HLEMT700FMulti-functional T&A Terminal

i Multi-functional T&A Terminal - MT700 - User’s Manual Version 1.0 i About This Manual Preface This manual explains how to install, operate and maintain the MT700 Multi-Function Versatile Controller. No part of this publication may be reproduced or used in any form, or by any electrical or mechanical means, without permission in writing from the manufacturer, which includes photocopying, recording, or information storage and retrieval systems. The material in this manual is subject to change without notice. © Copyright 2013 unitech Electronics Co., Ltd. All rights reserved. Unitech global website address: http:\\www.unitech-adc.com Microsoft, Windows and ActiveSync are either registered trademarks or trademarks of Microsoft Corporation. Other product names mentioned in this manual may be trademarks or registered trademarks of their respective companies and are hereby acknowledged. Regulatory Compliance Statements FCC Warning Statement This equipment has been tested and found to comply with the limits for a Class B digital device, pursuant to part 15 of the FCC rules. These limits are designed to provide reasonable protection against harmful interference in a residential installation. This equipment generates, uses and can radiate radio frequency energy and, if not installed and used in accordance with the instructions, may cause harmful interference to radio communications. However, there is no guarantee that interference will not occur in a particular installation. If this equipment does cause harmful interference to radio or television reception, which can be determined by turning the equipment off and on, the user is encouraged to try to correct the interference by one or more of the following:
Relocate the receiving antenna.
Increase the separation between the equipment and r eceiver.
Connect the equipment into an outlet on a circuit that is different from the receiver.
Consult the distributor or an experienced radio/tel evision technician for help. 1. This Transmitter must not cohabitate or operate in conjunction with any other antenna(s) or transmitter(s). 2. This equipment complies with FCC RF radiation exposure limits set forth for an uncontrolled environment. To maintain compliance with FCC RF exposure compliance requirements, avoid direct contact to the transmitting antenna during transmission. 3. Any changes or modifications (including the antennas) made to this device that are not expressly approved by the manufacturer may void the user’s authority to operate the equipment. ii This device complies with Part 15 of the FCC Rules. Operation is subject to the following two conditions: (1) this device may not cause harmful interference, and (2) this device must accept any interference received, including interference that may cause undesired operation. FCC Radiation Exposure Statement This device complies with FCC radiation exposure limits set forth for an uncontrolled environment and it also complies with Part 15 of the FCC RF Rules. This equipment must be installed and operated in accordance with provided instructions and the antenna(s) used for this transmitter must be installed to provide a separation distance of at least 20 cm from all persons and must not be co-located or operating in conjunction with any other antenna or transmitter. End-users and installers must be provide with antenna installation instructions and consider removing the no-collocation statement. Canadian Compliance Statement This Class A Digital apparatus meets all requirements of the Canadian Interference-Causing Equipment Regulations. Cet appareil numérique de la classe A respecte les exigences du Règlement sur le matériel broilleur du Canada. European Conformity Statement Declaration of Conformity with Regard to the R&TTE 1999/5/EC and EMC 89/336/ EEC directives. RoHS Statement This device conforms to RoHS (Restriction of Hazardous Substances) European Union regulations that set maximum concentration limits on hazardous materials used in electrical and electronic equipment. Taiwan NCC Warning Statement 交通部電信總局低功率電波輻射性電機管理辦法 (930322) 根據交通部低功率管理辦法規定： 第十二條 經型式認證合格之低功率射頻電機，非經許可，公司、商號或使用者均不得擅自變更 頻率、加大功率或變更原設計之特性及功能。 第十四條 低功率射頻電機之使用不得影響飛航安全及幹擾合法通信；經發現有干擾現象時，應 立即停用，並改善至無幹擾時方得繼續使用。前項合法通信，指依電信法規定作業之無線電通信。 低功率射頻電機須忍受合法通信或工業、科學及醫療用電波輻射性電機設備之干擾。 Warranty The following items are covered under Unitech Limited Warranty:  MT700 Multi-Function Versatile Controller – 1-year limited warranty.  Cables – three-month limited warranty. iii Table of Contents PREFACE ................................................................................................................................... I Regulatory Compliance Statements.................... ..................................................................... i ABOUT THIS MANUAL ................................... ........................................................................... I Warranty ..................................................................................................................................ii CHAPTER 1 ............................................................................................................................... 1 Introducing the MT700 ............................... ............................................................................. 1 Tour of the MT700................................................................................................................... 1 GETTING STARTED..................................... ............................................................................. 1 Front View .......................................... ................................................................................. 2 Side View ............................................................................................................................ 2 Bottom View ....................................................................................................................…

Text truncated - open the document above for the full version.

2 NOTE: The MT700’s display is shipped with a transparent protection film that has been pasted onto the surface of touch panel of the MT700 for protecting the top cover and touch panel. Before using the MT700, tear out the protective film. If MT700 is provided with RFID reader, you will see the RFID reader logo on the front panel of MT700. DO NOT wipe the MT700 with any chemical cleansing agent! We recommend the usage of clean water or soft cloth for display panel/eyeglasses to clean the machine. The following sections describe the main components and features of the M700. Front View Side View Left Right Touch Screen Camera Microphone LED Keypad Finger Printer RFID Speaker Lock Reset Speaker 3 Bottom View Front Main Board The Main board can be access via unlocking the right side lock of the MT700 and removing the back steel plate. Cable hole 4 Back Terminal Board The terminal board can be access via unlocking the right side lock of the MT700 and removing the back steel plate. Setting up the MT700 Connecting Power Connect power to the MT700 through the following instruction: Plug the Power Adapter Cable into the MT700’s DC input jack and then connect the other end of the Power Adapter into an electrical outlet. Powering On the MT700 The MT700 automatically powers on when the Power Adapter plugs into an external power source. The MT700 welcome screen appears. Using the MT700 for the First Time Using the Touch-screen 1. Tap the screen to choose a menu option. 2. Double tap to open programs. 3. Use the Windows CE Keyboard to type letters or numbers into a data field or on a form. Magnetic Hall sensor 5 Setting the Date and Time In the Date/Time Properties window, touch the screen to select the current date/time, time zone and daylight saving time option.
Tap the Left or Right arrows to scroll through the desired year and month, or directly tap the year or month to change the setting.
Tap on the Hr/Min/Sec AM/PM to input the Hr/Min/Sec to set the time.
Tap the arrow and set the correct time zone from th e drop-down menu.
Check the box to enable Windows to automatically adjust for day-light saving time.
Tap Apply to save the settings and exit the Date/Ti me Properties dialog, or tap to exit without saving. Date Setting Time Setting Time Zone Setting Daylight Saving 6 Basic Operation Chapter 2 On-screen virtual Keyboard Windows CE features on-screen virtual keyboard that simulates all functions and behaviors of physical PC keyboard. To launch the on-screen virtual keyboard, please tap  L argeKB. Entering Characters Entering alphabetic and numeric characters on the MT700 is the same as character input on a standard PC keyboard. Tap the onscreen button corresponding to the desired character. Keyboard Icon 7 Moving the Keyboard Tap the title bar and drag the keyboard to a desired location. Closing the Keyboard Tap the keyboard icon  Hide Input Panel to close the Windows CE keyboard. RFID Reader (Optional) If the MT700 is with built-in RFID reader, you will see the RFID reader logo on the front panel of MT700. The MT700 features a standard RFID reader, which is compatible with 13.56MHz MiFare cards. RFID Card Verification The MT700 has built-in demo programs that allow RFID card verifications. 1. Double-tap the My Device icon on the Windows CE desktop. 2. Tap Windows. 3. Double-tap PDA_1.0 to open the demo program. 4. Set the COM Port: field at 2. Tap Connect. 5. Choose a card type to activate the demo test program. 8 6. Tap Auto and bring the RFID card close to the sensor. The code will display on the field below. 7. Tap Stop to end the reading. Audio Input/Output An audio demo program will test the audio input (recording) and output (playback). 1. Double tap My Device on the Windows CE desktop. 2. Double-tap Windows. 3. Double-tap wavtest to open the demo program. 4. Do one of the following: -- Tap Rec to record the voice. -- Tap Stop to finish recording. -- Tap Play to listen to the recording. 9 Built-in Camera The MT700 has a built-in 2.0 megapixel camera which provides the following extra functionality:  Enables users to capture still pictures when a card is being read  Checks attendant time with a photo image  Records video continuously  Functions as an audio/video intercom A dditionally, facial recognition can be incorporated using third party software. The MT700 has a demo program that enables users to capture a still picture with a card number and time stamp when a card is read. To start the camera demo: 1. Double-tap the My Device icon on the Windows CE desktop. 2. Double-tap the Windows folder. 3. Double-tap CameraDemo to open the program. The testing program is displayed. 4. Tap Preview → Start. A continuous image is displayed enabling users to capture and playback video. 10 Tools/Utilities/Applications BootMode Path: Start Menu/Programs/Utilities/Boot Mode This tool allows you to perform warm boot or cold boot. Warm Boot 1. Select Start Menu -> Programs -> Utilities -> Bootmode 2. Tap “Warm Boot”. The system will be warm started. 11 Cold Boot Caution: Backup your data first! 1. Tap “BootMode”, and Tap “Cold Boot”. Then confirm the choice by selecting YES when program asked to reconfirm the command. 2. The terminal will be cold started. 3. Calibrate the screen according to the instruction displayed, and tap the screen anywhere again once the calibration is completed to continue. 4. Set the date and time, press OK. I/O Card Control Path: Start Menu/Programs/Utilities/IO Card This tool allows you enable or disable CF slot whenever it is necessary. Once you disable the slot, the card in that slot will not work until you enable the slot again. 1. Select Start Menu ->Programs -> Utilities -> IO Card 2. You may choose to enable or disable the card from this tool. Once you selected 12 disable, the card will no longer be detected unless it is enabled again. Tap “Enable” to enable the card. 3. Tap “Hide” to hide I/O Card Control window. 4. Tap “Exit” to exit I/O card control. The…

Text truncated - open the document above for the full version.

CERTIFICATE OF COMPLIANCE Authorized under Declaration of Conformity according to 47 CFR, Part 2 and Part 15 of the FCC Rules. The product listed in follows was (were) tested in the Neutron EMC Laboratory to comply with the criteria limits Class B of conducted and radiated emissions of the Technical Standards FCC Part 15, Subpart B, established by the FCC, USA. Equipment Multi-functional T&A Terminal Model Name MT700 Brand Name unitech; TASHI Applicant unitech electronics co., ltd. Address 5F, No. 136, Lane 235, Pao-Chiao Rd., Hsin-Tien Dist., New Taipei City, Taiwan Standard(s) FCC Part 15, Subpart B: 2012 ANSI C63.4: 2009 ICES-003 Issue 5: 2012 CISPR 22: 2008 CAN/CSA-CISPR 22-10 Report(s) NEI-FCCE-1-1311155B The test data, data evaluation, and equipment configuration contained in our test report(s) above was (were) obtained utilizing the test procedures, test instruments, test sites that has been accredited by the Authority of TAF according to the ISO-17025 quality assessment standard and technical standard(s). The test data contained in the referenced test report relate only to the EUT sample and item(s) tested. Andy Chiu Authorized Signatory Neutron Engineering Inc. B1, No. 37, Lane 365, YangGuang St., NeiHu District 114, Taipei, Taiwan. TEL: +886-2-2657-3299 FAX: +886-2-2657-3331

RV-0000000 Project No.: 1311157A Page 2 of 48 Neutron Engineering Inc. With Fingerprinter RV-0000000 Project No.: 1311157A Page 3 of 48 Neutron Engineering Inc. Without Fingerprinter RV-0000000 Project No.: 1311157A Page 4 of 48 Neutron Engineering Inc. RV-0000000 Project No.: 1311157A Page 5 of 48 Neutron Engineering Inc. RV-0000000 Project No.: 1311157A Page 6 of 48 Neutron Engineering Inc.

50 mm 30 mm

RV-0000000 Project No.: 1311157A Page 7 of 48 Neutron Engineering Inc. With Fingerprinter RFID Antenna RFID Module Fingerprinter AP Module RV-0000000 Project No.: 1311157A Page 8 of 48 Neutron Engineering Inc. With Fingerprinter RV-0000000 Project No.: 1311157A Page 9 of 48 Neutron Engineering Inc. Without Fingerprinter RV-0000000 Project No.: 1311157A Page 10 of 48 Neutron Engineering Inc. Without Fingerprinter RV-0000000 Project No.: 1311157A Page 11 of 48 Neutron Engineering Inc. RFID Antenna RV-0000000 Project No.: 1311157A Page 12 of 48 Neutron Engineering Inc. RV-0000000 Project No.: 1311157A Page 13 of 48 Neutron Engineering Inc. RV-0000000 Project No.: 1311157A Page 14 of 48 Neutron Engineering Inc. RV-0000000 Project No.: 1311157A Page 15 of 48 Neutron Engineering Inc. RV-0000000 Project No.: 1311157A Page 16 of 48 Neutron Engineering Inc. RV-0000000 Project No.: 1311157A Page 17 of 48 Neutron Engineering Inc. Fingerprinter Reader RV-0000000 Project No.: 1311157A Page 18 of 48 Neutron Engineering Inc. Fingerprinter Reader RV-0000000 Project No.: 1311157A Page 19 of 48 Neutron Engineering Inc. Fingerprinter Reader RV-0000000 Project No.: 1311157A Page 20 of 48 Neutron Engineering Inc. RV-0000000 Project No.: 1311157A Page 21 of 48 Neutron Engineering Inc. RV-0000000 Project No.: 1311157A Page 22 of 48 Neutron Engineering Inc. RV-0000000 Project No.: 1311157A Page 23 of 48 Neutron Engineering Inc. Fingerprinter Module RV-0000000 Project No.: 1311157A Page 24 of 48 Neutron Engineering Inc. Fingerprinter Module RV-0000000 Project No.: 1311157A Page 25 of 48 Neutron Engineering Inc. Fingerprinter Module RV-0000000 Project No.: 1311157A Page 26 of 48 Neutron Engineering Inc. Fingerprinter Module RV-0000000 Project No.: 1311157A Page 27 of 48 Neutron Engineering Inc. Fingerprinter Module RV-0000000 Project No.: 1311157A Page 28 of 48 Neutron Engineering Inc. Fingerprinter Module RV-0000000 Project No.: 1311157A Page 29 of 48 Neutron Engineering Inc. RV-0000000 Project No.: 1311157A Page 30 of 48 Neutron Engineering Inc. RV-0000000 Project No.: 1311157A Page 31 of 48 Neutron Engineering Inc. RFID Module RV-0000000 Project No.: 1311157A Page 32 of 48 Neutron Engineering Inc. RFID Module RV-0000000 Project No.: 1311157A Page 33 of 48 Neutron Engineering Inc. RFID Module RV-0000000 Project No.: 1311157A Page 34 of 48 Neutron Engineering Inc. RFID Module RV-0000000 Project No.: 1311157A Page 35 of 48 Neutron Engineering Inc. RV-0000000 Project No.: 1311157A Page 36 of 48 Neutron Engineering Inc. AP Module RV-0000000 Project No.: 1311157A Page 37 of 48 Neutron Engineering Inc. RV-0000000 Project No.: 1311157A Page 38 of 48 Neutron Engineering Inc. AP Module RV-0000000 Project No.: 1311157A Page 39 of 48 Neutron Engineering Inc. RV-0000000 Project No.: 1311157A Page 40 of 48 Neutron Engineering Inc. RV-0000000 Project No.: 1311157A Page 41 of 48 Neutron Engineering Inc. RV-0000000 Project No.: 1311157A Page 42 of 48 Neutron Engineering Inc. RV-0000000 Project No.: 1311157A Page 43 of 48 Neutron Engineering Inc. RV-0000000 Project No.: 1311157A Page 44 of 48 Neutron Engineering Inc. RV-0000000 Project No.: 1311157A Page 45 of 48 Neutron Engineering Inc. RV-0000000 Project No.: 1311157A Page 46 of 48 Neutron Engineering Inc. RV-0000000 Project No.: 1311157A Page 47 of 48 Neutron Engineering Inc. RV-0000000 Project No.: 1311157A Page 48 of 48 Neutron Engineering Inc.

FCC ID: HLEMT700F RV-0000000 Report No.: NEI-FCCP-1-1311157A Page 1 of 27 Neutron Engineering Inc. Radio Test Report FCC ID: HLEMT700F This report concerns (check one) : Original Grant Class I Change Issued Date : Mar. 19, 2014 Project No. : 1311157A Equipment : Multi-functional T&A Terminal Model Name : MT700 Applicant : unitech electronics co., ltd. Address : 5F, No. 136, Lane 235, Pao-Chiao Rd., Hsin-Tien Dist., New Taipei City, Taiwan Tested by: Neutron Engineering Inc. EMC Laboratory Date of Receipt: Jan. 03, 2014 Date of Test: Jan. 03, 2014 ~ Feb. 24, 2014 Testing Engineer : (Josh Lin) Technical Manager : (Jeff Yang) Authorized Signatory : (Andy Chiu) Neutron Engineering Inc. B1, No. 37, Lane 365, YangGuang St., NeiHu District 114, Taipei, Taiwan. TEL: +886-2-2657-3299 FAX: +886-2-2657-3331 FCC ID: HLEMT700F RV-0000000 Report No.: NEI-FCCP-1-1311157A Page 2 of 27 Neutron Engineering Inc. Declaration Neutron represents to the client that testing is done in accordance with standard procedures as applicable and that test instruments used has been calibrated with the standards traceable to National Measurement Laboratory (NML) of R.O.C., or National Institute of Standards and Technology (NIST) of U.S.A. Neutron's reports apply only to the specific samples tested under conditions. It is manufacture’s responsibility to ensure that additional production units of this model are manufactured with the identical electrical and mechanical components. Neutron shall have no liability for any declarations, inferences or generalizations drawn by the client or others from Neutron issued reports. Neutron’s reports must not be used by the client to claim product endorsement by the authorities or any agency of the Government. This report is the confidential property of the client. As a mutual protection to the clients, the public and Neutron-self, extracts from the test report shall not be reproduced except in full with Neutron’s authorized written approval. Neutron’s laboratory quality assurance procedures are in compliance with the ISO Guide 17025 requirements, and accredited by the conformity assessment authorities listed in this test report. Limitation For the use of the authority's logo is limited unless the Test Standard(s)/Scope(s)/Item(s) mentioned in this test report is (are) included in the conformity assessment authorities acceptance respective. FCC ID: HLEMT700F RV-0000000 Report No.: NEI-FCCP-1-1311157A Page 3 of 27 Neutron Engineering Inc. Table of Contents REPORT ISSUED HISTORY 4 1 CERTIFICATION 5 2 SUMMARY OF TEST RESULTS 6 2.1 TEST FACILITY 7 2.2 MEASUREMENT UNCERTAINTY 7 3 GENERAL INFORMATION 8 3.1 GENERAL DESCRIPTION OF EUT 8 3.2 DESCRIPTION OF TEST MODES 9 3.3 BLOCK DIAGRAM SHOWING THE CONFIGURATION OF SYSTEM TESTED 10 3.4 DESCRIPTION OF SUPPORT UNITS 11 4 CONDUCTED EMISSION 12 4.1 LIMITS 12 4.2 MEASUREMENT INSTRUMENTS LIST 12 4.3 TEST PROCEDURES 13 4.4 TEST SETUP LAYOUT 13 4.5 DEVIATION FROM TEST STANDARD 13 4.6 EUT OPERATING CONDITIONS 13 4.7 TEST RESULTS 14 5 RADIATED EMISSION 16 5.1 LIMITS 16 5.2 MEASUREMENT INSTRUMENTS LIST 17 5.3 TEST PROCEDURE 17 5.4 DEVIATION FROM TEST STANDARD 18 5.5 TEST SETUP 18 5.6 EUT OPERATING CONDITIONS 19 5.7 TEST RESULTS- FCC PART 15.209 20 5.8 TEST RESULTS- FCC PART 15.225 22 6 FREQUENCY STABILITY 24 6.1 LIMITS 24 6.2 MEASUREMENT INSTRUMENTS LIST 24 6.3 TEST PROCEDURE 24 6.4 DEVIATION FROM TEST STANDARD 24 6.5 EUT OPERATING CONDITIONS 24 6.6 TEST RESULTS 25 7 EUT TEST PHOTO 26 FCC ID: HLEMT700F RV-0000000 Report No.: NEI-FCCP-1-1311157A Page 4 of 27 Neutron Engineering Inc. REPORT ISSUED HISTORY Issue No. Description Issued Date NEI-FCCP-1-1311157AOriginal Issue. Mar. 19, 2014 FCC ID: HLEMT700F RV-0000000 Report No.: NEI-FCCP-1-1311157A Page 5 of 27 Neutron Engineering Inc. 1 CERTIFICATION E q u i p m e n t : Multi-functional T&A Terminal Brand Name : unitech; TASHI Model Name : MT700 A p p l i c a n t : unitech electronics co., ltd. Date of Test : Jan. 03, 2014 ~ Feb. 24, 2014 Standards : FCC Part 15, Subpart C: 2012 ANSI C63.4: 2009 The above equipment has been tested and found compliance with the requirement of the relative standards by Neutron Engineering Inc. EMC Laboratory. The test data, data evaluation, and equipment configuration contained in our test report (Ref No. NEI-FCCP-1-1311157A) were obtained utilizing the test procedures, test instruments, test sites that has been accredited by the Authority of TAF according to the ISO-17025 quality assessment standard and technical standard(s). FCC ID: HLEMT700F RV-0000000 Report No.: NEI-FCCP-1-1311157A Page 6 of 27 Neutron Engineering Inc. 2 SUMMARY OF TEST RESULTS Test procedures according to the technical standards: Standard Section Test Item Result 15.207 Conducted emission PASS 15.35 / 15.205 / 15.209 / 15.225 Radiated emission PASS 15.225(e) Frequency Stability PASS 15.203 Antenna Requirement PASS NOTE: 1. N/A: denotes test is not applicable in this Test Report FCC ID: HLEMT700F RV-0000000 Report No.: NEI-FCCP-1-1311157A Page 7 of 27 Neutron Engineering Inc. 2.1 TEST FACILITY The test facilities used to collect the test data in this report: Conducted emission Test: C02: (VCCI RN: C-3477; FCC RN: 614388; FCC DN: TW1054) 1F., No. 61, Ln. 77, Sing-ai Rd., Neihu Dist., Taipei City 114, Taiwan (R.O.C.) Radiated emission Test: CB08: (FCC RN: 614388; FCC DN: TW1054; IC Assigned Code: 4428C-1) 1F., No. 61, Ln. 77, Sing-ai Rd., Neihu Dist., Taipei City 114, Taiwan (R.O.C.) 2.2 MEASUREMENT UNCERTAINTY The measurement uncertainty is not specified by FCC/Industry Canada rules and for reference only. The reported uncertainty of measurement y ± U，where expended uncertainty U is based on a standard uncertainty multiplied by a coverage factor of k=2，providing a level of confidence of approximately 95%. The measurement instrumentation uncertainty considerations contained in CISPR 16-4-2. A. Conducted emission test: Test Site Measurement Frequency Range U，(dB) NOTE C02 150 kHz ~ 30 MHz 2.59 B. Radiated em…

Text truncated - open the document above for the full version.

FCC ID: HLEMT700F RV-0000000 Report No.: NEI-FCCP-1-1311157A Page 26 of 27 Neutron Engineering Inc. 7 EUT TEST PHOTO Conducted emission test photos FCC ID: HLEMT700F RV-0000000 Report No.: NEI-FCCP-1-1311157A Page 27 of 27 Neutron Engineering Inc. Radiated emission test photos
