HLERP902BUBluetooth UHF Pocket Reader

RP902 Quick Start Guide V1.2 Package LCD Display& OperationMode Product View Please make sure the following contents are in the RP902 gift box. If something is missing or damaged, please contact your Unitechrepresentative. •RP902 One-Slot Charging Cradle •Hand Strap (P/N 5500-900007G) •Neck Strap (P/N 3210-900019G) •Power Supply (P/N 1010-900067G) Optional Accessories 1.StatusLED 2.Communication LED 3. 0.96” LCD 4. Power/Triger Key 5. Select Down/Power Off 6.Function/Select Up Key 7.Antenna Area 8. Battery Lock 9. Battery Cover 10. USB Type-C Port 11.POGO Pin 12. NFCTag Bluetooth UHF Pocket Reader •RFID tags/labels 12 Left: The icon and the alphabet indicates the operation mode. Middle: Time Right: Battery State Operation Mode IconOperation Mode USB SPP BTSPP BT HID Buffer BLEHID To enable USB SPP and BT SPP mode, Please click the URL Tag Access APK or scan the barcode to download. The Package Contents •RP902 Terminal •Battery (P/N 1400-900066G) •USB Type-C Cable (P/N 1550-905908G) Note:Once you select a different operation mode, the terminal will automatically restart. Charging the battery Specifications Install the Battery Default Settings Frequency865 -928 MHz (US/EU/JP/TW/CN) Standard EPCglobal Class1 Gen2,ISO/IEC 18000-6C Read Range 1M: When Power is 22dBm 2M: When Power is 27dBm (Depends on the type andquantity of RFID tag and environment) Weight 106g Operating Time > 12 hours with 75,000 tag readings Charge Time 2 hours (via RP902 chargingcradle) 3.5hours (via USB type-C cable) BluetoothBluetooth Class 2, BLE 5.0 (HID / SPP) Compatibility RP902with MfiVersinon: BT: Android / Windows / iOS (MFi) USB: Windows RP902W/O MfiVersinon BT: Android / Windows / iOS (BLE) USB: Windows Operating Temp -10°C to 50 °C Operating ModeBTSPP Mode Read ModeSingle Read Power Setting22dBm Beep SettingLow Vibrate SettingEnable Auto Power-off2 min 1. Turn the terminal to its rear side, and push the battery lock to the right to unlock the battery. 3.Insert the battery into the battery compartment from the top side and press down, make sure to leave half of the battery strap outside. OffPoweroff/ Fully charged ―― Red SolidBatterychargingConnectedwith USB cable Green FlashRFID tag being successfully read RP902turned on Blue Flashing ―― Waiting for BT connection BlueSolid ―― BT connection is successful LED LED Status Status LED Communication LED LED Indication Note: During F/W Upgrade, Status LED shows red solid light & Communication LED shows green solid light. 2. Grab two protrusions on two sides of the battery cover, and lift upward to remove it. 4. Press down the battery. 5.Align two hooks at the bottom of the battery cover with the recesses on the batter compartment and insert, please make sure to completely cover the battery strap. 6.Press down the battery cover and push the battery lock to the left to secure the battery. Note: Please ensure the battery strap is not revealed. 1.Plug the one end of the USB Type-C cable into the port on the reader and another end into a USB port on the host PC or power adapter. 2. Please fully charge the reader (or until the Status LED turns off) before use. Required Time for full charge: RP902 Charging Cradle: 2hours. USB Type-C Cable: 3.5 hours. Buttons Behavior Charging the Battery Install the Battery Power On / Off Power OnShort press Power / Trigger Key Power OffLong press Select Down / Power Off Key about 3 secs Setting Page Enter the Setting Page Short press Function / Select Up Key EnterShort press Power / Trigger Key UpShort press Function / Select Up Key DownShort press Select Down / Power OffKey Read Mode Single Reading:Short press Power / Trigger Key Continuous Reading: Keep pressing Power / Trigger Key Note: Pleaseselect the multiple reading mode to enable Continuous Reading. Returnto Scan Page Long press Function /Select Up Keyabout 3 secs Buttons Behavior Power/ Trigger Key Function/ Select Up Key Select Down/ Power Off Read Mode Power Up/Shut Down Power Up •Short press the Power/Trigger Key to power up. You will hear short beeps (SPP mode: 1 beep/HID mode: 2 beeps/Buffer mode: 3 beeps) with green flash appears on the communication LED, thenthe LCD screen will appear. Shut Down •Long press the Select Down/ Power Off button for about 3 seconds to shut down the terminal. Start-up Screen Note: •The “*” indicates the default setting. •The data will be temporarily saved in the reader under Buffer Mode. Reading RFID Tags It is recommended to read RFID tagsby aiming the antenna area of RP902 at the RFID tag horizontally (as shown in the picture below.) Reading distance may be impacted by the type of tag and environmental conditions. Reading range is 1m when power is 22dBm, and the maximum reading range is 2m when power setting is 27 dBm. Single Read: The terminal only reads one tag upon each press. Please release the Power/trigger key and press again to read another tag. The LCD screen will show the EPC code of the RFID tag being read (shown as picture below). Multiple Read: The terminal can read multiple tags that are under RF coverage upon each press. Keep pressing the Power/trigger key to read the tags that have not been read. The tags that had been read will not be read again, unless you release the button and press again. When there is only one tag: Shows the EPC Code of the tag being read. Multiple tags being read: Shows the amount of tags being read. Operating Mode Buffermode USB SPPmode *BT SPPmode BT HIDmode BLE HIDmode Read Mode Multiple Read *Single Read PowerSetting11-27 dBm (*22 dBm) Beep Setting High *Low Medium Mute Vibrate Setting*Enable/Disable Auto-Power-off Disable 1-3/5/10 min (*2min) Factory Default Enable/Disable Setting Page Power/ Trigger Key Function/ Select Up Key Select Down/ Power Off Communication LED Status LED ≤ 1. Short press the power/trigger key to power on RP902. 2. After powering on RP902, the communication LED should show “flashing blue light”, it means RP902 is waiting for Bluetooth connection. Note: RP902 Supports NFC quick …

Text truncated - open the document above for the full version.

Registration number: W6M22206-21924-C-1 FCC ID: HLERP902BU Worldwide Testing Services(Taiwan) Co., Ltd. Appendix page 2 of 27 External Photos Registration number: W6M22206-21924-C-1 FCC ID: HLERP902BU Worldwide Testing Services(Taiwan) Co., Ltd. Appendix page 3 of 27 Registration number: W6M22206-21924-C-1 FCC ID: HLERP902BU Worldwide Testing Services(Taiwan) Co., Ltd. Appendix page 4 of 27 Registration number: W6M22206-21924-C-1 FCC ID: HLERP902BU Worldwide Testing Services(Taiwan) Co., Ltd. Appendix page 5 of 27 Registration number: W6M22206-21924-C-1 FCC ID: HLERP902BU Worldwide Testing Services(Taiwan) Co., Ltd. Appendix page 6 of 27 Registration number: W6M22206-21924-C-1 FCC ID: HLERP902BU Worldwide Testing Services(Taiwan) Co., Ltd. Appendix page 7 of 27 Registration number: W6M22206-21924-C-1 FCC ID: HLERP902BU Worldwide Testing Services(Taiwan) Co., Ltd. Appendix page 8 of 27

Registration number: W6M22206-21924-C-1 FCC ID: HLERP902BU Worldwide Testing Services(Taiwan) Co., Ltd. Appendix page 9 of 27 Internal Photos Registration number: W6M22206-21924-C-1 FCC ID: HLERP902BU Worldwide Testing Services(Taiwan) Co., Ltd. Appendix page 10 of 27 Registration number: W6M22206-21924-C-1 FCC ID: HLERP902BU Worldwide Testing Services(Taiwan) Co., Ltd. Appendix page 11 of 27 Registration number: W6M22206-21924-C-1 FCC ID: HLERP902BU Worldwide Testing Services(Taiwan) Co., Ltd. Appendix page 12 of 27 Registration number: W6M22206-21924-C-1 FCC ID: HLERP902BU Worldwide Testing Services(Taiwan) Co., Ltd. Appendix page 13 of 27 Registration number: W6M22206-21924-C-1 FCC ID: HLERP902BU Worldwide Testing Services(Taiwan) Co., Ltd. Appendix page 14 of 27 Registration number: W6M22206-21924-C-1 FCC ID: HLERP902BU Worldwide Testing Services(Taiwan) Co., Ltd. Appendix page 15 of 27 Registration number: W6M22206-21924-C-1 FCC ID: HLERP902BU Worldwide Testing Services(Taiwan) Co., Ltd. Appendix page 16 of 27 Registration number: W6M22206-21924-C-1 FCC ID: HLERP902BU Worldwide Testing Services(Taiwan) Co., Ltd. Appendix page 17 of 27 Registration number: W6M22206-21924-C-1 FCC ID: HLERP902BU Worldwide Testing Services(Taiwan) Co., Ltd. Appendix page 18 of 27 Registration number: W6M22206-21924-C-1 FCC ID: HLERP902BU Worldwide Testing Services(Taiwan) Co., Ltd. Appendix page 19 of 27 Registration number: W6M22206-21924-C-1 FCC ID: HLERP902BU Worldwide Testing Services(Taiwan) Co., Ltd. Appendix page 20 of 27

Registration number: W6M22206-21924-C-1 FCC ID: HLERP902BU Worldwide Testing Services(Taiwan) Co., Ltd. Page 20 of 64 3.2 Equivalent Isotropic Radiated Power (EIRP) FCC Rule: 15.247(b)(3) BT5.0 (BR/EDR) EIRP = max. conducted output power + antenna gain EIRP = 6.46 dBm + 2 dBi [antenna gain claimed by manufacturer] = 8.46 dBm = 7.0146 mW BT5.0 (BLE) EIRP = max. conducted output power + antenna gain EIRP = 3.81 dBm + 2 dBi [antenna gain claimed by manufacturer] = 5.81 dBm = 3.8107 mW 3.3 Exemption Limits for Routine Evaluation according to FCC KDB Publication RESULT: Test standard : FCC KDB Publication 447498 D01 General RF Exposure Guidance v06 3.3.1 Exemption Limits for Routine Evaluation – SAR Evaluation SAR evaluation is required if the separation distance between the user and/or bystander and the antenna and/or radiating element of the device is less than or equal to 20 cm, except when the device operates at or below the applicable output power level (adjusted for tune-up tolerance) for the specified separation distance defined in Table . Table: SAR evaluation — Exemption limits for routine evaluation based on frequency and separation distance BT MHz 5 10 15 20 25 mm 2441 10.02 19.05 29.07 38.10 48.10 SAR Test Exclusion Threshold (mW) MHz 30 35 40 45 50 mm 2441 57.13 67.15 77.16 86.20 96.21 SAR Test Exclusion Threshold (mW) Output power level shall be the higher of the maximum conducted or equivalent isotropically radiated power (e.i.r.p.) source-based, time-averaged output power. BT Established separation distance is 5 mm. Operating frequency band : 2402-2480 MHz Max. output power level at 5 mm separation distance at 2441 MHz according to table is: 10.02 mW The product is exempt from SAR Evaluation/Testing because the output power of 7.0146 mW is below the exemption limit of 10.02 mW. Explanation: UHF, please see the SAR report.

of Applicant: unitech Electronics Co., Ltd. Address: 5F., No. 136, Ln. 235, Baoqiao Rd. , Xindian Dist., New Taipei City , Taiwan Tested and Prepared by Worldwide Testing Services (Taiwan) Co., Ltd. FCC Registration No.: TW1477, TW1072 Industry Canada filed test laboratory Reg. No.: 20037, 5107A Report No.: W6M22206-21924-C-1 6F, NO. 58, LANE 188, RUEY-KUANG RD., NEIHU TAIPEI 114, TAIWAN, R.O.C. TEL: 886-2-66068877 FAX: 886-2-66068879 E-mail: [email protected] 47 CFR PART 15 SUBPART C TEST REPORT for Bluetooth UHF Pocket Reader Model No.: RP902 FCC ID: HLERP902BU Registration number: W6M22206-21924-C-1 FCC ID: HLERP902BU Worldwide Testing Services(Taiwan) Co., Ltd. Page 1 of 64 TABLE OF CONTENTS 1 GENERAL INFORMATION .......................................................................................................... 2 1.1 NOTES .......................................................................................................................................... 2 1.2 TESTING LABORATORY ................................................................................................................ 3 1.2.1 Location .............................................................................................................................. 3 1.2.2 Details of accreditation status ............................................................................................ 3 1.3 D ETAILS OF APPROVAL HOLDER ................................................................................................... 3 1.4 A PPLICATION DETAILS ................................................................................................................. 4 1.5 G ENERAL INFORMATION OF TEST ITEM ........................................................................................ 4 1.6 T EST STANDARDS ......................................................................................................................... 5 2 TECHNICAL TEST ......................................................................................................................... 6 2.1 S UMMARY OF TEST RESULTS ........................................................................................................ 6 2.2 TEST ENVIRONMENT .................................................................................................................... 6 2.3 TEST EQUIPMENT LIST ................................................................................................................. 7 2.4 G ENERAL TEST PROCEDURE ...................................................................................................... 10 3 TEST RESULTS (ENCLOSURE) ................................................................................................ 12 3.1 PEAK OUTPUT POWER (TRANSMITTER) ...................................................................................... 13 3.2 E QUIVALENT ISOTROPIC RADIATED POWER ................................................................................ 20 3.3 RF EXPOSURE COMPLIANCE REQUIREMENTS ............................................................................ 20 3.4 TRANSMITTER RADIATED EMISSIONS IN RESTRICTED BANDS .................................................... 21 3.5 S PURIOUS EMISSIONS (TX) ......................................................................................................... 22 3.6 C ARRIER FREQUENCY SEPARATION ........................................................................................... 24 3.7 N UMBER OF HOPPING FREQUENCIES .......................................................................................... 28 3.7.1 Pseudorandom Frequency Hopping Sequence ................................................................. 31 3.7.2 Coordination of hopping sequences to other transmitters ................................................ 31 3.7.3 System Receiver Hopping Capability ............................................................................... 31 3.8 T IME OF OCCUPANCY (DWELL TIME) ........................................................................................ 32 3.9 20DB BANDWIDTH ..................................................................................................................... 41 3.9.1 System Receiver Input Bandwidth ..................................................................................... 46 3.10 M INIMUM 6 DB BANDWIDTH ..................................................................................................... 47 3.11 R ADIATED EMISSION ON THE BAND EDGE .................................................................................. 50 3.12 P EAK POWER SPECTRAL DENSITY ............................................................................................. 58 3.13 RADIATED EMISSION FROM DIGITAL PART ................................................................................ 61 3.14 POWER LINE CONDUCTED EMISSION ......................................................................................... 62 Registration num ber: W6M22206-21924-C-1 FCC ID: HLERP902BU Worldwide Testing Services(Taiwan) Co., Ltd. Page 2 of 64 1 General Information 1.1 Notes The purpose of conformity testing is to increase the probability of adherence to the essential requirements or conformity specifications, as appropriate. The complexity of the technical specifications, however, means that full and thorough testing is impractical for both technical and economic reasons. Furthermore, there is no guarantee that a test sample which has passed all the relevant tests conforms to a specification. Neither is there any guarantee that such a test sample will interwork with other genuinely open systems. The existence of the tests nevertheless provides the confidence that the test sample possesses the qualities as maintained and that is performance generally conforms to representative cases of communications equipment. Laboratory disclaimer- 1. The test results of this test report…

Text truncated - open the document above for the full version.

CUSTOMER: CUSTOMER MODEL NO.: JOYMAX MODEL NO.: DESCRIPTION: REV: A DATE: 2021/11/26 IBF-A04BMPXX-752 #A04B FPCB Embedded Antenna 精聯電子股份有限公司 承 認 書 A P P R O V A L S H E DATE: 2021/11/26 Joymax Approval 桃園市中壢區中壢工業區東園二路 5 號 No.5 Dong Yuan Rd.2,Jhongli industrial Park, Jhongli Dist,Tao Yuan,Taiwan,R.O.C. http://www.joymax.com.tw Tel:+886-3-4335698 Fax:+886-3-4337898 E-mail:[email protected] Customer Approval 1. Specification & Dimension 3 2. Test Condition & Report 2.1 V.S.W.R4 2.2 Pattern6 2.3 Gain and Efficiency7 3. Package 9 Index ------------------------------------ ------------------------------------ ------------------------------------ ------------------------------------ ------------------------------------ Page: 2 /9 Modification History: Date 2021/11/26 Rev.Content A Page: 2 /9 M e c h a n i c a l P r o p e r t i e s C o n n e c t o r T y p e O p e r a t i n g T e m p . P I － 2 0 °C ～ ＋ 6 5 °C M i n i P C I C o n n F r e q u e n c y R a n g e I m p e d a n c e V . S . W . R . R a d i a t i o n P o l a r i z a t i o n 5 0 Ω 2 . 4 ~ 2 . 5 G H z ≤ 2 . 0 w i t h t h e c l i e n t c a s e E l e c t r i c a l P r o p e r t i e s O m n i V e r t i c a l R a d o m e M a t e r i a l W a v e L e n g t h , t y p e M i c r o s t r i p 1 g ( e s t ) － 3 0 °C ～ ＋ 7 0 °C S t o r a g e T e m p . D i m e n s i o n L = 9 4 m m 2 . 4 ~ 2 . 4 5 G H z 2 d B i ( w i t h o u t t h e c l i e n t c a s e ) 比 對 波 形 c o m p a r e d w i t h r e p o r t c u r v e 2.Test Condition & Report 2.1 V.S.W.R (test without client case) Page: 4 /9 Test Configuration Page: 4 /9 2.Test Condition & Report 2.1 V.S.W.R (test with client case) Page: 5 /9 Test Configuration Page: 5 /9 2.2 Pattern (test with client case) Page: 6 /9 Page: 6 /9 2.3 Gain and Efficiency (test with client case) Page: 7 /9 Page: 7 /9 Pattern Test Equipment Anechoic chamber: 100MHz~6GHz 8*6*6m (※ 1m Quiet zone at 800MHz) Source Antenna: ETS-3164 Dual Polarized Horn Network Analyzer: Agilent E5071B 100kHz~8.5GHz 0deg 90deg 350mm 350cm 0 deg. 90 deg. Page: 8 /9 0deg 90deg 350mm 0 deg. 90 deg. Page: 8 /9 3. Package 2000pcs antenna / 1 Carton Carton size 330*180*180mm 100pcs antenna / 1 PE bag PE bag size 16.5*30mm C/NO: MADE IN TAIWAN 1 2 Page: 9 /9 Packing q'ty is for reference only, adjust it based on production packing MODEL No.: PCSQ'ty: PCSN.W: PCSG.W: C/NO: MADE IN TAIWAN Page: 9 /9

Registration number: W6M22206-21924-C-1 FCC ID: HLERP902BU Worldwide Testing Services(Taiwan) Co., Ltd. Appendix page 21 of 27 Set Up Photo of Radiated Emission BT Below 1 GHz Registration number: W6M22206-21924-C-1 FCC ID: HLERP902BU Worldwide Testing Services(Taiwan) Co., Ltd. Appendix page 22 of 27 Above 1 GHz Registration number: W6M22206-21924-C-1 FCC ID: HLERP902BU Worldwide Testing Services(Taiwan) Co., Ltd. Appendix page 23 of 27 Registration number: W6M22206-21924-C-1 FCC ID: HLERP902BU Worldwide Testing Services(Taiwan) Co., Ltd. Appendix page 24 of 27 UHF Below 1 GHz Registration number: W6M22206-21924-C-1 FCC ID: HLERP902BU Worldwide Testing Services(Taiwan) Co., Ltd. Appendix page 25 of 27 Above 1 GHz Registration number: W6M22206-21924-C-1 FCC ID: HLERP902BU Worldwide Testing Services(Taiwan) Co., Ltd. Appendix page 26 of 27 Registration number: W6M22206-21924-C-1 FCC ID: HLERP902BU Worldwide Testing Services(Taiwan) Co., Ltd. Appendix page 27 of 27 Set Up Photo of Conducted Emission
