Unitech MODEL NAME: MS860 APPLICANT: Unitech Electronics Co., Ltd. 8F, No. 118, Lane 235, Pao-Chiao Rd., Hsin-Tien, Taiwan 231, R.O.C. MANUFACTURER: The same as Applicant. ISSUED BY: SPORTON INTERNATIONAL INC. 6F, No. 106, Sec. 1, Hsin Tai Wu Rd., His Chih, Taipei Hsien, Taiwan, R.O.C. Statements: The test result in this report refers exclusively to the presented test model / sample. Without written approval of SPORTON International Inc., the test report shall not be reproduced except in full. Certificate or Test Report could not be used by the applicant to claim the product endorsement by CNLA, NVLAP or any agency of U.S. government. The test equipment used to perform the test are calibrated and traceable to NML/ROC or NIST/USA. Lab Code: 200079-0 FAX : 886-2-2696-2255 FCC ID: HLEMS860 Issued on Feb. 16, 2004 Report No.: F390307 Table of Contents History of this test report....................................................................................................................................ii 1. General Description of Equipment under Test.............................................................................................1 1.1. General Description.........................................................................................................................................................................1 1.2. List of EUT Accessories..................................................................................................................................................................1 1.3. Technical Features..........................................................................................................................................................................1 2. TEST CONFIGURATION OF THE EQUIPMENT UNDER TEST.....................................................................3 2.1. Description of the Test....................................................................................................................................................................3 2.2. Frequency Range Investigated.......................................................................................................................................................3 2.3. Details of the Supporting Units........................................................................................................................................................4 2.4. Connection Diagram of Test System..............................................................................................................................................4 3. TEST SOFTWARE............................................................................................................................................5 4. TEST LOCATION AND STANDARDS.............................................................................................................6 4.1. Test Location...................................................................................................................................................................................6 4.2. Test Standards................................................................................................................................................................................6 4.3. DoC Statement................................................................................................................................................................................6 5. TEST RESULT AND DETAILS.........................................................................................................................7 5.1. Summary of the Test Results..........................................................................................................................................................7 5.2. Hopping Channel Bandwidth...........................................................................................................................................................8 5.3. Number of Hopping Frequency.....................................................................................................................................................11 5.4. Hopping Channel Separation........................................................................................................................................................13 5.5. Dwell Time of Each Frequency within a 30 Seconds Period.........................................................................................................16 5.6. Output Power................................................................................................................................................................................19 5.7. 100KHz Bandwidth of Frequency Band Edges.............................................................................................................................22 5.8. Conducted Emission.....................................................................................................................................................................25 5.9. Test of Radiated Emission............................................................................................................................................................31 5.10.Antenna Requirements.................................................................................................................................................................38 5.11.RF Exposure.................................................................................................................................................................................39 6. List of Measuring Equipments Used............…

Text truncated - open the document above for the full version.

Photographs of Radiated Emission Test Configuration FRONT VIEW REAR VIEW
